Axvue A1HD User manual

1. LED
2. Menu/Pan/Tilt
3. Volume
4. Brightness
5. Cam/Split
6. VOX
7. Zoom/Talk Back (OK)
8. Microphone
9. Power/Video
10. Speaker
11. DC Jack
12. Kickstand
13. Baery Compartment
Red LED flashs Red LED stop flashing
Camera:
7. DC Jack
8. Wall Mounng Hole
Get to know us at: www.axvue.com
Please read the following instrucons and warnings carefully
Keep this instrucon manual for the future.
For technical support see the FAQ page.
For adult use only.
SETUP & USE
INSTRUCTION MANUAL
Model- A1HD
Revised at 03/2021
AXVUE A1HD VIDEO BABY MONITOR
with 5.0" HD LCD Screen and Two Cameras
Step 2:
Step 3:
Step 4:
Step 5:
Make sure the power adapter is plugged into
camera and turn on the camera by pressing
Power/Code “ ” buon for 3 seconds.
FEATURES & COMPONENTS
Press
Power & Low Baery Sound Lights
*LED
-Store this product out of the reach of babies (at least 3 feets (0.9 m)
away from the crib). A strap wound around the baby’s neck may result in
asphyxiaon. Use a safety clip to clamp the power cord and keep it out
of baby’s reach. Do not use other extension cords. Only use the power
adapter provided.
-Do not touch the exposed part if the adapter is connected with power.
-Test regularly before inial use or when change the posion of camera.
-Avoid placing the product in humid place or contacng with liquid. (such as bathtub, sink, etc.)
-Do not apply heat to the product.(such as stoves, radiators, etc.)
-Using the product in venlated place. Avoid placing it on sofas, cushions, beds or other places which
may block venlaon.
-The product only can be operated by adult. Do not allow baby to play with it. Tiny accessories are
contained, please be careful when unpack and install it.
THIS PRODUCT CAN NOT SUBSTITUE PARENT’S SUPERVISION
ON YOUR CHILD.
WARNING
-Only use the recommended rechargeable baery. Please contact us if you need to change it.
For the contact list, please refer to the last page of the instrucon.
-Please clean the baery compartment before using it.
-Avoid short circuits the power supply terminal.
-Remove the baery when you are not using it or when running out of power.
-Keep the baery away from children.
-Dispose of the empty baery properly.
BATTERY WARNING
4. Temperature Sensor
5. Speaker
6. Power/Code
Monitor:
Step 1: Place the monitor display in living room, bedroom or any place you want to watch your baby.
Use adapter to connect camera with electrical outlet.
Step 2: Turn on monitor by pressing Power/Video
“ ” buon for 5 seconds unl “ axvue ” logo or
video shows up on the screen.
Step 3: Press Power/Video
“ ” buon to turn off the video if you only need to hear the voice.
Step 4: Turn off the monitor completely by pressing and holding Power/Video
“ ” buon for
5 seconds.
Please charge the battery for at least 8 hours before using
the product.
Step 1: Test recepon first, put camera in a suitable place that
will provide you the best view of your baby in the crib (Note:
Do not hang up the camera firmly unl inial installaon test
is completed). Plug adapter into wall outlet and turn on the
camera.
Step 2: Turn on monitor by pressing and holding
Power/Video
“ ” buon for 5 seconds unl “axvue” shows up, then
video will show up on the screen immediately. If video does
not show up, please refer to “TO PAIR MONITOR AND
CAMERA (ADD CAMERA)” at next page. If video shows up, the
inial installaon test is completed, then you can set up the
camera according to the instrucon below.
Set Up Camera: Place camera on a flat surface, such as
wardrobe or shelf (Figure 1). Or hang it on the wall (Figure 2).
No maer wherever to place the camera, please make sure to
keep it away from the crib for at least 3 feet and all power
cords should be placed behind the camera properly. Then
adjust the angle of camera lens unl the enre crib shows up
on the display, or adjust it to the best angle that you think to
watch your baby.
The monitor and camera are paired before shipment. If it is unpaired for some reason, please refer
to the following steps:
Step 1: Make sure the camera and monitor are in the same space.
Step 1: Charge the baery for at least 6 ~ 8 hours before using portable / baery mode.
Step 2: Make sure the adapter is plugged into camera.
Step 3: The baery life can be up to 10 hours if it is fully charged.
Baery life will be shortened if recharging it connuously. Unplug the AC adapter when you are not
using it for a long me.
Please charge the baery for 6~8 hours before using the product.
TO USE PORTABLE/BATTERY MODE
TO USE PLUGGED-IN MODE
TO PAIR MONITOR AND CAMERA (ADD CAMERA)
3 feet
3 feet
Figure 1
Figure 2
8
1
3
2
5
4
7
6
Turn on the monitor by pressing and
holding Power/Video “ ”buon
for 5 seconds.
Keep the distance between sensor and body at
least 0.6 inch for accurate temperature result.
1. Night-Vision LED
2. Lens
3. Microphone
0.6 in
Adapters:
× 3× 1 × 2

6X DIGITAL ZOOM IN & OUT
The zoom opon enables you to get a closer and clear view on screen. Press the Zoom/Talk Back “ ”
buon for mes to 6x zoom in the video on screen or return to the normal size.
TWO-WAY COMMUNICATION
Your baby is always eager to hear your voice when crying. Press and hold the Zoom/Talk Back “ ”
buon on the monitor to acvate two-way communicaon mode. When you see this icon “ ” shows up
on the screen, then you can talk with your baby. Release the buon to end this mode.
NIGHT VISION
The infrared LEDs and the lens are used for night vision which will light up automacally aer you turn off
the light. The image on the monitor will turn to black and white when camera is in a low-light or dark room.
SOUND LIGHT
The LED sound light bar on the top of the monitor will light up in red based on the level of baby’s sounds.
Louder sounds will acvate more LEDs to light up.
VOLUME CONTROL
Turn up the volume to hear every lile sound from your baby (like cooing), turn down the volume to
monitor louder sounds and crying from baby. Easily adjust to the volume level you want by pressing Volume
“ ” buon, and then choose le “ ” or right “ ” to adjust.
BRIGHTNESS ADJUSTMENT
Screen brightness can be adjusted according to the light intensity of your room. adjust lighter or darker
video image by using brightness control funcon. press Brightness “ ” buon at the right of monitor, and
then choose le “ ” or right “ ” to adjust to the brightness you want.
VIDEO ON/OFF
To preserve baery life when monitor is not plugged into AC outlet, the screen will turn off by pressing
Power/Video “ ” buon, under this paern, monitor sll can get audio and sound from camera
detecon. Press Power/Video “ ” buon again, screen will turn on to resume video & audio
monitoring.
6
SETUP & USE ( connued )
FCC INFORMATION
This device complies with part 15 of FCC Rules. Operaon is subject to
the following two condions: (1) The device may not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operaon.
CAUTION
Changes and modificaons not expressly approved by AXVUE may void the
users authority to operate this equipment.
NOTE
This equipment has been tested and found to comply with the limits for a
Class B digital device,
Pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucons, may
cause harmful interference to radio communicaons. However, there is no
guarantee that interference will not occur in a parcular installaon. If this
equipment does cause harmful interference to radio or television
recepon, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separaon between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
CAUTION
1. To comply with the FCC RF exposure compliance requirement, a separaon
distance of 20 cm must be maintained between the antenna of this device
and all persons.
2. This transmier most not be co-located or operang in conjuncon with
any other antenna or transmier.
DO NOT EXPOSE TO RAIN OR MOISTURE
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
• Make sure you read this instrucon carefully before using the product.
• Store this instrucon safely for your future reference.
• Ensure that you read the “Warning” secon of the product package and this instrucon carefully.
• Use the product properly by following this instrucon.
• Wipe the product by wet towel aer you take it down from the wall.
• Avoid possible danger by following manufacturer’s instrucon.
• Do not using the product in humid place or contact with liquid, like bathtub, hand washing sink, kitchen sink, laundry tub, humid
basement, swimming pool, etc.
• Ensure the product is installed in a flat place. Otherwise, it will cause serious personal injury and product damage when dropped.
• Only follow this instrucon and use installaon tools provided by the manufacturer to set up the product.
• The slots and holes on the product are used for venlaon, please ensure that it is not covered or blocked by other objects.
• Do not place the product on bed, sofa, rug or other similar places, it will block or cover the slots and holes on the product. Do not place
the product in a closed bookcase or shelf unless it has parcular part for venlaon.
• This product should be connected with certain power supply unit, if you are not sure about the power supply system in your home,
please contact with your product dealer and local power supply company. Please refer to the operang instrucon if you want to
operate the product in portable/baery mode or by connecng with other power supply sources.
• Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them,
paying parcular aenon to cords at plugs, convenience receptacles, and the point where they exit from the product.
• An outside antenna system should not be located in the vicinity of overhead power lines or other electrical lines or power circuits, it will
cause interference for the signal transmission. When installing an outside antenna system, extremely aenon should be paid to avoid
touching such power lines or circuits, otherwise, you will have possible danger of electrical shock.
• Do not overload wall outlet, extension cords or convenience receptacles, this can be cause a risk of fire or electrical shock.
• Do not insert any ny objects into the product’s inside, it may touch dangerous voltage point or cause short-circuit, this can be cause a
risk of fire or electrical shock. Any kind of liquid spillage happens on the product should be avoid.
• Do not maintain the product by yourself as opening and removing the covering, this may expose you to dangerous voltage or other
hazards. Please contact with qualified service personnel for maintaining.
• Unplug the product from wall outlet and contact with qualified service personnel if you have problems as below:
- When the power-supply cord or plug has been damaged.
- If liquid has been spilled, or objects have fallen into the product.
- If the product has been exposed to rain or water.
- If the product didn’t operate normally by following the operang instrucons, please only adjust those controls which are covered by
the operang instrucons. An improper adjustment of other controls may result in product damage, it will also require extensive work
from qualified service personnel to restore the product to its normal operaon mode.
- If the products has been dropped or damaged in any way, or when the product shows a disnct change in performance
- this indicated that the product need to be maintained.
• Replacement parts - When replacement parts are required, be sure the service technician has used replacement parts specified by the
manufacturer or its have the same characteriscs as the original part. Unauthorized substuons may result in fire, electrical shock or
other hazards.
• Safety Check - Upon compleon of any service or repairs to this product, ask the service technician to run safety checks on the product
to confirm that it is in a proper operang condion.
• The product only can be mounted on the wall or ceiling as recommended by the manufacturer.
• The product should be kept away from heat sources, such as radiator, heat registers, stoves or other products (including amplifier)
which can produce heat.
TO DELETE A CAMERA
AXVUE INC.
Revised at 03/2021
*Any updated or revised version please refer to axvue official website.
AXVUE stands behind all of its products.
If you are not completely sasfied or have any quesons,
please contact us at hps://www.axvue.com
Connect with us:
Favorite Features
TO USE MOTION TRACKING FUNCTION
TO SET UP VOX—Video on Crying
TO SELECT TEMPERATURE UNIT
6X MAGNIFYING CANVAS MOVEMENT FUNCTION
TO ADJUST TIME
TO VIEW ONE CAMERA WITH FULL SCREEN ( SELECT CAMERA )
Note*:
Note*:
Under VOX mode, screen turns off automacally and turns on only when a certain level of
sound is detected by camera: “3” for High Volume, “2” for Medium, “1” for Low.
Under this mode, any changes of camera seng (eg. Talk back, Moon detecon, VOX
level seng, etc.) will only be available for Camera 1.
Under this mode, any changes of camera seng (eg. Talk back, Moon detecon, VOX
level seng, etc.) will only be available for Camera 2.
TO VIEW TWO CAMERAS WITH SPLIT SCREEN
TO USE 2-WAY COMMUNICATION
IMPORTANT SAFETY INSTRUCTIONS
Press and hold the Zoom/Talk
Back (OK) “ ” buon on the
monitor to acvate two-way
communicaon mode.
Press &
hold
1
1
1
1
3 5
4
14
3
3
2
2
3
2
5
4
7
6
9
8
3
2
1
3
2
1
2
3 7
62
5
4
°F °C
1
3 7
2
5
4
6
10:24PM
09:15PM
09:15PM
