Axxess AXAC-MZ1 User manual

CAUTION! All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
AXAC-MZ1
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 2/17/20 INSTAXAC-MZ1
INTERFACE FEATURES
TOOLS REQUIRED
INTERFACE COMPONENTS
REQUIRED ITEMS (sold separately)
TABLE OF CONTENTS
Introduction............................................................2
Configuration .....................................................2-4
Connections ............................................................5
Installation .............................................................6
Programming .........................................................6
• (4) Camera inputs
• Turn signal trigger generated via CAN bus communication of the vehicle
• (4) Programmable camera control wires
• Micro-B USB updatable
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape • Wire cutter • Zip ties
• AXAC-MZ1 interface
• AXAC-MZ1 interface harness
• AXAC-MZ1 vehicle harness (qty. 2)
• 24-pin T-harness
• 4-pin T-harness (cam harness)
Update Cable: AXUSB-MCBL
† With full color LCD screen
Visit AxxessInterfaces.com for more detailed information about the product and up-to-date
vehicle specific applications
Mazda† Camera Interface With Pre-Wired Harness
2007-2015
APPLICATIONS
Mazda
CX-5 2013-2015
CX-9 2013-2015
CX-9 (with NAV) 2007-2012

2
CONFIGURATION
• Download and install the Axxess Updater available at: AxxessInterfaces.com
• Connect the AXUSB-MCBL update cable (sold separately) between the interface and the computer.
The cable will connect into the micro-B USB port in the interface.
• Open the Axxess Updater and wait until the word Ready is listed in the bottom left of the screen.
• Select Add-Cam Configuration.
Continued on the next page
INTRODUCTION
The AXAC-MZ1 is a camera switching interface that provides up to (3) additional camera inputs
to the factory radio, while still retaining the factory camera. With this interface a front camera,
and/or side cameras, can be added to the factory radio. The cameras function automatically, no
human interaction required, unless desired to do so. The interface can also be used if the vehicle
doesn’t come equipped with a backup camera, adding up to (4) cameras in this scenario. Axxess
recommends cameras from the iBEAM product line for best results.

3
REV. 2/17/2020 INSTAXAC-MZ1
• Under Configuration, configure the (4) video trigger inputs to the desired settings. †
• Once all selections have been configured, press Write Configuration to save the settings.
• Unplug the update cable from the interface and computer.
† Refer to the following page for more information.
CONFIGURATION (CONT.)
Continued on the next page
• Select the vehicle in the drop down list. A tab labeled Configuration will appear after the
vehicle has been selected.

4
CONFIGURATION (CONT.)
Video trigger legend
• Disable (will turn off the input)
• Backup Camera (dedicated backup camera)
• Left Blinker (will be used for activation)
• Right Blinker (will be used for activation)
• Control 1 (positive trigger activation)
• Control 1 (negative trigger activation)
• Control 2 (positive trigger activation)
• Control 2 (negative trigger activation)
• Control 3 (positive trigger activation)
• Control 3 (negative trigger activation)
• Control 4 (positive trigger activation)
• Control 4 (negative trigger activation)
• Auto (Reverse -> Drive) will activate once
that sequence is seen (only available for
video trigger 4)
Video trigger description
• Reverse camera: Dedicated by default to Video Trigger 1. Will activate the backup camera
while the vehicle is in reverse.
• Left blinker: Activation of the left turn signal will activate the left camera.
• Right blinker: Activation of the right turn signal will activate the right camera.
• Auto (reverse -> drive): Available only for Video Trigger 4, when installing a front camera. With
this feature selected, the camera will activate automatically once a reverse-then-drive sequence
is seen from the vehicle. Example of this scenario would be while parallel parking the vehicle. As
an alternative, a control wire can be used instead to manually activate the camera
.
Note: Auto (Reverse -> Drive) will disable the camera once 15 MPH is reached. A control wire
activated will also disable the camera.
Note: If the control wire is activated while driving, the camera will activate and deactivate
during stop-and-go traffic.
• Control 1-4 (positive or negative) trigger activation wires: Can be used as a positive or
negative trigger to manually activate a camera via a toggle switch, or similar device.

5
REV. 2/17/2020 INSTAXAC-MZ1
CONNECTIONS
For models with a factory backup camera:
The camera signal will need to be interrupted and connected to the corresponding input/output
RCA jacks from the interface.
• Connect the RCA jack from the AXAC-MZ1 vehicle harness labeled “Camera input”, to the RCA
jack from the AXAC-MZ1 interface harness labeled “Camera output”.
• Connect the RCA jack from the AXAC-MZ1 vehicle harness labeled “Camera output”, to the
RCA jack from the AXAC-MZ1 interface harness labeled “Camera 1”.
• Connect the Red wire from the AXAC-MZ1 vehicle harness labeled “Camera 12V”, to the Red
wire from AXAC-MZ1 interface harness labeled “Camera 12V”.
• From the AXAC-MZ1 vehicle harness: Connect the Gray/Blue wire labeled “Reverse”, to the
Gray/Blue wire labeled “Control 1”.
For models without a factory backup camera:
• Connect the RCA jack from the AXAC-MZ1 vehicle harness labeled “Camera input”, to the RCA
jack from the AXAC-MZ1 interface harness labeled “Camera output”.
• Connect the RCA jack from the AXAC-MZ1 interface harness labeled “Camera 1”, to the
aftermarket backup camera.
• Disregard the RCA jack labeled “Camera output” from the AXAC-MZ1 vehicle harness.
Note: Also disregard the 4-pin female connector this RCA jack is connected to.
• Connect the Red wire from the AXAC-MZ1 interface harness labeled “Camera 12V”, to the
power wire from the aftermarket backup camera.
• From the AXAC-MZ1 vehicle harness: Connect the Gray/Blue wire labeled “Reverse”, to the
Gray/Blue wire labeled “Control 1”.
Camera Input:
Camera 1 Backup camera input
Camera 2 Left or right camera, user assignable
Camera 3 Left or right camera, user assignable
Camera 4 Front camera
Analaog control trigger wires:
The (optional) analog control wires can be used with either a negative or positive trigger, depending
on how they are configured in the Axxess Updater. These wires will only be used for manual control of
the camera(s). Otherwise disregard them.
Control Wire Wire Color
Control 1 (reserved) Gray/Blue
Control 2 Gray/Red
Control 3 Orange
Control 4 Orange/White

6
I N S TAL L ATI O N PROGRAMMING
With the ignition cycled off:
1. Remove the harnesses from the factory radio, then install the AXAC-MZ1 vehicle harness in
between.
2. Connect the AXAC-MZ1 vehicle harness to the AXAC-MZ1 interface harness.
3. Connect the AXAC-MZ1 interface harness to the AXAC-MZ1 interface.
4. Make sure the camera(s) is connected to the appropriate input.
5. Make sure the interface has been configured beforehand as shown in the Configuration
section. Failure to configure the interface will result in the interface not functioning properly.
AUX-IN
Camera Input
Camera Output
Camera Output
Camera 1
FACTORY RADIO TO VEHICLE HARNESS
Camera 4
Camera 2
Control 1
Control 2
Control 3
Control 4
Camera 3
Camera 12V
VSS output
VSS input
For models with a factory backup camera:
1. Cycle the ignition on and wait until the LED in the interface comes on.
Note: If the LED doesn’t come on within a few seconds, yet blinks instead, turn the key to the off
position, disconnect the interface, check all connections, reconnect the interface, and then try again .
2. Test all functions of the installation for proper operation.
For models without a factory backup camera:
1. Cycle the ignition on.
2. Wait until the Mazda logo is present (dim), then put the vehicle in reverse. Wait until ‘Please
Check Surroundings For Safety” is shown, then put the vehicle back in the park position. This
process should take within 30 seconds.
3. Test all functions of the installation for proper operation.

7
REV. 2/17/2020 INSTAXAC-MZ1

KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
®
Metra recommends MECP
certified technicians
IMPORTANT
If you are having difficulties with the installation of this product,
please call our Tech Support line at 386-257-1187. Before doing
so, look over the instructions a second time, and make sure the
installation was performed exactly as the instructions are stated.
Please have the vehicle apart and ready to perform troubleshooting
steps before calling.
AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 2/17/20 INSTAXAC-MZ1
INSTALLATION INSTRUCTIONS
AXAC-MZ1
