Axis Q6215-LE User manual

AXISQ6215-LENetworkCamera
RepaintingInstructions

AXISQ6215-LENetworkCamera
Impactonwarranty
Impactonwarranty
ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat
www.axis.com/warranty-implication-when-repainting
Riskswithrepainting
ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training
ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:
ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD
damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.
Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.
Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.
Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems
withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe
parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.
2

AXISQ6215-LENetworkCamera
owtorepainttheproduct
owtorepainttheproduct
Preparations
•Ifapplicable,disassembletheeuipmentaccordingtotheinstructionsinthisdocument.
•Cleanallpartstoberepaintedthoroughlytoremovegrease,dust,oroil.
•Toensurereassemblyandfunctionalityoftheproduct,maskopeningsforscrews,LEDindicators,ormicrophonesbefore
painting.
Pretreatmentofparts
Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentshouldbedoneforthenewpaintto
adhereaswellaspossible.Cleanthepartsproperlytoremoveoil,greaseanddust.
Formoreinformationonthematerialsusedintheproduct,seeitsdatasheetatwww.axis.com
Powdercoatedparts-Useaprimer.Alternatively,removetheoriginalpowdercoatingdowntothebasematerial,usingne
sandpaper,andcleanthepartsbeforepainting.
Anodisedandchromatedparts-Useaprimer.
Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.
Plastic-Useaprimer.
isassembly
1.Insertascrewdriverunderthewiperandpushitasclosetothefasteningaspossible.Pullthewiperstraightout
toremoveit.
CAUTION
•Pullingonthewiperarmwillbendthewiperarm.
•Pushingthewiperacrossthewindowwilldamagethewipermotor.
3

AXISQ6215-LENetworkCamera
owtorepainttheproduct
2.Unscrewthefourscrewsfromthemainwindow.
3.Disconnecttheheaterconnector.
Note
Donottouchthecircuitboardontheinsideofthewindow.
4

AXISQ6215-LENetworkCamera
owtorepainttheproduct
4.UnscrewthefourscrewsfromtheIRwindowandremovetheIRwindow.
5.Removethescrewsandwashersfromthefoot.
5

AXISQ6215-LENetworkCamera
owtorepainttheproduct
6.RemovetheSDcardcover.
Repainting
Masking
Maskthefollowingparts:
•TheIRwindow
•Themainwindow
•Thecontrolbutton
•Thescrewholesinthefoot
•TheSDcardslot
•TheIRwarninglabel
•TheAxislogo
6

AXISQ6215-LENetworkCamera
owtorepainttheproduct
Repaintingtheparts
RepaintthecameraunitandtheSDcardcover.
1Cameraunit
2SDcardcover
1.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.
2.Letthepaintdry.
3.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.
4.Whenthepaintisdry,removethemasking.
7

AXISQ6215-LENetworkCamera
owtorepainttheproduct
Reassembly
1.Assemblethescrewsandthewasherswiththefoot.
2.PuttheSDcardcoverbackinitsplace.
3.Connecttheheaterandassemblethemainwindow.
4.AssembletheIRwindow.
5.Pushthewiperintotheholder.
8

RepaintingInstructionsVer.M1.5
AXISQ6215-LENetworkCameraDate:April2019
©AxisCommunicationsAB,2019PartNo.T10137739
