AXIOMTEK MMB501 User manual

MMB501
Intel®Socket 1151 CoreTM i7/ i5/ i3
Processors Micro MICRO ATX
Industrial Motherboard
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2018 Axiomtek Co., Ltd.
All Rights Reserved
MAY 2018, Version A1
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity. To prevent chipsets
from electrostatic discharge damage, please take care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel®and Celeron®are trademarks of Intel Corporation.
Windows®is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers ......................................................................................................ii
ESD Precautions............................................................................................. iii
Chapter 1 Introduction............................................. 1
1.1 Features................................................................................................2
1.2 Specifications........................................................................................2
Chapter 2 Board and Pin Assignments.................... 5
2.1 Board Layout.........................................................................................5
2.2 Rear I/O.................................................................................................7
2.3 Jumper Settings....................................................................................8
2.3.1 Clear CMOS (JP1) ...................................................................................... 9
2.3.2 AT/ATX Mode Select (JP2).......................................................................... 9
2.3.3 COM1 Mode Select (JP3, JP5, JP6)......................................................... 10
2.3.4 COM1 Data/Power Select (JP4) ............................................................... 10
2.3.5 COM2 Mode Select (JP7, JP9, JP10)....................................................... 10
2.3.6 COM2 Data/Power Select (JP8) ................................................................11
2.4 Connectors..........................................................................................12
2.4.1 Front Panel Header (CN5) ........................................................................ 13
2.4.2 Mini PCIE Slot with SIM Card Slot (CN6 & CN7)...................................... 14
2.4.3 HDMI & DP Connector (CN9) ................................................................... 15
2.4.4 VGA and DVI-D Connector (CN10)........................................................... 16
2.4.5 LAN and USB 3.0 Connectors (CN11 and CN12)..................................... 17
2.4.6 Audio Jack (CN13).................................................................................... 17
2.4.7 Front Audio Header (CN14) ...................................................................... 18
2.4.8 Power Input Connectors (CN15 and CN16).............................................. 18
2.4.9 SMBus Header (CN18) ............................................................................. 19
2.4.10 Fan Connectors (CN19~CN21)................................................................. 19
2.4.11 GPIO Header (CN22)................................................................................ 20
2.4.12 Internal USB 3.0 Connector (CN23).......................................................... 20
2.4.13 Internal USB Headers (CN17 and CN24~CN25)...................................... 21
2.4.14 SPI interface for TPM module (CN26) ...................................................... 21
2.4.15 COM1 Connector (COM1) ........................................................................ 21
2.4.16 COM Headers (COM2~COM6)................................................................. 22
2.4.17 SATA 3.0 Connectors (SATA1~SATA6)..................................................... 22
Chapter 3 Hardware Description ........................... 23
3.1 Microprocessors..................................................................................23
3.2 BIOS....................................................................................................23

v
3.3 System Memory..................................................................................23
Chapter 4 AMI BIOS Setup Utility .......................... 25
4.1 Starting................................................................................................25
4.2 Navigation Keys..................................................................................25
4.3 Main Menu ..........................................................................................27
4.4 Advanced Menu..................................................................................28
4.5 Chipset Menu......................................................................................44
4.6 Security Menu .....................................................................................53
4.7 Boot Menu...........................................................................................54
4.8 Save & Exit Menu................................................................................55
Appendix A Watchdog Timer................................... 57
A.1 About Watchdog Timer........................................................................57
A.2 Sample Program .................................................................................57
Appendix B BIOS Flash Utility ................................ 59

vi
This page is intentionally left blank.

MMB501 LGA1151 ATX Motherboard
Introduction 1
Chapter 1
Introduction
The MMB501 is an advanced micro ATX industrial motherboard based on the 7th / 6th
Generation Intel® Core™ i7/ i5/ i3/ Pentium®and Celeron®processors (Kabylake-S / Skylake-S)
in LGA1151 Socket with Intel®Q170. The optimized MMB501 is specially designed for better
computing and visual performance; ideally used in every major industry for tasks ranging from
financial modeling to designing complex buildings and vehicles. With its built-in Intel®HD
Graphics 530/510, this industrial grade motherboard delivers great 3D visual performance with
triple display capability through DP, DVI-D, HDMI and VGA ports demanded by
professional-grade CAD and media/entertainment fields.
In addition, the MMB501 supports Intel®Turbo Boost 2.0 technology, Intel®Hyper-Threading
technology, Intel®HD Graphics with DX11 support, 3-D Tri-Gate transistors, 64GB DDR4
2133/2400MHz memory, and PCI-Express 3.0 x16 slot. It also features Intel®Active
Management Technology 9.0 (iAMT), SATA RAID, as well as PCI-Express x4 expansion
making it ideal for applications with added security features.

MMB501 LGA1151 ATX Motherboard
2 Introduction
1.1 Features
LGA1151 Socket 7th/6th Generation Intel®Core™i7/i5/i3, Pentium®and Celeron®
processors (Kabylake-S/Skylake-S) up to 65W
4 DDR4 2133/2400MHz DIMM with maximum capacity up to 64GB (max. 16GB per slot)
DP, DVI-D, HDMI, and VGA with triple view supported
6 SATA 6Gb/s RAID 0/1/5/10
6 USB 3.0 and 5 USB 2.0 ports
PCI-Express Mini Card
1.2 Specifications
CPU
LGA1151 Socket 6th Generation Intel®Core™ i7/ i5/ i3, Pentium®and Celeron®
processors.
Chipset
Intel®Q170.
BIOS
AMI BIOS.
System Memory
Four 288-pin DIMM sockets.
Maximum up to 64GB DDR4 memory (max. 16GB per slot).
Support 2133/2400MHz.
Onboard Multi I/O
One PS/2 keyboard and mouse.
Six serial ports:
- Four RS-232 (internal box headers).
- Two RS-232/422/485 (one in rear I/O, and the other in internal box header).
USB Interface
Six USB 3.0 ports (four in rear I/O, and the others in internal header)
Five USB 2.0 ports (internal box headers)
Ethernet
LAN1: 1000/100/10Mbps Gigabit/Fast Ethernet supports Wake-on-LAN, PXE Boot
ROM, iAMT with Intel®i219LM.
LAN2: 1000/100/10Mbps Gigabit/Fast Ethernet supports Wake-on-LAN, PXE Boot
ROM with Intel®i211AT.
Serial ATA
Six SATA 6Gb/s with RAID 0/1/5/10.
Audio
Realtek ALC662 2 channel HDA Codec.
Support MIC-in/line-in/line-out.

MMB501 LGA1151 ATX Motherboard
Introduction 3
Display
One 15-pin D-Sub as VGA connector. Resolution max. up to 1920x1200 @60Hz.
One HDMI 1.4b with resolution max. up to 4096x2160 @24Hz.
One DVI-D with resolution max. up to 1920×1200 @60Hz.
One DP with resolution max. up to 5120x2880@60Hz
Expansion Interface
One PCI-Express x16 slot.
Two PCI-Express x4 slots.
One PCI slots.
One PCI Express Mini Card(full size, for wifi/3G/4G w/SIM slot)
Power Input
One ATX power input connector.
One 12V ATX power input connector for CPU Power.
Operating Temperature
0°C ~ 60°C.
Storage Temperature
-20°C ~ 75°C.
Form Factor
244 x 244mm.
Note
All specifications and images are subject to change without notice.

MMB501 LGA1151 ATX Motherboard
4 Introduction
This page is intentionally left blank.

MMB501 LGA1151 ATX Motherboard
Board and Pin Assignments 5
Chapter 2
Board and Pin Assignments
2.1 Board Layout

MMB501 LGA1151 ATX Motherboard
6 Board and Pin Assignments
Board Layout (BOTTOM)

MMB501 LGA1151 ATX Motherboard
Board and Pin Assignments 7
2.2 Rear I/O
Note
A direct contact CPU cooler back plate is not available for MMB501.
Jumpers/Headers/Connectors
1
CPU Socket for LGA1151(J1)
20
Front Panel Header (CN5)
2
CPU Fan Connector (CN19)
21
System Fan Connector (CN20)
3
Coin battery Socket for RC2032 (BAT1)
22
System Fan Connector (CN21)
4
ATX2 CPU Power Input Connector (CN15)
23
Mini PCIE Slot (CN6)
5
COM1 Mode Select (JP3. JP5. JP6)
24
SIM Card Slot (CN7)
6
COM1 Data/Power Select (JP4)
25
SMBus Header (CN18)
7
PCI-Express x16 Slot (CN1)
26
SATA 3.0 Connector (SATA1~SATA6)
8
PCI-Express x4 Slots (CN2. CN3)
27
ATX1 24-pin Power Input Connector (CN16)
9
PCI Slots (CN4)
28
DDR4 Slots (DIMM1~4)
10
COM2 Data/Power Select (JP8)
29
Front Audio Header (CN14)
11
COM2 Mode Select (JP7, JP9, JP10)
30
COM1 Connector (COM1)
12
COM Headers (COM2~COM6)
31
PS/2 Connector (CN8)
13
GPIO Header (CN22)
32
DVI-D & VGA Connector (CN10)
14
Internal USB Headers (CN24. CN25)
33
HDMI & DP Connector (CN9)
15
AT/ATX Mode Select (JP2)
34
LAN and USB 3.0 Connectors (CN11. CN12)
16
Clear CMOS (JP1)
35
Audio Jack (CN13)
17
Internal USB 3.0 Connector (CN23)
36
SPI Flash Socket (BIOS2)
18
USB 2.0 Type-A 180D Connector (CN17)
19
SPI interface for TPM module (CN26)

MMB501 LGA1151 ATX Motherboard
8 Board and Pin Assignments
Note
To identify the first pin of a header or jumper, please refer to the following
information:
Usually, there is a thick line or a triangle near the header or jumper pin 1.
Square pad, which you can find on the back of the motherboard, is usually
used for pin 1.
2.3 Jumper Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. The following
illustration shows how to set up jumper.
Before applying power to MMB501 Series, please make sure all of the jumpers are in factory
default position. Below you can find a summary table of all jumpers and onboard default
settings.
Note
Once the default jumper setting needs to be changed, please do it under power-off
condition.
Jumper
Description
Setting
JP1
Clear CMOS
Default: Normal Operation
1-2 Close
JP2
AT/ATX Power Mode Select
Default: ATX Mode
1-2 Close
JP3
COM1/2 RS-232/422/485 Mode Select
Default: RS-232
1-2 Close
JP5
3-5, 4-6 Close
JP6
3-5, 4-6 Close
JP4/8
COM1/2 Data/Power Select
Default: RS-232 Data
3-5 Close
4-6 Close

MMB501 LGA1151 ATX Motherboard
Board and Pin Assignments 9
2.3.1 Clear CMOS (JP1)
This jumper (3x1-pin p=2.54mm) allows you to clear the Real Time Clock (RTC) RAM in
CMOS. You can clear the CMOS memory of date, time, and system setup parameters by
erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM
data in CMOS, which includes system setup information such as system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Remove the onboard battery.
3. Move the jumper clip from pins 1-2 (default) to pins 2-3. Keep the clip on pins 2-3
for about 5~10 seconds, then move the clip back to pins 1-2.
4. Re-install the battery.
5. Plug the power cord and turn ON the computer.
6. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter
data.
2.3.2 AT/ATX Mode Select (JP2)
This 3x1-pin p=2.00mm jumper allows you to select AT or ATX power mode.
Function
Setting
Normal operation (Default)
1-2 close
Clear CMOS
2-3 close
Function
Setting
ATX mode (Default)
1-2 close
AT mode
2-3 close

MMB501 LGA1151 ATX Motherboard
10 Board and Pin Assignments
2.3.3 COM1 Mode Select (JP3, JP5, JP6)
Use these jumpers (3x2-pin p=2.54mm) to set COM1 port to operate in RS-232, RS-422
or RS-485 communication mode.
JP3 JP5 JP6
2.3.4 COM1 Data/Power Select (JP4)
The COM1 port has +5V power capability on DCD# and +12V on RI# by setting this
jumper (3x2-pin p=2.54mm).
2.3.5 COM2 Mode Select (JP7, JP9, JP10)
Use these jumpers (3x2-pin p=2.54mm) to set COM1 port to operate in RS-232, RS-422
or RS-485 communication mode.
JP7 JP9 JP10
Function
Setting
RS-232 mode
(Default)
JP3 1-2 close
JP5 3-5, 4-6 close
JP6 3-5, 4-6 close
RS-422 mode
JP3 3-4 close
JP5 1-3, 2-4 close
JP6 1-3, 2-4 close
RS-485 mode
JP3 5-6 close
JP5 1-3, 2-4 close
JP6 1-3, 2-4 clos
Function
Setting
Power: Set COM1 pin 1 to +5V
1-3 close
Data: Set COM1 pin 1 to DCD# (Default)
3-5 close
Power: Set COM1 pin 9 to +12V
2-4 close
Data: Set COM1 pin 9 to RI# (Default)
4-6 close
Function
Setting
RS-232 mode
(Default)
JP7 1-2 close
JP9 3-5, 4-6 close
JP10 3-5, 4-6 close
RS-422 mode
JP7 3-4 close
JP9 1-3, 2-4 close
JP19 1-3, 2-4 close
RS-485 mode
JP7 5-6 close
JP9 1-3, 2-4 close
JP10 1-3, 2-4 clos

MMB501 LGA1151 ATX Motherboard
Board and Pin Assignments 11
2.3.6 COM2 Data/Power Select (JP8)
The COM2 port has +5V power capability on DCD# and +12V on RI# by setting this
jumper (3x2-pin p=2.54mm).
Function
Setting
Power: Set COM2 pin 1 to +5V
1-3 close
Data: Set COM2 pin 1 to DCD# (Default)
3-5 close
Power: Set COM2 pin 8 to +12V
2-4 close
Data: Set COM2 pin 8 to RI# (Default)
4-6 close

MMB501 LGA1151 ATX Motherboard
12 Board and Pin Assignments
2.4 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table showing connectors on the hardware.
Connector
Description
CN1
PCI-Express x16 Slot
CN2~CN3
PCI-Express x4 Slots
CN4
PCI Slots
CN5
Front Panel Header
CN6~ CN7
Mini PCIE Slot & SIM Card Slot
CN8
PS/2
CN9
HDMI & DP Connector
CN10
DVI-D & VGA Connector
CN11, CN12
LAN and USB 3.0 Connectors
CN13
Audio Jack
CN14
Front Audio Header
CN15
ATX2 CPU Power Input Connector
CN16
ATX1 24-pin Power Input Connector
CN17
USB 2.0 Type-A 180D Connector
CN18
SMBus Header
CN19
CPU Fan Connector
CN20~CN21
System Fan Connectors
CN22
GPIO Header
CN23
Internal USB 3.0 Connector
CN24~CN25
Internal USB Headers
CN26
SPI interface for TPM module
BAT1
Coin battery Socket for RC2032
COM1
COM1 Connector
COM2~COM6
COM Headers
DIMM1~DIMM4
DDR4 Slots
SATA1~SATA6
SATA 3.0 Connector
J1
CPU Socket for LGA1151
BIOS2
SPI Flash Socket

MMB501 LGA1151 ATX Motherboard
Board and Pin Assignments 13
2.4.1 Front Panel Header (CN5)
This is front panel header (5x2-pin p=2.54mm).
Note
[*]: The buzzer on motherboard will be active when pin 2 and pin 4 is
connected; the external speaker on chassis will be active when pin 2 and
pin 4 is open.
Pin
Signal
1
PWR LED-
2
SPK-
3
GND
4
BUZZER-
5
PWRLED+
6
NC
7
NC
8
VCC5
9
PWRSW-
10
PWRSW+
11
HW RST-
12
HW RST+
13
HDD LED-
14
HDD LED+

MMB501 LGA1151 ATX Motherboard
14 Board and Pin Assignments
2.4.2 Mini PCIE Slot with SIM Card Slot (CN6 & CN7)
Mini PCIE Slot (CN6)
SIM Card Slot (CN7)
The CN6 is a half-size PCI-Express Mini Card connector. It supports the PCI-Express
Mini Cards which are applied to either PCI-Express x1 or USB.
Pin
Signal
Pin
Signal
1
PCH_WAKE_
N
2
VCC3_DUAL
3
NC
4
GND
5
NC
6
VCC1P5
7
NC
8
UIM_PWR
9
GND
10
UIM_DAT
11
CLKOUT_PCI
E_N
12
UIM_CLK
13
CLKOUT_PCI
E_P
14
UIM_REST
15
GND
16
UIM_VPP
17
NC
18
GND
19
NC
20
RF_KILL#_WIFI
21
GND
22
BUF_PLT_RST_N
23
PCIE_RX_DN
24
VCC3_DUAL
25
PCIE_RX_DP
26
GND
27
GND
28
VCC1P5
29
GND
30
SMB_CLK_RESUME
31
PCIE_TX_DN
32
SMB_DATA_RESUM
E
33
PCIE_TX_DP
34
GND
35
GND
36
USB-
37
GND
38
USB+
39
VCC3_DUAL
40
GND
41
VCC3_DUAL
42
NC
43
GND
44
NC
45
CL_CLK
46
NC
47
CL_DATA
48
VCC1P5
49
CL_RST_N
50
GND
51
NC
52
VCC3_DUAL
53
GND
54
GND
55
NC
56
NC
Pin
Signal
Pin
Signal
1
UIM_PWR
2
UIM_REST
3
UIM_CLK
4
NC
5
NC
6
UIM_DAT
7
UIM_VPP
8
GND
9
GND
10
GND
11
GND
12
GND
