FAAFTECH FT-LVDS-AUD4 User manual

INSTALLATION MANUAL
FT-VIDEO-LVDS
AUD4
REV 161117

• Congratulations for purchasing the video interface FT-LVDS-AUD4.
• Please, read this manual with attention before installing your new device.
• Keep this manual with you to check the functioning procedures and the
security information.
• We recommend that a professional, with experience in the field of installation
of vehicle devices, is the one to install this interface.
• The car ignition must be off during the entire installation process.
CHARACTERISTICS
• Unblocks video while vehicle is moving (Original USB video/DVD/TV)
• Enables 3 AV inputs
• Enables inputs for rear camera and front camera*
• TV and DVD controlled by iDrive and original vehicle commands
• 12V, ACC and CAMERA output
• Plug and Play Connections
• 1-year warranty against manufacturer defect
• Compatible vehicles:www.faaftech.com/produtos/interface-de-video/ft-lvds-aud4
* 3rd AV input can be set up to be used as AV, NAV or Front Camera.
PRESENTATION
1

Set up the interface’s DIP Switches while the equipment is unplugged from the
whip, and while the car ignition is off.
DIP Switches
ON
1 2 3 4 5 6 7 8
DIP 1
SETUP DIP SWITCHES
UP enables AV2 (TV) input
DOWN disables AV2 input
UP enables AV1 (DVD) input
DOWN disables AV1 input
DIP 2
UP enables AV3, NAV or FRONT CAM input (see pages 11-12)
DOWN disables AV3 input
Cars with an 8,2” screen: DIP 4 and DIP 5 up
Cars with a 7,0” screen: DIP 4 up and DIP 5 down
Cars with a 5,8” screen: DIP 4 and DIP 5 down
DIP 3
DIP 5
DIP 4
DVD AND TV SELECTION DIP SWITCHES
FAAFTECH TV
FAAFTECH DVD
FT-DVD II
VDVD-155SOUNDSTREAM DVD
FT-TV-1SEG DIP 6 up and DIP 7 down
DIP 6 down and DIP 7 down
DIP 8 up
DIP 8 down
FT-TV-1SEG II
FT-TV-1SEG III
FT-TV-HD II
LBSAT TV DIP 6 up and DIP 7 upLBCR-1100
FT-DVD-1/2DIN
2

CONNECTIONS
Connect to
the whip
Connect to
the whip
Connect to the radio located
inside the glove compartment
Connect to the radio’s pink
or gray LVDS plug
Saida Audio
Modelo: FT-LVDS-AUD4
Versão: xx
S/N: xxxxxxxxxx
DATA OUT/
ANTENA
AV
IN/OUT
LVDS
IN/OUT
CAN/POWER
IN
POWER
OUT
UPDATE
DIP
SELECT
Connect to the AUX entry
on the console or on the glove
compartment
3

Accessories Connections
Check this example on the installation of a DVD, a TV, a front camera on the AV3
input and a rear camera.
Accessories such as DVD, TV and camera are sold separately.
Modelo: FT-LVDS-AUD4 Versão: xx S/N: xxxxxxxxxx
DATA OUT/
ANTENA
AV
IN/OUT
LVDS
IN/OUT
CAN/POWER
IN
POWER
OUT
UPDATE
DIP
SELECT
Entrada TV
(AV2)
Entrada AV3
Entrada Video Camera
Use the auxiliary exits to power the
accessories, such as DVD, TV and
camera, if you install them.
Front CameraRear Camera
MOBILE MULTI-MEDIA PLAYER
SD DVD
Receptor de TV Digital
Entrada DVD
(AV1)
4

Follow the steps bellow to access the accessories that are installed on the
device’s inputs.
1st Select the AUX audio source from the multimedia;
2nd Press and hold the button (on the steering wheel) or the MENU button
(on the dashboard or central console) to gain access to the interface’s AV mode;
3rd Simply touch the same button to toggle between the DVD (AV1), TV (AV2)
and the AV3;
4th If you want to return to the original menu, press and hold one of those
buttons again for two seconds.
FUNCTIONING
Steering wheel command’s button
Central console MENU button
5

See below the available commands to control the DVD and the TV through the
vehicle’s original commands.
FUNCTIONING
DVD commandComandos TV
Turn right
Movimento
Turn left Channel - Menu navigation
Quick press List/Enter Enter
Long press List Menu
Menu navigationChannel +
iDrive commands
DVD commandTV command
Push to the right
Command
Push to the right and hold Scan --------
Push to the left Channel - Faixa -
Faixa +Channel +
Console buttons commands
DVD command
TV command
Simply touch the 1 button
Command
Simply touch the 2 button Channel + Track +
Hold the 2 button for 3 seconds Scan --------
Track -Channel -
Steering wheel commands
12
6

The parking lines do not offer 100% precision on the track they show. Use
them only as an auxiliary resource as you park your vehicle.
Important Notice:
Rear Camera
Once you put your vehicle on reverse, the rear camera will automatically show
on the screen.
As you spin the steering wheel, the parking lines will move, showing the
vehicle’s approximate direction as you keep going.
Frontal camera
When you put the car on reverse, then switch the gear to N or D, the front
camera will automatically appear on the screen. The camera will remain turned
on for 30 seconds, or until the car reaches the speed of 15 km/h (9.32 mph) or if
you press the OK button on the steering wheel (see image of the MEDIA button
on the next page).
CAMERA FUNCTIONS
7

Camera Visualization
You can view your installed cameras at any point by following these steps:
• Press and hold the OK button on the steering wheel for three seconds, to view
your rear camera;
• Simply touch the OK button if you want to alter between the rear camera and
the front camera (in case both are installed);
• Press and hold for three seconds the OK button to exit the camera view and
return to the original menu.
Notice: the rear camera view is not compatible with the original vehicle
manufacturer’s camera.
CAMERA FUNCTIONS
Steering wheel
command’s OK button
