AZLA AZPG-RF2000 User manual
Warning! Risk of hearing lossWarning
Picture 1
Front of the connector
Back of the connector
Appearnace
Accessibility
Voice & Video
Text & Images
Notifications
Keybinds
APP SETTINGS
Voice Settings
Earphone (AZPG-RF2000)
INPUT DEVICE OUTPUT DEVICE
OUTPUT VOLUME
Default
Default
MIC (3-USB Audio CODEC)
MIC (AZPG-RF2000)
#1663
AZLA
#9999
1. This product has been manufactured under strict QC and inspection processes.
2. The product is covered by warranty only for the malfunctions that
has occurred under the consumer’s proper usage
and within the warranty period (2-years)
3. If the warranty period has passed, or even if not, a service charge
may be required depending on the issue of the product.
4. Please make sure to provide the included warranty card
when requesting for maintenance.
5. Please take good care of the warranty card as it cannot be reissued if lost.
6. This warranty card is only valid within South Korea.
7. AZLA Corp. abides by the Consumer Dispute Resolution Standards prescribed
by the Framework Act on Consumers.
8. Warranty will be processed according to the terms
described on the warranty card.
※ Excluding the device itself and the USB dongle, any other accessory
(cables, eartips, etc.) is not covered by warranty.
※ The specifications, designs, components, and manuals of the product are subject
to change without notice.
Declaration of Conformity
Manufacturer Name:
AZLA Inc
Manufacturer Address:
3F, 332, Hyoryeong-ro, Seocho-gu, Seoul, Republic of Korea
Importer Name*:
(Or authorized representative):
*If manufacturer is not in EU
Under Article 10(2) and 10(10), there are no restrictions of use
Importer Address:
-
Declare under our sole responsibility that the product
Product Type/Description:
RF Gaming Earphone
Model:
AZPG-RF2000
Variant Model:
AZPG-RF2000W, AZPG-RF2000B, AZPG-RF2000R
Trade Name:
AZLA
Product Identification Element:
RADIO
Product Accessories (if applicable):
N/A
Hardware version
1.0
Software version
1.0
Is in conformity with the following standards or other normative documents
Test standards
Radio: ETSI EN 300 328 V2.2.2 (2019-07)
EMC : ETSI EN 301 489-1 V2.2.3 (2019-11), ETSI EN 301 489-17 V3.1.1(20017-02)
Safety : IEC 62368-1:2018 and EN IEC 62368-1:2020+A11:2020
Health : EN 62311:2008
We hereby declare that [all essential radio test suites have been carried out and that] the above
named product is in conformity to all the essential requirement of Directive 2014/53/EU.
This product can be used in which EU members, in accordance with Article 10(10) / or this product
can be used in at least one EU country, in accordance with Article 10(2)
The conformity assessment procedure referred to in Article 17 and detailed in Annex [III] of Directive
2014/53/EU has been followed with the involvement of the following Notified Body(ies):
PHOENIX TESTLAB GmbH (Notified Body Number: 0700)
Königswinkel 10 D‐32825 Blomberg Germany
EU‐Type Examination Certificate No.:
Name :
kyungjin Hong
Title :
Chief Research Enginee
Address:
3F, 332, Hyoryeong-ro, Seocho-gu, Seoul, Republic of Korea
Date: November 24, 2021
Signature of Authorized person
EU Declaration of Conformity (CE)
This product is CE marked according to the provisions of the Radio Equipment Directive (RED)
2014/53/EU. Hereby, Suprema Inc. declares that this product is in compliance with the essenti
al requirements and other relevant provisions of Radio Equipment Directive (RED) 2014/53/EU.
The RF distance between body and product is 20cm
This device meet the EU requirements on the limitation of exposure of the general public to electroma
gnetic fields by way of health protection.
AZPG-RF2000
Frequency Range: 2 0404~2 460 MHz
Modulation technique: Shaped_8FSK
Channels: 15 ch
Maximum target power:
CE
Channel
Power(dBm)
Tolerance(dB)
1
-9.5
±1
8
-11.5
±1
15
-14.0
±1
FCC
Channel
Power(dBm)
Tolerance(dB)
1
-13
±1
8
-15
±1
15
-16
±1
AZPG-RF2000DG
Frequency Range: 2 0404~2 460 MHz
Modulation technique: Shaped_8FSK
Channels: 15 ch
Maximum target power:
CE: 4 dBm ±1.5 dB
FCC: 4 dBm ±1.5 dB
For more information, contact us at the following contact information.
AZLA Inc
Website: https://www.azla.co.kr/
Address: 3F, 332, Hyoryeong-ro, Seocho-gu, Seoul, Republic of Korea
Tel: +82-2-565-1954 / Fax: +82-
FCC Compliance Information
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for hel
Modifications not expressly approved by the manufacturer could void the user's authority to operate the
equipment under FCC rules.
This appliance and its antenna must not be co-located or operation in conjunction with any other
antenna or transmitter.
