AXM Paper Space Scale Models Delta IV Medium User manual

© 2015
Delta IV Medium Instruction Manual

Building the Delta IV Medium
The Delta IV Medium variant consists of only on CBC. The assembly is exactly as building a CBC
for the Heavy variant with the exception of the attachments. The attachments for the Medium Plus
variant are only for the Solid Rocket Motors (SRM).
Depending on the fairing and the number of SRMs, there are 4 types of Delta IV Medium variants:
-Medium
-Medium Plus (4-2)
-Medium Plus (5-2)
-Medium Plus (5-4)

Building the fairings
There are two types of fairings for the Medium variant: a 4 m diameter and a 5 m diameter

Building the Solid Rocket Motors

Types of Solid Rocket Motors
2 SRMs configuration: SRMs 1 and 2
4 SRMs configuration: SRMs 1-2-3-4
SRM 1 & 2
SRM 3 & 4

Positioning the SRMs on the CBC
