AXIOMTEK MANO522 Series User manual

MANO522 Series
Intel®Socket 1151 CoreTM i7/ i5/ i3
Processors Mini ITX Motherboard
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2020 Axiomtek Co., Ltd.
All Rights Reserved
November 2020, Version A2
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity. To prevent chipsets
from electrostatic discharge damage, please take care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel®and Celeron®are trademarks of Intel Corporation.
Windows®is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers ......................................................................................................ii
ESD Precautions............................................................................................. iii
Chapter 1 Introduction............................................. 1
1.1 Features................................................................................................1
1.2 Specifications........................................................................................2
1.3 Utilities Supported.................................................................................3
1.4 Block Diagram.......................................................................................4
Chapter 2 Board and Pin Assignments.................... 5
2.1 Board Layout.........................................................................................5
2.2 Rear I/O.................................................................................................6
2.3 Jumper Settings....................................................................................7
2.3.1 Clear CMOS (JP1) ...................................................................................... 8
2.3.2 AT/ATX Power Mode Select (JP3) .............................................................. 8
2.3.3 COM1 RS-232/422/485 Mode Select (JP4, JP6, JP7) ............................... 9
2.3.4 COM1 Data/Power Select (JP5) ................................................................. 9
2.3.5 LVDS Backlight PWM/DC Mode Select (JP8)............................................. 9
2.3.6 LVDS VDD Select (JP9).............................................................................. 9
2.3.7 Case Open Select (JP10) ......................................................................... 10
2.4 Connectors..........................................................................................11
2.4.1 SIM Card Slot (CN5) ................................................................................. 12
2.4.2 mSATA Connector (CN6) .......................................................................... 12
2.4.3 SATA 3.0 Connectors (CN7~CN8) ............................................................ 13
2.4.4 Front Panel Header (CN12) ...................................................................... 13
2.4.5 USB 2.0 Port (CN13)................................................................................. 14
2.4.6 ATX Power Input Connectors (CN16 and CN17)...................................... 15
2.4.7 Fan Connectors (CN18 and CN19)........................................................... 16
2.4.8 GPIO Header (CN20)................................................................................ 16
2.4.9 COM D-Sub Connector (CN21) ................................................................ 17
2.4.10 COM Headers (CN22~CN23 and CN36~CN37)....................................... 17
2.4.11 LAN and USB 3.0 Connectors (CN26 and CN27) .................................... 18
2.4.12 Audio Jack (CN28).................................................................................... 18
2.4.13 Front Audio Header (CN29) ...................................................................... 19
2.4.14 HDMI Connector (CN30)........................................................................... 19
2.4.15 LVDS Signal Header (CN31)..................................................................... 20
2.4.16 LVDS Backlight Control Header (CN32) ................................................... 21
2.4.17 M.2 Key E Connector (CN34) ................................................................... 22
2.4.18 VGA Connector (CN35)............................................................................. 23

v
Chapter 3 Hardware Description ........................... 25
3.1 Microprocessors..................................................................................25
3.2 BIOS....................................................................................................25
3.3 System Memory..................................................................................25
Chapter 4 AMI BIOS Setup Utility .......................... 27
4.1 Starting................................................................................................27
4.2 Navigation Keys..................................................................................27
4.3 Main Menu ..........................................................................................29
4.4 Advanced Menu..................................................................................30
4.5 Chipset Menu......................................................................................43
4.6 Security Menu .....................................................................................49
4.7 Boot Menu...........................................................................................50
4.8 Save & Exit Menu................................................................................52
Appendix A Watchdog Timer................................... 55
A.1 About Watchdog Timer........................................................................55
A.2 Sample Program .................................................................................55
Appendix B TPM Settings........................................ 57

vi
This page is intentionally left blank.

MANO522 Mini ITX Motherboard
Introduction 1
Section 1
Introduction
The MANO522 Mini-ITX motherboard supports the new 14nm 8th Generation Intel®Core™ i7/
i5/ i3 and Pentium®processors in LGA1151 package. Featuring the new Intel®H310 Express
chipset with two DDR4 2400/2666MHz memory support, this motherboard is built to perform
best stability and reliability for industrial applications.
It comes with two SATA 3.0, four USB 3.0, two USB 2.0 and one RS-232/422/485 port
providing robust storage and I/O options. Users also can increase board functionality with
PCI-Express x16 and mSATA slot. The high quality MANO522 allows four display interfaces
via HDMI, one VGA and LVDS in quadruplicate views, making it an ideal solution for gaming,
workstation, digital signage, medical and other IoT&M2M applications.
1.1 Features
LGA1151 Socket for 8th Generation Intel®Core™ i7/ i5/ i3 and Pentium®processors
(Coffee Lake)
2 DDR4 2400/2666MHz memory with maximum capacity up to 64GB
1 PCI-Express x16
1 mSATA (support SATA, USB 2.0 signal) and 1 SIM card slots
1 M.2 Key E, size: 22x30 for WiFi (support PCIE x1, USB 2.0 signal)
2 SATA-600
4 USB 3.0 and 2 USB 2.0

MANO522 Mini ITX Motherboard
2 Introduction
1.2 Specifications
CPU
LGA1151 Socket for 8th Generation Intel®Core™ i7/ i5/ i3 and Pentium®processors.
Chipset
Intel®H310.
BIOS
AMI BIOS via SPI interface.
System Memory
Two 260-pin SO-DIMM sockets.
Maximum up to 64GB DDR4 memory.
Support 2400/2666MHz.
Onboard Multi I/O
Controller: ITE8786.
Six serial ports:
- COM1 supports RS-232/422/485; COM2~COM6 support RS-232 only.
- COM1~COM2 on the rear I/O; COM3~COM6 in wafer connectors.
USB Interface
Four USB 3.0 ports (on the rear I/O).
Two USB 2.0 ports (on the rear I/O).
Ethernet
LAN1: 1000/100/10Mbps Gigabit/Fast Ethernet supports Wake-on-LAN, PXE with
Intel®i219LM.
LAN2: 1000/100/10Mbps Gigabit/Fast Ethernet supports Wake-on-LAN, PXE with
Intel®i211AT.
Serial ATA
Two SATA 3.0 port (6Gb/s).
One mSATA slot.
Audio
Realtek ALC662 5.1 channel HDA codec.
Support MIC-in/line-out (on the rear I/O).
Support MIC-in/line-out/line-in in box headers (internal).
Display
One HDMI with resolution max. up to 3840x2160 @30Hz.
One VGA with resolution max. up to1920 x 1200 @60Hz.
One 24-bit dual channel LVDS and one 8-pin inverter connector. LVDS resolution is
max. up to 1920x1200.
Expansion Interface
One PCI-Express x16 slot.
One SIM card slot.
One M.2 Key E slot

MANO522 Mini ITX Motherboard
Introduction 3
Power Input
One ATX power input connector.
One 12V ATX power input connector for CPU power.
Operating Temperature
0°C ~ 60°C.
Storage Temperature
-20°C ~ 65°C.
Form Factor
Mini ITX (6.7”x 6.7”, 17.0cm x 17.0cm).
Note
All specifications and images are subject to change without notice.
1.3 Utilities Supported
Chipset driver
Graphics driver
Intel ME driver
Ethernet driver
Audio driver
Intel_Rapid_Storage_Technology driver

MANO522 Mini ITX Motherboard
4 Introduction
1.4 Block Diagram

MANO522 Mini ITX Motherboard
Board and Pin Assignments 5
Section 2
Board and Pin Assignments
2.1 Board Layout

MANO522 Mini ITX Motherboard
6 Board and Pin Assignments
2.2 Rear I/O
Jumpers/Headers/Connectors
1
4-pin ATX Power Input Connector (CN16)
16
SATA 3.0 Connectors (CN7~CN8)
2
PCI-Express x16 Slot (CN15)
17
Front Audio Header (CN29)
3
LVDS Backlight PWM/DC Mode Select
Jumper (JP8)
18
COM1 Data/Power Select Jumper (JP5)
4
DDR4 SO-DIMM Connectors (CN1, CN2)
19
COM1 RS-232/422/485 Mode Select
Jumpers (JP4, JP6, JP7)
5
LVDS VDD Select Jumper (JP9)
20
M.2 Key E Connector (CN34)
6
LVDS Signal Header (CN31)
21
CPU Fan Connector (CN18)
7
LVDS Backlight Control Header (CN32)
22
System Fan Connector (CN19)
8
SIM Card Slot (CN5)
23
mSATA Connector (CN6)
9
GPIO Header (CN20)
24
Audio Jack (CN28)
10
24-pin ATX Power Input Connector (CN17)
25
COM1 and COM2 D-Sub Connector
(CN21)
11
Case Open Select Jumper (JP10)
26
USB 2.0 Port (CN13)
12
Front Panel Header (CN12)
27
LAN1 and USB 3.0 Connector (CN26)
13
AT/ATX Power Mode Select Jumper (JP3)
28
LAN2 and USB 3.0 Connector (CN27)
14
COM3~COM6 Headers (CN22~CN23,
CN36~CN37)
29
HDMI Connector (CN30)
15
Clear CMOS Jumper (JP1)
30
VGA Connector (CN35)

MANO522 Mini ITX Motherboard
Board and Pin Assignments 7
Note
To identify the first pin of a header or jumper, please refer to the following
information:
Usually, there is a thick line or a triangle near the header or jumper pin 1.
Square pad, which you can find on the back of the motherboard, is usually
used for pin 1.
2.3 Jumper Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. The following
illustration shows how to set up jumper.
Before applying power to MANO522 Series, please make sure all of the jumpers are in factory
default position. Below you can find a summary table of all jumpers and onboard default
settings.
Note
Once the default jumper setting needs to be changed, please do it under power-off
condition.

MANO522 Mini ITX Motherboard
8 Board and Pin Assignments
Jumper
Description
Setting
JP1
Clear CMOS
Default: Normal Operation
1-2 Close
JP3
AT/ATX Power Mode Select
Default: ATX Mode
1-2 Close
JP4
COM1 RS-232/422/485 Mode Select
Default: RS-232
1-2 Close
JP6
3-5, 4-6 Close
JP7
3-5, 4-6 Close
JP5
COM1 Data/Power Select
Default: RS-232 Data
COM1 Pin 1: DCD#
3-5 Close
COM1 Pin 9: RI#
4-6 Close
JP8
LVDS Backlight PWM/DC Mode Select
Default: PWM
1-2 Close
JP9
LVDS VDD Select
Default: +3.3V
1-2 Close
JP10
Case Open Select
Default: Close
1-2 Close
2.3.1 Clear CMOS (JP1)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can
clear the CMOS memory of date, time, and system setup parameters by erasing the
CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS,
which includes system setup information such as system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Remove the onboard battery.
3. Move the jumper clip from pins 1-2 (default) to pins 2-3. Keep the clip on pins 2-3
for about 5~10 seconds, then move the clip back to pins 1-2.
4. Re-install the battery.
5. Plug the power cord and turn ON the computer.
6. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter
data.
2.3.2 AT/ATX Power Mode Select (JP3)
This 3-pin (pitch=2.0mm) jumper allows you to select AT or ATX power mode.
Function
Setting
Normal operation (Default)
1-2 close
Clear CMOS
2-3 close
Function
Setting
ATX mode (Default)
1-2 close
AT mode
2-3 close

MANO522 Mini ITX Motherboard
Board and Pin Assignments 9
2.3.3 COM1 RS-232/422/485 Mode Select (JP4, JP6, JP7)
These are 3x2-pin (pitch=2.0mm) jumpers for setting COM1 port to operate in RS-232,
RS-422 or RS-485 communication mode.
JP4JP6 JP7
2.3.4 COM1 Data/Power Select (JP5)
This is a 3x2-pin (pitch=2.0mm) jumper. The COM1 port has +5V power capability on
DCD and +12V on RI by setting JP5.
2.3.5 LVDS Backlight PWM/DC Mode Select (JP8)
This 3-pin (pitch=2.0mm) jumper enables you to select PWM or voltage control mode for
LVDS backlight control header (CN32). These two control modes are for adjusting the
brightness of LVDS panel.
2.3.6 LVDS VDD Select (JP9)
The motherboard supports voltage selection for flat panel displays. Use this 3x2-pin
(pitch=2.54mm) jumper to set up VDD power of the LVDS connector. To prevent
hardware damage, before connecting please make sure that the input voltage of LVDS
panel is correct.
Function
Setting
RS-232 mode
(Default)
JP4 1-2 close
JP6 3-5, 4-6 close
JP7 3-5, 4-6 close
RS-422 mode
JP4 3-4 close
JP6 1-3, 2-4 close
JP7 1-3, 2-4 close
RS-485 mode
JP4 5-6 close
JP6 1-3, 2-4 close
JP7 1-3, 2-4 close
Function
Setting
Power: Set COM1 pin 1 to +5V
1-3 close
Data: Set COM1 pin 1 to DCD (Default)
3-5 close
Power: Set COM1 pin 9 to +12V
2-4 close
Data: Set COM1 pin 9 to RI (Default)
4-6 close
Function
Setting
Controlled by PWM (Default)
1-2 close
Controlled by DC Voltage
2-3 close
Function
Setting
+3.3V (Default)
1-2 close
+5V
3-4 close
+12V
5-6 close

MANO522 Mini ITX Motherboard
10 Board and Pin Assignments
2.3.7 Case Open Select (JP10)
The motherboard has one 2-pin (pitch=2.54mm) jumper for chassis intrusion detection
feature.
Function
Setting
Close (Default)
1-2 close
Active case open
1-2 open

MANO522 Mini ITX Motherboard
Board and Pin Assignments 11
2.4 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table showing connectors on the hardware.
Connector
Description
CN1
DIMM1: DDR4 SO-DIMM Connector
CN2
DIMM2: DDR4 SO-DIMM Connector
CN5
SIM Card Slot
CN6
mSATA Connector
CN7~CN8
SATA 3.0 Connectors
CN12
Front Panel Header
CN13
USB 2.0 port
CN15
PCI-Express x16 Slot
CN16~CN17
ATX Power Input Connectors
CN18~CN19
Fan Connectors
CN20
GPIO Header
CN21
COM1 and COM2 D-Sub Connector
CN22~CN23, CN36~CN37
COM3, COM4, COM5 and COM6 Headers
CN26~CN27
LAN and USB 3.0 Connectors
CN28
Audio Jack
CN29
Front Audio Header
CN30
HDMI Connector
CN31
LVDS Signal Header
CN32
LVDS Backlight Control Header
CN34
M.2 Key E Connector
CN35
VGA Connector

MANO522 Mini ITX Motherboard
12 Board and Pin Assignments
2.4.1 SIM Card Slot (CN5)
The CN5 is for inserting SIM Card which is mainly used in 3G/4G wireless network
application. In order to work properly, the SIM Card must be used together with 3G/4G
module which is inserted to CN6.
87 6 5
2.4.2 mSATA Connector (CN6)
Pin
Signal
Pin
Signal
1
PWR_UIM
5
N/C
2
REST_UIM
6
DAT_UIM
3
CLK_UIM
7
VPP_UIM
4
N/C
8
GND
Pin
Signal
Pin
Signal
1
N/C
2
+3.3VAUX
3
N/C
4
GND
5
N/C
6
+1.5V
7
N/C
8
UIM_PWR
9
GND
10
UIM_DAT
11
N/C
12
UIM_CLK
13
N/C
14
UIM_REST
15
GND
16
UIM_VPP
17
N/C
18
GND
19
N/C
20
N/C
21
GND
22
PERST#
23
SATA0_RX_DP
24
+3.3VAUX
25
SATA0_RX_DN
26
GND
27
GND
28
+1.5V
29
GND
30
SMB_CLK
31
SATA0_TX_DN
32
SMB_DATA
33
SATA0_TX_DP
34
GND
35
GND
36
USB#6_D-
37
GND
38
USB#6_D+
39
+3.3VAUX
40
GND
41
+3.3VAUX
42
N/C
43
GND
44
N/C
45
N/C
46
N/C
47
N/C
48
+1.5V
49
N/C
50
GND
51
N/C
52
+3.3VAUX
1 2 3 4

MANO522 Mini ITX Motherboard
Board and Pin Assignments 13
2.4.3 SATA 3.0 Connectors (CN7~CN8)
These Serial Advanced Technology Attachment (Serial ATA or SATA) connectors are for
SATA 3.0 interfaces allowing up to 6.0Gb/s data transfer rate. They are computer bus
interfaces for connecting to devices such as hard disk drives.
CN8 CN7
2.4.4 Front Panel Header (CN12)
The CN12 is a 7x2-pin (pitch=2.54mm) header for front panel interface.
Power LED
Pin 1 connects anode(+) of LED and pin 5 connects cathode(-) of LED. The power LED
lights up when the system is powered on.
External Speaker and Internal Buzzer
Pin 2, 4, 6 and 8 connect the case-mounted speaker unit or internal buzzer. While
connecting the board to an internal buzzer, please set pin 2 and 4 closed; while
connecting to an external speaker, you need to set pins 2 and 4 opened and connect the
speaker cable to pin 8(+) and pin 2(-).
Power On/Off Button
Pin 9 and 10 connect the power button on front panel to the board, which allows users to
turn on or off power supply.
Pin
Signal
1
GND
2
SATA_TX+
3
SATA_TX-
4
GND
5
SATA_RX-
6
SATA_RX+
7
GND
Pin
Signal
1
Power LED+
2
SPK-
3
GND
4
BUZZER-
5
Power LED-
6
N/C
7
N/C
8
SPK+
9
PWR-
10
PWR+
11
RESET-
12
RESET+
13
HD LED-
14
HD LED+

MANO522 Mini ITX Motherboard
14 Board and Pin Assignments
System Reset Switch
Pin 11 and 12 connect the case-mounted reset switch that reboots your computer
without turning off the power switch. It is a better way to reboot your system for a longer
life of system power supply.
HDD Activity LED
This connection is linked to hard drive activity LED on the control panel. LED flashes
when HDD is being accessed. Pin 13 and 14 connect the hard disk drive to the front
panel HDD LED, pin 13 is assigned as cathode(-) and pin 14 is assigned as anode(+).
2.4.5 USB 2.0 Port (CN13)
The motherboard comes with one double-deck Universal Serial Bus (compliant with
USB 2.0 (480Mbps)) connector on the rear I/O for installing USB peripherals such as
keyboard, mouse, scanner, etc.
1 2 3 4
5 6 7 8
Pin
Signal
Pin
Signal
1
USB VCC (+5V
level)
5
USB VCC (+5V
level)
2
USB #1_D-
6
USB #8_D-
3
USB #1_D+
7
USB #8_D+
4
GND
8
GND
