Axor 34133XX1 34213XX1 User manual

Citterio M
34133XX1
Citterio M
34213XX1
Installation Instructions / Warranty

2
Installation Considerations
For best results, Hansgrohe recommends that this unit be installed by a licensed, professional
plumber.
Please read over these instructions thoroughly before beginning installation. Make sure that
you have all tools and supplies needed to complete the installation.
This faucet can be used with a continuous flow water heater if the flow pressure is at least 20
psi. For best service, the hot and cold supplies should be at equal pressure.
This faucet requires 1/2" supply lines (not included).
•
•
•
•
Technical Information
Recommended water pressure 14.7 - 72.5 psi
Max. water pressure 145 psi
Recommended hot water temp. 120� - 140� F*
Max. hot water temp 165�F*
Hole size in mounting surface
valves 1-1/4"
spout 1 3/8"
Max. mounting surface depth 1 3/8"
Flow rate 2.2 gpm
*Please know and follow all applicable local plumbing codes when setting the temperature on the water heater.
Axor Citterio M widespread lavatory faucet 34133XX1
Axor Citterio M widespread bidet faucet 34213XX1
34133XX134213XX1

3
Installation
Install the friction washer and fiber washer on the valve.
Push the valve up through the hole in the mounting surface.
Install the sealing ring, escutcheon, and nut.
Rest the valve assembly on the mounting surface (1).
Tighten the screws (2).
Push the handles into place (3).
Push the spout shank up through the mounting surface
(1).
Install the sealing ring, escutcheon, and shaft fastening
ring (2).
The notch on the shaft fastening ring and the notch
on the shank must face away from the basin.
Install the fiber washer, friction washer, and mounting
nut (3). Tighten the mounting nut.
1
2
3
2
1
3

4
Check the alignment of the handles.
If one is not aligned, pull it off (1), turn it slightly (2), and
reinstall it (3).
Install the glide ring and the o-ring.
2
1
3

5
Lubricate spout the o-ring.
Push the spout into place.
Tighten the spout screw with a 2 mm Allen wrench.
Tighten the mounting nut screws.
Install the drain pull rod.

6
Thread the connecting hoses into the spout shank by
hand.
Connect the hoses to the valves with the compression
fittings. Tighten the fittings using two wrenches. Do not
allow the hoses to twist.
Install the hot and cold
supply lines (not included).
Install the pop-up drain.
onoff

7
Install the pop-up drain
Remove the plunger assembly.
Unscrew the drain outlet flange from the tee.
Unscrew the tailpiece from the tee. Wrap the
threads with plumbers’ thread tape and replace.
Install the white, flexible sealing gasket to the
flange. Place it in the sink outlet.
From under the sink, install the black mack gas-
ket, white friction ring and retainer nut to the
flange. Do not tighten the nut against the bottom
of the sink at this time.
Thread the tee and tailpiece to the flange. The
pivot must face the faucet. If necessary, turn the
drain assembly.
Tighten the retainer nut.
Place the plunger assembly in the drain.
Install the horizontal rod so that the end goes
through the loop in the bottom of the height
adjuster.
Install and hand tighten the pivot ball nut.
Attach the swivel connector to the end of the
horizontal rod.
Attach the swivel connector to the end of the pull rod.
Position as desired and tighten with a small, flat bladed
screwdriver.
plunger
flange
sealing gasket
mack gasket
friction ring
retainer nut
horizontal rod
height adjuster
pivot ball nut
swivel connector
pull rod
tee
tailpiece

8
Cleaning (34133 only)
If the flow of water diminishes over time, unscrew the
aerator using the service key.
Rinse the aerator with clear water.
Reinstall the aerator. Tighten it with the service key.

9
Replacement Parts
1 aerator 98926000
2 handle 34095XX0
3 color-ring set 98927000
4 spout 98928XX0
5 nut 98929XX0
6 pull rod 96657XX0
7 cold cartridge 94008000
8 hot cartridge 94009000
9 fixation set 13961000
10 connection hose 94071001
11 handle fixing set 98932000
12 flange 98930XX0
13 aerator 97360XX0
14 ball joint 97362XX0
15 spout 98931XX0
16 aerator service key 98987000
17 compression fittings (pr.) 88513000compression fittings (pr.) 8851300088513000
XX = color
00 = chrome
82 = brushed nickel
11
2
1
4
3
7
8
9
6
10
14
15
16
5
12
13
17
30x1.5

10
Limited Lifetime Consumer Warranty
This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This
warranty is limited to Hansgrohe products which are purchased by a consumer in the United States after March 1, 1996, and
installed in either the United States or Canada.
WHO IS COVERED BY THE WARRANTY
This warranty extends to the original consumer purchaser only. This warranty is non-transferable.
WHAT IS COVERED BY THE WARRANTY
This warranty covers only your Hansgrohe manufactured product. Hansgrohe warrants this product against defects in material
or workmanship as follows: Hansgrohe will repair at no charge for parts only or, at its option, replace any product or part of
the product that proves defective because of improper workmanship and/or material, under normal installation, use, service
and maintenance. If Hansgrohe is unable to provide a replacement and repair is not practical or cannot be timely made,
Hansgrohe may elect to refund the purchase price in exchange for the return of the product.
LENGTH OF WARRANTY
Replacement or repaired parts of products will be covered for the term of this warranty as stated in the following two sentenc-
es. If you are a consumer who purchased the product for use primarily for personal, family, or household purposes, this war-
ranty extends for as long as you own the product and the home in which the product is originally installed. If you purchased
Cleaning Recommendation for Hansgrohe Products
Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the
market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain criteria when
cleaning.
Cleaning Materials for Faucets and Showers
Acids are a necessary ingredient of cleaning materials for removing lime, however please pay attention to the following points
when cleaning faucets and showers:
Only use cleaning materials which are explicitly intended for this type of application.
Never use cleaning materials which contain hydrochloric, formic, phosphoric, or acetic acid, as they cause considerable
damage.
Never mix one cleaning material with another.
Never use cleaning materials or appliances with an abrasive effect, such as unsuitable cleaning powders, sponge pads,
or micro fiber cloths.
Cleaning Instructions for Faucets and Showers
Please follow the cleaning material manufacturer’s instructions. In addition, pay attention to the following points:
Clean the faucets and showers as and when required
Use the amount of cleaning product and the amount of time recommended by the manufacturer. Do not leave the cleaner
on the fixture longer than necessary.
Regular cleaning can prevent calcification.
When using spray cleaners, spray first onto a soft cloth or sponge. Never spray directly onto the faucet as droplets can
enter openings and gaps and cause damage.
After cleaning, rinse thoroughly with clean water to remove any cleaner residue.
Important
Residues of liquid soaps, shampoos, and shower foams can also cause damage, so rinse with clean water after using.
Please note: if the surface is already damaged, the effect of cleaning materials will cause further damage.
Components with damaged surfaces must be replaced or injury could result.
Damage caused by improper treatment is not covered under the warranty.
•
•
•
•
•
•
•
•
•

11
the product for use primarily for any other purpose, including, without limitation, a commercial purpose, this warranty extends
only (i) for 1 year, with respect to Hansgrohe and Commercial products, and (ii) for 5 years, with respect to AXOR products.
THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR:
A. Conditions, malfunctions or damage not resulting from defects in material or workmanship.
B. Conditions, malfunctions or damage resulting from (1) normal wear and tear, improper installation, improper mainte-
nance, misuse, abuse, negligence, accident or alteration, or (2) the use of abrasive or caustic cleaning agents or “no-
rinse” cleaning products, or the use of the product in any manner contrary to the product instructions. (3) Conditions in the
home such as excessive water pressure or corrosion.
C. Labor or other expenses for the disconnection, deinstallation, or return of the product for warranty service, or for installa-
tion or reinstallation of the product (including but not limited to proper packaging and shipping costs), or for installation or
reinstallation of the product.
D. Accessories, connected materials and products, or related products not manufactured by Hansgrohe.
TO OBTAIN WARRANTY PARTS OR INFORMATION
Contact your Hansgrohe retailer, or contact Technical Service at:
Hansgrohe Inc.
1492 Bluegrass Lakes Parkway
Alpharetta GA 30004
Toll-free [phone].
In requesting warranty service, you will need to provide
1. The sales receipt or other evidence of the date and place of purchase.
2. A description of the problem.
3. Delivery of the product or the defective part, postage prepaid and carefully packed and insured, to Hansgrohe Inc. 1492
Bluegrass Lakes Parkway, Alpharetta, Georgia 30004, Attention: Technical Service, if required by Hansgrohe.
When warranty service is completed, any repaired or replacement product or part will be returned to you postage prepaid.
EXCLUSIONS AND LIMITATIONS
REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE PRICE) AS PROVIDED UNDER
THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER. HANSGROHE NEITHER ASSUMES NOR AUTHORIZES
ANY PERSON TO CREATE FOR IT ANY OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT.
HANSGROHE SHALL NOT BE LIABLE TO PURCHASER OR ANY PERSON FOR ANY INCIDENTAL, SPECIAL, OR CONSE-
QUENTIAL DAMAGES, ARISING OUT OF BREACH OF THIS WARRANTY OR ANY IMPLIED WARRANTY (INCLUDING
MERCHANTABILITY).
Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclu-
sion may not apply to you. This warranty gives you specific legal rights, and you may have other rights which vary from State
to State. You may be required by law to give us a reasonable opportunity to correct or cure any failure to comply before you
can bring any action in court against us under the Magnuson-Moss Warranty Act.
PRODUCT INSTRUCTIONS AND QUESTIONS
Upon purchase or prior to installation, please carefully inspect your Hansgrohe product for any damage or visible defect.
Prior to installing, always carefully study the enclosed instructions on the proper installation and the care and maintenance of
the product. If you have questions at any time about the use, installation, or performance of your Hansgrohe product, or this
warranty, please call or write to us or call us toll-free at 800 334 0455.

Hansgrohe, Inc. •1490 Bluegrass Lakes Parkway •Alpharetta, GA 30004
Tel. [phone] •Fax [phone]
www.hansgrohe-usa.com
US - Installation Instructions •Part No. 90445721 •Revised 04/2008
