INSTRUCTION MANUAL
AT1901BT
Watertight All-Terrain
Bluetooth Multimedia System 2YEAR WARRANTY
GENERAL
- USB Input (Rear)
- 2ch Aux Inputs (Rear)
- LCD Display
- Clock
- IP66 Watertight
- Water & Salt Protection PCB Coating
- Diecast Aluminium Housing
- Loud Impedance: 4-8Ohms
- 155 x 104mm Face (Gauge Type)
- 134 x 85mm cut out
- 55mm Mounting Depth
- 20W x 4ch RMS Output @ 14.4V
- 40W x 4ch Peak Output @ 14.4V
MULTIMEDIA
- MP3 Playback via USB
- S/N Ratio: >55dB
- Frequeny Response: 20 - 20KHz
- A/D Conversion Filter: 16 Bit
TUNER
- AM/FM Auto Seek Receiver
- FM 87.5~108 MHz; AM 522~1710 KHz
- Radio Regions: Australia, (Europe) and USA
BLUETOOTH
- Bluetooth A2DP Audio Streaming
- Bluetooth Handsfree
SPECIFICATIONS
INCLUDES
- U Mounting Bracket
- USB Cable
- ISO Wiring Harness

2
Controls
1. POWER On/Off MUTE - The power button is a multi-function button, depending on how
long you hold the button. A quick press turns the unit on. A press and hold, engages the MUTE
while a long press powers the unit off.
2. Audio Mode - Press the button quickly, to see show “SEL” on the screen. Then with quick
presses scroll through each of the audio functions: BASS, TRE, BAL, FAD, LOUD, EQ, BEEP.
Each function is adjusted using the #5 button VOL Up/Down.
3. APS - In FM or AM Mode, press the button quickly to scan stored radio stations. Press and
hold to automatically scan all stations programmed with a short audition of each. Press the
button again to stop the scan.
4. MOD - This is your input mode switch. Press to scroll through your various inputs, FM, BT,
USB, AUX-In.
5. VOL - Volume Up/Down. Press quickly for small increments in volume. Hold down for
quicker adjustments.
6. BND/Clock - This multi-function button when pressed quickly, scrolls between your FM1, 2
and 3 plus AM1 and 2 banks for programmed stations. Press and hold button #6 to adjust the
clock. When in “Clock” mode, press and hold again to adjust. Quickly press to switch hour or
minute. Use the #5 VOL Up/Down button to adjust time.

3
7. RWD/Back/Phone Answer - This multi-function button works with your music sources.
In radio mode, quickly press to go back to the next strongest station. For other sources,
press quickly to go back to the beginning of the current song, press twice to go back to the
beginning of the previous track. Press and hold for fast reverse within the current selection.
8. FWD/Forward/Phone End - This multi-function button works with your music sources. In
radio mode, quickly press to go forward to the next strongest station. For other sources, press
quickly to go to the beginning of the next song, press twice to go back to the beginning of the
previous track. Press and hold for fast forward within the current selection.
9. 1 - Play/Pause - This mult-function button works in several modes. For the BT, USB, Apple
Device mode this is play and pause. In FM and AM mode quickly press to select station preset
#1. In radio mode press and hold to store the current station to this preset.
10. 2 - INT/Intro - This mult-function button works in several modes. For the BT, USB, press this
to play the introduction (first 10 seconds) of each track. Press again to turn off the feature. (not
compatible in iPod mode). In FM and AM mode quickly press to select station preset #2. In
radio mode press and hold to store the current station to this preset.
11. 3 - RPT/Repeat - This mult-function button works in several modes. For the BT, USB, press
this button to repeat the current song. Press again to turn off the feature. (not compatible in
iPod mode). In FM and AM mode quickly press to select station preset #3. In radio mode press
and hold to store the current station to this preset.
12. 4 - RDM/Random - This mult-function button works in several modes. For the BT, USB,
press this button to allow random tracks to play from that unit. The RDM will not select random
tracks from different devices, only from the unit selected. (not compatible in iPod mode). In FM
and AM mode quickly press to select station preset #4. In radio mode press and hold to store
the current station to this preset.
Included
U Mounting Bracket USB Cable ISO Wiring Harness
