AYVAZ YS-600 User manual

Y-TYPE BRASS
STRAINER
YS-600
USER
MANUAL

© 10/2022 Hacı Ayvaz Endüstriyel Mamuller Sanayi ve Ticaret
A.Ş. All Rights Reserved.
AYVAZ® is a registered trademark.
Please read this manual before you start using it!
SYMBOLS AND DESCRIPTIONS
Warning Signs in User's Guide
MPORTANT INFORMATION
DANGER
FIRE DANGER Warning danger of fire!
HOT SURFACE Warning risk of hot surface!
HIGH VOLTAGE
Shows useful tips and suggestions.
Indicates danger to life and property.
Warning danger of electric shock!
YS-600

CONTENT
General Information
General Features
Safety and Environmental Instructions
Transport, Packaging and Storage
Installation
Operation
Maintenance and Cleaning Disassembly,
Maintenance and Cut-out
Technical Drawing
2
2
PAGE TITLE
3-4
4
5
5
6
7
8
YS-600

2
PRODUCT CODE: YS-600
2. GENERAL FEATURES
2.1 GENERAL SAFETY INFORMATION
The safety use of strainer according to working instructions can be done if it can
be install and maintain by qualified person. lnstallation of jacket to the line, safety
instructions, safety tools and correct use of tools must be available too..
PRESSURE
Before the maintenance, be careful if there is pressure at the pipeline which jacket
going to be installed. lf there is pressure in the system, it should be discharged by
safely.
TEMPERATURE
Before the maintenance, be careful of the temperature on the line. lt can cause
some physical injuries. Please wait unlil the temperature decrease to nominal
level.
2.2 GENERAL PRODUCT INFORMATION
YS-600 product is a Y type brass strainer.
·Products are designed and manufactured by professional team. All parts are
manufactured with high quality standards and environmental factors in mind.
·The user manual describes the correct and safe use of the item. All health and
safety instructions must be followed during the installation.
·The operating area must be selected correctly to avoid missapplication.
· That user manual is a part of the product and must be read.
·The installer must carry out the installation in accordance with the warnings and
information specified in the user manual.
· General terms and conditions stated at sales document.
· Ayvaz reserves the right to change products, specifications at any time without
any prior notice.
1. GENERAL INFORMATION
YS-600

3
A strainer must be used in front of the traps. The standard factory setting is
right to left flow direction.
3. SAFETY AND ENVIRONMENTAL INS.
This product is produced for industrial use. It is dangerous for household use.
3.1 General Safety Instructions
3.2 Working Conditions
Pressure Class PN16
PMA-Pressure Maximum Allowable (bar) 16
TMA-Temperature Maximum Allowable (°C) 130 °C
PMO-Pressure Maximum Operation (bar) 16
TMO-Temperature Maximum Operation (°C) 110 °C
·Follow the installation and maintenance instructions of the user manual.
·Wear protective goggles and gloves during operation.
· Repairs should only be carried out by technical experts. Otherwise, accidents
may occur.
·Do not use non-operating switches and electronic devices. Contact the
authorized service for support.
·Signs should be placed where the fluid temperature is 60 ° C and above.
The item must be operated in accordance with the general safety instructions
listed above. Ayvaz cannot be held responsible for problems arising from use that
does not comply with the safety instructions.
3.3 Incorrect Usage
Incorrect use may result in hazardous situations and injuries.
· Do not make any changes to the product without authorization. Otherwise the
product will not be covered by the warranty.
· Do not use the product in hazardous areas.
Ayvaz cannot be held responsible for any dangerous situations and injuries caused
by incorrect usage.
Do not use this item in combination with safety precautions or emergency
devices.
YS-600

4
3.4 Responsibility of the User
This item is a commercial product. Therefore, the user is responsible for legal
obligations related to occupational safety.
Along with the safety instructions specified in this user manual; accident
prevention measures and environmental protection laws must be considered.
To use the item safely, the user must follow the instructions below;
·The user must be regularly familiar with occupational health and safety issues, be
familiar with first aid and be able to follow the instructions in this manual.
·User must read user manual and safety instructions and understand.
·Do not test the item and do not use it out of design purpose.
·Control of the safety, pressure and temperature of the facility where the item
will be decided by the user.
3.5 User Competence
Operating and handling errors can cause serious injuries to the user and
damages to the product.
·Actions described in this guide, a user with qualifications which is mentioned
below can perform the installation.
·The installation has to be done by qualified installers.
Competent User
A competent user is an individual authorized by the company, who is eligible
to understand the technical information contained in this manual, has knowledge
of measurement and control, knows the legal responsibilities of the country in
which he performs the operation or installation operation, is able to
operate independently in dangerous areas, in compliance with current
standards and regulations.
3.6 Personal protective equipment
Personal protective equipment is a means of protecting competent users from
hazards that may occur during operation. The competent user must wear personal
protective equipment during installation.Follow the protection directives at the work
site.Personal protective equipment must be supplied by the company that
purchased the product.
4. TRANSPORT, PACKAGING AND STORAGE
4.1 Transport
After the item reaches you, check for damage caused by the transport. Report any
significant damage immediately.
4.2 Packaging and Storage
Do not remove the package before installing the item. Keep the item in a safe place
for damage.
YS-600

5
5. INSTALLATION
Before the installation, you should read safety instructions carefully.
a- Check the label and technical information sheet if the product is suitable
for the required installation.
b- Check the maximum pressure and temperature values. lf the pressure in
the system is higher than the maximum value of the product, provide the use
of safety tools in order to prevent the excess pressure.
c- Remove the product from package carefully. Parts of the product may
resemble the packaging element. In this case, please contact your dealer.
d- Determine the liquid flow direction and the correct mounting position (flow
direction on the body)
YS-600
6. MAINTENANCE & CLEANING
6.1 Maintenance
Before carrying out any operation on the strainer, the strainer should be
isolated from the supply line and return line and the pressure in the system
should be relieved safely. Then the strainer should be allowed to cool. When
reassembling the system, ensure that all connection surfaces are clean.
6.2 Cleaning
It can cause physical injury, product damage and environmental damage.
The fluid in the item can be a risk to the user, the environment and the item itself.
· If there is a shut-off valve, the bottom shut-off valve is closed first. The fluid in
the device is discharged into a suitable storage container by means of a drain plug
or valve.
·The device is carefully disassembled.
·The inside of the device is cleaned with a soft brush and the outside with a wet
cloth and allowed to dry.
· Electrical connections must not come into contact with the wet area.
· Do not use aggressive cleaning agents.
· Do not clean with sharp or hard objects.

YS-600
7. DISASSEMBLY, MAINTENANCE AND CUT-OUT
Fluid that can cause physical injury, product damage and environmental damage.
·Carefully clean the dismantled item to eliminate physical injuries, fluid damage,
and damage to the environment.
7.1 Disassembly
If there are closing valves, remove the item safely after closing the closing valves. If
there is not closing valve, remove only the item to be disassembled on the tank
when the system pressure and electrical connections are cut off.
7.2 Maintenance
Clean the item carefully to eliminate physical injuries, product damage, and
environmental damage from the fluid before sending it to maintenance. Contact
our customer representative for shipping operations.
7.3 Cut-Out
This product is made of high quality parts and materials which are recyclable and
reusable. Therefore, do not dispose of the product with household or other waste
at the end of its service life.
Metal recycling facilities can be taken to recyling.
Production Material
NO Part Name Material
1Body Brass
2Strainer Stainless Steel
3Gasket Klingerite
4Cover Brass
8.TECHNICAL DRAWING
6
Ø (mm) D L L1 HWeight (g)
16 1/2" 53 10.50 51 125
22 3/4" 67.5 13 65 220
26 1" 76 13 67 290
33 1 1/4" 90 15 90 560
40 1 1/2 99 16 101 800
50 2" 117 17 127 1300

USER MANUAL
Y TYPE STRAINER
YS-600
Haci Ayvaz M.E.
Dubai/U.A.E
Tel: [phone]
[phone]
[email protected]
Ayvaz China
Cixi City/China
Tel: [phone]
[e-mail]
Ayvaz Kazakhstan LLP
Almaty/Kazakhstan
Tel: [phone]
[email protected]om
www.ayvaz.kz
Ayvaz N
Isperih/Bulgaria
Tel: [phone]
Ayvaz Serbia
Belgrad/Serbia
Tel: [phone]
[email protected]om
Cona
Caserta/Italy
Tel: [phone]
[email protected]om
Ayvaz Russia
Moscow/Russia
Tel: [phone]
[e-mail]
Ayvaz Germany
Viernheim/Germany
Tel: [phone]
[email protected]om
Ayvaz Ukraine
Kiev/Ukraine
Tel: [phone]
[email protected]om.ua
Tricorr
Warsaw/Poland
Tel: [phone]
[e-mail]
Ayvaz Bakü
Bakü/Azerbaijan
Tel: [phone]
ahayato[email protected]
