Aztech HL115EP Instructions for use

MODEL
HL115EP
The following items are included in your HL115EP package.
Package Contents
HomePlug AV devices are preconfigured with a common Private Network Name. Adding new HomePlug AV devices to an existing
network with the default Private Network Name is as easy as plugging the device into the power outlet. If you wish to have a unique
private Network Name, simply follow the instructions below. This Easy Start Guide, the User Manual, and the HomePlug AV Utility
software is included in the Resource CD and is also downloadable on our Aztech Support Website (www.aztech.com/support).
Device Overview
Setting up your HomePlug AV Network
Step 1
In Room A, plug in your HomePlug AV device into the power outlet
and connect it to the router using an Ethernet cable.
NOTE: Ensure that your router’s internet connection is UP to allow
access to the internet.
Step 2
In Room B plug in your other Homeplug AV device into the power
outlet and connect it to your computer’s ethernet port using an
Ethernet cable.
Resource CD Easy Start
Guide
Ethernet
Cable
A
B
C
HL115EP
Powerline
Activity LED
Ethernet
Activity LED
Power LED
Simple
Connect
Button
Reset
Button
Ethernet
Port
You may use this AC Pass-through
as an extra power outlet.
Step 3
Confirm that a connection has established on both HomePlug AV
devices. All 3 LEDs (Power , Powerline , and Ethernet )
must be ON. Your Homeplug AV Network is now ready to use and
can access Internet.
DEVICES ARE PLUG
AND PLAY READY.

MODEL
HL115EP
Setup for an Existing Network Connection
D
If in case you have changed the Private Network Name of your
existing network, you may use the Simple Connect Button of your
HL115EP and the other devices as indicated below:
Within two minutes, press the simple connect button of
HomePlug AV X for TWO SECONDS.
3
Step 3
To confirm if the connection has established, check the LEDs. The Power LEDs and
the Powerline Activity LEDs on all HomePlugs would be ON.
4
Step 4
NOTES:
When joining an existing network, you only
have to pair it to one HomePlug AV that belongs
to the existing network.
The Ethernet Activity LED will only be lit if it is
connected to an Ethernet device (e.g. computer,
laptop, etc) through an Ethernet cable.
To perform RESET to factory defaults, press the
reset button for 3 SECONDS.
•
•
•
Press the Simple Connect button of your HomePlug
AV X for 10 SECONDS. After you release the button,
the Power and Powerline Activity LED will turn
OFF and turn ON.
1
Step 1
Press the Simple Connect Button of HomePlug AV Y for
TWO SECONDS. The Power LED will continuously blink. If
the Power LED did not blink, press the Simple Connect button
again for two seconds.
2
Step 2
Press for 3 SECONDS
to perform factory
defaul reset.
HomePlug X
(Your new HomePlug)
HomePlug Y
(A HomePlug that
belongs to the existing
network)
HomePlug X
(Your new HomePlug)
HomePlug Y
(A HomePlug that
belongs to the existing
network)
HomePlug X
(Your new HomePlug)
HomePlug Y
(A HomePlug that
belongs to the existing
network)
HomePlug X
(Your new HomePlug)
HomePlug Y
(A HomePlug that
belongs to the existing
network)
