AXIS 225FD
Network Camera
Installation Guide

AXIS 225FD Installation Guide Page 3
ENGLISH DEUTSCH ESPAÑOL ITALIANO
AXIS 225FD
Fixed Dome Network Camera
Installation Guide
This installation guide provides instructions for installing the AXIS 225FD Fixed Dome
Network Camera on your network. For all other aspects of using the product, please see the
AXIS 225FD User’s Manual, available from www.axis.com or on the Axis Network Video
Product CD.
Installation steps
1. Check the package contents against the list below
2. Install the hardware - page 5
3. Connect the cables - page 5
4. Set the IP address - page 6
5. Set the password - page 9
6. Adjust the image - page 10
Package contents
Note: To comply with the vandal resistant design of the AXIS 225FD, it is necessary to use vandal
resistant conduits to protect the cables.
Fixed Dome Network Camera AXIS 225FD
Indoor Power Adapter
Note: The power adapter is country specific,
please check that the type of power adapter
you are using is correct
Europe
UK
Australia
USA/Japan
Korea
Mounting kit Tool for tamper-proof screws
3 screws and plugs for solid walls
Cable gland with blind plugs
Drill template
Silica gel packet
Documentation AXIS 225FD Installation Guide
Axis Network Video Product CD
Warranty Document
Important!
This product must be installed in
compliance with local laws and
regulations.

Page 4 AXIS 225FD Installation Guide
Hardware overview
Notes:
• Use cables and conduits that are suitable for the installation and that are in compliance
with the IP66 rated, outdoor-proof, vandal resistant design of the AXIS 225FD.
• Conduit dimensions: NPT 3/4" -14 (pipe thread).
Important!
If the AXIS 225FD is not mounted according to the instructions, there may be problems with
moisture which is not covered by warranty.
Conduit hole
Conduit hole
Network
connector
Serial number (S/N)
Control
Plug
LED
indicators
(see table 2)
1234
The serial number is required
during the installation.
1
7
button
Power connector block
(see table 1)
I/O terminal
block
GND
+orAC
AC
(side)
(bottom)
Tamper-proof
screws
Unit casing
Dome casing
Cable
Conduit
hole
Cables
Cable
gland Outer
ring
gland
Rubber
plug

AXIS 225FD Installation Guide Page 5
ENGLISH DEUTSCH ESPAÑOL ITALIANO
Install the hardware
Refer to the illustration on page 4 for a detailed overview of the AXIS 225FD.
1. Make a note of the serial number (S/N) which is located on the product label on the base
of the unit casing. The serial number is used in the installation.
2. Loosen the tamper-proof screws using the supplied allen key and lift the dome casing
from the unit casing. Be careful not to damage the dome or scratch the glass.
3. Disassemble the cable gland (see illustration).
4. Thread the network/power and I/O cables through the outer ring
and rubber plug (push the network cable through the slit).
5. Use the supplied blind plugs to fill unused holes in the rubber plug.
6. Attach the cable gland to the conduit hole on the side or bottom of
the AXIS 225FD, depending on the installation.
7. Route the cables through the cable gland, push the rubber plug into
place and tighten the outer ring to secure the cables. Use silicon
sealant, if necessary.
8. Using the drill template, drill three holes in the ceiling/wall.
The conduit hole must face downwards if the camera is installed
vertically.
9. Install the unit casing on the ceiling/wall using the supplied screws and plugs. Seal the
holes with silicon sealant to prevent moisture from leaking in to the casing.
Note: Use of the cable gland is optional. For full vandal resistant protection of the cables, use
vandal resistant conduits instead.
Connect the cables
1. Connect the camera to the network using a shielded network cable.
2. Optionally connect external input/output devices, e.g. alarm devices. See page 14 for
information on the terminal connector pins.
3. Connect power to the power connector block, using one of the methods listed below:
• PoE (Power over Ethernet) via the network cable. This will automatically be detected if
available via the network. Note that PoE provides power for the camera only (not the
heater).
• Connect the supplied indoor power adapter to the power connector block in the camera
casing. Note that this indoor power adapter provides power for the camera only (not the
heater).
• Connect an outdoor power supply to the power connector block in the camera casing. For
information on available outdoor power supplies, please visit the Support pages at http://
www.axis.com/techsup/
4. Check that the indicator LEDs indicate the correct conditions. See the table on page 14 for
further details. Note that some LEDs can be disabled and may be unlit.
Conduit hole
must face
downwards

Page 6 AXIS 225FD Installation Guide
Assign an IP address
Most networks today have a DHCP server that automatically assigns IP addresses to connected
devices. If your network does not have a DHCP server the AXIS 225FD will use 192.168.0.90
as the default IP address.
If you would like to assign a static IP address the recommended method in Windows is either
AXIS IP Utility or AXIS Camera Management. Depending on the number of cameras you
wish to install, use the method that best suits your purpose.
Both of these free applications are available on the Axis Network Video Product CD supplied
with this product, or they can be downloaded from www.axis.com/techsup
Notes:
• If assigning the IP address fails, check that there is no firewall blocking the operation.
• For other methods of assigning or discovering the IP address of the AXIS 225FD, e.g. in other
operating systems, see page 15.
Method Recommended for Operating system
AXIS IP Utility
See page 7
Single camera
Small installations
Windows
AXIS Camera Management
See page 15
Multiple cameras
Large installations
Installation on a different subnet
Windows 2000
Windows XP Pro
Windows 2003
Server

AXIS 225FD Installation Guide Page 7
ENGLISH DEUTSCH ESPAÑOL ITALIANO
AXIS IP Utility - single camera/small installation
AXIS IP Utility automatically discovers and displays Axis devices on your network. The
application can also be used to manually assign a static IP address.
Note that the computer running AXIS IP Utility must be on the same network segment
(physical subnet) as the AXIS 225FD.
Automatic discovery
1. Check that the AXIS 225FD is connected to the network and that power has been applied.
2. Start AXIS IP Utility.
3. When the camera appears in the window, double-click it to open its home page.
4. See page 9 for instructions on how to assign the password.
Assign the IP address manually
1. Acquire an unused IP address on the same network segment as your computer.
2. Click the button Assign new IP address using serial number and enter the serial
number and IP address for the AXIS 225FD. The serial number is located on the product
label.
3. Click the Assign button and follow the instructions.
4. Click the Home Page button to access the camera’s web pages.
See page 9 for instructions on how to set the password

Page 8 AXIS 225FD Installation Guide
AXIS Camera Management - multiple cameras/large installations
AXIS Camera Management can
automatically discover multiple
Axis devices, show connection
status, manage firmware upgrades
and set IP addresses.
Automatic discovery
1. Check that the camera is con-
nected to the network and that
power has been applied.
2. Start AXIS Camera Management. When the AXIS 225FD appears in the window, double-
click it to open the camera’s home page.
3. See page 9 for instructions on how to set the password.
Assign an IP address in a single device
1. Select AXIS 225FD in AXIS Camera Management and click
the Assign IP button.
2. Select Assign the following IP address and enter the IP
address, subnet mask and default router the device will use.
3. Click the OK button.
Assign IP addresses in multiple devices
AXIS Camera Management speeds up the process of assigning IP addresses to multiple devices,
by suggesting IP addresses from a specified range.
1. Select the devices you wish to configure (different models
can be selected) and click the Assign IP button.
2. Select Assign the following IP address range and enter the
range of IP addresses, the subnet mask and default router
the devices will use.
3. Click the OK button.

AXIS 225FD Installation Guide Page 9
ENGLISH DEUTSCH ESPAÑOL ITALIANO
Setting the Password
When accessing the AXIS 225FD for the
first time, the ‘Configure Root Password’
dialog will be displayed on the screen.
4. Enter a password and then re-enter it,
to confirm the spelling. Click OK.
5. Enter the User name: root
Note: The default administrator user
name root is permanent and cannot be
deleted.
6. Enter the password as set in step 2 above, and click OK. If the password is lost, the AXIS
225FD must be reset to the factory default settings. See page 15.
7. If required, click Yesto install AMC (AXIS Media Control), to allow viewing of the video
stream in your browser. You will need administrator rights on the computer to do this.
8. The Live View page of the AXIS 225FD is displayed, complete with links to the Setup
tools, which allow you to customize the camera to your specific needs.
9. Proceed to “Adjust the image” on page 10 to set the focus and zoom and complete the
hardware installation.
Setup - Provides all the
necessary tools for config-
uring the camera to suit
your requirements.
Help - Displays online help
on all aspects of using the
camera.

Page 10 AXIS 225FD Installation Guide
Adjust the image
1. Open the Live View page in the Web interface and make the following adjustments:
2. Loosen the pan adjustment ring and tilt adjustment screws. Hold the lens while turning the
pan adjustment ring, otherwise the lens may rotate with the lock ring and damage or
disconnect the cable.
3. Turn the lens to the desired direction. Do not turn the lens more than 360° as this may
cause the internal cables to disconnect.
4. Once satisfied, gently tighten the pan adjustment ring and tilt adjustment screws to secure
the camera’s position.
5. Turn the image balance ring to set the image to the correct angle.
6. Loosen the zoom puller counterclockwise, rotate the zoom ring and determine the desired
zoom position.
Note: Due to the dome’s refraction, the image might appear slightly out of focus once the dome has
been placed. To compensate, focus on an object slightly closer than the intended area.
Pan adjustment ring
Zoom
Focus puller
Tilt
screw
3 tamper-proof
screws
Unit casing
Dome casing
balance
ring
adjustment
Tilt
screw
adjustment
puller

AXIS 225FD Installation Guide Page 11
ENGLISH DEUTSCH ESPAÑOL ITALIANO
7. Go to the Basic Configuration menu in the Web interface and select Focus. Follow the
on-screen instructions to set the focus.
8. After determining the zoom and focus, lock the zoom puller and the focus puller in
position by rotating the screws clockwise.
Note: The image can be fine-tuned for low lighting conditions.
Go to 'Setup > Video & Image > Advanced' and refer to the help files for more information.
Completing the installation
1. Check that the safety cord is attached to the hook to prevent the dome casing from falling
off the unit casing during the installation process. Be careful not to damage the dome or
scratch the glass.
2. Rotate the black protective shield inside the dome to match the camera’s position.
3. Clean the dome with a dry soft cloth to remove dust and finger prints and use a blower to
remove dust from the lens.
4. Remove the silica gel packet from the
plastic bag and remove the protective paper
from the adhesive strip. Place the silica gel
packet on the camera unit as suggested in
the illustration.
5. Replace the dome casing and tighten the
tamper-proof screws using the allen key.
The installation is now complete.
Note: The silica gel packet will absorb moisture
trapped in the dome casing during installation. Be
sure to attach the packet so it does not obstruct
the camera, LED indicators or cable connections.
Place silica gel
packet
here

Page 12 AXIS 225FD Installation Guide
Other methods of setting the IP address
The table below shows the other methods available for setting or discovering the IP address.
All methods are enabled by default, and all can be disabled.
Operating
system
Notes
UPnP™
Windows
(ME or XP)
When enabled on your computer, the camera is automat-
ically detected and added to “My Network Places.”
Bonjour MAC OSX
(10.4 or later)
Applicable to browsers with support for Bonjour. Navigate
to the Bonjour bookmark in your browser (e.g. Safari) and
click on the link to access the camera’s web pages.
AXIS Dynamic
DNS Service
All A free service from Axis that allows you to quickly and
simply install your camera. Requires an Internet connec-
tion with no HTTP proxy. See www.axiscam.net for more
information.
ARP/Ping All See below. The command must be issued within 2 min-
utes of connecting power to the camera.
View DHCP server
admin pages
All To view the admin pages for the network DHCP server, see
the server’s own documentation.

AXIS 225FD Installation Guide Page 13
ENGLISH DEUTSCH ESPAÑOL ITALIANO
Setting the IP address with ARP/Ping
1. Acquire an IP address on the same network segment your computer is connected to.
2. Locate the serial number (S/N) on the AXIS 225FD product label.
3. Open a Command Prompt on your computer and enter the following commands
(as appropriate for your operating system):
4. Check that the network cable is connected to the camera. Start/restart the camera by
disconnecting and reconnecting power.
5. Close the Command prompt when you see ‘Reply from 192.168.0.125: ...’ or similar.
6. Start your browser, type in http://<IP address> in the Location/Address field and press
Enteron your keyboard.
7. See page 9 for instructions on how to set the password.
Notes:
• The ARP/Ping command must be issued within 2 minutes of connecting power to the
camera.
• To open a command prompt in Windows: from the Start menu, select Run... and type
cmd (or command in Windows 98/ME). Click OK.
• To use the ARP command on a Mac OS X, use the Terminal utility, which is found under
Application > Utilities.
Windows syntax:
arp -s <IP Address> <Serial Number>
ping -l 408 -t <IP Address>
Windows example:
arp -s 192.168.0.125 00-40-8c-18-10-00
ping -l 408 -t 192.168.0.125
UNIX/Linux/Mac syntax:
arp -s <IP Address> <Serial Number> temp
ping -s 408 <IP Address>
UNIX/Linux/Mac example:
arp -s 192.168.0.125 00:40:8c:18:10:00 temp
ping -s 408 192.168.0.125

Page 14 AXIS 225FD Installation Guide
Table 1 - I/O terminal connector block
Table 2 - LED indicators
Pin Function Description
1Output A On the external device output terminals (A and B), there is no distinc-
tion between positive and negative (+ and -). The terminals use a pho-
tocoupler and are electrically isolated from the other internal
circuitry.
The maximum load should not exceed 100mA and the maximum volt-
age should be not more than 50VDC or 35VAC.
2Output B
3Digital Input 1 Connect to GND to activate, or leave floating (or unconnected) to
deactivate.
4Digital Input 2
5RS-485/422-A
(non-inverting)
A half-duplex RS-485/422 interface for controlling auxiliary equip-
ment.
6RS-485/422-B
(inverting)
7GND Ground.
LED Function Color Description
1Network Green Steady for connection to 100 Mbit/s network. Flashes for network
activity.
Amber Steady for connection to 10 Mbit/s network. Flashes for network activ-
ity.
Red Flashes rapid red, together with the Status indicator, for hardware
error.
Unlit No connection.
2Status Green Shows steady green for normal operation.
Amber Shows steady amber during reset to factory default or when restoring
settings.
Red Slow flash for failed upgrade. Rapid flash, together with the Network
indicator, for hardware error.
3Heater Green Steady green when the power connected is sufficient for the heater
i.e. (12V DC min 20W or 24V AC min 25VA)
Red Insufficient power for the heater.
4Power Green Normal operation.
Amber Flashes green/amber during firmware upgrade.

AXIS 225FD Installation Guide Page 15
ENGLISH DEUTSCH ESPAÑOL ITALIANO
Accessing the AXIS 225FD from the Internet
Once installed, your AXIS 225FD is accessible on your local network (LAN). To access the
camera from the Internet, network routers must be configured to allow incoming traffic,
which is usually done on a specific port. Please refer to the documentation for your router for
further instructions.
For more information on this and other topics, please visit the Axis Support Web at
www.axis.com/techsup
Resetting to the Factory Default Settings
This will reset all parameters, including the IP address, to the Factory Default settings:
1. Disconnect power from the camera.
2. Press and hold the Control button and reconnect power.
3. Keep the control button pressed until the Power Indicator flashes amber (this may take up
to 15 seconds).
4. Release the control button.
5. When the Power Indicator displays green (which can take up to 1 minute) the process is
complete and the camera has been reset.
6. Re-install the AXIS 225FD using one of the methods described in this document.
More information
Please refer to the help files and the user’s manual for information on the functionality of the
AXIS 225FD. The AXIS 225FD User’s Manual is available from the Axis Web site at http://
www.axis.com or from the Axis Network Video Product CD.

AXIS 225FD Guide d’installation Page 17
FRANCAIS
AXIS 225FD
Guide d’installation
Ce guide d’installation vous explique comment installer l’ AXIS 225FD Fixed Dome Network
Camera sur votre réseau. Pour d’autres informations sur l’utilisation de ce produit, consultez
le Manuel de l’utilisateur de l’ AXIS 225FD disponible sur le CD d’installation ou surfez sur
www.axis.com.
Étapes de l’installation
1. Vérifiez le contenu de la livraison à l’aide de la liste ci-dessous.
2. Installation du matériel - page 19
3. Branchement des câbles - page 20
4. Paramétrage de l’adresse IP - page 21
5. Définition du mot de passe - page 24
6. Réglage de l‘image - page 25.
Contenu de l’emballage
Article Titre/variantes
Fixed Dome Network Camera AXIS 225FD
Alimentation intérieure
Remarque : l’alimentation varie selon le pays.
Vérifiez que l’alimentation que vous utilisez est
adaptée.
Europe
Royaume-Uni
Australie
États-Unis / Japon
Corée
Kit de montage Clé hexagonale pour vis inviolables
3 vis et chevilles pour murs pleins
Presse-étoupe avec chevilles aveugles
Gabarit de perçage
Sachet de gel de silice
Documentation AXIS 225FDGuide d’installation
CD d’installation d’Axis
Document de garantie
Important !
Ce produit doit être installé
conformément à la réglementation
en vigueur dans votre pays.

Page 18 AXIS 225FD Guide d’installation
Description
Remarques :
• Utilisez des câbles, des presse-étoupe et des conduits adaptés à l’installation et à l’AXIS 225FD,
qui est conforme à l’indice de protection IP66, utilisable en extérieure et anti-effraction.
• Dimensions des conduits : NPT 3/4" -14 (filetage du tuyau).
Important!
Si la caméra AXIS 225FD est montée de manière incorrecte, vous pouvez rencontrer des
problèmes d'humidité, non couverts par la garantie.
Trou de conduit
Trou de conduit
Connecteur
réseau
Bouton de
Trou de
Témoins
(voir tableau 2)
1234
Notez le numéro de série et conservez-le
Le numéro de série (S/N) est nécessaire
pendant l’installation.
pour une utilisation ultérieure.
1
7
commande
Connecteurs
(voir tableau 1)
Terminaux E/S
GND
+ou CA
CA
(latéral)
(bas)
Vis inviolables
Boîtier
Boîtier du dôme
d’alimentation
DEL conduit
Presse-
Câbles
Presse-
étoupe Bague
extérieure
étoupe
Cheville en
caoutchouc

AXIS 225FD Guide d’installation Page 19
FRANCAIS
Installation du matériel
Reportez-vous à l’illustration à la page 18 pour une représentation détaillée de l’ AXIS
225FD.
1. Notez le numéro de série (S/N) de l’étiquette située au bas du boîtier. Le numéro de série
sera nécessaire pendant l’installation.
2. Desserrez les vis inviolables à l’aide de la clé hexagonale fournie et soulevez le boîtier du
dôme. Veillez à ne pas endommager le dôme ni à rayer la vitre.
3. Démontez le presse-étoupe (voir l’illustration).
4. Faites passer les câbles de réseau et d’alimentation ainsi que les
câbles d’E/S à travers la bague extérieure et la cheville en
caoutchouc (poussez le câble de rèseau à travers la fente).
5. Utilisez les chevilles aveugles fournies pour remplir les trous non
utilisés dans la cheville en caoutchouc.
6. Fixez le presse-étoupe au trou de conduit situé sur le côté ou au
bas de la caméra Axis 225FD, en fonction de l’installation.
7. Acheminez les câbles à travers le presse-étoupe, mettez en place la
cheville en caoutchouc en la poussant et serrez la bague extérieure
pour fixer les câbles. Si nécessaire, utilisez du joint silicone pour
rendre le tout bien étanche.
8. Avec le gabarit de perçage, percez trois trous dans le plafond/mur. Le trou du conduit
latéral doit être tourné vers le bas si la caméra est installée à la verticale.
9. Fixez le boîtier au plafond/mur avec les vis et chevilles fournies. Refermez les trous avec
du joint silicone pour rendre le boîtier étanche.
Remarque:
L'utilisation du presse-étoupe est facultative. Pour protéger les câbles contre toute effraction,
utilisez plutôt des conduits anti-effraction.
Le trou du conduit
latéral doit être
tourné vers le bas

Page 20 AXIS 225FD Guide d’installation
Branchement des câbles
1. Branchez le câble réseau au connecteur de réseau de la caméra.
2. Si vous le souhaitez, vous pouvez connecter des dispositifs d’entrée/sortie externes, tels
que des systèmes d’alarme. Reportez-vous à la page 29 pour plus d’informations sur les
broches du connecteur pour terminaux.
3. Branchez l’alimentation au connecteur d’alimentation, de l’une des manières suivantes :
• PoE (Power over Ethernet) via le câble réseau. Cette connexion sera automatiquement
détectée si elle est disponible via le réseau. La PoE alimente la caméra uniquement (par le
réchauffeur).
• Branchez l’alimentation intérieure fournie au connecteur d’alimentation dans le boîtier de la
caméra. De même, cette alimentation intérieure alimente la caméra uniquement (par le
réchauffeur).
• Branchez l’alimentation extérieure au connecteur d’alimentation dans le boîtier de la
caméra. Pour connaître la liste des alimentations extérieures disponibles, consultez les pages
de Support à l’adresse http://www.axis.com/techsup/
4. Vérifiez que les voyants du réseau, d’état et d’alimentation sont allumés et verts. Si vous
souhaitez utiliser le réchauffeur, vérifiez que son voyant est allumé et vert. Consultez le
tableau à la page 29 pour en savoir plus sur les voyants.
5. Reportez-vous à la section “Attribution d'une adresse IP” on page 21 pour savoir
comment assigner une adresse IP à l’ AXIS 225FD.
