AXIOMTEK PICO316 User manual

PICO316
Intel®Pentium®N4200/ Celeron®
N3350 Processor Pico-ITX Board
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2018 Axiomtek Co., Ltd.
All Rights Reserved
January 2018, Version A1
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity. To prevent chipsets
from electrostatic discharge damage, please take care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel®and Celeron®are trademarks of Intel Corporation.
Windows®is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers.....................................................................................................ii
ESD Precautions...........................................................................................iii
Chapter 1 Introduction............................................. 1
1.1 Features...............................................................................................2
1.2 Specifications......................................................................................2
1.3 Utilities.................................................................................................3
Chapter 2 Board and Pin Assignments.................... 5
2.1 Board Dimensions and Fixing Holes.................................................5
2.2 Board Layout.......................................................................................7
2.3 Assembly Drawing..............................................................................9
2.3.1 Installing Heatsink (Optional) ...................................................................... 9
2.3.2 Installing Heatspreader (Optional) ............................................................ 10
2.4 Jumper and Switch Settings ............................................................11
2.4.1 LVDS +3.3V/+5V Voltage Selection (JP2)................................................. 12
2.4.2 Restore BIOS Optimal Defaults (JP2)....................................................... 12
2.4.3 Auto Power On (SW1)............................................................................... 12
2.5 Connectors........................................................................................13
2.5.1 Inverter Connector (CN2).......................................................................... 14
2.5.2 Front Panel Connector (CN3) ................................................................... 14
2.5.3 Power Connector (CN4)............................................................................ 15
2.5.4 SMBus Connector (CN5) .......................................................................... 15
2.5.5 LVDS Connector (CN6)............................................................................. 16
2.5.6 USB 3.0 Type C Connectors (CN7 and CN8)........................................... 18
2.5.7 SATAPower Connector (CN9).................................................................. 18
2.5.8 USB 2.0 Wafer Connector (CN10)............................................................ 19
2.5.9 Ethernet Port (CN11)................................................................................. 19
2.5.10 Audio Jack (CN12).................................................................................... 19
2.5.11 HDMI Connector (CN13)........................................................................... 20
2.5.12 USB 3.0 Type A Connector (CN14)........................................................... 20
2.5.13 CMOS Battery Connector (BAT1) ............................................................. 20
2.5.14 SATA Connector (SATA1).......................................................................... 21
2.5.15 COM Connectors (SCN1 and SCN2)........................................................ 21
2.5.16 Full-size PCI-Express Mini Card or mSATAConnector (SCN3) ............... 22
Chapter 3 Hardware Description ........................... 23
3.1 Microprocessors ...............................................................................23

v
3.2 BIOS ...................................................................................................23
3.3 System Memory.................................................................................23
3.4 I/O Port Address Map........................................................................24
3.5 Interrupt Controller (IRQ) Map .........................................................25
3.6 Memory Map ......................................................................................28
Chapter 4 AMI BIOS Setup Utility .......................... 29
4.1 Starting...............................................................................................29
4.2 Navigation Keys ................................................................................29
4.3 Main Menu..........................................................................................31
4.4 Advanced Menu.................................................................................32
4.5 Chipset Menu.....................................................................................41
4.6 Security Menu....................................................................................45
4.7 Boot Menu..........................................................................................46
4.8 Save & Exit Menu ..............................................................................50
Appendix A Watchdog Timer................................... 53
A.1 About Watchdog Timer.....................................................................53
A.2 How to Use Watchdog Timer............................................................53
Appendix B BIOS Flash Utility ................................ 55

vi
This page is intentionally left blank.

PICO316 Pico-ITX Board
Introduction 1
Chapter 1
Introduction
The PICO316 is a Pico-ITX board with Intel®Pentium®N4200/ Celeron®N3350 processor that
delivers outstanding system performance through high-bandwidth interfaces, multiple I/O
functions for interactive applications and various embedded computing solutions.
The board has one 204-pin unbuffered SO-DIMM socket for single channel DDR3L 1600MHz
memory with maximum memory capacity up to 8GB. There is one Gigabit/Fast Ethernet port,
one SATA port with transfer rate up to 6Gb/s, three USB 3.0 and two USB 2.0 high speed
compliant, and built-in HD audio codec that can achieve the best stability and reliability for
industrial applications. Additionally, it provides you with unique embedded features, such as
two serial ports (RS-232) and 2.5”form factor that applies an extensive array of PC
peripherals.

PICO316 Pico-ITX Board
2 Introduction
1.1 Features
Intel®Pentium®quad core N4200 (1.1~2.5GHz) and Celeron®dual core N3350
(1.1~2.4GHz)
1 DDR3L SO-DIMM supports up to 8GB memory capacity
3 USB 3.0 ports and 2 USB 2.0 ports
2 COM ports
1 PCI-Express Mini Card with mSATA supported
+5V only DC-in adapter supported
1.2 Specifications
CPU
Intel®Pentium®quad core N4200 1.1~2.5GHz.
Intel®Celeron®dual core N3350 1.1~2.4GHz.
Thermal Solution
Passive.
Operating Temperature
-20°C~+60°C.
-20°C~+70°C (Optional).
BIOS
American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS.
64Mbit SPI Flash, DMI, Plug and Play.
PXE Ethernet Boot ROM.
System Memory
One 204-pin unbuffered DDR3L SO-DIMM socket.
Maximum up to 8GB DDR3L 1600MHz memory.
Onboard Multi I/O
Controller: ITE8528.
Serial Ports: Two RS-232 ports.
Serial ATA
One SATA-600 connector.
mSATA supported.
USB Interface
One USB 3.0 port in type A on the rear I/O.
Two USB 3.0 ports in type C.
Two USB 2.0 ports in 2x5-pin internal wafer connector.
Display
One 2x20-pin connector for 18/24-bit single/dual channel LVDS and one 8-pin
inverter connector. LVDS resolution is up to 1920x1200 in 24-bit dual channels.
One HDMI on the rear I/O with resolution up to 3840x2160 @30Hz.
Watchdog Timer
Timeout value range is 1~65535 seconds.

PICO316 Pico-ITX Board
Introduction 3
Ethernet
One RJ-45 LAN port by Intel®i211AT supports 1000/100/10Mbps Gigabit/Fast
Ethernet with Wake-on-LAN and PXE Boot ROM.
Audio
HD audio compliant with Realtek ALC662.
Line-out in 3.5 phone jack on the rear I/O.
Expansion Interface
One full-size PCI-Express Mini Card socket with PCI-Express and USB support and
complies with PCI-Express Mini Card Spec. V1.2.
Power Input
One 2x2-pin connector.
+5V DC-in adapter only.
Auto power on function supported.
Power Management
ACPI (Advanced Configuration and Power Interface).
Form Factor
Pico-ITX form factor.
Note
All specifications and images are subject to change without notice.
1.3 Utilities
Chipset and graphics driver
Ethernet driver
Audio driver
Trusted Execution Engine

PICO316 Pico-ITX Board
4 Introduction
This page is intentionally left blank.

PICO316 Pico-ITX Board
Board and Pin Assignments 5
Chapter 2
Board and Pin Assignments
2.1 Board Dimensions and Fixing Holes
Top View

PICO316 Pico-ITX Board
6 Board and Pin Assignments
Bottom View
Side View

PICO316 Pico-ITX Board
Board and Pin Assignments 7
2.2 Board Layout
Top View
Side View

PICO316 Pico-ITX Board
8 Board and Pin Assignments
Bottom View

PICO316 Pico-ITX Board
Board and Pin Assignments 9
2.3 Assembly Drawing
2.3.1 Installing Heatsink (Optional)
For thermal dissipation, a thermal solution enables the PICO316’s components to
dissipate heat efficiently. All heat generating components are thermally conducted to the
plate in order to avoid hot spots. Images below illustrate how to install heatsink on
PICO316.

PICO316 Pico-ITX Board
10 Board and Pin Assignments
2.3.2 Installing Heatspreader (Optional)
The heatspreader acts as a thermal coupling device that all heat generating components
are thermally conducted to the heatspreader in order to avoid hot spots. Heat dissipation
devices such as a heatsink with fan or without fan may need to be connected to the
heatspreader. Images below illustrate how to install the heatspreader on PICO316. And
there is a protective plastic covering on the thermal pads. This must be removed before
the heatspreader can be mounted.

PICO316 Pico-ITX Board
Board and Pin Assignments 11
2.4 Jumper and Switch Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. Below illustration
shows how to set up jumper.
Properly configure jumper and switch settings on the PICO316 to meet your application
purpose. Below you can find a summary table of jumpers, switch and onboard default settings.
Note
Once the default jumper or switch setting needs to be changed, please do it under
power-off condition.
Jumper and Switch
Description
Setting
JP2
LVDS +3.3V/+5V Voltage Selection
Default: +3.3V
1-3 Close
Restore BIOS Optimal Defaults
Default: Normal Operation
4-6 Close
SW1
Auto Power On
Default: Enable
2-3 Close

PICO316 Pico-ITX Board
12 Board and Pin Assignments
JP2
JP2
2.4.1 LVDS +3.3V/+5V Voltage Selection (JP2)
This is a 2x3-pin (pitch=2.0mm) jumper. The board supports voltage selection for flat
panel displays. Use these jumpers to set LVDS connector (CN6) pin 1~6 VCCM to +3.3V,
or +5V. To prevent hardware damage, before connecting please make sure that the input
voltage of flat panel is correct.
2.4.2 Restore BIOS Optimal Defaults (JP2)
This is a 2x3-pin (pitch=2.0mm) jumper. Put jumper clip to pin 2-4 for a few seconds then
move it back to pin 4-6. Doing this procedure can restore BIOS optimal defaults.
2.4.3 Auto Power On (SW1)
If SW1 is enabled for power input, the system will be automatically power on without
pressing soft power button. If SW1 is disabled for power input, it is necessary to
manually press soft power button to power on the system.
Function
JP2 Setting
+3.3V level (Default)
1-3 close
+5V level
3-5 close
Function
JP2 Setting
Normal (Default)
4-6 close
Restore BIOS optimal defaults
2-4 close
Function
Setting
Disable auto power on
1-2 close
Enable auto power on (Default)
2-3 close

PICO316 Pico-ITX Board
Board and Pin Assignments 13
2.5 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
Description
CN2
Inverter Connector
CN3
Front Panel Connector
CN4
Power Connector
CN5
SMBus Connector
CN6
LVDS Connector
CN7~CN8
USB 3.0 Type C Connectors
CN9
SATA Power Connector (+5V Only)
CN10
USB 2.0 Wafer Connector
CN11
Ethernet Port
CN12
Audio Line-out Jack
CN13
HDMI Connector
CN14
USB 3.0 Type A Connector
BAT1
CMOS Battery Connector
SATA1
SATA Connector
SCN1~SCN2
COM1 and COM2 Connectors
SCN3
Full-size PCI-Express Mini Card or mSATA Connector
SDIMM1
DDR3L SO-DIMM Connector

PICO316 Pico-ITX Board
14 Board and Pin Assignments
2.5.1 Inverter Connector (CN2)
This is a 8-pin (pitch=1.25mm) connector which is compliant with Hirose DF13-8P-1.25V
for inverter. We strongly recommend you to use the matching connector,
DF13-8S-1.25C, to avoid malfunction.
1 8
2.5.2 Front Panel Connector (CN3)
Power Status
Pin 1 and pin 2 are for power status button; letting user know the power status of this
board.
Power LED
Pin 4 connects anode (+) of LED and pin 3 connects cathode(-) of LED. The power LED
lights up when the system is powered on.
Power On/Off Button
Pin 5 and 6 connect the power button on front panel to CPU board, which allows users to
turn on or off power supply.
System Reset Switch
Pin 7 and 8 connect the case-mounted reset switch that reboots your computer without
turning off the power switch. It is a better way to reboot your system for a longer life of
system power supply.
HDD Activity LED
This connection is linked to hard drive activity LED on the control panel. LED flashes
when HDD is being accessed. Pin 9 and 10 connect the hard disk drive to the front panel
HDD LED, pin 9 is assigned as cathode(-) and pin 10 is assigned as anode(+).
Pin
Signal
1
NC
2
NC
3
VBL2 (+5V level)
4
VBL_ENABLE
5
GND
6
GND
7
GND
8
VBL Brightness Control
Pin
Signal
Pin
Signal
1
PWR-
2
PWR+
3
PWRLED-
4
PWRLED+
5
PWRSW-
6
PWRSW+
7
HW RST-
8
HW RST+
9
HDDLED-
10
HDDLED+
