AXISQ1615-EMkIINetworkCamera
SafetyInformation
ReadthroughthisInstallationGuidecarefullybeforeinstallingtheproduct.KeeptheInstallation
Guideforfuturereference.
HazardLevels
DANGER
Indicatesahazardoussituationwhich,ifnotavoided,willresultindeathorseriousinjury.
WARNING
Indicatesahazardoussituationwhich,ifnotavoided,couldresultindeathorseriousinjury.
CAUTION
Indicatesahazardoussituationwhich,ifnotavoided,couldresultinminorormoderate
injury.
NO NO
NOTICE TICE TICE
Indicatesasituationwhich,ifnotavoided,couldresultindamagetoproperty.
OtherMessageLevels
Important
Indicatessignicantinformationwhichisessentialfortheproducttofunctioncorrectly.
Note
Indicatesusefulinformationwhichhelpsingettingthemostoutoftheproduct.
5

AXISQ1615-EMkIINetworkCamera
SafetyInstructions
NO NO
NOTICE TICE TICE
•TheAxisproductshallbeusedincompliancewithlocallawsandregulations.
•TousetheAxisproductoutdoors,orinsimilarenvironments,itshallbeinstalledinan
approvedoutdoorhousing.
•StoretheAxisproductinadryandventilatedenvironment.
•AvoidexposingtheAxisproducttoshocksorheavypressure.
•Donotinstalltheproductonunstablepoles,brackets,surfacesorwalls.
•UseonlyapplicabletoolswheninstallingtheAxisproduct.Usingexcessiveforcewith
powertoolscouldcausedamagetotheproduct.
•Donotusechemicals,causticagents,oraerosolcleaners.
•Useacleanclothdampenedwithpurewaterforcleaning.
•Useonlyaccessoriesthatcomplywiththetechnicalspecicationoftheproduct.These
canbeprovidedbyAxisorathirdparty.
•UseonlysparepartsprovidedbyorrecommendedbyAxis.
•Donotattempttorepairtheproductyourself.ContactAxissupportoryourAxisreseller
forservicematters.
•Thepowersupplyshallbepluggedintoasocketoutletinstalledneartheproductand
shallbeeasilyaccessible.
•Usealimitedpowersource(LPS)witheitheraratedoutputpowerlimitedto≤100Wora
ratedoutputcurrentlimitedto≤5A.
Transportation
NO NO
NOTICE TICE TICE
•WhentransportingtheAxisproduct,usetheoriginalpackagingorequivalenttoprevent
damagetotheproduct.
Battery
TheAxisproductusesa3.0VCR2032lithiumbatteryasthepowersupplyforitsinternalreal-time
clock(RTC).Undernormalconditionsthisbatterywilllastforaminimumofveyears.
LowbatterypoweraffectstheoperationoftheRTC,causingittoresetateverypower-up.When
thebatteryneedsreplacing,alogmessagewillappearintheproduct’sserverreport.Formore
informationabouttheserverreport,seetheproduct´ssetuppagesorcontactAxissupport.
Thebatteryshouldnotbereplacedunlessrequired,butifthebatterydoesneedreplacing,contact
Axissupportatwww.axis.com/techsupforassistance.
6

AXISQ1615-EMkIINetworkCamera
Lithiumcoincell3.0Vbatteriescontain1,2-dimethoxyethane;ethyleneglycoldimethylether
(EGDME),CASno.110-71-4.
WARNING
•Riskofexplosionifthebatteryisincorrectlyreplaced.
•ReplaceonlywithanidenticalbatteryorabatterywhichisrecommendedbyAxis.
•Disposeofusedbatteriesaccordingtolocalregulationsorthebatterymanufacturer's
instructions.
7

8

AXISQ1615-EMkIINetworkCamera
InstallationGuide
ThisInstallationGuideprovidesinstructionsforinstallingAXISQ115-EMkIINetworkCamera
onyournetwork.Forotheraspectsofusingtheproduct,seetheUserManualavailableat
www.axis.com
InstallationSteps
1.Makesurethepackagecontents,toolsandothermaterialsnecessaryfortheinstallation
areinorder.Seepage9.
2.Studythehardwareoverview.Seepage10.
3.Studythespecications.Seepage17.
4.Installthehardware.Seepage19.
PackageContents
•AXISQ115–EMkIINetworkCamera
•4–pinI/Oconnectorblockforconnectingexternaldevices
•2–pinRS485/422connectorblock(x2)
•Wallmount
•TorxscrewdriverT20
•Printedmaterials
-InstallationGuide(thisdocument)
-Extraserialnumberlabel(2x)
-AVHSAuthenticationkey
OptionalAccessories
Forinformationaboutavailableaccessories,includingpoweraccessoriesandoutdoorhousings
seewww.axis.com
9

AXISQ1615-EMkIINetworkCamera
HardwareOverview
1unshield
2unshieldadjustmentscrews
3Productnumber(P/N)&erialnumber(/N)*
4Topcover
5Heater.Caution!Maybehot.
6Networkcamera
7afetywiretab
8Cableholeswithcablegland
9Bottomcover
10Networkconnector
11Bottomcoverscrews(4x)
12Cablecoverscrews(2x)
13Cablecover
10

AXISQ1615-EMkIINetworkCamera
*Theserialnumbermayberequiredduringinstallation.
1Cablegland
2Gasket
3Cablehole
4Cablegland
5Networkcable(routethroughwallbracket)
6Bottomcover
7Bottomcoverscrews(4x)
8Wallmount
9Bracketadjustmentscrew
LEDIndicators
Note
•TheStatusLEDcanbeconguredtobeunlitduringnormaloperation.Tocongure,go
toSetupSystemOptionsPorts&DevicesLED.Seetheonlinehelpformore
information.
11

AXISQ1615-EMkIINetworkCamera
•TheStatusLEDcanbeconguredtoashwhileaneventisactive.
•TheStatusLEDcanbeconguredtoashforidentifyingtheunit.GotoSetupSystem
OptionsMaintenance.
StatusLEDIndication
GreenSteadygreenfornormaloperation.
AmberSteadyduringstartup.Flasheswhenrestoringsettings.
RedFlashesredforrmwareupgradefailure.
Note
TheNetworkLEDcanbedisabledsothatitdoesnotashwhenthereisnetworktrafc.
Tocongure,gotoSetupSystemOptionsPorts&DevicesLED.Seetheonline
helpformoreinformation.
NetworkLEDIndication
GreenSteadyforconnectiontoa100Mbit/snetwork.Flashesfor
networkactivity.
AmberSteadyforconnectiontoa10Mbit/snetwork.Flashesfor
networkactivity.
UnlitNonetworkconnection.
Note
ThePowerLEDcanbeconguredtobeunlitduringnormaloperation.Tocongure,go
toSetupSystemOptionsPorts&DevicesLED.Seetheonlinehelpformore
information.
PowerLEDIndication
GreenNormaloperation.
AmberFlashesgreen/amberduringrmwareupgrade.
HosingLEDIndicators
Note
ThehousingLEDreferredtointhetablebelowislocatedinthehousing.
Alarmeventswillbetriggeredthroughthecamera’sinputport.
12

AXISQ1615-EMkIINetworkCamera
HousingLED
(fanandheater)Indication
GreenNormaloperation.
FlashinggreenSingleash:Heatererror
Doubleash:Fanerror
Tripleash:Generalerror
ContactyourAxisresellerforinformationaboutsparepartsandtroubleshooting.
StatsLEDBehaviorforFocsAssistant
ThestatusLEDasheswhentheFocusAssistantisactive.
ColorIndication
RedTheimageisoutoffocus.
Adjustthelens.
AmberTheimageisclosetofocus.
Thelensneedsnetuning.
GreenTheimageisinfocus.
BzzerSignalforFocsAssistant
BuzzerLens
FastintervalOptimallyadjusted
MediumintervalLessoptimallyadjusted
SlowintervalPoorlyadjusted
StatsLEDBehaviorandBzzerSignalforLevellingAssistant
ForinformationontheFunctionbuttonusedforlevellingthecamera,seeConnectorsandButtons.
Pressandholdthefunctionbutton(2)formorethantwosecondstolevelthecamera.
•Whenthecameraislevel,bothLEDsaresteadygreen,andthebeepiscontinuous.
•Whenthecameraisnotlevel,theLEDsashacombinationofred,greenandorange,and
thebeepoccursatslowintervals.
BothLEDsbrieyashgreentoindicatethatthelevellingisgettingbetter.
13

AXISQ1615-EMkIINetworkCamera
ConnectorsandBttons
Forspecicationsandoperatingconditions,seepage17.
NetworkConnector
RJ45EthernetconnectorwithPoweroverEthernet(PoE).
NO NO
NOTICE TICE TICE
Duetolocalregulationsortheenvironmentalandelectricalconditionsinwhichtheproduct
istobeused,ashieldednetworkcable(STP)maybeappropriateorrequired.Allcables
connectingtheproducttothenetworkandthatareroutedoutdoorsorindemanding
electricalenvironmentsshallbeintendedfortheirspecicuse.Makesurethatthenetwork
devicesareinstalledinaccordancewiththemanufacturer’sinstructions.Forinformation
aboutregulatoryrequirements,seeElectromagneticCompatibility(EMC)2.
I/OConnector
Usewithexternaldevicesincombinationwith,forexample,tamperingalarms,motiondetection,
eventtriggering,timelapserecordingandalarmnotications.Inadditiontothe0VDCreference
pointandpower(DCoutput),theI/Oconnectorprovidestheinterfaceto:
•Digitaloutput–ForconnectingexternaldevicessuchasrelaysandLEDs.Connected
devicescanbeactivatedbytheVAPIX®ApplicationProgrammingInterface,output
buttonsontheLiveViewpageorbyanActionRule.Theoutputwillshowasactive
(shownunderSystemOptionsPorts&Devices)ifthealarmdeviceisactivated.
•Digitalinput–Analarminputforconnectingdevicesthatcantogglebetweenanopen
andclosedcircuit,forexample:PIRs,door/windowcontacts,glassbreakdetectors,
etc.Whenasignalisreceivedthestatechangesandtheinputbecomesactive(shown
underSystemOptionsPorts&Devices).
Note
TheI/Oconnectorisconnectedtothehousing(fan/heater)ondelivery.Inthecaseofafan
orheatererror,aninputsignalwillbetriggeredinthecamera.Setupanactionruleinthe
cameratocongurewhichactionthesignalshalltrigger.Forinformationabouteventsand
actionrules,seetheUserManualavailableonwww.axis.com
AdioConnector
TheAxisproducthasthefollowingaudioconnectors:
•Audioin(pink)–3.5mminputforamonomicrophone,oraline-inmonosignal.
•Audioout(green)–3.5mmoutputforaudio(linelevel)thatcanbeconnectedto
apublicaddress(PA)systemoranactivespeakerwithabuilt-inamplier.Astereo
connectormustbeusedforaudioout.
14

AXISQ1615-EMkIINetworkCamera
3.5mmaudio
connectors(stereo)
1Tip2Ring3Sleeve
AudioInputBalanced:‘Hot’signal
Microphone/Linein
Unbalanced:Microphone/Line
in
Balanced:‘Cold’signal
Microphone/Linein
Unbalanced:Unused
Ground
AudioOutputLineout,mono(stereo
connectorcompatible)Lineout,mono(stereo connectorcompatible)
Ground
Theinternalmicrophoneisusedbydefault;theexternalmicrophoneisusedwhenconnected.Itis
possibletodisabletheinternalmicrophonebyconnectingaplugtothemicrophoneinput.
RS485/RS422Connector
TwoterminalblocksforRS485/RS422serialinterfaceusedtocontrolauxiliaryequipmentsuchas
pan-tiltdevices.
SDcardslot
NO NO
NOTICE TICE TICE
•RiskofdamagetoSDcard.Donotusesharptools,metalobjectsorexcessiveforcewhen
insertingorremovingtheSDcard.Useyourngerstoinsertandremovethecard.
•Riskofdatalossandcorruptedrecordings.DonotremovetheSDcardwhiletheproduct
isrunning.DisconnectpowerorunmounttheSDcardfromtheAxisproduct’swebpages
beforeremoval.
ThisproductsupportsmicroSD/microSDHC/microSDXCcards(notincluded).
ForSDcardrecommendations,seewww.axis.com
ControlBtton
Forlocationofthecontrolbutton,seeHardwareOverviewonpage10.
Thecontrolbuttonisusedfor:
•Resettingtheproducttofactorydefaultsettings.Seepage23.
15

AXISQ1615-EMkIINetworkCamera
•ConnectingtoanAXISVideoHostingSystemserviceorAXISInternetDynamicDNS
Service.Formoreinformationabouttheseservices,seetheUserManual.
FnctionBtton
Thefunctionbuttonhasmultiplefunctions:
•Levellingassistant–Thisfunctionhelpstoensurethecameraislevel.Pressthebutton
forabout3secondstostartthelevellingassistantandpressagaintostoptheleveling
assistant.ThestatusLEDandbuzzersignalassistlevellingofthecamera,seetatusLED
BehaviorandBuzzerignalforLevellingAssistantonpage13.Thecameraislevelwhen
thebuzzerbeepscontinuously.
•Focusassistant–ThisfunctionisusedforenablingtheFocusAssistant.Toenable
thefocusassistant,pressandveryquicklyreleasethebutton.Pressagaintostopthe
focusassistant.
ConnectionDiagrams
I/OConnector
10VDC(-)
2DCoutput12V,max50mA
AI/Oconguredasinput
BI/Oconguredasoutput
16

AXISQ1615-EMkIINetworkCamera
Specications
OperatingConditions
ProductTemperatureHumidityRH(condensing)
AXISQ115–E
MkII-30°Cto0°C (-22°Fto140°F)withPoE;down
to-40°C(-40°F)withHighPoE
10–100%
Connectors
I/Oconnector
4–pinterminalblock
Foranexamplediagram,seeConnectionDiagramsonpage16.
FunctionPinNotesSpecications
0VDC(-)1
DCoutput2Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.12VDC Maxload=50mA
Digitalinput–Connecttopin1toactivate,
orleaveoating(unconnected)todeactivate.0tomax30VDC Congurable (Inputor
Output)
3–
4
Digitaloutput–Connectedtopin1when
activated,oating(unconnected)when
deactivated.Ifusedwithaninductiveload,
e.g.arelay,adiodemustbeconnectedin
parallelwiththeload,forprotectionagainst
voltagetransients.
0tomax30VDC,open
drain,100mA
17

AXISQ1615-EMkIINetworkCamera
AdioConnector
3.5mmaudio
connectors(stereo)
1Tip2Ring3Sleeve
AudioInputBalanced:‘Hot’signal
Microphone/Linein
Unbalanced:Microphone/Line
in
Balanced:‘Cold’signal
Microphone/Linein
Unbalanced:Unused
Ground
AudioOutputLineout,mono(stereo
connectorcompatible)Lineout,mono(stereo connectorcompatible)
Ground
Theinternalmicrophoneisusedbydefault;theexternalmicrophoneisusedwhenconnected.Itis
possibletodisabletheinternalmicrophonebyconnectingaplugtothemicinput.
RS485/422Connector
Two2-pinterminalblocksforRS485/RS422serial
interface.Theserialportcanbeconguredtosupport:
•Two-wireRS485halfduplex
•Four-wireRS485fullduplex
•Two-wireRS422simplex
•Four-wireRS422fullduplexpointtopoint
communication
FunctionPinNotes
RS485Balt
RS485/422RX(B)
1
RS485Aalt
RS485/422RX(A)
2
RXpairforallmodes(combinedRX/TXfor2-wireRS485)
RS485/RS422TX(B)3
RS485/RS422TX(A)4
TXpairforRS422and4-wireRS485
Important
Therecommendedmaximumcablelengthis30m(98.4ft).
18

AXISQ1615-EMkIINetworkCamera
InstalltheHardware
Dothefollowingtoinstallthewallbracket:
Note
•Theweightofthecamerais3525g(7.7lb).Checkthatthematerialisstrongenoughto
supportthisweight.
•Usinganyotherthantheprovidedcableglandmaycausewatertoseepinanddamage
theproduct.
•Alwaysuseashieldednetworkcable(STP)intendedforoutdoorusebetweenthe
Axisproductandtheendpointandensurethattheendpointisproperlygrounded.
InstallationsofAxisproductsusingashieldednetworkcable(STP)andaproperly
groundedendpointhavebeentestedtocomplywithindustryimmunitystandardlevels
suchassurgeprotection.Anyotherinstallationmethodwillvoidthewarrantyand
leavetheunitatarisk.
•Anoptionalcablewithadiameterof4.0mm-5.5mmshouldberoutedthrougha
separatecablegland.SeeHardwareOverviewonpage10.
1.Usethesupplieddrilltemplatetoprepareawallorpoleforinstallationofthewall
bracket.
2.Routethenetworkcablethroughthewallbracket,andthroughthebracketadapter.
Leaveapproximately30cm(11.8”)ofcableforconnectingtothecamera.
3.Installthewallbracketonawall,ceiling,orpoleusingscrewsandplugsappropriatefor
thematerial(e.g.wood,metal,sheetrock,stone).
Dothefollowingtoroutethenetworkandother(optional)cables:
1.Loosenthecablecoverscrews;detachthecablecoverfromthebottomcover.
2.Removethecap,theplugandthegasketfromthecableglandtobeused.
3.Routethenetworkcablethroughthecap.
4.Slidethenetworkcablethroughtheslitinthegasket.
5.Routethenetworkcablethroughthecablegland.
.Pressthegasketintothecableglandandscrewthecaponrmly.
Dothefollowingtoattachthecameratothewallbracket
1.Placethecamerawiththebottomcoveronthewallbracketandtightenthebracket
screws.
2.Replacethecablecoverandtightenthescrews.
3.Connectthecables.SeeConnecttheCablesonpage20.
4.Loosenthebracketadjustmentscrewtofocusthecamera;focusthecameraaccording
totheinstructionsunder.
5.Alsoseetoaccessthevideostream.
.Attachthesafetywireinthetopcovertothetabinthebottomcover.Seeimageunder
HardwareOverviewonpage10.
19

AXISQ1615-EMkIINetworkCamera
7.OptionallyinsertanSDmemorycard(notincluded)intotheSDHC(SecureDigitalHigh
Capacity)cardslot.AstandardorhighcapacitySDcardisrequiredtostoreimages
locallyinthecamera.
ConnecttheCables
NO NO
NOTICE TICE TICE
Duetolocalregulationsortheenvironmentalandelectricalconditionsinwhichthe
productistobeused,ashieldednetworkcable(STP)maybeappropriateorrequired.Any
networkcablesthatareroutedoutdoorsorindemandingelectricalenvironmentsshallbe
shielded(STP)andintendedfortheirspecicuse.
Note
TolocatethedifferentcomponentsseeillustrationsunderHardwareOverviewonpage10.
1.Optionallyconnectexternalinput/outputdevices,seeConnectorsonpage17.
2.Connectthenetworkcabletothenetworkconnectorinthehousing.
AccesstheProdct
AXISIPUtilityandAXISCameraManagementarerecommendedmethodsforndingAxisproducts
onthenetworkandassigningthemIPaddressesinWindows®.Bothapplicationsarefreeandcan
bedownloadedfromwww.axis.com/techsup
Theproductcanbeusedwithmostoperatingsystemsandbrowsers.Werecommendthefollowing
browsers:
•InternetExplorer®withWindows®
•Safari®withOSX®
•ChromeTMorFirefox®withotheroperatingsystems.
Formoreinformationaboutusingtheproduct,seetheUserManualavailableatwww.axis.com
Adjstfocsandzoomforincldedlens
1.Accesstheproduct’swebpageandgotoSetupBasicSetupFocus&Zoom.
2.UndertheBasictab,adjustZoomlevelandthenclickPerformautofocus.
3.Foradditionalfocusadjustments,gototheAdvancedtab.
Note
Ifthecameradoesnotfocus,trytocalibratetheopticsinSystemOptionsMaintenance,
andperformautofocusagain.
20
