Aztech WMB250AC Instructions for use

1

2
Product Registration:
https://www.aztech.com/aztech-support/product-registration
Customer Care:
https://www.aztech.com/service-centre
Service Center Address:
31 Ubi Road 1, #01-05
Singapore 408694
Operating Hours
Monday to Friday: 9:00 AM to 6:15 PM
Saturday: 9:00 AM to 1:00 PM (Except Sunday & Public Holidays)
AZTECH TECHNICAL SUPPORT DETAILS

3
Table of Contents
Package Contents………………………………………………………………………4
Visual Guide……………………………………………………………………………….4
Building a New Mesh Network……………………………………………………
5
LED
Behavior…………………………………………………………………………………….6
Adding a New Node to an Existing Mesh Network………………………7
Changing the SSID and Password using the AztechMesh
app…………………………………………………………………………………………….8
Adding a new Mesh Node using the AztechMesh app………………..10
These Easy Start Guide and User Manual are available at www.aztech.com.
3

4
PACKAGE CONTENTS
The following items are included in your WMB250AC package.
WMB250AC
Power Adapter
Ethernet Cable
Easy Start Guide
Warranty Policy
WMB250AC VISUAL GUIDE
1. FAST ETHERNET LED
2. GIGABIT ETHERNET LED
3. WPS LED
4. MESH LED
5. POWER LED
6. FAST ETHERNET PORTS 1-4
7. GIGABIT ETHERNET PORT
8. FACTORY RESET BUTTON
9. 12 DC POWER INPUT

5
BUILDING A NEW MESH NETWORK
This requires a router to set a mesh system with your WMB250AC as your
Mesh Node. You would need an RJ45 or Ethernet cable (y
ou may use the
RJ45 provided on the package). You can follow the steps
below to build your
mesh network.
A. Take out any one WMB250AC in the package (there may be two or
three devices in a package).
B. Power on and connect the device to any router via RJ45 or
Ethernet cable. This will become the master automatically.
C. Take out the rest of the device in the package and power on.
D. If you find that the MESH LED with master is solid white, it means
the mesh network has been established successfully.
E. You can access the Web GUI via new Master IP address to change
the default SSID and Password of your mesh network. The
Master
IP address can be found in your router’s GUI. Or you can do this by
“AztechMesh” App.
NOTE: At least two (2) WMB250AC units are needed for Mesh system to
work.
5

6
LED BEHAVIOR
LED
Status
Description
Power
Off
Blinking White
Solid White
No Power
Device is booting
Device is connected to power
supply
WPS
Solid White
Blinking White
Off
WPS Pairing has been
established
Ongoing/active WPS process
WPS is not running
Mesh
Off
Solid White
Blinking White
Mesh Disabled
Mesh connected
Mesh disconnected
LAN5
Off
Solid White
Giga Ethernet Port
disconnected
Giga Ethernet Port connected
LAN 1-4
Off
Solid White
Fast Ethernet Port connected
Fast Ethernet Port
disconnected

7
ADDING A NEW NODE TO AN EXISTING MESH
NETWORK
This requires a master at least. Power on the new WMB250AC and connect to
your PC or laptop using the RJ45 or Ethernet cable. You may also connect
wirelessly as well. Follow the steps below to add a new node to your existing
mesh network.
A. Connect your PC to new WMB250AC via RJ45 cable or Wi-Fi with SSID and
Password shown on product label. Your PC can get IP address 192.168.1.x
by DHCP.
B. Access the new WMB250AC GUI by IP address 192.168.1.100 and set
SSID/password as the same as the existing mesh network and then power
cycle the WMB250AC.
C. Then this device will be added the existing mesh network. If the MESH
LED is solid white means add to mesh network successfully.
NOTE: At least two (2) WMB250AC units are needed for Mesh system to work.

8
CHANGING THE SSID AND PASSWORD USING
THE AZTECHMESH APP
A. Install the
AztechMesh
app on
your phone.
B. Connect your phone to
WMB250AC Wi-Fi Network and
launch
AztechMesh
app. Slide to
start.

9
C. Select your WMB250AC master
node from the list.
D. Enter username and password to
login. Both are “admin” by
default.
E. Click the Wi-Fi Settings button
to enter Wi-Fi Settings screen.
F. Edit SSID and Password. Click
Apply to save your changes.

10
8
ADDING A NEW WMB250AC MESH NODE TO AN
EXISTING NETWORK
A. Power on the new WMB250AC
node. Click on the Home icon at
the middle of the screen.
B. Click “Add Mesh Node” button.

11
11
8
C. Select your preferred method
to add the new mesh node.
D. You may choose QR code or
Manual input method. Click the
Manual button to enter the SSID
and Password of the new node
manually.
E. To add via QR code, select the
“Scan QR” option. The camera
shall open. Scan QR code of the
new mesh node from its
product label.
F. After successfully adding a mesh
node, wait for the mesh node to
restart. The process might take
up to 2 minutes.
NOTE: If the MESH LED with the new device is solid white, it means the mesh node
has been address successfully.
