AXIOMTEK MANO860 User manual

MANO860
Intel® Core™ i7/ i5/ i3/ Celeron
with QM67Mini-ITX Motherboard
User’s Manual

MANO860 User’s Manual
II
Contents
1.1 Product highlights .....................................................................................................8
1.1.1 Product Overview...........................................................................................................8
1.1.2 Platform Features and Benefits......................................................................................8
1.1.3 Key Architecture Features .............................................................................................9
1.2 Before you Proceed .................................................................................................10
1.3 Motherboard Overview ............................................................................................10
1.3.1 Placement Direction.....................................................................................................10
1.3.2 Screw Holes.................................................................................................................11
1.3.3 Motherboard Layout.....................................................................................................11
1.3.4 Layout Content List......................................................................................................12
1.3.5 Internal Connector .......................................................................................................13
1.4 Central Processing Unit (CPU)................................................................................13
1.4.1 Installing the CPU........................................................................................................14
1.4.2 Installing the CPU Heatsink and Fan...........................................................................18
1.5 System Memory........................................................................................................19
1.5.1 Overview......................................................................................................................19
1.5.2 Memory Configurations................................................................................................20
1.5.3 Installing a SO-DIMM...................................................................................................20
1.5.4 Removing a SO-DIMM.................................................................................................22
1.6 Expansion Card........................................................................................................23
1.6.1 Installing an Expansion Card.......................................................................................23
1.6.2 Configuring an Expansion Card...................................................................................23
1.6.3 PCI Express x16 slot....................................................................................................23
1.6.4 MINI PCI Express ........................................................................................................24
1.6.5 CFast Card...................................................................................................................24
1.7 Jumpers....................................................................................................................25
1.7.1 Clear CMOS (CMOS1) ................................................................................................25
1.7.2 COM3, COM4, COM5 RI/+5V/+12V Select (JCOMPWR3 JCOMPWR4 JCOMPWR5)
..............................................................................................................................................26
1.7.3 LVDS Back Light controller form SIO (JBLK1).............................................................26
1.7.4 AT/ATX Power Mode Select (PSON1).........................................................................27
1.8 Connectors...............................................................................................................27
1.8.1 Rear panel connectors.................................................................................................27
1.8.2 CPU and System fan connectors (CPU_FAN1, SYS_FAN1).......................................29
1.8.3 System Panel (F_PANEL)............................................................................................29
1.8.4 ATX power connectors (EATXPWR1, ATX12V1) ........................................................30
1.8.5 Serial Port connectors (COM3, COM4, COM5) ...........................................................31
1.8.6 GPIO Connector (JGPIO) ............................................................................................31

MANO860 User’s Manual
III
1.8.7 Audio Mic.-In & Line-Out Connector (FPAUD1)...........................................................32
1.8.8 LVDS Connector (LVDS1)...........................................................................................32
1.8.9 LCD Inverter Connector (JBL1) ...................................................................................33
1.8.10 SPI Connector (JSPI).................................................................................................34
1.8.11 LPC Connector (JLPC1)............................................................................................34
1.8.12 Serial ATA 3 Connector (SATA1, SATA2).................................................................35
1.8.13 Serial ATA II Connector (SATA3 , SATA4 , SATA5)..................................................35
1.8.14 Case open connectors (JCASE1)..............................................................................36
1.8.15 USB connectors (USB56, USB78, USB910, USB1112,) ...........................................36
2.1 BIOS Setup Program................................................................................................37
2.1.1 Legend Box..................................................................................................................38
2.1.2 List Box........................................................................................................................38
2.1.3 Sub-menu....................................................................................................................38
2.2 BIOS Menu Screen...................................................................................................39
2.3 Main Setup................................................................................................................40
2.4 Advanced BIOS Setup .............................................................................................41
2.4.1 PCI Subsystem Setting................................................................................................42
2.4.2 ACPI Settings ..............................................................................................................44
2.4.3 Trusted computing.......................................................................................................45
2.4.4 CPU configuration........................................................................................................46
2.4.5 SATA Configuration.....................................................................................................48
2.4.6 Intel TXT(LT) Configuration .........................................................................................49
2.4.7 PCH-FW Configuration................................................................................................50
2.4.7.1 Firmware Update Configuration................................................................................51
2.4.8 AMT Configuration.......................................................................................................53
2.4.9 USB Configuration.......................................................................................................55
2.4.10 Super IO Configuration..............................................................................................56
2.4.10.1 Serial Port 0 configuration.......................................................................................57
2.4.10.2 Serial Port 1 configuration.......................................................................................58
2.4.10.3 Serial Port 2 configuration.......................................................................................59
2.4.10.4 Serial Port 3 configuration.......................................................................................59
2.4.10.5 Smart Fan Mode Configuration...............................................................................61
2.4.10.6 Digital I/O Configuration..........................................................................................62
2.4.11 Hardware Monitor ......................................................................................................64
2.4.12 Serial Port Console Redirection.................................................................................65
2.4.13 Intel ICC.....................................................................................................................66
2.4.14 Sandybridge DTS Configuration ................................................................................67
2.4.15 Sandybridge PPM Configuration................................................................................68
2.5 Chipset......................................................................................................................69
2.5.1 System Agent (SA) Configuration................................................................................69

MANO860 User’s Manual
IV
2.5.1.1 Intel IGFX Configuration ...........................................................................................71
2.5.1.1.1 LCD Control...........................................................................................................72
2.5.1.2 DMI Configuration.....................................................................................................74
2.5.1.3 NB PCIe Configuration..............................................................................................75
2.5.1.4 Memory Configuration...............................................................................................76
2.5.2 PCH-IO Configuration..................................................................................................77
2.5.2.1 USB Configuration....................................................................................................78
2.5.2.2 PCI Express Configuration........................................................................................79
2.5.2.2.1 PCI Express Root Port 1........................................................................................81
2.6 Boot...........................................................................................................................82
2.7 Security.....................................................................................................................83
2.8 Save & Exit................................................................................................................84

MANO860 User’s Manual
BIOS Setup
1
Safety Information
Electrical safety
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating
the system.
When adding or removing devices to or from the system, ensure that the power cables for the devices are
unplugged before the signal cables are connected. If possible, disconnect all power cables from the
existing system before you add a device.
Before connecting or removing signal cables from the motherboard, ensure that all power cables are
unplugged.
Seek professional assistance before using an adapter or extension cord. These devices could interrupt the
grounding circuit.
Make sure that your power supply is set to the correct voltage in your area. If you are not sure about the
voltage of the electrical outlet you are using, contact your local power company.
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your
retailer.
Operation safety
Before installing the motherboard and adding devices on it, carefully read all the manuals that came with
the package.
Before using the product, make sure all cables are correctly connected and the power cables are not
damaged. If you detect any damage, contact your dealer immediately.
To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and
circuitry.
Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may
become wet.
Place the product on a stable surface.
If you encounter technical problems with the product, contact a qualified service technician or your retailer.
The symbol of the crossed out wheeled bin indicates that the product
(electrical and electronic equipment) should not be placed in municipal waste. Check
local regulations for disposal of electronic products.

MANO860 User’s Manual
2 BIOS Setup
Safety Declaration
This device complies with the requirements in Part 15 of the FCC rules. Operation is subject to the following two
conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired
operation.
About this guide
This user guide contains the information you need when installing and configuring the motherboard.
How this guide is organized
This manual contains the following parts:
Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new technology it supports. This chapter
also lists the hardware setup procedures that you have to perform when installing system components. It
includes description of the jumpers and connectors on the motherboard.
Chapter 2: BIOS setup
This chapter tells how to change system settings through the BIOS Setup menus. Detailed descriptions of
the BIOS parameters are also provided.
Where to find more information
Refer to the following sources for additional information and for product and software updates.
1. Technical Support
If a problem arises with your system and no solution can be obtained from the user’s manual, please contact
your place of purchase or local distributor. Alternatively, please try the following help resources for further
guidance. Visit the Axiomtek Taiwan website:
http://www.axiomtek.com
2. Optional documentation
Your product package may include optional documentation, such as warranty flyers, that may have been added
by your dealer. These documents are not part of the standard package.

MANO860 User’s Manual
BIOS Setup
3
Conventions used in this guide
To make sure that you perform certain tasks properly, take note of the following symbols used throughout this
manual.
DANGER/WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying to
complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to help you complete a task.
Typography
Bold text Indicates a menu or an item to select
Italics Used to emphasize a word or a phrase
<Key> Keys enclosed in the less-than and greater-than sign means that you must
press the enclosed key
Example: <Enter> means that you must press the Enter or
Return key
<Key1>+<Key2>+<Key3> If you must press two or more keys simultaneously, the key names are
linked with a plus sign (+)
Example: <Ctrl>+<Alt>+<D>
Command Means that you must type the command exactly as shown, then supply the
required item or value enclosed in brackets
Example: At the DOS prompt, type the command line:
afudos /i[filename]
afudos /iP5P800VM.ROM

MANO860 User’s Manual
4 BIOS Setup
Packing List
Before you begin installing your single board, please make sure that the following materials have been shipped:
1 x MANO860 Mini-ITX Main board
1 x CD-ROM contains OS drivers
2 x COM cable
2 x SATA cable
1 x I/O Shield
1 x Startup Manual
If any of the above items is damaged or missing, please contact your retailer.
Specifications Summary
Specifications
System
CPU Support Intel rPGA988 Socket (Socket G2) Intel Mobile Core i7/ i5/ i3 CPU
BIOS AMI 16Mb SPI
System Chipset Intel® QM67
I/O Chipset Nuvoton NCT6776F
Memory
Two 204-pin SODIMM support up to 16GB dual channel DDR3 1066/1333, up to
16GB
Watchdog Timer Reset: 1 to 255 sec/min per step
H/W Status Monitor
Monitoring temperature, voltage and cooling fan status. Auto throttling control
when CPU overheats.
Expansion Slots 1 PCI-E x 16, 1 Mini PCI-E x 1, 1 CFast Card Connector
Power State S1, S3, S4, S5
Wake up on LAN or Ring LAN (WOL) and Ring (WO)
Smart Fan Control Yes
Smart Fan Control Supports 3 modes (Silent/Optimal/Performance)

MANO860 User’s Manual
BIOS Setup
5
Display
Chipset Intel® GMA HD 2000/ 3000 supports DirectX 10.1, OpenGL 3.0
Display Memory Shared Memory, up to 1.7GB
Dual Display VGA + LVDS, VGA + Display Port, VGA + HDMI, Display Port + HDMI,
LVDS + HDMI, LVDS + Display Port
VGA Onboard, supports max resolution 2048 x 1536
HDMI Onboard HDMI 1.3, supports max resolution 1920 x 1080
DisplayPort Onboard, supports max resolution 2560 x 1600
LVDS Onboard dual channel 24-bit LVDS supports max resolution 1600 x
1200
LVDS Backlight Yes, through internal LVDS Backlight Connector
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface Line-in, Line-out, Mic-in, Front Audio Header
TPM
TPM Infineon SLB9635 supports TPM 1.2
Ethernet
LAN1 Intel 82579LM
LAN2 Intel 82583V
Specifications
Back Panel I/O Port
Back Panel I/O Port
1 VGA Port,
1 HDMI Port,
1 DisplayPort,
1 COM RS-232 Port
4 USB 2.0/1.1 Ports,
2 LAN RJ45 Ports,
1 Audio I/O (3 Jacks)

MANO860 User’s Manual
6 BIOS Setup
Internal I/O Connector
Internal I/O Connector
4 USB Connectors support 8 USB Ports,
3 COM RS-232 Connectors with 5V/ 12V Power,
5 SATA Connectors (2 SATA 3.0, 3 SATA II),
1 Front Panel Connector,
1 Front Audio,
1 CPU Fan Connector (3-pin),
1 System Fan Connector (3-pin),
1 LVDS (2 x 20-pin),
1 LVDS Backlight Power Connector,
1 Clear CMOS Jumper (3-pin),
1 GPIO
Mechanical & Environmental
Power Requirement +12V (4.86A), +5V (1.28A), +3.3V (1.05A), -12V (0.41A), 5VSB (0.36A)
Power Type ATX (supports AT Mode)
Power Connector 1 20-pin ATX Power Connector,
1 4-pin ATX 12V Power Connector
Operating Temperature 0°C to 60°C (32°F to 140°F)
Operating Humidity 0% to 90% relative humidity, non-condensing
Size (L x W) 6.69" x 6.69" (170 x 170mm)
LAN2 Intel 82583V
Weight 1.03 lbs (0.47 Kg)
* Specifications are subject to change without notice.

MANO860 User’s Manual
BIOS Setup
7
Block Diagram

MANO860 User’s Manual
8 BIOS Setup
Chapter 1 - Product Introduction
1.1 Product highlights
1.1.1 Product Overview
Supports latest Intel rPGA998 CPU-socket interface processor, the 2nd Generation Intel® Core i3, i5, i7,
Celeron mobile processors which are built on 32 nm technologies to provide smart performance and
responsiveness on executing tasks, It combines the CPU and GPU to offer fantastic HD media and graphics,
especially on 3D gaming experience. Doubles the bandwidth of your system memory up to 21GB/s and pumps
up the system performance at lower power.
DMI (Direct Media Interface) architecture connects between the processor and chipset at 5.0GT/s which twice
the speed of previous version. The exceptionally increased interconnect bit rate from 2.5GT/s up to 5.0GT/s
would effectively eliminates the bottle neck of the system performance and brings the most terrific computing
experience from the present to the future.
There are 2 of 5 SATA ports running at speed up to 6.0Gb/s, and each port can connect with any other SATA
3.0Gb/s and 1.5Gb/s devices for backward compatibility. It supports RAID 0(Striped disk array), RAID
1(Mirroring disk array), RAID 5(Block Interleaved Distributed Parity), RAID 10 (A Stripe of Mirrors).
The MB also provides users the performance and protection. It is integrated 5.1-channel HD Audio CODEC
delivering advanced multi-channel audio and bringing you the experience of home theater-quality sound.
Delivers transfer speed ten times faster than conventional 10/ 100 Ethernet connections, supporting a high
transfer rate up to Gigabit/s. Gigabit LAN is the networking standards for the future and is ideal for handing large
amount of data such as video, audio, and voice. Supports TPM 1.2.
1.1.2 Platform Features and Benefits
•Integrated Gfx (Intel® HD Graphics 3000/2000) with enhanced operating modes to enable excellent graphics
performance in power and cost sensitive embedded applications
• DirectX® 10.1 & Open GL 3.0 let you enjoy awesome graphics performance, stunning 3D visual effect and
dynamic interactivity
• Memory support, integrated low voltage DDR3 memory controller
• Operating system support:
- Microsoft
- WindRiver
- Redhat
- Novell
- Green Hills
- QNX
- LinuxWorks

MANO860 User’s Manual
BIOS Setup
9
1.1.3 Key Architecture Features
• Supports Intel LGA 1155 CPU, the 2nd Generation Intel® Core i3, i5, i7 desktop processors.
- 32nm monolithic die
- Integrated Gfx (Intel® HD Graphics 3000/2000) & memory controller
- 4 &2 Cores, up to 6MB LLC
- HW accelerated video CODECs
- Compatible with high speed DDR3-1333
- PCIe* (CPU): Gen 2.0, 5GT/s, up to 20 lanes (4 ctls)**
- TDP: 17W-45W (Low Power), 65W-95W (Scalable)
• Intel® Turbo Boost Technology
-More efficient power sharing between CPU and Graphics
• Intel® Hyper-Threading Technology
• Intel® Advanced Vector Extensions (Intel® AVX)
• Intel® AES-New Instructions
• Integrated Display Interfaces
- Dual Independent Display Support
- HDMI
- Display Port
- Analog VGA
- LVDS
• Intel® HD Graphics 3000/2000
- DirectX® 10.1
- Improved realism for DX 3D applications. Improved rendering.
- OpenGL 3.0
- Improved realism for OGL 3D based application
- UVD (Unified Video Decoder) 2.01
Hardware decode of most common HD codecs (MPEG-2, H.264/AVC MPEG-4 and VC-1)
- Supports ATI Hybrid CrossFireXTM Technology2
• Intel Quick Sync Video
- Enables faster and higher quality video editing, recording and sharing
• TPM
- Support TPM 1.2
• I/O
- PCI Express® x 16 Gen 2 5GT/s
- Mini PCI Express® x 1Gen 2 5GT/s
- CFast connector SATA II interface
- Five SATA ports (2 port of Gen 2.0 and 3 ports of Gen 3.0) support RAID 0,1, 5, 10
- Gigabit Ethernet Media Access Controller (GbE MAC)
IPv4 and IPv6 Checksum Offload

MANO860 User’s Manual
10 BIOS Setup
- High Definition Audio
- USB: Gen 2.0, up to 12 ports
- SMBus 2.0
- LPC Bus
• Supports SPI devices
- Hardware Monitor
Fan control (Voltage, Temp)
Watchdog timer
1.2 Before you Proceed
Take note of the following precautions before you install motherboard components or change any motherboard
settings.
Unplug the power cord from the wall socket before touching any component.
Use a grounded wrist strap or touch a safely grounded object or a metal object, such
as the power supply case, before handling components to avoid damaging them
due to static electricity
Hold components by the edges to avoid touching the ICs on them.
Whenever you uninstall any component, place it on a grounded anti-static pad or in
the bag that came with the component.
Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so
may cause severe damage to the motherboard, peripherals, and/or components.
1.3 Motherboard Overview
Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits
into it. Refer to the chassis documentation before installing the motherboard.
Make sure to unplug the power cord before installing or removing the motherboard.
Failure to do so can cause you physical injury and damage motherboard components.
1.3.1 Placement Direction
When installing the motherboard, make sure that you place it into the chassis in the correct orientation. The
edge with external ports goes to the rear part of the chassis as indicated in the image below.

MANO860 User’s Manual
BIOS Setup
11
1.3.2 Screw Holes
Place four (4) screws into the holes indicated by circles to secure the motherboard to the chassis.
Do not over tighten the screws! Doing so can damage the motherboard.
Place this side towards the rear of the chassis.
1.3.3 Motherboard Layout

MANO860 User’s Manual
12 BIOS Setup
1.3.4 Layout Content List
Slots & socket
Label Function Note Page
FCPGA988 FCPGA988 socket
DIMMA1 204-pin DDR3 SO-DIMM Slot A1 23
DIMMB1 204-pin DDR3 SO-DIMM Slot B1 23
PCIEX16 PCI-e x16 Slot 26
MINI-PCIE MINI PCI-e Slot 26
CFAST Cfast Slot Rear Side
Jumpers
Label Function Note Page
JCMOS1 Clear CMOS 3 x 1 header, pitch 2.54mm 27
JPSON1 AT/ATX Mode Select 3 x 1 header, pitch 2.54mm 28
JBLK1 BL controller from SIO 3 x 1 header, pitch 2.54mm
JCOMPWR3
JCOMPWR4
JCOMPWR5
COM3 COM4 COM5
RI/+5V/+12V Select
2 x 3 header, pitch 2.0 mm
Rear Panel Connector
Label Function Note Page
KBMS PS/2 Keyboard and Mouse 6-pin Mini-Din 29
COM1 COM1 Connector D-sub 9-pin, male 29
DP1 DisplayPort Connector DisplayPort
VGA1 VGA Port D-sub 15-pin, female 29
HDMI1 HDMI Port HDMI 1.3 19-pin 29
LAN1USB12 RJ-45 Ethernet Connector x 1
USB 2.0 Connector x 2
29
LAN2USB34 RJ-45 Ethernet Connector x 1
USB 2.0 Connector x 2
Audio1 Audio Line-In , Line-Out , Mic.-In 5.1 Channel Audio I/O (3 jacks) 29

MANO860 User’s Manual
BIOS Setup
13
1.3.5 Internal Connector
Internal Connector
Label Function Note Page
CPU_FAN1 CPU Fan Connector 3 x 1 wafer, pitch 2.54mm 30
SYS_FAN1 System Fan Connector 3 x 1 wafer, pitch 2.54mm 30
COM3 ~ 5 Serial Port Connector * 3 5 x 2 header, pitch 2.54mm
JGPIO GPIO Connector 5 x 2 header, pitch 2.54mm 30
F_PANEL Intel Front Panel connector 5 x 2 header, pitch 2.54mm 31
EATXPWR1 ATX power connectors 10 x 2 header 32
FPAUD1 Audio Mic.-In & Line-Out Connector 5 x 2 header, pitch 2.54mm 35
JLVDS 24-bit LVDS Connector 1 x HIROSE DF-13 /40P,1.25mm
connector
38
JLVDS_BKL2 LCD Inverter Connector 1 x 5 JST S5B-PH-K
wafer, pitch 2.00mm
38
SPI SPI Connector 4 x 2 header, pitch 2.54mm 36
SATA1 ~ 5 SATA Data Connector * 5 7P Male connector 36
USB5 ~ 12 USB Connector * 8 5 x 2 header, pitch 2.54mm 37
1.4 Central Processing Unit (CPU)
The motherboard comes with a surface mount LGA1155 socket designed for the Intel® Core™ i7/ i5/ i3
processor in the 1155-land package.

MANO860 User’s Manual
14 BIOS Setup
Your boxed Intel® Core™ i7/ i5/ i3 Mobile processor package should come with
installation instructions for the CPU, fan and heatsink assembly. If the
instructions in this section do not match the CPU documentation, follow the
latter.
Upon purchase of the motherboard, make sure that the PnP cap is on the socket
and the socket pins are not bent. Contact your retailer immediately if the PnP
cap is missing, or if you see
any damage to the PnP cap/socket
pins/motherboard components. Axiomtek will shoulder the cost of repair only if
the damage is shipment/transit-related.
Keep the cap after installing the motherboard. Axiomtek will process Return
Merchandise Authorization (RMA) requests only if the motherboard comes with
the cap on the FCPGA988 socket.
The product warranty does not cover damage to the socket pins resulting from
incorrect CPU installation/removal, or misplacement/loss/incorrect removal of
the PnP cap.
Install the CPU fan and heatsink assembly before you install motherboard to the
chassis.
If you purchased a separate CPU heatsink and fan assembly, make sure that you
have properly applied Thermal Interface Material to the CPU heatsink or CPU before
you install the heatsink and fan assembly.
1.4.1 Installing the CPU
1. Locate the CPU socket on the motherboard.

MANO860 User’s Manual
BIOS Setup
15
Before installing the CPU, make sure that the socket box is facing towards you and
the load lever is on your left.
2. Separate CPU cooler and its base first by screw drawer
3. Assemble the CPI FAN retention module
4. Position the CPU over the socket, making sure that the gold triangle is the same side as CPU Socket
triangle .

MANO860 User’s Manual
16 BIOS Setup
CPU Socket triangle Gold triangle
