AXIOMTEK SBC84833 Series User manual

SBC84833 Series
Intel®Atom™Processor N270
Capa Board with LVDS
User’s Manual

II
Disclaimers
This manual has been carefully checked and believed to contain
accurate information. Axiomtek Co., Ltd. assumes no responsibility for
any infringements of patents or any third party’s rights, and any
liability arising from such use.
Axiomtek does not warrant or assume any legal liability or
responsibility for the accuracy, completeness or usefulness of any
information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or
product at any time without notice.
No part of this document may be reproduced, stored in a retrieval
system, or transmitted, in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise, without the prior
written permission of Axiomtek Co., Ltd.
Caution
If you replace wrong batteries, it causes the danger of explosion. It is
recommended by the manufacturer that you follow the manufacturer’s
instructions to only replace the same or equivalent type of battery,
and dispose of used ones.
©Copyright 2011 Axiomtek Co., Ltd.
All Rights Reserved
April 2011, Version A4
Printed in Taiwan

III
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity.
To prevent chipsets from electrostatic discharge damage, please take
care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static
packaging until you are ready to install them.
Before holding the board or integrated circuit, touch an unpainted
portion of the system unit chassis for a few seconds. It
discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic
component stores, when handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Windows®is a trademark of Microsoft Corporation.
AMI®is a registered trademark of American Megatrends Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business
Machines Corporation.
Intel®and Atom™ are trademarks of Intel Corporation.
Winbond is a trademark of Winbond Electronics Corp.
Other brand names and trademarks are the properties and registered
brands of their respective owners.

IV
Table of Contents
Disclaimers ................................................................................. II
ESD Precautions........................................................................ III
CHAPTER 1..............................................................................................1
INTRODUCTION....................................................................................1
1.1Specifications............................................................ 2
1.2Utilities Supported.................................................... 4
CHAPTER 2 ...............................................................................................5
JUMPERS AND CONNECTORS..........................................................5
2.1Board Dimensions and Fixing Holes...................... 5
2.2Board Layout............................................................. 7
2.3Jumper Settings........................................................ 9
2.3.1LCD Voltage Slection Jumper (JP1)......................... 10
2.3.2Audio Output Jumper (JP2)...................................... 10
2.3.3CompactFlash™ Voltage Jumper (JP3)...................11
2.3.4CMOS Clear Jumper (JP4).......................................12
2.3.5Auto Power On Jumper (JP5)................................... 13
2.3.6COM1 Mode Select Jumpers (JP6, JP7, JP8) ......... 14
2.3.7COM2 Mode Selection Jumper (JP9).......................15
2.3.8COM1 Mode Selection Jumper (JP10).....................16
2.3.9COM3 Mode Selection Jumper (JP11).....................17
2.3.10COM4 Mode Selection Jumper (JP12) .................... 18
2.3.11 CRT Always On Jumper (JP13).............................. 19
2.4Connectors.............................................................. 20
2.4.1ATX 4 Pin 12V Connector (ATX1)............................21
2.4.2LVDS Backlight Connector (CN1) ............................ 21
2.4.3Audio Phone Jack Connector (CN2) ........................ 21
2.4.4LVDS Flat Panel Connector (CN3)........................... 22
2.4.5Flat Panel Bezel Connector (CN4) ........................... 23
2.4.6Digital I/O Port Connector (CN6)..............................25
2.4.7 Mini PCI-Express Card Connector (CN7).................. 25
2.4.8SMBus Connector (CN9).......................................... 27
2.4.9Serial Port3 & Serial Port4 (CN10)...........................28
2.4.10 Keyboard and PS/2 Mouse Connector (CN11)........ 29
2.4.11 VGA Connector (CN13) ...........................................29
2.4.12 Serial Port1 Connector (COM1)............................... 30

V
2.4.13Serial Port 2 Connectors (CN15)................. 30
2.4.14Power output Connector (CN8) ................... 31
2.4.15Ethernet Connectors (LAN1) ........................ 31
2.4.16SATA Connectors (SATA1, SATA2)............. 31
2.4.17USB Port Connector (USB3) ....................... 32
2.4.18Internal USB Connector (USB1)..................32
2.4.19Internal USB Connector (USB4)................... 33
2.4.20Internal USB Connector (USB2)..................33
2.4.21CompactFlash™ Socket (SCF1) .................. 34
CHAPTER 3 .............................................................................................36
HARDWARE DESCRIPTION.............................................................36
3.1Microprocessors..................................................... 36
3.2BIOS ......................................................................... 36
3.3System Memory ...................................................... 36
3.4I/O Port Address Map ............................................. 37
3.5Interrupt Controller................................................. 39
CHAPTER 4 .............................................................................................40
AMI BIOS SETUP UTILITY.................................................................40
4.1Starting .................................................................... 40
4.2Navigation Keys...................................................... 40
4.3Main Menu ............................................................... 42
4.4Advanced Menu ...................................................... 43
4.5Boot Menu ............................................................... 59
4.6Security Menu ......................................................... 62
4.7Chipset Menu .......................................................... 63
4.8Exit Menu................................................................. 67
APPENDIX A...........................................................................................69
WATCHDOG TIMER............................................................................69
What is Watchdog Timer ......................................................... 69
How to Use the Watchdog Timer............................................ 69
APPENDIX B...........................................................................................72
DIGITAL I/O...........................................................................................72
Digital I/O Software Programming.......................................... 73

SBC84833 Series All-In-One Capa Board User’s Manual
INTRODUCTION 1
CHAPTER 1
INTRODUCTION
The SBC84833, a Capa board, supports Intel® Atom™processor
N270, at FSB 533 MHz. The board integrates chipsets Intel®945GSE
and ICH7M that deliver outstanding system performance through high-
bandwidth interfaces, multiple I/O functions for interactive applications
and various embedded computing solutions. There is one 200-pin
unbuffered SO-DIMM sockets for singe channel DDR2-400/533 MHz
memory, maximum memory capacity up to 2GB. It also features one
Gigabit/Fast Ethernet, two serial ATA channels for total two Serial ATA
hard drives at maximum transfer rate up to 150MB/sec, seven USB 2.0
high speed compliant, built-in HD audio codec that can achieve the
best stability and reliability for industrial applications. Additionally, it
provides you with unique embedded features, such as 4 serial ports
and 3.5” form factor that applies an extensive array of PC peripherals.

SBC84833 Series All-In-One Capa Board User’s Manual
INTRODUCTION
2
1.1 Specifications
zCPU
Intel®AtomTM processor N270
zSystem Chipset
Intel®945GSE & ICH7M
zFront-Side Bus
533 MHz
zBIOS
American Megatrends Inc. BIOS.
8Mbit SPI Flash, DMI, Plug and Play
“Load Optimized Default” to backup customized Setting in
the BIOS flash chip to prevent from CMOS battery fail
zSystem Memory
One 200-pin unbuffered DDR2 SO-DIMM sockets
Maximum to 2GB DDR2 400/533 MHz memory

SBC84833 Series All-In-One Capa Board User’s Manual
INTRODUCTION 3
zOnboard Multi I/O
Controller: Winbond W83627UHG
Serial Ports: One port for RS-232/422/485 and three ports
for RS-232
Two SATA-150 connectors
zCompactFlash™Socket
One CompactFlash™ Type II Socket
zUSB Interface
Seven USB ports with fuse protection and complies with USB
Spec. Rev. 2.0
zDisplay
CRT connector
One 40-pin connector for 18 single channel LVDS and one 7-
pin inverter connector
One 40-pin 24-bit single/dual channel LVDS via Chrontel
CH7308B from SDVO as EFP port and one 7-pin inverter
connector
zWatchdog Timer
1~255 seconds; up to 255 levels
zEthernet
One port with RTL8111DL for Gigabit/Fast Ethernet
zAudio
HD Audio compliant (with Speaker/line-out & MIC-in) via
ALC662
Internal Audio features for speaker-out & MIC-in & Line-in via
Box Header connector
zPower Management
ACPI (Advanced Configuration and Power Interface)
zForm Factor
3.5” form factor
NOTE All specifications and images are subject to change
without notice.

SBC84833 Series All-In-One Capa Board User’s Manual
INTRODUCTION
4
1.2 Utilities Supported
zChipset Driver
zEthernet Driver
zGraphic Driver
zAudio Driver

SBC84833 Series All-In-One Capa Board User’s Manual
JUMPERS AND CONNECTORS 5
CHAPTER 2
JUMPERS AND CONNECTORS
2.1 Board Dimensions and Fixing Holes
Component Side

SBC84833 Series All-In-One Capa Board User’s Manual
JUMPERS AND CONNECTORS
6
Solder Side

SBC84833 Series All-In-One Capa Board User’s Manual
JUMPERS AND CONNECTORS 7
2.2 Board Layout
Component Side

SBC84833 Series All-In-One Capa Board User’s Manual
JUMPERS AND CONNECTORS
8
Solder Side

SBC84833 Series All-In-One Capa Board User’s Manual
JUMPERS AND CONNECTORS 9
2.3 Jumper Settings
Proper jumer settings configure the SBC84833 to meet your
application purpose. We are herewith listing a summary
table of all jumpers and default settings for onboard devices,
respectively.
Jumper Default Setting Jumper Setting
JP1 LVDS Voltage Selection
Default: 3.3V Short 1-2
JP2 Audio Speak Out/Line Out Selection
Default: Line Out Short 1-3, 2-4
JP3 Compact Flash Voltage Selection
Default: 3.3V Short 1-2
JP4 Normal Operation/Clear CMOS setting
Default: Normal Operation Short 1-2
JP5 Auto Power ON
Default: Disable Short 1-2
JP6
COM1 RS-232/422/485 Mode setting
Default: RS-232
Short 3-5、4-6
JP7 Short 3-5、4-6
JP8 Short 1-2
JP9 COM2 Mode Select COM2 Pin 1: DCD Short 3-5
COM2 Pin 8: RI Short 4-6
JP10 COM1 Mode Select COM1 Pin 1: DCD Short 3-5
COM1 Pin 8: RI Short 4-6
JP11 COM3 Mode Select COM3 Pin 1: DCD Short 3-5
COM3 Pin 8: RI Short 4-6
JP12 COM4 Mode Select COM4 Pin 1: DCD Short 3-5
COM4 Pin 8: RI Short 4-6

SBC84833 Series All-In-One Capa Board User’s Manual
JUMPERS AND CONNECTORS
10
2.3.1 LCD Voltage Slection Jumper (JP1)
The board supports +3.3V or +5V flat panel displays.
Configure the jumper JP1 to the appropriate voltage of the
flat panel.
Description Function Jumper Setting
LCD Voltage
Selection 3.3V (Default)
5V
2.3.2 Audio Output Jumper (JP2)
This jumper is to select the Audio output.
Description Function Jumper Setting
Audio Output Line Out
(Default)
Speaker
Out

SBC84833 Series All-In-One Capa Board User’s Manual
JUMPERS AND CONNECTORS 11
2.3.3 CompactFlash™ Voltage Jumper (JP3)
The jumper is to select the voltage for CompactFlash™interface.
Description Function Jumper Setting
Compact Flash
Voltage
Selection
3.3V
(Default)
5V

SBC84833 Series All-In-One Capa Board User’s Manual
JUMPERS AND CONNECTORS
12
2.3.4 CMOS Clear Jumper (JP4)
You may need to use this jumper is to clear the CMOS memory if
incorrect settings in the Setup Utility.
Description Function Jumper Setting
CMOS Clear Normal (Default)
Clear CMOS

SBC84833 Series All-In-One Capa Board User’s Manual
JUMPERS AND CONNECTORS 13
2.3.5 Auto Power On Jumper (JP5)
When Jumper JP5 is set OPEN for AC power input, the system will be
automatically power ON without pressing soft power button; when JP5
is SHORT for AC power input, it is necessary to manually press soft
power button to make the system power ON.
Note This function is similar to the feature of Power On after
Power Failed, which is controlled by hardware circuitry
instead of BIOS.
Description Function Jumper Setting
Auto Power
On Disable (Default)
Enable

SBC84833 Series All-In-One Capa Board User’s Manual
JUMPERS AND CONNECTORS
14
2.3.6 COM1 Mode Select Jumpers (JP6, JP7, JP8)
These jumpers select the communication mode of COM1 port to
operate RS-232 or RS-422 or RS-485.
Description Function Jumper Setting
COM 1
RS-232
(Default)
JP8 JP7 JP6
RS-422
JP8 JP7 JP6
RS-485
JP8 JP7 JP6
