AXIOMTEK MANO300 Series User manual

MANO300 Series
Intel®Braswell SoC CPU
Mini ITX Motherboard
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2016 Axiomtek Co., Ltd.
All Rights Reserved
April 2016, Version A1
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity. To prevent chipsets
from electrostatic discharge damage, please take care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel®and Celeron®are trademarks of Intel Corporation.
Windows®is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers ......................................................................................................ii
ESD Precautions............................................................................................. iii
Chapter 1 Introduction............................................. 1
1.1 Features................................................................................................1
1.2 Specifications........................................................................................2
1.3 Utilities Supported.................................................................................3
1.4 Block Diagram.......................................................................................4
Chapter 2 Board and Pin Assignments.................... 5
2.1 Board Layout.........................................................................................5
2.2 Rear I/O.................................................................................................6
2.3 Jumper Settings....................................................................................7
2.3.1 Clear CMOS Select (JP2) ........................................................................... 8
2.3.2 AT/ATX Power Mode Select (JP3) .............................................................. 8
2.3.3 LVDS Backlight PWM/CCFL Select (JP5)................................................... 9
2.3.4 LVDS VDD Select (JP4).............................................................................. 9
2.3.5 COM1 RS-232/422/485 Mode Select (JP7, JP8, JP9) ............................... 9
2.3.6 COM2 RS-232/422/485 Mode Select (JP10, JP11, JP12)........................ 10
2.3.7 COM3 Data/Power Select (JP13) ............................................................. 10
2.4 Connectors..........................................................................................11
2.4.1 Fan Connectors (CN3 and CN4)............................................................... 12
2.4.2 Internal USB 2.0 Header (CN5) ................................................................ 12
2.4.3 Internal USB 2.0 Connector (CN6)............................................................ 12
2.4.4 SATA 3.0 Connector (CN7) ....................................................................... 13
2.4.5 SD Card Slot (CN8)................................................................................... 13
2.4.6 SIM Card Slot (CN9) ................................................................................. 13
2.4.7 LVDS Signal Header (CN10)..................................................................... 14
2.4.8 LVDS Backlight Control Header (CN11).................................................... 14
2.4.9 12VDC Jack Power Input Connector (CN12)......................................... 15
2.4.10 ATX 12V Only Power Input Connector (CN13)......................................... 15
2.4.11 Front Panel Header (CN14) ...................................................................... 15
2.4.12 Power Status Header (CN15).................................................................... 16
2.4.13 DC12V/5V Power Output Connector (CN16)............................................ 16
2.4.14 PS/2 Keyboard and Mouse Connector (CN17)......................................... 16
2.4.15 GPIO Header (CN18)................................................................................ 17
2.4.16 COM Connector (CN19)............................................................................ 17
2.4.17 COM Headers (CN20~CN23) ................................................................... 18
2.4.18 LAN and USB 3.0 Connectors (CN25 and CN26) .................................... 18

v
2.4.19 PCI-Express x1 Slot (CN27) ..................................................................... 19
2.4.20 PCI-Express Mini Card Connector (CN28) ............................................... 20
2.4.21 mSATA Slot (CN29)................................................................................... 21
2.4.22 VGA Connector (CN30)............................................................................. 21
2.4.23 HDMI Connector (CN31)........................................................................... 22
2.4.24 Audio Jack (CN32).................................................................................... 22
2.4.25 Front Audio Header (CN33) ...................................................................... 22
2.4.26 ATX Power Input Connector (CN34)......................................................... 23
Chapter 3 Hardware Description ........................... 25
3.1 Microprocessors..................................................................................25
3.2 BIOS....................................................................................................25
3.3 System Memory..................................................................................25
Chapter 4 AMI BIOS Setup Utility .......................... 27
4.1 Starting................................................................................................27
4.2 Navigation Keys..................................................................................27
4.3 Main Menu ..........................................................................................29
4.4 Advanced Menu..................................................................................30
4.5 Chipset Menu......................................................................................40
4.6 Security Menu .....................................................................................43
4.7 Boot Menu...........................................................................................44
4.8 Save & Exit Menu................................................................................45
Appendix A BIOS Flash Utility ................................ 47

vi
This page is intentionally left blank.

MANO300 Mini ITX Motherboard
Introduction 1
Chapter 1
Introduction
The MANO300 is a Mini ITX board based on Intel®Celeron®N3160 processor. It delivers
outstanding system performance through high-bandwidth interfaces, multiple I/O functions for
interactive applications and various embedded computing solutions. There are two 204-pin
DDR3L SO-DIMM for DDR3L 1600/1333MHz memory with maximum capacity up to 8GB. This
Mini ITX board features two Gigabit Ethernet ports, one SATA 3.0 port with maximum transfer
rate up to 6Gb/s, four USB 3.0 and two USB 2.0 high speed compliant ports that can achieve
the best stability and reliability for industrial applications.
1.1 Features
Intel®Celeron®N3160 processor
2 DDR3L 1600/1333MHz memory with maximum capacity up to 8GB
1 PCI-Express x1
1 PCI-Express Mini Card
1 SATA-600
1 mSATA
4 USB 3.0 and 2 USB 2.0 ports
Triple view display
Display: VGA/HDMI/LVDS

MANO300 Mini ITX Motherboard
2 Introduction
1.2 Specifications
CPU
Intel®Celeron®quad core N3160 (up to 2.08GHz).
BIOS
AMI BIOS.
System Memory
Two 204-pin SO-DIMM sockets. The upper socket must be installed.
Maximum up to 8GB DDR3L memory.
Support 1600/1333MHz memory.
Note
If only one memory module is used, please install in DIMM1 (the upper SO-DIMM
socket).
Onboard Multi I/O
Controller: ITE8786.
One PS/2 keyboard and mouse on the rear I/O.
Six serial ports:
- COM1~COM2 support RS-232/422/485; COM3~COM6 support RS-232 only.
- COM1~COM2 on the rear I/O; COM3~COM6 in box headers.
USB Interface
Four USB 3.0 ports (on the rear I/O).
Two USB 2.0 ports (internal).
Ethernet
Two Realtek GbE LAN ports.
Support 1000/100/10Mbps Gigabit/Fast Ethernet.
Serial ATA
One SATA 3.0 port (6Gb/s).
One mSATA slot; only support mSATA.
Audio
Realtek ALC662 5.1 channel HDA codec.
Support line-out/MIC-in.
Display
One 15-pin D-Sub as VGA connector. Resolution max. up to 1920x1200.
One HDMI with resolution max. up to (3840x2160)@ 30Hz or 2560x1600 @ 60Hz.
One 24-bit dual channel LVDS and one 8-pin inverter connector. LVDS resolution is
max. up to 1920x1200.
Expansion Interface
One PCI-Express x1 slot.
One PCI-Express Mini Card; support WiFi USB signal.
One SIM card slot.
SSD
One SD card slot.

MANO300 Mini ITX Motherboard
Introduction 3
Power Input
One ATX power input connector.
One 12V only ATX power input connector.
One 12VDC jack power input connector.
Note
Please plug only one of the three power input interfaces when power on.
Operating Temperature
0~60°C.
Storage Temperature
-20~60°C.
Form Factor
Mini ITX (6.7”x 6.7”, 17.0cm x 17.0cm).
Note
All specifications and images are subject to change without notice.
1.3 Utilities Supported
Chipset driver
Ethernet driver
Graphics driver
Audio driver

MANO300 Mini ITX Motherboard
4 Introduction
1.4 Block Diagram

MANO300 Mini ITX Motherboard
Board and Pin Assignments 5
Chapter 2
Board and Pin Assignments
2.1 Board Layout

MANO300 Mini ITX Motherboard
6 Board and Pin Assignments
2.2 Rear I/O
1
Front Audio Header (CN33)
22
SATA 3.0 Connector (CN7)
2
LVDS Signal Header (CN10)
23
SD Card Slot (CN8)
3
LVDS Backlight Control Header (CN11)
24
DDR3L SO-DIMM Sockets (CN24)
4
LVDS VDD Select Jumper (JP4)
25
ATX Power Input Connector (CN34)
5
LVDS Backlight PWM/CCFL Select
Jumper (JP5)
26
ATX 12V Only Power Input Connector (CN13)
6
COM3 Data/Power Select Jumper
(JP13)
27
SIM Card Slot (CN9)
7
COM3~COM6 Headers (CN20~CN23)
28
12VDC Jack Power Input Connector (CN12)
8
Power Status Header (CN15)
29
PS/2 Keyboard and Mouse Connector (CN17)
9
DC12V/5V Power Output Connector
(CN16)
30
COM1 Connector (CN19)
10
GPIO Header (CN18)
31
COM2 Connector (CN19)
11
Front Panel Header (CN14)
32
VGA Connector (CN30)
12
System Fan Connector (CN4)
33
HDMI Connector (CN31)
13
Internal USB 2.0 Connector (CN6)
34
LAN1 Connector (CN25)
14
AT/ATX Power Mode Select Jumper
(JP3)
35
LAN2 Connector (CN26)
15
Internal USB 2.0 Header (CN5)
36
USB 3.0 port 1 (CN25,CN26)
16
CPU Fan Connector (CN3)
37
USB 3.0 port 2 (CN25,CN26)
17
COM1/COM2 RS-232/422/485 Mode
Select Jumpers (JP7~JP12)
38
USB 3.0 port 3 (CN25,CN26)
18
Debug Header (CN2)
39
USB 3.0 port 4 (CN25,CN26)
19
PCI-Express Mini Card Connector
(CN28)
40
Audio Jack (CN32)
20
PCI-Express x1 Slot (CN27)
41
CMOS Clear Jumper (JP2)
21
mSATA Slot (CN29)

MANO300 Mini ITX Motherboard
Board and Pin Assignments 7
Note
To identify the first pin of a header or jumper, please refer to the following
information:
Usually, there is a thick line or a triangle near the header or jumper pin 1.
Square pad, which you can find on the back of the motherboard, is usually
used for pin 1.
2.3 Jumper Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. The following
illustration shows how to set up jumper.
Before applying power to MANO300 Series, please make sure all of the jumpers are in factory
default position. Below you can find a summary table of all jumpers and onboard default
settings.
Note
Once the default jumper setting needs to be changed, please do it under power-off
condition.

MANO300 Mini ITX Motherboard
8 Board and Pin Assignments
Jumper
Description
Setting
JP2
Clear CMOS
Default: Normal
1-2 Close
JP3
AT/ATX Power Mode Select
Default: ATX Mode
1-2 Close
JP5
LVDS Backlight PWM/CCFL Select
Default: PWM
1-2 Close
JP4
LVDS VDD Select
Default: +3.3V
1-2 Close
JP7
COM1 RS-232/422/485 Mode Select
Default: RS-232
1-2 Close
JP8
3-5, 4-6 Close
JP9
3-5, 4-6 Close
JP10
COM2 RS-232/422/485 Mode Select
Default: RS-232
1-2 Close
JP11
3-5, 4-6 Close
JP12
3-5, 4-6 Close
JP13
COM3 Data/Power Select
Default: RS-232 Data
COM3 Pin 1: DCD#
7-9 Close
COM3 Pin 8: RI#
8-10 Close
2.3.1 Clear CMOS Select (JP2)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can
clear the CMOS memory of date, time, and system setup parameters by erasing the
CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS,
which includes system setup information such as system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Remove the onboard battery.
3. Move the jumper clip from pins 1-2 (default) to pins 2-3. Keep the clip on pins 2-3
for about 5~10 seconds, then move the clip back to pins 1-2.
4. Re-install the battery.
5. Plug the power cord and turn ON the computer.
6. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter
data.
2.3.2 AT/ATX Power Mode Select (JP3)
This 3x1-pin p=2.54mm jumper allows you to select AT or ATX power mode.
Function
Setting
Normal operation (Default)
1-2 close
Clear CMOS
2-3 close
Function
Setting
ATX mode (Default)
1-2 close
AT mode
2-3 close

MANO300 Mini ITX Motherboard
Board and Pin Assignments 9
2.3.3 LVDS Backlight PWM/CCFL Select (JP5)
This 3x1-pin p=2.54mm jumper enables you to select PWM or voltage control mode for
LVDS backlight control header (CN11). These two control modes are for adjusting the
brightness of LVDS panel.
2.3.4 LVDS VDD Select (JP4)
This motherboard supports voltage selection for flat panel displays. Use this 3x2-pin
p=2.54mm jumper to set up VDD power of the LVDS connector. To prevent hardware
damage, before connecting please make sure that the input voltage of LVDS panel is
correct.
2.3.5 COM1 RS-232/422/485 Mode Select (JP7, JP8, JP9)
Use these jumpers (3x2-pin p=2.54mm) to set COM1 port to operate as RS-232, RS-422
or RS-485 communication mode.
JP7 JP8 JP9
Function
Setting
Controlled by PWM (Default)
1-2 close
Controlled by DC Voltage
2-3 close
Function
Setting
+3.3V (Default)
1-2 close
+5V
3-4 close
+12V
5-6 close
Function
Setting
RS-232 mode
(Default)
JP7 1-2 close
JP8 3-5, 4-6 close
JP9 3-5, 4-6 close
RS-422 mode
JP7 3-4 close
JP8 1-3, 2-4 close
JP9 1-3, 2-4 close
RS-485 mode
JP7 5-6 close
JP8 1-3, 2-4 close

MANO300 Mini ITX Motherboard
10 Board and Pin Assignments
2.3.6 COM2 RS-232/422/485 Mode Select (JP10, JP11, JP12)
Use these jumpers (3x2-pin p=2.54mm) to set COM2 port to operate as RS-232, RS-422
or RS-485 communication mode.
JP10 JP11 JP12
2.3.7 COM3 Data/Power Select (JP13)
The COM3 port has +5V/+12V power capability on DCD and +5V/+12V on RI by setting
this jumper (5x2-pin p=2.54mm).
Function
Setting
RS-232 mode
(Default)
JP10 1-2 close
JP11 3-5, 4-6 close
JP12 3-5, 4-6 close
RS-422 mode
JP10 3-4 close
JP11 1-3, 2-4 close
JP12 1-3, 2-4 close
RS-485 mode
JP11 5-6 close
JP12 1-3, 2-4 close
Function
Setting
Power: Set COM3 pin 1 to +12V level
1-3 close
Power: Set COM3 pin 1 to +5V level
3-5 close
Data: Set COM3 pin 1 to DCD# (Default)
7-9 close
Power: Set COM3 pin 8 to +12V level
2-4 close
Power: Set COM3 pin 8 to +5V level
4-6 close
Data: Set COM3 pin 8 to RI# (Default)
9-10 close

MANO300 Mini ITX Motherboard
Board and Pin Assignments 11
2.4 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table showing connectors on the hardware.
Connector
Description
CN3
CPU Fan Connector
CN4
System Fan Connector
CN5
Internal USB 2.0 Header
CN6
Internal USB 2.0 Connector
CN7
SATA 3.0 Connector
CN8
SD Card Slot
CN9
SIM Card Slot
CN10
LVDS Signal Header
CN11
LVDS Backlight Control Header
CN12
12VDC Jack Power Input Connector
CN13
ATX 12V Only Power Input Connector
CN14
Front Panel Header
CN15
Power Status Header
CN16
DC12V/5V Power Output Connector
CN17
PS/2 Keyboard and Mouse Connector
CN18
GPIO Header
CN19
COM1~COM2 Connector
CN20~CN23
COM3~COM6 Headers
CN24
DDR3L SO-DIMM Sockets
CN25, CN26
LAN and USB 3.0 Connectors
CN27
PCI-Express x1 Slot
CN28
PCI-Express Mini Card Connector
CN29
mSATA Slot
CN30
VGA Connector
CN31
HDMI Connector
CN32
Audio Jack
CN33
Front Audio Header
CN34
ATX Power Input Connector

MANO300 Mini ITX Motherboard
12 Board and Pin Assignments
2.4.1 Fan Connectors (CN3 and CN4)
This motherboard has two fan connectors. You can find fan speed option(s) at BIOS
Setup Utility. For further information, see BIOS Setup Utility: Advanced\HW Monitor\PC
Health Status.
The CN3 (4x1-pin p=2.54mm) is for CPU fan interface.
The CN4 (3x1-pin p=2.54mm) is for system fan interface.
2.4.2 Internal USB 2.0 Header (CN5)
This is a USB 2.0 header (5x2-pin p=2.54mm).
2.4.3 Internal USB 2.0 Connector (CN6)
This is an internal USB 2.0 connector (4x1-pin p=2.00mm).
Pin
Signal
1
GND
2
+12V
3
FAN Speed Detection
4
FAN Speed Control
Pin
Signal
1
GND
2
+12V
3
FAN Speed Detection
Pin
Signal
Pin
Signal
1
+5V
2
+5V
3
USB1-
4
USB2-
5
USB1+
6
USB2+
7
GND
8
GND
9
N/C
10
N/C
Pin
Signal
1
+5V
2
USB D-
3
USB D+
4
GND

MANO300 Mini ITX Motherboard
Board and Pin Assignments 13
2.4.4 SATA 3.0 Connector (CN7)
This Serial Advanced Technology Attachment (Serial ATA or SATA) connector is for
SATA 3.0 interface allowing up to 6.0Gb/s data transfer rate. It is a computer bus
interface for connecting to devices such as hard disk drive.
2.4.5 SD Card Slot (CN8)
The CN8 is for inserting SD card.
1 11
2.4.6 SIM Card Slot (CN9)
The CN9 is for inserting SIM Card. It is mainly used in 3G wireless network application.
In order to work properly, the SIM Card must be used together with 3G module which is
inserted to CN28.
Pin
Signal
1
GND
2
SATA_TX+
3
SATA_TX-
4
GND
5
SATA_RX-
6
SATA_RX+
7
GND
Pin
Signal
Pin
Signal
1
WP
7
GND
2
DATE 1
8
CD
3
DATE 0
9
CMD
4
GND
10
DATE 3
5
CLK
11
DATE 2
6
VCC
Pin
Signal
1
PWR
2
RST
3
CLK
4
NC
5
GND
6
VPP
7
I/O
8
NC

MANO300 Mini ITX Motherboard
14 Board and Pin Assignments
2.4.7 LVDS Signal Header (CN10)
This motherboard has a 20x2-pin p=1.00mm header for LVDS panel interface.
Note
[*]: Panel power VDD is +3.3V by default, +5V or 12V is selectable by
jumper JP4, see section 2.3.4.
[**]: Grounding of this pin is required to ensure normal LVDS output.
2.4.8 LVDS Backlight Control Header (CN11)
This is an 8x1-pin p=1.25mm header for LVDS backlight control interface.
Note
[*]: This signal is selectable by jumper JP3, see section 2.3.2.
Pin
Signal
Pin
Signal
1
VDD[*]
2
VDD[*]
3
VDD[*]
4
VDD[*]
5
VDD[*]
6
VDD[*]
7
N/C
8
N/C
9
GND(Detect)[**]
10
GND
11
LVDS_B_DATA3-
12
LVDS_B_DATA0-
13
LVDS_B_DATA3+
14
LVDS_B_DATA0+
15
GND
16
GND
17
LVDS_B_CLK-
18
LVDS_B_DATA1-
19
LVDS_B_ CLK +
20
LVDS_B_DATA1+
21
GND
22
GND
23
LVDS_A_DATA0-
24
LVDS_B_DATA2-
25
LVDS_A_DATA0+
26
LVDS_B_DATA2+
27
GND
28
GND
29
LVDS_A_DATA1-
30
LVDS_A_DATA3-
31
LVDS_A_DATA1+
32
LVDS_A_DATA3+
33
LVDS_PRSNT#
34
GND
35
LVDS_A_DATA2-
36
LVDS_A_CLK-
37
LVDS_A_DATA2+
38
LVDS_A_ CLK +
39
GND(Detect)[**]
40
GND
Pin
Signal
1
+12V
2
+12V
3
+5V
4
LVDS_BKL_EN
5
GND
6
GND
7
GND
8
LVDS_BKL_CTL[*]
