Axis ADAYO HM4Z05A User manual

1

2
2
Safety Precautions
Thank you for purchasing this product. Please
read through these operating instructions
so you will know how to operate your model
properly. After you’ve finished reading the
instructions, keep this manual in a safe place for
future reference.
Please don't change the fuse on the power cord
without professional guidance, using improper
fuse may cause damage to this unit or even
cause fire.
Only connect the unit to a 12-volt power supply with
negative grounding.
Never install this unit where the operation &
condition for safe driving is impaired.
Please contact your nearest dealer if one of the
following symptoms is experienced:
(a). Water or other objects enters the unit.
(b). There is smoke.
(c). Peculiar smell.
Never use the video display function in the front
when driving to prevent the violation of laws &
regulations and also to reduce the risk of traffic
accident except for using rear view camera.
Never expose this unit, amplifier, and speakers
to moisture or water to prevent electric sparks
or fire.
To ensure safe driving, please adjust the
volume to a safe and comfortable level in
case of emergency situations.

3
3
D
Safety Precautions
1. Never disassemble or adjust the unit without any professional guidance.
For details, please consult any professional car shop / dealer for inquiry.
2. If the front panel or TFT monitor is dirty, please use a clean silicone cloth and neutral detergent
to wipe off the spot. Using a rough cloth and non-neutral detergent such as alcohol for
cleaning may result in scratching or discoloration to the monitor.
3. If any abnormal behavior of the unit is found, please refer to trouble shooting guide of this
manual. If no relevant information is found, please press [Reset] with a ball-point pen or similar
tool to resume factory default.
4. If you have parked the car in hot or cold weather for a long time, please wait until the
temperature in the car becomes normal before operating the unit.
5. Do not impact the LCD monitor which could cause damage.
6. To prevent damage to the screen, avoid touching it with sharp objects.
7. To provide a clear demonstration and an alternative for easy understanding to the operation
of this unit, graphic illustrations are used.
However, some illustrations are different from the actual images displayed on the screen.
8. Operate the unit correctly according to this manual to prevent unnecessary problem. The
guarantee won't be valid if the problem is caused by inappropriate operation.

4
4
Contents
Controls - Device...................................................... 5
Placing the device in operation..............................6
Switching on/off ............................................................... 6
Volume ................................................................................ 6
Main menu (Home) .......................................................... 6
Setting the reception area ............................................. 6
Radio mode ..............................................................7
Start radio mode ............................................................... 7
Select memory bank ....................................................... 7
Tuning into a station ....................................................... 7
Storing stations manually .............................................. 7
Search Stations Automatically ..................................... 7
Tune to a Preset Station ................................................. 7
Adjusting the seek tuning sensitivity ......................... 7
USB playback ........................................................... 8
Basic information ............................................................. 8
USB data carrier................................................................. 8
Audio playback from USB .............................................. 8
Video playback from USB .............................................. 9
Image playback from USB ............................................. 9
Bluetooth mode.....................................................10
Starting Bluetooth mode ............................................. 10
Registering Bluetooth devices ................................... 10
Telephone mode ............................................................ 10
Making a call .................................................................... 10
Receiving a call ................................................................ 11
Alphabetic search .......................................................... 11
Audio playback via Bluetooth streaming ............... 11
Bluetooth settings ......................................................... 11
Apple CarPlay.........................................................12
How to enter CarPlay mode ........................................ 12
How to use CarPlay ........................................................ 12
Android Auto .........................................................12
Play with Android Auto ................................................ 12
Map ..................................................................................... 12
Call Out / Receive Call ................................................... 12
Back to Android Auto .................................................... 12
Play Music ......................................................................... 12
Talk with Google ............................................................. 12
Back to unit menu .......................................................... 12
External audio/video sources...............................13
Rear Camera input.................................................13
Sound settings.......................................................13
Volume distribution (fader/balance) ....................... 13
Equalizer ........................................................................... 13
Basic settings .........................................................14
General .............................................................................. 14
Video .................................................................................. 14
Volume .............................................................................. 14
Time .................................................................................... 14
System ............................................................................... 14
Connection diagram .............................................15
Trouble Shooting ..................................................16
General Specifications ..........................................17
Warranty ................................................................18
5
D
Controls - Device
Controls – Device
1.
Activate Siri/Google voice control
2.
Short press: Switch on device
In operation: Mute audio source
Long press: Switch off device
3.
Return to home page at any point
4.
Show the volume bar
5. Touchscreen user interface
6. Reset Key
7. USB socket - Front
Connect a USB device for playback of music/video/picture files.
1
2
3
4
5
6
7

5
5
D
Controls - Device
Controls – Device
1.
Activate Siri/Google voice control
2.
Short press: Switch on device
In operation: Mute audio source
Long press: Switch off device
3.
Return to home page at any point
4.
Show the volume bar
5. Touchscreen user interface
6. Reset Key
7. USB socket - Front
Connect a USB device for playback of music/video/picture files.
1
2
3
4
5
6
7
5
D
Controls - Device
Controls – Device
1.
Activate Siri/Google voice control
2.
Short press: Switch on device
In operation: Mute audio source
Long press: Switch off device
3.
Return to home page at any point
4.
Show the volume bar
5. Touchscreen user interface
6. Reset Key
7. USB socket - Front
Connect a USB device for playback of music/video/picture files.
1
2
3
4
5
6
7
5
D
Controls - Device
Controls – Device
1.
Activate Siri/Google voice control
2.
Short press: Switch on device
In operation: Mute audio source
Long press: Switch off device
3.
Return to home page at any point
4.
Show the volume bar
5.
Touchscreen user interface
6.
Reset Key
7.
USB socket - Front
Connect a USB device for playback of music/video/picture files.
1
2
3
4
5
6
7
5
D
Controls - Device
Controls – Device
1.
Activate Siri/Google voice control
2.
Short press: Switch on device
In operation: Mute audio source
Long press: Switch off device
3.
Return to home page at any point
4.
Show the volume bar
5.
Touchscreen user interface
6.
Reset Key
7.
USB socket - Front
Connect a USB device for playback of music/video/picture files.
1
2
3
4
5
6
7

6
6
Startup
Placing the device in operation
Switching on/off
Switching on/off with the rotary/pushbutton
For switch-on, press the button.
For switch-off, hold the button pressed for more
than 2 seconds.
Switching on/off via vehicle ignition
If the car sound system is connected with the vehicle
ignition and it was switched off with the button, it is
switched on or off with the ignition.
Volume
Adjusting the volume
You can adjust the volume in steps from 0 (off) to 39
(maximum).
Press the button and touch the volume bar on the
screen to change the volume.
Muting the car sound system (Mute)
Briefly press the button to mute the device or to
reactivate the previous volume.
Main menu ( Home )
In the main menu, you press the buttons on the
touchscreen to call up the different sources and
operating modes.
Press the button to display the main menu.
Note:
The icons used in these instructions are intended to
facilitate the explanations and details may deviate
from your device.
Setting the reception area
You can set a different reception areas.
In the main menu, press the Settings icon .
In the left area of the Settings menu, press the
General icon.
The current setting is displayed behind "Radio region".
Tap on the Radio region icon to display the list of
available reception areas.
Select the desired reception area by clicking.
The list is then hidden and the selected reception
area is set.
The main menu is displayed again.

7
7
Radio mode
Storing stations manually
Radio mode
Start radio mode
In the main menu, press the Radio icon.
The radio playback menu is displayed.
Select memory bank
Different memory banks and wavebands are available.
Up to 30 stations can be stored.
Press the icon to switch to FM or AM band.
Tuning into a station
Tuning into stations manually
Briefly press the or icon once or to
change the frequency in increments.
Enter broadcast frequency directly
If the frequency of the desired stations is known, it can
be entered directly via the touchscreen.
Press the button.
A numeric keypad is displayed for the frequency
input.
Enter the frequency of the desired station with the
numeric keypad.
Press the ok icon.
The radio playback menu is displayed, the station of
the frequency entered is played back.
Starting station seek tuning
Press the or button for approx. 2
seconds to start station seek tuning.
The radio tunes into the next receivable station.
Select the desired memory bank with the icon.
Set the desired station.
Press one of the memory buttons P1 - P6 for
approx. 2 seconds to store the current station at the
button.
The station is stored.
- Or -
Touch .
Press one of the memory buttons P1 - P6 to save
the selected station.
Search Stations Automatically
Touch to search stations and store strongest stations
in current band automatically.
Tune to a Preset Station
Touch .
Touch one of the preset channels on the screen.
Adjusting the seek tuning sensitivity
The seek tuning sensitivity decides whether the
auto
matic station seek tuning finds only strong
stations or also weaker stations that may be noisy.
If LoC is displayed, only stations with a strong signal
are found during seek tuning.
Note:
For the reception area Europe: In the FM waveband,
only traffic information stations are tuned into if the
priority for traffic information is switched on.

8
8
USB playback
USB playback
Basic information
The car sound system can be used to play media files on
USB data carriers.
In addition, you can view movies and images from USB
data carriers on the display or a connected monitor.
For safety reasons, the playback of movies and images
on the integrated monitor is allowed only while the
vehicle is standing and the hand brake is applied. The
"PARKING" cable must be connected with the hand brake
connection of the vehicle (see Connection diagram at
the end of these instructions). The movie playback on an
external monitor is also possible while driving.
Note:
•We cannot guarantee the flawless function of
USB
data due to so many formats.
USB data carrier
This device features 2 x USB ports (front and rear).
Connecting a USB data carrier
Insert the USB data carrier in the USB socket.
The device automatically switches to USB mode. The
data is read, then playback starts with the first media
file recognized by the device.
Removing a USB data carrier
Turn off the unit before ejecting the USB device.
Audio playback from USB
The principles of the audio playback (MP3/WMA) from
data carriers are identical for all sources.
Select USB via the main menu.
The
unit automatically starts playback.
If the playback does not start,
press the icon to change folder/file list.
Press the icon to display all the audio files. data
carrier.
Briefly tap on the name of the folder/track. The folder
is opened and the track is started.
After starting a title, the playback menu is displayed.
Short press: Title selection.
Fast press: Fast searching.
/
Pause/Play.
Short press: Title selection.
Long press: Fast searching.
Display the folder/file list.
Show additional operating options.
Tap on to display additional operating
options of the playback menu.
Hide additional operating options.
Select REPEAT mode.
The REPEAT mode changes each time the
ic on is pressed.
REPEAT mode
Repeat current track
Repeat current folder
Repeat all tracks of data carrier
Start MIX random track play and end it
again.
If the MIX function is switched on, the
symbol is displayed in white.
The MIX mode depends on the selected
REPEAT function.
Display equalizer.

9
9
Video
playback from USB
Select the USB via the menu.
Image playback from USB
Select the USB via the menu.
USB playback
If
the unit does not start with the video playback,
Press the icon to change to the folder/file.
Press the ic on to display all the video files .
Note:
Folders and videos are selected and started as di
scribed under audio playback.
If
you selected a movie, the playback is started.
Briefly touch the touchscreen once to display the
playback menu again.
If the playback does not start with the image playback,
Press the button to change the folder/file .
Press the button to display all the images of
the data carrier.
Note:
Folders and images are selected and started as de-
scribed under audio playback.
Select previous movie.
/
Pause/Play.
Select next movie.
Display the folder/file list.
Show additional operating options.
Tap on
to display additional operating options
of the playback menu.
Hide additional operating options.
Select REPEAT mode.
Start MIX random play and end it again.
Display equalizer.

10
10
Bluetooth mode
Bluetooth mode
The Bluetooth® function allows paired phones and
media playback devices with the unit.
When p aired, you can make phone calls with the
built-in hands-free
function. You can access the list
of dialed numbers and
the phone book of the paired
phone.
If the connected Bluetooth® device supports the
functions A2DP and AVRCP, you can play the music via
the unit and control the playback. During a call, the
music playback is interrupted and continued
again
after the call.
If a phone is paired via Bluetooth® and a call
is received during the playback of another source,
the source playback is interrupted and the call
menu is displayed.
Starting Bluetooth mode
In the main menu, press on Phone icon.
The Bluetooth® menu is displayed. It contains the list
of known Bluetooth® devices.
The car sound system appears as "AXIS" in the list of
Bluetooth® devices.
The connection is being established and the menu
for the registered device is displayed.
Note:
If a telephone is connected with the HM4Z05A
unit, the Bluetooth® icon is displayed at the top
right edge of the display in all audio/video sources.
Telephone mode
If you connected a phone with the car sound system via
Bluetooth®, the following menu appears.
Display the favorite contact menu.
Call up the phone book.
Call up caller lists.
Display the phone keypad.
Establish the connection.
Display options menu.
Add new Bluetooth® device.
Display options menu.
Press the icon of the Bluetooth® device with
which you want to establish a connection.
When the device is in range, the connection is
established and the menu for the device is displayed.
Press the icon if you want to delete the
Bluetooth® device from the list.
Registering Bluetooth devices
If you want to register a device with the unit for the first
time, proceed as follows:
Ensure that Bluetooth® is activated at the car sound
system and at your Bluetooth® device.
Search for new devices/connections on your
Bluetooth® device.
The car sound system appears as "AXIS" in the list
of Bluetooth® devices.
Establish the connection.
Making a call
Select a contact via the favorite list or
phone book or,
Select a contact/number via the caller lists
and press the
icon in the pop-up
Select a contact/number via the caller lists and
press the button in the pop-up window.
The connection is being established.
- Or -
Enter a phone number with the keypad and press the
icon.

11
11
Receiving a call
If a call is coming in, the call menu is displayed.
Hang up or reject a call.
Answer a call.
Alphabetic search
Press on the left bottom of the screen to access
Phonebook. If you want to search a contact, press
and enter the characters via the keypad.
Audio playback via Bluetooth streaming
If an audio streaming device is connected with the
unit
via Bluetooth®, you can play back the music and
control the playback.
Press the BT Music icon on the main menu to
change to the audio playback.
Bluetooth mode
Auto connect – If "Auto Connect" is activated,
the device automatically connects with known
Bluetooth® devices as soon as they are in range.
Auto answer – If "Auto Answer" is activated,
incom
ing phone calls are automatically answered.
Phone book sync – To be able to access the phone
book of a connected telephone, you must first
synchronize it via this menu entry.
Press to exit the options menu.
Short press: Title selection.
Long press: Fast searching.
Pause/play .
Short press: Title selection.
Long press: Fast searching.
Display equalizer.
Bluetooth settings
In the options menu for Bluetooth®, you can make the
basic settings for the Bluetooth® mode.
Press the icon.
/

12
12
Apple CarPlay | Android Auto
Apple CarPlay/Android Auto
This feature enables you to display and take control of
your supporting mobile phone. Once connected you
can get directions,
make calls, send and receive
messages and listen to
audio books and music all in a
way that allows you to stay
focused on the road.
*Note
Only the rear USB port supports Apple Carplay and
Android Auto, (the front USB port does not
support Apple Carplay and Android Auto).
Setup CarPlay/Android Auto mode
1. Connect your Phone to the rear USB port via
the Apple or Android lead. The unit will enter
CarPlay or Android Auto mode automatically.
2. To exit, touch the button on the front panel.
3. If you want to return to this feature mode,
touch Apple CarPlay or Android Auto icon on
the menu.
4. To activate Siri/Google assist, touch the
icon on the front panel.
Android Auto
You will need to pair your phone to this unit via
Bluetooth.
Android Auto App must be installed on the phone
before connecting and have minimum software
version of Android OS: 6.0.
Map
Touch the icon of Android Auto to let the
phone show you the way.
Call / Receive Call
Touch the
icon on Android Auto to make calls.
Back to Android Auto
Touch the icon of Android Auto to go
back to the main menu.
Play Music
Touch the icon of Android Auto to play music.
Talk with Google
1. Touch the icon on the screen*.
2.
When the Phone is connected, activate
Google Assistant by steering wheel control
(requires programming in SWC menu).
3. Control with “Ok, Google”.
*Note
You can use the touch screen of the unit to control
CarPlay/Android Auto, however in some regions it
is illegal to touch your unit while the engine is
on and/or driving. It is recommended to use Siri
® or
Google Assistant, If your vehicle includes it; use
the voice button on your steering wheel
(requires programming in SWC menu).

13
13
External audio/video
AV inputs
External audio/video sources | Rear Camera input | Sound settings
This device features external AV input for audio and
video playback. The AV-IN input is located at the rear of
the radio.
Touch the AV IN icon- the display will shows the
audio or video playback of the
selected AV source.
Rear Camera input
This device features a video input at the rear of the device
for connecting a camera that is available as an option. If
a rear camera is connected and professionally installed,
the image is displayed on the
screen, when the rear
gear is engaged.
Sound settings
Volume distribution (fader/balance)
You can adjust the settings for all sources.
In the main menu or on the control bar of each
source, press the
/ icon.
The equalizer menu is then displayed.
Press the button.
The menu for fader and balance is displayed.
Equalizer
You can adjust the equalizer for all sources.
In the main menu or on the control bar of the
audio source, press the
icon.
The equalizer menu is displayed.
Select a preset equalizer via the buttons.
- Or -
Press the Customize icon to adjust the level of
the available frequency bands according to your
preferences.
Note:
The Reset icon, will also reset the customized setting.
- Or -
Press the FLAT icon for a linear sound.
Press the
Loudness icon to increase the bass at low
volume.

14
14
Basic settings
Basic settings
In the settings menu, you can adjust settings for the
different functions of the device to your requirements.
In the main menu, press the Settings icon.
The settings menu is displayed.
General
The following settings are possible:
Language – Select the language for the user interface
of the device.
Light – Select the backlight color of the buttons.
White (default) or Red
.
Radio region – Select the reception region for the radio
reception.
Beep – Switch confirmation beep on/off
Wallpaper – Select the wallpaper of the main menu.
SWC – The buttons of a connected steering wheel control
can be configured here.
Local – When On , only stations with a strong signal are
found during seek tuning.
Display Off – Turn the display off.
Video
Adjust the Brightness of the screen.
Volume
Adjust the volume ratio for all audio sources in the
volume menu.
Time
Set Date – Set the date.
Set Time – Set the time.
24Hr – Selection between 12 and 24 hour mode.
System
MCU/MPEG Update - Update the software when the
updated file is required.
MCU/MPEG Version - Show the version of software.
Factory settings - Reset all personalized settings.

15
D
Connection diagram
Connection diagram
ENGLISH

16
Trouble Shooting
NOTE: If any problems persist or are not listed below, consult your nearest service dealer.
Symptom Cause Solution
No Power The car ignition switch is not on If the power supply is connect-
ed to the car
accessory circuit, but the engine
is not moving, switch the
ignition key to “ACC”
The fuse is blown Replace the fuse
No Sound Volume is on minimum Adjust volume to desired level
Wiring is not properly
connected
Check wiring connection
The operation keys do not work The built-in micro computor is
not operating properly dur to
noise
Press the reset button
The unit does not tune in to a
radio sation (seek up/down does
not tune)
The antenna cable is not con-
nected
Insert the antenna cable firmly
The signals are too weak Select a station manually
Vehicle has an amplified antenna
system
Find the antenna power wire
in the factory wiring loom and
connect to
accessories power
Clock resets, but radio stations
presets are retained in memory
OR
Unit resets frequently
Voltage Check if there is 12 volts on
the blue fuse at the back of the
head unit while the vehicle is
turned off. If there is no voltage,
disconnect the two bullet
connectors on the red and
yellow wires on the supplied
wiring harness and cross the
connections.
A warning to park or stop the
vehicle is displayed when
watching in either USB, AV IN,
Apple CarPlay or Android Auto
mode.
Parking wire not connected Connect the parking wire to the
hand brake negative circuit.
Apple CarPlay/Android Auto
does not activate when plugged
into the front USB port.
USB support The front USB port does not
support Apple CarPlay or
Android Auto. Only the USB
port supports Apple CarPlay or
Android Auto.

17

18

19

20
Serial Number:
Date of Purchase: / /
Congratulations on your purchase of a quality Mobile Safety System! You’re joining thousands of satisfied
customers who enjoy & experience the benefits of the products we distribute. In the unlikely event that some technical
difficulty arises with your purchase, be assured that we are most anxious to see that the problem is quickly rectified to
your satisfaction. Please familiarise yourself with the following simple conditions of our warranty. This warranty covers
faults through component failure or failure of the product to operate in accordance with published specifications.
Product failure as a result of unreasonable environmental conditions, accident, misuse, improper installation,
unauthorised repair, vehicle electrical or wiring faults or neglect etc, will not be covered by this warranty. Removal and
installation costs, if any, would be paid by the owner as well as any freight or postage costs of transporting the product
to AudioXtra. AudioXtra shall not be liable or responsible for any loss of use of this product or any form of consequential
loss.
CONSUMER WARRANTY
This product is warranted by AudioXtra Pty Ltd to be free from defects in materials and workmanship under
NORMAL USE for a period of TWENTY FOUR MONTHS from the date of purchase.
WITHIN 30 DAYS OF PURCHASE DATE:
Please return the unit for replacement to our National Service Centre or the Retailer from where you made the purchase.
All accessories must be included. Proof of purchase date must accompany the products.
AFTER 30 DAYS OF PURCHASE DATE:
Warranty repair and service is carried out by our National Service Centre. Repair and service will be carried out at no cost
to the owner if proof of ownership and the date of purchase can be verified to the satisfaction of the authorised centre
concerned with this repair. This proof should take the form of either:
a) The warranty card accompanying this product, stamped and dated by the dealer.
b) A Tax Invoice or Receipt showing full details of original vendor, purchaser, model number and serial number.
COMMERCIAL WARRANTY
A product used in or associated with a commercial application will carry a limited SIX MONTH warranty. An abnormal
commercial application is one where usage, dust, vibration, heat/cold and other environmental conditions exist at an
extreme level.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
Please complete details below in the event of warranty service being required.
Purchaser’s Name:
Purchaser’s Address:
Model Number:
Dealer Name:
Dealer Address:
Invoice/Sales Docket no:
General Hints: To expedite service and prompt return of the equipment, please:
a) Clearly describe the fault in detail b) Safely and securely pack the unit for transport
c) Include your return address d) Provide proof of purchase date as outlined above
WARRANTY
National Service Centre:
10 STODDART ROAD, PROSPECT,
SYDNEY, NSW, 2148, AUSTRALIA
Telephone: [phone]
Fax: [phone]
email: [email protected] audioxtra.com.au
