AXIOMTEK PICO50R User manual

PICO50R/51R
6th and 7th Generation Intel®CoreTM
i7/ i5/ i3 and Celeron®Pico-ITX
Board
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2019 Axiomtek Co., Ltd.
All Rights Reserved
June 2019, Version A1
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity. To prevent chipsets
from electrostatic discharge damage, please take care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel®and Celeron®are trademarks of Intel Corporation.
Windows®is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers.....................................................................................................ii
ESD Precautions...........................................................................................iii
Chapter 1 Introduction............................................. 1
1.1 Features...............................................................................................2
1.2 Specifications......................................................................................2
1.3 Utilities.................................................................................................3
Chapter 2 Board and Pin Assignments.................... 5
2.1 Board Dimensions and Fixing Holes.................................................5
2.2 Board Layout.......................................................................................8
2.3 Assembly Drawing............................................................................10
2.4 Jumper and Switch Settings ............................................................12
2.4.1 LVDS +3.3V/+5V/+12V Voltage Selection (JP1)....................................... 13
2.4.2 Restore BIOS Optimal Defaults (SW1)..................................................... 13
2.4.3 Auto Power On (SSW1) ............................................................................ 13
2.5 Connectors........................................................................................14
2.5.1 Front Panel Connector (CN2) ................................................................... 15
2.5.2 Inverter Connector (CN3).......................................................................... 15
2.5.3 LVDS Connector (CN4)............................................................................. 16
2.5.4 USB 2.0 Wafer Connector (CN5).............................................................. 18
2.5.5 SMBus Connector (CN6) .......................................................................... 18
2.5.6 M.2 2242 Key B Connector (CN7) ............................................................ 19
2.5.7 M.2 2230 Key E Connector (CN8) ............................................................ 20
2.5.8 Power Connector (CN9)............................................................................ 21
2.5.9 USB 3.0 Port (CN10)................................................................................. 21
2.5.10 Ethernet Ports (CN11 and CN12).............................................................. 22
2.5.11 DisplayPort Connector (CN13).................................................................. 22
2.5.12 Digital I/O Connector (CN14) .................................................................... 23
2.5.13 CMOS Battery Connector (BAT1) ............................................................. 23
2.5.14 Fan Connector (SCN2) ............................................................................. 23
2.5.15 COM Wafer Connectors (SCN3 and SCN4) ............................................. 24
2.5.16 Power Output Connector (SCN5).............................................................. 24
Chapter 3 Hardware Description ........................... 25
3.1 Microprocessors ...............................................................................25
3.2 BIOS ...................................................................................................25

v
3.3 System Memory.................................................................................25
3.4 I/O Port Address Map........................................................................26
3.5 Interrupt Controller (IRQ) Map .........................................................27
3.6 Memory Map ......................................................................................32
Chapter 4 AMI BIOS Setup Utility .......................... 33
4.1 Starting...............................................................................................33
4.2 Navigation Keys ................................................................................33
4.3 Main Menu..........................................................................................35
4.4 Advanced Menu.................................................................................36
4.5 Chipset Menu.....................................................................................50
4.6 Security Menu....................................................................................56
4.7 Boot Menu..........................................................................................57
4.8 Save & Exit Menu ..............................................................................58
Appendix A Watchdog Timer................................... 61
A.1 About Watchdog Timer.....................................................................61
A.2 How to Use Watchdog Timer............................................................61
Appendix B Digital I/O ............................................. 63
B.1 About Digital I/O................................................................................63
B.2 Digital I/O Programming ...................................................................63
Appendix C iAMT Settings ...................................... 65
C.1 Entering MEBx...................................................................................65
C.2 Set and Change Password...............................................................65
C.3 iAMT Configuration...........................................................................67
C.4 iAMT Web Console............................................................................75

vi
This page is intentionally left blank.

PICO50R/51R Pico-ITX Board
Introduction 1
Chapter 1
Introduction
The PICO50R is a Pico-ITX board with 6th Generation Intel®CoreTM i7/ i5/ i3 and Celeron®
processor and the PICO51R is with 7th Generation Intel®CoreTM i7/ i5/ i3 and Celeron®that
deliver outstanding system performance through high-bandwidth interfaces, multiple I/O
functions for interactive applications and various embedded computing solutions.
Both of them have one 260-pin unbuffered SO-DIMM socket for DDR4 2133MHz SO-DIMM
memory with maximum capacity up to 16GB. They also feature two Gigabit/Fast Ethernet, two
USB 3.0 and two USB 2.0 high speed compliant, one M.2 Key B for storage and one M.2 Key
E for wireless module. Additionally, they provide you with unique embedded features such as
two serial ports which support RS-232/422/485 and 2.5”form factor that applies an extensive
array of PC peripherals. The board can be enhanced by its built-in watchdog timer function, a
special industrial feature not commonly seen on other motherboards.

PICO50R/PICO51R Pico-ITX Board
2 Introduction
1.1 Features
PICO50R - 6th Generation Intel®CoreTM i7/ i5/ i3 and Celeron®processor
PICO51R - 7th Generation Intel®CoreTM i7/ i5/ i3 and Celeron®processor
1 DDR4 SO-DIMM supports up to 16GB memory capacity
2 USB 3.0 ports and 2 USB 2.0 ports
2 Gigabit Ethernet ports
1 M.2 Key B for SATA storage (BOM optional for NVMe PCIe x2 storage)
1 M.2 Key E
1.2 Specifications
CPU
PICO50R
- 6th Generation Intel®CoreTM i7/ i5/ i3 and Celeron®processor.
PICO51R
- 7th Generation Intel®CoreTM i7/ i5/ i3 and Celeron®processor.
Thermal Solution
Active
Operating Temperature
-20°C~+60°C
BIOS
American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS.
64Mbit SPI Flash, DMI, Plug and Play.
PXE Ethernet Boot ROM.
System Memory
One 260-pin unbuffered DDR4 SO-DIMM socket.
Maximum up to 16GB DDR4 2133MHz memory.
Serial Port
Controller: ITE8528.
Two serial ports: Support RS-232/422/485.
Storage
One M.2 Key B slot with 22mm(width) x 42mm(length).
USB Interface
Two USB 3.0 ports in type A on the rear I/O.
Two USB 2.0 ports in 2x5-pin internal wafer connector.
Display
A standard DisplayPort connector: Support DP1.2a and DP++. The DP resolution is
up to 3840x2160 @60Hz.
One 2x20-pin connector for 18/24-bit single and dual channel LVDS (with one 8-pin
wafer connector for inverter control). LVDS resolution is up to 1920x1200 in 24-bit
dual channel.

PICO50R/51R Pico-ITX Board
Introduction 3
Watchdog Timer
1~65536 seconds or minutes; up to 65535 levels.
Ethernet
Two 1000/100/10Mbps Gigabit/Fast Ethernet ports in RJ-45 connector.
LAN1: Intel®i219LM supports 1000/100/10Mbps Gigabit/Fast Ethernet with
Wake-on-LAN and PXE Boot ROM.
LAN2: Intel®i211AT supports 1000/100/10Mbps Gigabit/Fast Ethernet with
Wake-on-LAN and PXE Boot ROM.
Audio
N/A
Expansion Interface
One M.2 Key E connector with 22mm(width) x 30mm(length).
Power Input
One 2x2-pin connector.
+12V DC-in only at minimum 12V/2A.
Auto power on function supported.
Power Management
ACPI (Advanced Configuration and Power Interface).
Form Factor
Pico-ITX form factor.
Note
All specifications and images are subject to change without notice.
1.3 Utilities
Chipset and graphics driver
Ethernet driver
ME driver

PICO50R/PICO51R Pico-ITX Board
4 Introduction
This page is intentionally left blank.

PICO50R/51R Pico-ITX Board
Board and Pin Assignments 5
Chapter 2
Board and Pin Assignments
2.1 Board Dimensions and Fixing Holes
Top View

PICO50R/PICO51R Pico-ITX Board
6 Board and Pin Assignments
34,68
39,75
100
47,12
72
Bottom View

PICO50R/51R Pico-ITX Board
Board and Pin Assignments 7
Side View

PICO50R/PICO51R Pico-ITX Board
8 Board and Pin Assignments
2.2 Board Layout
SW1
CN1
JP1
CN3
CN4
CN8
CN9
CN6
BAT1
CN14
CN13
CN12
CN11
CN10
CN7
CN5
CN2
Top View
Side View

PICO50R/51R Pico-ITX Board
Board and Pin Assignments 9
SCN3
SCN5 SCN4
1
SSW13
SCN2
CPU
Bottom View

PICO50R/PICO51R Pico-ITX Board
10 Board and Pin Assignments
2.3 Assembly Drawing
For thermal dissipation, a thermal solution enables the PICO50R/51R’s components to
dissipate heat efficiently. All heat generating components are thermally conducted to the
heatspreader in order to avoid hot spots. Images below illustrate how to install the thermal
solution on PICO50R/51R.
1. Standard –Heatsink with fan for PICO50R/51R (see image below):
Note
Please pay attention to the position of fan cable when assembling heatsink.
Fan
cable
Fan
cable

PICO50R/51R Pico-ITX Board
Board and Pin Assignments 11
2. Optional -- Heatspreader for PICO50R/51R (see image below):
Note
Heatspreader has a large, flat surface on top. It has no fan and no fins. Instead of
cooling by forced air, it is pressed directly up against another large flat surface
(for example: the frame or the inside wall of a sealed container) and heat is
allowed to pass from the small heatspreader out to the larger metal surface.
Heatspreader does not cool the CPU by itself, it only transfer the heat to another
object where it can safely dissipate away from the processor.
The standard heatsink with fan cannot be screwed above heatspreader.

PICO50R/PICO51R Pico-ITX Board
12 Board and Pin Assignments
2.4 Jumper and Switch Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. Below illustration
shows how to set up jumper.
Properly configure jumper and switch settings on the PICO50R/51R to meet your application
purpose. Below you can find a summary table of jumper, switch and onboard default settings.
Note
Once the default jumper or switch setting needs to be changed, please do it under
power-off condition.
Jumper and Switch
Description
Setting
JP1
LVDS +3.3V/+5V/+12V Voltage Selection
Default: +3.3V Level
1-2 Close
SW1
Restore BIOS Optimal Defaults
Default: Normal Operation
Release
SSW1
Auto Power On
Default: Enable
2-3 Close

PICO50R/51R Pico-ITX Board
Board and Pin Assignments 13
2.4.1 LVDS +3.3V/+5V/+12V Voltage Selection (JP1)
The board supports voltage selection for flat panel displays. Use these jumpers to set
LVDS connector (CN4) pin 1~6 VCCM to +3.3V, +5V or +12V. To prevent hardware
damage, before connecting please make sure that the input voltage of flat panel is
correct.
2.4.2 Restore BIOS Optimal Defaults (SW1)
Use SW1 to clear CMOS. Press the tact switch for at least 3 second to restore BIOS
optimal defaults.
2.4.3 Auto Power On (SSW1)
If SSW1 is enabled for power input, the system will be automatically power on without
pressing soft power button. If SSW1 is disabled for power input, it is necessary to
manually press soft power button to power on the system.
Function
Setting
+3.3V level (Default)
1-2 close
+5V level
2-4 close
+12V level
5-6 close
Function
Setting
Normal (Default)
Release
Restore BIOS optimal defaults
Press
Function
Setting
Disable auto power on
1-2 close
Enable auto power on (Default)
2-3 close

PICO50R/PICO51R Pico-ITX Board
14 Board and Pin Assignments
2.5 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
Description
CN1
DDR4 SO-DIMM Connector
CN2
Front Panel Connector
CN3
Inverter Connector
CN4
LVDS Connector
CN5
USB 2.0 Wafer Port 3 and 4
CN6
SMBus Connector
CN7
M.2 2242 Key B Connector
CN8
M.2 2230 Key E Connector
CN9
Power Connector
CN10
USB 3.0 Port 1 and 2
CN11, CN12
Ethernet Ports
CN13
DisplayPort Connector
CN14
Digital I/O Connector
BAT1
CMOS Battery Connector
SCN2
Fan Connector
SCN3, SCN4
COM2 and COM1 Wafer Connectors
SCN5
Power Output Connector
