b4Adventure Adventure Sky Swing User manual

1
AGE: 3+
MAX WEIGHT: 300 lb (136 kg)
Adventure Sky Swing
CONTENTS:
(4) Foam covered metal ring sections
(1) Fabric swing cover (size varies by model)
(2) Adjustable hanging rope
(2) Delta Clips
WARNING! ADULT
ASSEMBLY REQUIRED-
This product should be
unpacked and assembled by
an adult, including site and
tree selection, as well as the
secure and proper
installation
WARNING! ADULT
SUPERVISION REQUIRED!
SERIOUS INJURY OR
DEATH MAY RESULT -
Always exercise extreme
caution when using the
Adventure Sky Swing. Keep
bystanders at least 10 ft
(3 m) away from the course
to avoid collisions
BE SAFE! ALWAYS FOLLOW THESE RULES
• Adult supervision is required at all times.
• This product should be unpacked and assembled by an adult,
including site and tree selection.
• Adult installation is required. Children should not use product until
properly installed.
• Instruct children not to walk close to, in front of, behind, or between
moving swings.
• Instruct children not to twist the chains/ropes and not to loop them
over the swing beam since this may reduce the strength of the
rope/chain.
• Instruct children not to jump from swings in motion
• Instruct children not to push empty swings, the seat may hit them
and cause injury.
• Instruct children to sit in the center of chairs with their full weight on
the seats.
• Wear close fitting clothing, NO scarves or other loose clothing.
• If worn or damaged parts are found, contact b4Adventure for
replacement parts - Do not substitute with other, non-b4Adventure
parts or failure resulting in injury could result.
Warranty: one year on all parts and workmanship
FAILURE TO FOLLOW THESE INSTRUCTIONS
COULD RESULT IN SERIOUS INJURY!
WARNING!
UNHEALTHY TREE
HAZARD - Do not attach to
or use a tree that is
diseased, unhealthy, or
damaged. It may fail, causing
serious injury or death
b4Adventure • Denver Colorado 80216 • 1-844-834-4334 QUESTIONS? [email protected] •
www.b4adventure.com - DC:102919

b4Adventure • Denver Colorado 80216 • 1-844-834-4334 QUESTIONS? [email protected] •
www.b4adventure.com - DC:102919 2
SWING ASSEMBLY:
• Start by sliding the foam/metal bars into the 4 sleeves sewn into the outter portion of the swing to create a circular
shape.
• NOTE: all 4 bars should be facing the same direction so that the male/female connectors match up.
• Your swing should contain 2 ropes, each with 2 connecting rings at the bottom of each end. Lay the rope out with
each end adjacent to eachother at the connection points of the metal frame.
• Slide the plastic rings over the female ends of the metal bars.
• Make sure the ropes are not twisted, they should create an upside down V shape when the swing is fully assembled.
• Connect all the male and female ends together to create a complete circle.
• NOTE: You may need to push the foam away from the connection point to make room for assembly
• You should hear a “click” sound once the bars are secured.
• BE SURE TO CHECK ALL CONNECTION POINTS TO ENSURE THEYARE FULLY LOCKED AND SECURED
BEFORE USING THE SWING!

300
300
lb lb
STRUCTURE / TREE LIMB
3
CHOOSING THE SITE:
• Do not install home playground equipment over concrete, asphalt, packed earth, grass, carpet, or any other hard
surface. A fall onto a hard surface can result in serious injury or death to the equipment user. Due to the variety of
swing sets and places that this product can be suspended, we must urge caution when attaching the swing to your
structure.
• Protective surfacing under swings is recommended. “To and Fro” swings should have a fall zone extending a
minimum of 6 ft (2 m) from the outer edge of the support structure on each side. The “fall zone” in front and back of
the swing should extend out a minimum distance of twice the height of the swing as measured from the ground to
the top of the swing support structure. Swings should have a minimum of 8 in (20 cm) between them. (ASTM
F-1148-18) The bottom of a swing should not be less than 8 in (20 cm) above the protective surfacing material.
SURFACES: Maximum fall height is 84 in (213 cm), playground surface material should be 8.9 in (23 cm). See
“Outdoor Home Playground Safety Handbook” from the U.S. Consumer Product Safety Commission.
SUPPORT STRUCTURES: Be certain that the overhead structure can support at least 500 lb (227 kg). If attaching
to a tree limb, make sure the tree is alive and healthy. Recommended diameter of tree limb is 10 in (25 cm) Before
anyone uses the swing, a stress/weight test should be performed (see step 3).
ATTACHING THE SKY SWING:
• Use the carabiners included with your product to attach the rope to your structure. Other suitable hardware (ie.
chain, links or fasteners) may be needed (not included).
• Attach the swing to your structure at 6-24 in(15-60 cm) off the ground.
• 2 Point attachment will swing in a lateral motion perpendicular to the support structure.
• 1 Point attachment will swing in a circular motion in any direction.
•ADJUSTING HEIGHT: Your swing has adjustable S-hooks that allow you to adjust the hanging height of the swing.
Recommended swing height is 12-18 in (30-45 cm) above the ground depending on the height of the rider.
MANDATORY LOAD STRESS TEST:
• First check all connections
• Have 2 Adults, whose combined weight is apx. 300 lb (136 kg), pull down together on the swing.
CAUTION: make sure they are in a safe position in case the branch or structure should come down. Gradually have
them apply all their combined weight. During this process, check for breaking or cracking.
1 POINT
ATTACHMENT
2 POINT
ATTACHMENT
(136 kg)
b4Adventure • Denver Colorado 80216 • 1-844-834-4334 QUESTIONS? [email protected] •
www.b4adventure.com - DC:102919

4
b4Adventure • Denver Colorado 80216 • 1-844-834-4334 QUESTIONS? [email protected] •
www.b4adventure.com - DC:102919
MAINTENANCE OF YOUR ADVENTURE SKY SWING
Take down your swing when not in use for long periods of time, this will help prevent UV damage
and weathering of materials and unsupervised usage.
At the beginning of each play season:
• Tighten all hardware - check all connections for any hint of looseness, damage, deterioration, excess wear, rope
fraying, breaks or sharp edges and replace as necessary.
• Lubricate all metallic moving parts per manufacturer’s instructions.
• Check all protective coverings on bolts, pipes, edges, and corners. Replace if they are loose, cracked, or missing.
• Check all moving parts including swing seats, ropes, cables, and chains for wear, rust, or other deterioration.
Replace as needed.
• Check metal parts for rust. If found, sand and repaint using a nonlead-based paint meeting the requirements of
16 CFR 1303.
• Reinstall any plastic parts, such as swing seats or any other items that were removed for the cold season.
• Use only b4Adventure replacement parts
Once a month during play season:
• Lubricate all metallic moving parts per manufacturer’s instructions.
• Tighten all hardware - check all protective coverings on bolts, pipes, edges, and corners. Replace if they are
loose, cracked, or missing.
• Check all moving parts: including all grips for wear, rust, or other deterioration. Replace as needed.
• Perform the Load Stress test.
• If using a step ladder or other platform, inspect it every month for looseness, stability & wear.
Twice a month during play season:
• Tighten all hardware - Check all protective coverings on bolts, pipes, edges, and corners. Replace if they are
loose, cracked, or missing.
• Rake and check depth of loose fill protective surfacing materials to prevent compaction and to maintain
appropriate depth. Replace as necessary.
At the end of each play season or when the temperature drops below 32° F (0° C):
• Inspect all parts for wear/damage. Replace as needed before next season of use.
• Take down your entire swing setup and store indoors.
• X.3.1.1 Loose-Fill Materials: Maintain a minimum depth of 9 in (23 cm) of loose-fill materials such as
wood mulch/chips, engineered wood fiber (EWF), or shredded/recycled rubber mulch for equipment up to
8 ft high (2.5 m); and 9 in (23 cm) of sand or pea gravel for equipment up to 5 ft (1.5 m) high. NOTE: An initial fill
level of 12 in (30 cm) will compress to about a 9 in (23 cm) depth of surfacing over time. The surfacing will also
compact, displace, and settle, and should be periodically refilled to maintain a least a 9 in (23 cm) depth.
PLEASE DO NOT RETURN YOUR PRODUCT TO THE STORE!
WE ARE HERE TO HELP YOU!
IF YOU HAVE ANY QUESTIONS ABOUT YOUR PRODUCT
PLEASE CONTACT US:
1-844-834-4334 • [email protected]

5
b4Adventure • Denver Colorado 80216 • 1-844-834-4334 QUESTIONS? [email protected] •
www.b4adventure.com - DC:102919
PRODUCT DISCLAIMER & NOTICE
The installation and use of the Adventure Sky Swing is potentially hazardous. Any person purchasing,
installing or using equipment from the b4Adventure must:
See section 4 of the United States Consumer Product Safety Commission’s Outdoor Home
Playground Safety Handbook . Visit www.cpsc.gov//PageFiles/122149/325.pdf.
Observing the following statements and warnings reduces the likelihood of serious or fatal
injury:
• Maximum user weight should not exceed 300 lb (136 kg)
• Instruct children not to walk close to, in front of, behind, or between moving items,
• Instruct children not to twist swing chains or ropes or loop them over the top support bar since this may reduce
the strength of the chain or rope.
• Instruct children to avoid swinging empty seats.
• Teach children to sit in the center of the swings with their full weight on the seat.
• Instruct children not to use the equipment in a manner other than intended.
• Do not not to allow children to wear inappropriate items, such as but not limited to, loose fitting clothing, hood and
neck drawstrings, scarves, cord-connected items, capes and ponchos. These items can cause death by
strangulation.
• Instruct children not to attach items to the playground equipment that are not specifically designed for
use with the equipment, such as, but not limited to, jump ropes, clothesline, pet leashes, cables and
chain as they may cause a strangulation hazard.
• Instruct children to remove their bike or others sports helmet before playing on the playground
equipment.
• Instruct children to dress with well-fitting and full foot enclosing footwear. Example of inappropriate
footwear are clogs, flip flops and sandals.
• Do not use when equipment is wet.
• Never add extra length to chain or rope. The chains or ropes provided are the maximum length designed for the
swinging element(s).
• Obtain training and instruction regarding proper use and safety precautions to always practice.
• Ensure proper & adequate supervision and instruction (this include the continuous use of appropriate
safety procedures & equipment) for themselves and others using the equipment;
• Check that all equipment is properly maintained, in good working order and inspected for damage or
wear prior to each use.
• You assume all risks and accept full responsibility for any injury (including death) or damages that may
occur from its use.
All the information provided by b4Adventure either printed, electronic or other, is not to be considered
professional instruction or advice. Users of this equipment are encouraged to seek professional
instruction regarding specific questions about usage, location, installation or other aspects of hanging swings.
Please save these instructions for future reference.
Owners shall be responsible for maintaining the legibility of the warning labels.
Disposal instructions: Recycle your Adventure Sky Swing according to Local, State or Federal Laws.
PRODUCT CONFORMS TO ASTM F1148, CONSUMER SAFETY PERFORMANCE SPECIFICATION FOR HOME
PLAYGROUND EQUIPMENT
