Kenwood DDX919WS User manual

B5A-2891-00 d (M/M2/X/A9)© 2019 JVC KENWOOD Corporation
MONITOR WITH DVD RECEIVER
DDX919WS
DDX919WSM
DDX9019DABS
DDX9019S
DDX9019SM
MONITOR WITH RECEIVER
DMX8019DABS
DMX8019S
INSTRUCTION MANUAL
• Updated information (the latest Instruction Manual, system updates, new
functions, etc.) is available from
<http://www.kenwood.com/cs/ce/>.

2
Contents
Before Use 4
Precautions................................................................... 4
How to read this manual ......................................... 5
Basic Operations 6
Functions of the Buttons on the Front Panel ... 6
Turning on the Unit ................................................... 8
Initial Settings.............................................................. 8
Adjusting the volume.............................................11
Display Adjustment.................................................11
Viewing Angle ...........................................................12
Touch screen operations .......................................12
Gesture Control.........................................................13
HOME screen descriptions....................................13
Popup menu ..............................................................14
Source selection screen description..................14
Source control screen descriptions ...................17
List screen ...................................................................18
Widget 19
Widget..........................................................................19
Multi Widget...............................................................19
Photo Frame Widget ...............................................21
Widget Setup.............................................................21
Disc 22
Playing a disc .............................................................22
DVD/VCD Basic Operation ....................................22
Music CD/Disc media Basic Operation .............24
File search Operation..............................................25
DVD Disc Menu Operation....................................26
DVD Setup...................................................................27
APPS 28
Wireless Mirroring Operation...............................28
Apple CarPlay Operation .......................................28
Android Auto™ Operation.....................................31
Spotify Operation.....................................................33
USB 35
Connecting a USB device ......................................35
USB Basic Operation................................................35
Search Operation......................................................37
iPod/iPhone 38
Preparation.................................................................38
iPod/iPhone Basic Operation ...............................39
Search Operation......................................................40
Radio 41
Radio Basic Operation ............................................41
Memory Operation ..................................................42
Selecting Operation ................................................42
Traffic Information ...................................................43
Radio Setup ................................................................43
Digital Radio 44
Digital Radio Basic Operation..............................44
Storing Service in Preset Memory......................45
Selecting Operation ................................................45
Traffic Information ...................................................46
Digital Radio Setup..................................................47

3English
Bluetooth Control 48
Information for using Bluetooth® devices.......48
Register the Bluetooth device .............................49
Bluetooth Setup........................................................50
Playing the Bluetooth Audio Device .................52
Using the Hands-Free Unit....................................54
Hands-Free Setup.....................................................59
Other External Components 60
View Camera ..............................................................60
Use Dashboard Camera..........................................63
External audio/video players (AV-IN).................63
HDMI source...............................................................63
TV tuner .......................................................................64
Using the external navigation unit....................64
Setup 65
Monitor Screen Setup.............................................65
System Setup.............................................................65
User Interface Setup................................................66
Special Setup .............................................................68
Display Setup.............................................................69
AV Setup ......................................................................71
Controlling Audio 73
3-way speaker system setup ................................73
Speaker / X’over setup............................................74
Controlling General Audio....................................76
Equalizer Control ......................................................76
Volume Offset............................................................77
Zone Control ..............................................................78
Sound Effect...............................................................79
Listening Position / DTA.........................................80
Audio Setup memory .............................................81
Remote control 82
Battery Installation...................................................82
Functions of the Remote control Buttons.......82
Connection/Installation 85
Before Installation....................................................85
Installing the unit .....................................................87
Troubleshooting 97
Problems and Solutions.........................................97
Error Messages ..........................................................97
Appendix 99
Playable Media and Files........................................99
Region Codes in the World ................................ 101
DVD Language Codes.......................................... 102
Specifications.......................................................... 103
About this Unit....................................................... 106

Before Use
4
Before Use
Precautions
#WARNINGS
Ñ To prevent injury or fire, take
the following precautions:
• To prevent a short circuit, never put or leave
any metallic objects (such as coins or metallic
tools) inside the unit.
• Do not watch or fix your eyes on the unit’s
display when you are driving for any extended
period.
• If you experience problems during installation,
consult your KENWOOD dealer.
Ñ Precautions on using this unit
• When you purchase optional accessories,
check with your KENWOOD dealer to make
sure that they work with your model and in
your area.
• You can select a language to display menus,
audio file tags, etc. See User Interface Setup
(P.66).
• The Radio Data System or Radio Broadcast
Data System feature won’t work in areas
where the service is not supported by any
broadcasting station.
Ñ Protecting the monitor
• To protect the monitor from damage, do not
operate the monitor using a ball point pen or
similar tool with a sharp tip.
Ñ Cleaning the unit
• If the faceplate of this unit is stained, wipe it
with a dry soft cloth such as a silicon cloth.
If the faceplate is stained badly, wipe it with
a cloth moistened with neutral cleaner, then
wipe it again with a clean soft dry cloth.
NOTE
• Applying spray cleaner directly to the unit
may damage its mechanical parts. Wiping the
faceplate with a hard cloth or using a volatile
liquid such as thinner or alcohol may scratch the
surface or erase the screened print.
Ñ Lens fogging
When you turn on the car heater in cold
weather, dew may form on the lens in the
disc player of the unit due to condensation.
This condensation on the lens (also called lens
fogging) may not allow discs to play. In such a
situation, remove the disc and wait for the dew
to evaporate. If the unit still does not operate
normally after a while, consult your KENWOOD
dealer.
Ñ Precautions on handling discs
• Do not touch the recording surface of the disc.
• Do not stick tape etc. on the disc, or use a disc
with tape stuck on it.
• Do not use disc type accessories.
• Clean the disc from the center toward the
outside rim.
• When removing a disc from this unit, pull it out
horizontally.
• If the disc center hole or outside rim has burrs,
use the disc only after removing the burrs with
a ballpoint pen etc.
• Discs that are not round cannot be used.
• 8-cm (3 inch) discs cannot be used.
• Discs with coloring on the recording surface or
discs that are dirty cannot be used.
• This unit can only play the following types of
CDs.
• This unit may not correctly play discs which do
not have the mark.
• You cannot play a disc that has not been
finalized. (For the finalization process, see
your writing software and your recorder's
instruction manual.)

Before Use
5English
Ñ Acquiring GPS signal
The first time you turn on this unit, you must
wait while the system acquires satellite signals
for the first time. This process could take up
to several minutes. Make sure your vehicle
is outdoors in an open area away from tall
buildings and trees for fastest acquisition.
After the system acquires satellites for the first
time, it will acquire satellites quickly each time
thereafter.
Ñ About GLONASS
This unit uses Global Navigation Satellite System
(GLONASS) in addition to GPS.
Combining GPS and GLONASS can refine
positioning accuracy than using GPS only.
Ñ Caution for Smartphone Users
Simultaneously running multiple applications
on your smartphone while screen sharing places
heavy demand on the microprocessor of the
phone, potentially affecting communication and
performance.
For best results while pairing with your Kenwood
receiver, please be sure to close any unused
applications.
How to read this manual
• The screens and panels shown in this
manual are examples used to provide a clear
explanation of operations.
For this reason, they may be different from the actual
screens or panels, or some display patterns may be
different from the actual ones.
• Display language: English is used for the
purpose of explanation. You can select a
display language from the [SETUP]menu. See
User Interface Setup (P.66).

Basic Operations
6
Basic Operations
Functions of the Buttons on the Front Panel
DDX919WS / DDX919WSM
1
2
4
5
6
7
3
8
NOTE
• The panels shown in this manual are examples used to provide clear explanations of the operations. For this
reason, they may be different from the actual panels.
• In this manual, each model name is abbreviated as follows.
– DDX919WS / DDX919WSM:
If above icon is showed, read the article applicable to the unit you use.
Number Name Motion
1
Gesture
control
sensor
• A sensor which detects motions of your hand. (P.13)
2
• Displays the APP (Apple CarPlay/Android Auto/Wireless Mirroring) screen.
• Pressing and holding displays the Voice Recognition screen (P.56).
• When neither Apple CarPlay, Android Auto, nor a Bluetooth Hands-Free phone is
connected, pressing and holding displays Bluetooth pairing waiting dialog. (P.49)
3
S, R
(Volume)
• Adjusts volume.
The volume will go up until 15 when you keep pressing R. (P.11)
4
HOME • Displays the HOME screen (P.13).
• Pressing for 1 second turns the AV off.* (Touch the display to turn on the screen.)
* Turns off the screen and audio. Interrupts from incoming hands-free calls, rear camera
views and so on are functional, though.
5
MENU • Displays the popup menu screen.
6
G• Displays the Angle Adjust screen.
– [DISC EJECT]: Ejects the disc.
• When the panel is opened, closes the panel.
• To forcibly eject the disc, press it for 2 seconds and then touch [DISC EJECT]after the
message is displayed.
7
Remote
Sensor
• Receives the remote control signal.
8
Disc insert
slot
• A slot to insert a disc media.

Basic Operations
7English
DDX9019DABS / DDX9019S / DDX9019SM
9
1 2 3 4 5 6 7
DMX8019DABS / DMX8019S
1 2 8 4 5 6 3
NOTE
• The panels shown in this manual are examples used to provide a clear explanation of operations. For this reason,
they may be different from the actual panels.
• In this manual, each model name is abbreviated as follows.
– DDX9019DABS / DDX9019S / DDX9019SM:
– DMX8019DABS / DMX8019S:
If above icon is showed, read the article applicable to the unit you use.
Number Name Motion
1
Remote
Sensor
• Receives the remote control signal.
2
S, R
(Volume)
• Adjusts the volume.
The volume will go up to 15 when you keep pressing R. (P.11)
3
CAM • Switches view camera display on/off.
The camera whose view is displayed first changes according to the "Camera Setup"
setting and the shift lever position in the shift gate.
• Pressing and holding turns the screen off. ([ ])
4
HOME • Displays the HOME screen (P.13).
• Pressing for 1 second turns the power off.
• When the power is off, turns the power on.
5
MENU • Displays the popup menu screen.
• Pressing for 1 second switches attenuation of the volume on/off. ([ ])
• Pressing for 1 second turns the screen off. ([ ])
6
• Displays the APP (Apple CarPlay/Android Auto/Wireless Mirroring) screen.
• Pressing and holding displays the Voice Recognition screen (P.56).
• When neither Apple CarPlay, Android Auto, nor a Bluetooth Hands-Free phone is
connected, pressing and holding displays Bluetooth pairing waiting dialog. (P.49)

Basic Operations
8
Number Name Motion
7
G• Displays the Angle Adjust screen.
– [DISC EJECT]: Ejects the disc.
• When the panel is opened, closes the panel.
• To forcibly eject the disc, press it for 2 seconds and then touch [DISC EJECT]after the
message is displayed.
8
AT T • Switches attenuation of the volume on/off.
9
Disc insert
slot
• A slot to insert a disc media.
([ ])
Turning on the Unit
The method of turning on is different
depending on the model.
[ ]
1
Touch the display.
 The unit is turned on.
[ ][ ]
1
Press the [HOME]button.
[
]
[ ]
 The unit is turned on.
●To turn off the unit:
1
Press the [HOME]button for 1 second.
NOTE
• If it is your first time to turn the unit on after
installation, it will be necessary to perform Initial
setup (P.8).
Initial Settings
Initial setup
Perform this setup when you use this unit first
time.
1
Set each item as follows.
■[Language]
Select the language used for the control
screen and setting items. Default is“British
English(en)”.
1Touch [Language].
2Touch [Language Select].
3Select the desired language.
4Touch [
].
For details, see User Interface Setup
(P.66).
■[Clock]
Sets the synchronization of the clock and
adjusts it.
For details, see Calendar/clock settings
(P.10).
■[Display]
Set the key illumination color.
If it is hard to see the image on the screen
even, adjust the viewing angle.
1Touch [Display].

Basic Operations
9English
2Touch [Key Colour].
3Select the desired color.
4Touch [
].
([
]/ [ ]only)
5Touch [Display Adjustment].
6Adjust a viewing angle and a tilt position.
7Touch [
].
For details, see Display Adjustment
(P.11).
([
]only)
5Touch [Viewing Angle].
6Select a viewing angle.
7Touch [
].
For details, see Viewing Angle (P.12).
For details, see Display Setup (P.69).
■[Camera]
Set the parameters for the camera.
1Touch [Camera].
2Set each item and touch [
].
For details, see Camera Setup (P.60).
■[DEMO]
Set the demonstration mode. Default is “ON”.
■[3way X'over]
Displays the message screen.
For details, see (P.73).
2
Touch [Finish].
NOTE
• These settings can be made from the SETUP
menu. See Setup (P.65).
Security Code Setup
You can set up a security code to protect your
receiver system against theft.
When the Security Code function is activated,
the code cannot be changed and the function
cannot be deactivated. Note that the Security
Code can be set with a 4 to 8 digit number of
your choice.
Preparation
• Set [DEMO]to [OFF]in the Special screen
(P.68).
1
Press the [MENU]button.
 Popup menu appears.
2
Touch [SETUP].
 SETUP Menu screen appears.
3
Touch [Security].
 Security screen appears.
4
Touch [Security Code Set]on the Security
screen.
 Security Code Set screen appears.
5
Enter a security code with 4 to 8 digit
number and touch [Enter].

Basic Operations
10
6
Enter the same code again and touch
[Enter].
Now, your security code is registered.
NOTE
• Touch [BS]to delete the last entry.
• If you enter a different security code, the
procedure returns to step 5 (for first code entry).
• If you have disconnected the Receiver from the
battery, enter the correct security code as that
you have entered in step 5 and touch [Enter]. You
can use your receiver.
To change the security code:
1
Touch [Security Code Change]on the
Security screen.
 Security Code Set screen appears.
2
Enter the current registered security code
and touch [Enter].
3
Enter a new security code with 4 to 8
digit number and touch [Enter].
4
Enter the same code again and touch
[Enter].
The new security code is registered.
To clear the security code:
1
Touch [Security Code Cancellation]on
the Security screen.
 Security Code Set screen appears.
2
Enter the current registered security code
and touch [Enter].
The security code is cleared.
Calendar/clock settings
1
Press the [MENU]button.
 Popup menu appears.
2
Touch [SETUP].
 SETUP Menu screen appears.
3
Touch [User Interface].
 User Interface screen appears.
4
Set each item as follows.
Scroll the page to show hidden items.
■[Time Format]
Select the time display format.
[12-Hour ](Default)/24-Hour]
■[Clock]
[GPS-SYNC ](Default): Synchronizes the clock
time with the GPS.
[Manual]: Set the clock manually.
■[Time Zone]
If you have selected [Manual]for Clock,
select the time zone.
■[Clock Adjust]
If you select [Manual]for Clock, adjust the
date and time manually. (P.67)
NOTE
• Please set the date and time. If they are not set,
some functions may not work.

Basic Operations
11English
Adjusting the volume
You can adjust the volume (0 to 40).
Press [R]to increase, and press [S]to decrease.
Holding [R]increases the volume continuously
to level 15.
[ ]
[ ]
[ ]
Display Adjustment
([ ] / [ ])
1
Press the [G]button.
 Display Adjustment screen appears.
2
Select a tilt position you want to set up.
Default is "0".
1 2
3
1
Viewing Angle
You can adjust the viewing angle when the
image on the screen is difficult to see evenly. The
smaller the (negative) value, the more whitish
the image on the screen looks.
"0" (Default)/"-1"/"-2"/"-3"
2
Angle Adjustment
Select a tilt position you want to set up.
Default is "0".
3
Off Position
You can store the current monitor angle as the
angle during power off. Touch [Memory]when
the desired angle is selected.

Basic Operations
12
Viewing Angle ([ ])
You can adjust the viewing angle when the
image on the screen is difficult to see evenly.
The smaller the (negative) value, the more
whitish the image on the screen looks.
1
Press the [MENU]button.
 Popup menu appears.
2
Touch [SETUP].
3
Touch [Display].
 Display screen appears.
4
Touch [Viewing Angle].
5
Select an angle you want to set up.
Default is "0". (P.69)
Touch screen operations
To perform operations on the screen, you need
to touch, touch and hold, flick or swipe to
select an item, display a setting menu screen
or change pages.
●Touch
Touch the screen gently to
select an item on the screen.
●Touch and hold
Touch the screen and keep
your finger in place until
the display changes or a
message is displayed.
●Flick
Slide your finger quickly
to the left or right on the
screen to change the page.
You can scroll a list screen
by flicking up/down on the
screen.
●Swipe
Slide your finger up or down
on the screen to scroll the
screen.

Basic Operations
13English
Gesture Control ([ ])
You can also operate the unit by moving your
hand in front of the gesture control sensor.
1
7
12
• To control by hand motion, select [ON]for
[Gesture Control]on the "User Interface"
screen beforehand. (P.66)
• When shipped from the factory, you can
operate by moving your hand as follows:
– To the right: Displays the current source control
screen.
– To the left: Switches to Apple CarPlay/Android Auto
screen. (P.28)
– Up: Displays the Home screen.
– Down: When a call comes in, answers the call.
• You can assign the functions or sources/
screens to display on the "Gesture SETUP"
screen. (P.66)
HOME screen descriptions
Most functions can be performed from the
HOME screen.
1
3
2
1
• Widget (P.19)
– You can change the widget by flicking left
or right on the widget area.
– Touch the widget to display the detailed
screen.
2
• Displays the source selection screen. (P.15)
3
• Short-cut playback source icons (P.15)
Display the HOME screen
1
Press the [HOME]button.
[
]
[ ]
[ ]
 HOME screen appears.

Basic Operations
14
Popup menu
1
Press the [MENU]button.
 Popup menu appears.
2
Touch to display the popup menu.
1
The contents of the menu are as follows.
• Displays the Screen Adjustment screen.
(P.65)
• Turns the display off. (P.14)
• Displays the view camera screen.
(P.60)
• Displays the SETUP Menu screen.
(P.65)
• Displays the Audio screen. (P.73)
• Displays the control screen of current
source. Icon feature differs depending on
the source. This icon is for USB source.
• Close the popup menu.
1
• Short-cut source icons: The source
changes to the one you have set with a
short-cut. For the short-cut setting, refer
to Customize Short-cut source icons on
HOME screen (P.16).
Turn off the screen
1
Select [Display OFF]on the popup menu.
NOTE
• Touch the display to turn on the screen.
• To display the clock while the screen is off, it is
necessary to set "OSD Clock" to "ON". (P.69)
Source selection screen
description
You can display icons of all playback sources
and options on the source selection screen.
4 5
321
1
• Changes playback sources.
For playback sources, see P.15.
2
• Page indication
3
• Changes pages. (Touch []/[ ].)
You can also change pages by flicking left or
right on the screen.
4
• Returns to the previous screen.
5
• Displays the SETUP Menu screen. (P.65)

Basic Operations
15English
Select the playback source
1
Press the [HOME]button.
 HOME screen appears.
2
Touch [ ].
From the screen, you can select the
following sources and functions.
• Switches to the Apple CarPlay screen
from the connected iPhone. (P.28)
• Switches to the Android Auto screen
from the connected Android device.
(P.31)
• Displays the Hands Free screen. (P.54)
When neither Apple CarPlay, Android
Auto, nor a Bluetooth Hands-Free phone
is connected, displays Bluetooth pairing
waiting dialog.*1(P.49)
• Switches to the Radio broadcast.
(P.41)
• Switches to the Digital Radio broadcast.*2
(P.44)
• Plays a Bluetooth audio player. (P.48)
• Plays a disc.*3(P.22)
• Plays an iPod/iPhone. (P.38)
• Plays files on a USB device. (P.35)
• Switches to Spotify. (P.33)
• Plays a device connected to the HDMI
input terminal. *4(P.63)
• Switches to an external component
connected to the AV-IN input terminal.*5
(P.63)
• Switches to the Wireless Mirroring screen
from the connected Android device.*4
(P.28)
• Displays the navigation screen when a
navigation unit is connected. (P.64)
• Displays the Audio screen. (P.73)
• Puts the unit in standby. (P.16)
*1 When connecting as Apple CarPlay or Android Auto,
it works as a phone provided in Apple CarPlay or
Android Auto. If Apple CarPlay or Android Auto are
connected during talking by the Bluetooth device or
iDataLink phone, the current call will be continued.
*2 DDX9019DABS / DMX8019DABS only
*3 / only
*4 Except DMX8019S
*5 CA-C3AV (optional accessory) is connected to the
AV-IN input terminal for visual. (P.93)
To select the playback source on the
HOME screen
The 4 items displayed on the source selection
screen with large icons are shown on the
HOME screen.
You can change the items displayed on this
area by customizing the source selection
screen. (P.16)

Basic Operations
16
To select the playback source on the
source control screen
Display source selection icons by touching
[ ]/[ ] or flicking left or right on the source
control screen, then select a playback source.
Put the unit in standby
1
Press the [HOME]button.
 HOME screen appears.
2
Touch [ ].
3
Touch [STANDBY].
Customize Short-cut source icons
on HOME screen
You can arrange the positions of the source
icons as you like.
1
Press the [HOME]button.
 HOME screen appears.
2
Touch [ ].
3
Touch and hold the icon which you want
to move in the customizing mode.
4
Drag the icon to the desired position.
Changes the page

Basic Operations
17English
Source control screen
descriptions
There are some functions which can be
performed from most screens.
Indicators
5
6
1 2
3
4
7
Short-cut source icons
1
All sources icon
Displays the source selection screen. (P.14)
2
Secondary screen
• [
]/[ ] : The Secondary screen changes to
another one every time you touch it. You can
also change the Secondary screen by flicking
left or right on the screen.
• Indicators: Displays the current source
condition and so on.
– [ATT]: The attenuator is active.
– [DUAL]: The dual zone function is active.
– [MUTE]: The mute function is active.
– [LOUD]: The loudness control function is active.
• Short-cut source icons: The source changes to
the one you have set with a short-cut. For the
short-cut setting, refer to Customize Short-
cut source icons on HOME screen (P.16).
3
Content list
Displays the track/file/station/channel list.
4
• Connected Bluetooth device information.
5
Artwork & information
You can select whether to display an artwork
and song information or only song information
in more detail.
Touching the artwork area switches to the
VU meter. (The Disc, USB, iPod, Digital Radio,
Bluetooth audio sources only)
Change the text size of song information when
the "Small Audio Text" is set to "ON"/"OFF" in the
User Interface screen (P.66).
6
Function panel
Touch the left side of the screen to display the
function panel. Touch again to close the panel.
7
Operation keys
You can operate the current source with these
operation keys. The available functions are
different depending on the source type.

Basic Operations
18
List screen
There are some common function keys in the
list screens of most sources.
See (P.25, 37, 40, 54).
Display the list screen
For Disc media/USB/iPod:
1
Touch [1]or the item listed on the
information area in the source control
screen.
 The list screen appears.
For Bluetooth audio:
1
Touch [1].
 The list screen appears.
You can use following operation keys from this
screen.
61 2
3 4 5
1
Displays the list type selection window.
2
Displays a music/movie file list.
3
Text scroll
Scrolls the displayed text.
4
etc.
Keys with various functions are displayed here.
• : Plays all tracks in the folder containing
the current track.
• : Jumps to the letter you entered
(alphabetical search).
• : Moves to the upper hierarchy
level.
5
[ ]/[ ]/[ ]/[ ] Page scroll
You can change pages to display more items by
pressing [
]/[ ].
• [
]/[ ] : Displays the top or bottom page.
6
Return
Returns to the previous screen.
NOTE
• Depending on the current source or mode, some
function key may not appear.

Widget
19English
Widget
Widget
1 Press the [HOME]button.
2 You can change the widget by flicking left
or right on the widget area.
Widget list
• Multi Widget *
• Clock Widget
• Photo Frame Widget
* Up to 3 pages can be set to the multi widget screen.
Multi Widget
You can place a widget on each of the
following areas. Up to 4 widgets can be placed
per a multi widget screen.
1 Press the [HOME]button.
2 Flick the widget area to the left/right to
display the multi widget.
1
2
3
4
1
Widget (L)
2
Widget (M)
3
Widget (S1)
4
Widget (S2)
Ñ Replace the widget
●To move the widget
1 Touch and hold the widget.
 Widget customize mode is activated.
2 Drag the widget to the desired position.
●To delete the widget
1 Touch and hold the widget.
 Widget customize mode is activated.
2 Touch [×]on the right top corner of the
widget.
 The selected widget is deleted.

Widget
20
●To replace the widget
1 Touch [ ] on the multi widget screen.
1
 Widget list popup appears.
1
Widget icon
The widgets which can be placed to the
multi widget screen are listed.
2 Flick the widget list popup to the left/
right to select the widget to replace.
3 Touch and hold the new widget.
 Widget customize mode is activated.
4 Drag the widget from the widget list
popup to the desired widget area.
You can set up following items.
• Clock Widget
• NAV Widget *1
• Compass Widget
• Current source information *2
• Visualizer Widget
• Mirroring Widget *3 *4
• Photo Frame Widget
*1 This can be selected when connecting the external
navigation unit. (Except Indonesia models and
DMX8019DABS) (P.64)
*2 You cannot display the screen of Wireless Mirroring
on this widget. To display the screen of the source,
select the Mirroring Widget.
*3 This can be selected when using Wireless Mirroring.
*4 You cannot play the audio/video file on the USB/Disc
media when using Wireless Mirroring.
NOTE
• and the widget list popup disappear when no
operation is done for 5 seconds.
• When the screen is switched from another widget
to multi widget screen, [
]appears again.
Ñ Add a new multi widget
You can add pages to the multi widget screen.
1 Touch [ ] on the multi widget screen.
 Widget list popup appears.
■[ ]
Displays confirmation message to delete the
current page from the multi widget screen.
For details, see To delete the multi widget
(P.20).
■[
]
Adds a page to the multi widget screen.
2 Touch [ ] on the widget list popup.
 A new page is added.
NOTE
• You can add up to 2 pages to the multi widget
screen. If you have already added 2 pages, you
cannot select [
].
• The widget list popup is displayed on the new
page until you place a widget to.
To delete the multi widget
1 Touch [ ] on the widget list popup.
 Confirmation message appears.
2 Touch [YES].
 Current page is deleted.
NOTE
• You cannot delete the first page of the multi
widget screen.
