Baby Jogger Citi Mini User manual

Read these instructions carefully
before use and keep them for
future reference. Your child’s
safety may be affected if you do
not follow these instructions.
www.babyjogger.com
CITY MINI
4 WHEEL SINGLE
ASSEMBLY INSTRUCTIONS
This product complies with
BS EN 1888:2003 inc. A1, 2, 3: 2005
PR_102511d_MA_City Mini_4Whl_Instruct_UK.indd 1 11/18/11 12:14 PM

2 1
2
• This stroller is suitable from birth to 15kg [33lb].
• This stroller is tested to 15kg [33lb] in accordance with BS EN 1888:2003.
• WARNING: Never leave your child unattended.
• WARNING: Watch out for cars – never assume that a driver can see you and your child.
• WARNING: If your buggy is to be used by someone unfamiliar with it, e.g. grandparents,
then show them how it works before letting them use it.
• WARNING: DO NOT exceed 3mph (normal walking speed). This stroller is not suitable
for running, jogging, skating or roller blading.
• WARNING: Prevent serious injury to your child by always using the safety harness. Child
may slip into leg openings and strangle if harness is not properly fastened. Never use
in reclined carriage position unless safety harness is properly fastened - SEE ‘Safety
Harness’ PAGE 5.
• WARNING: Parcels, accessories and other items (E.g. handbags, shopping bags etc.) that
are placed on the stroller handlebars may cause the unit to become unstable.
• WARNING: Excessive weight may cause a hazardous unstable condition to exist. Do not
put heavy items (more than 1kg [4lb]) in the seat pocket. The basket weight must not
exceed 2kg [8lb]. (Combined passenger and baggage max. total weight 15 kg [33lb]).
• WARNING: Check that any accessories are attached correctly before use.
• WARNING: Never leave raincovers, hoods and aprons on indoors or in a hot
atmosphere.
For the sake of your precious cargo, please
read these warnings before using your stroller.
WARNING: WARNING:
• WARNING: Ensure that children are clear of moving parts before making adjustments.
• WARNING: Do not allow children to play with the stroller.
• WARNING: Taking children up or down stairs, steps, escalators, steep slopes and muddy/
rough terrain in a stroller could be dangerous and should not be attempted. Damage
resulting to stroller will not be covered under warranty. Remove your child from the
stroller and fold it up for easy carrying to negotiate such hazards, or simply avoid them.
• WARNING: The passenger must remain seated (no standing in the stroller).
• WARNING: Do not use stroller in high winds, lightening or stormy weather.
• WARNING: Ensure all locking devices are engaged before use.
• WARNING: Do not let go of the stroller unless it is in a safe location (away from high
winds, traffic, trains, steps/slopes etc.) with the brakes on.
• WARNING: Hold on to your stroller when close to moving vehicles and trains as the
draught from the vehicles may move the stroller even with the brakes on.
• WARNING: Do not carry or lift the stroller while open or with a child in it.
• Only use parts and accessories which are approved by the manufacturer or distributor.
Non-approved parts and accessories may be unsafe and must not be used and will
invalidate warranty.
• This stroller seats one passenger.
PR_102511d_MA_City Mini_4Whl_Instruct_UK.indd 2-1 11/18/11 12:14 PM

2 3
1 Lay stroller on its back so the handle is resting on the floor.
2 Attach the front wheel by sliding the axle into the wheel end until it clicks.
Gently tug on wheel to make sure the front wheel is locked in place.
Swivel/Straight Feature
• Push the lever to the left to lock the front wheel assembly in the straight position.
• Push the lever to the right to allow the front wheel assembly to swivel.
NOTE: When loading and unloading child, always lock the wheels in the straight position.
• You must engage both front wheel levers in order to swivel or lock the front wheels.
• Although the front wheels of your City Mini lock straight it is not intended for jogging
or exercise purposes.
FRONT WHEEL
CLICK
1 Unpack stroller from box and set
wheels aside.
3 The stroller will click into place.
2 Begin to unfold stroller by pulling the Auto-lock lever
while pushing the bottom frame up and away from
the handle.
4 Turn stroller over to upright position. Snap red safety
strap to frame under the fold mechanism before use.
FRAME
To fold: Unsnap safety strap from frame and pull up on fold strap.
WARNING: Ensure all locking devices are engaged before use.
PR_102511d_MA_City Mini_4Whl_Instruct_UK.indd 2-3 11/18/11 12:14 PM

4 5
4 5
1 Align wheel axle with wheel mount on stroller frame.
2 Insert the wheel axle into the wheel mount until it clicks into place.
Gently tug on wheel to make sure the rear wheel is locked in place.
REAR WHEELS
To install rear wheels:
1 Press the wheel release button while gently sliding the wheel
away from the wheel mount.
To remove the rear wheels:
Wheel
release
button
1 Unclip top of shoulder strap
from the seat and re-clip on
the pair of seat loops closest
to child’s shoulder height.
1 Pull shoulder pads down close to main harness buckle.
2Hold the plastic guide and pull the strap end to tighten
or pull the upper harness strap to loosen.
3 Fasten both shoulder strap buckles
into the crotch strap buckle. The
buckles should always be clicked
into place before use.
NOTE: If you have special harness requirements and wish to attach
your own harness, then there are D rings provided on the
waist harness for the attachment of your alternative harness
system. The alternative harness system must conform to
BS EN 13210:2004.
SAFETY HARNESS
To adjust harness height: To adjust harness length:
WARNING:
Always use the
crotch strap in
combination with
the shoulder straps
and waist belt.
To buckle: To unbuckle:
4 Press both sides of the
shoulder buckles to
release them from the
crotch buckle. WARNING:
Avoid serious
injury from falling
or sliding out.
Always properly
adjust and fasten
safety harness.
PR_102511d_MA_City Mini_4Whl_Instruct_UK.indd 4-5 11/18/11 12:14 PM

6 7
2 At the top and on the side of
the canopy, wrap Velcro strap
around upper frame handle,
fasten snap and attach Velcro
to seat back.
1 Slide canopy peg into the top
hole of the universal mounting
bracket until you hear it click
into place. (The bottom hole can
be used to attach Baby Jogger
accessories to your stroller).
CANOPY
To attach canopy to frame:
3 Secure the top of canopy around
stroller frame with Velcro tab.
To remove the canopy:
1 Press gray button to release the
canopy peg from the universal
mounting bracket and unfasten all
Velcro at the top of the canopy.
CLICK
Engaged Disengaged
BRAKE
Simply push brake pedal down to engage rear wheel parking brake and lift up to release.
WARNING: Engage parking device before loading
and unloading passenger.
PR_102511d_MA_City Mini_4Whl_Instruct_UK.indd 6-7 11/18/11 12:14 PM

8
8 9
1 Pinch the clamp behind the seat, and slide it down to desired recline.
Pull seat down on both sides to match recline position of clamp.
Reverse steps to return to the upright position.
Weather Cover: If desired,
pull weather cover down and
over the seat back mesh.
Secure firmly over both sides
of seat. When not in use, roll
weather cover up and fasten
with elastic loop and barrel
provided under top of the
canopy fabric.
SEAT RECLINE
To recline:
Removing the seat:
4 Loosen fold strap
rings and unhook
from fold mechanism.
1 Remove the canopy. 3 Unfasten seat straps from around the bottom/back
of the frame, located behind the front wheel.
2 Starting with the top snap closest to
the handle and working your way
down the entire frame, unsnap seat
from frame.
SEAT
PR_102511d_MA_City Mini_4Whl_Instruct_UK.indd 8-9 11/18/11 12:14 PM

10 11
1110
FOLDING
To fold stroller:
1 Remove child from seat. Unsnap safety straps from frame.
Pull upwards on the fold strap with a gentle tug.
To remove the basket:
1 From the rear of the stroller: Unsnap the top
snaps of the basket from around the frame
tubing above the middle crossbar. Unsnap
the bottom snaps of the basket from around
the frame tubing below the middle crossbar.
2 From the front of the stroller: Unsnap lower
seat fabric to expose the bottom front
portion of frame. Unfasten basket Velcro
from around the frame tubing. Snap seat
fabric to frame once complete.
BASKET
The basket of your City Mini comes fully attached.
PR_102511d_MA_City Mini_4Whl_Instruct_UK.indd 10-11 11/18/11 12:14 PM

12 13
12 13
Baby Jogger's Limited Lifetime Warranty:
• Baby Jogger warrants that the frame is free of manufacturer defects for the lifetime of the product. Manufacturer’s
defects include but are not limited to the breaking of welds and frame tube damage.
• Textile or soft side materials and all other components shall be warranted for manufacturing defects for one year from
the date of purchase (except for tubes and tires).
• In the UK proof of purchase is required to make a warranty claim and the warranty only applies to the original
purchaser.
THIS WARRANTY DOES NOT COVER:
• Normal wear and tear
• Corrosion or rust
• Incorrect assembly or the installation of third party parts or accessories which are not Baby Jogger Approved Parts and
Accessories
• Repairs, maintenance and modification that has not been carried out by Baby Jogger Approved Dealers
• Accidental or intentional damage, abuse or neglect
• Commercial Use
• Improper storage/care of the unit
• Any stroller that is returned in an unsanitary condition [ie covered in urine, vomit, animal faeces, food waste, mould etc]
or with bits missing, as we will not be able to inspect/repair it
• Any claims arising from products bought outside the UK, or products bought through outlets that are not Baby Jogger
Approved Dealers
• Use of this product outside the UK or damage in transit
• This warranty specifically excludes claims for indirect, incidental, or consequential damages. The implied warranties of
merchantability and fitness for a particular purpose are according to the specific warranty period for this model unit at
time of purchase.
• Baby Jogger U.S. has different terms, conditions, models and test criteria. Baby Jogger
U.S. must not be used to get information on specifications or warranty terms. Application
online is only for U.S. customers.
CONTACT : [email protected] • 0161 335 2508
REGISTER YOUR STROLLER ONLINE AT
www.babyjogger.com/register
To preserve the longevity of your stroller, it is important to perform simple, regular maintenance.
From time to time, make sure that the joints and folding areas are still in good condition. If you hear
any squeaking or feel tension, you can take your stroller to a local bike shop for added lubrication.
All repairs should only be carried out by an authorized dealer.
Washing
Seat Fabric
• You can machine wash your stroller’s seat in cold water with a mild detergent.
• Be sure to remove the metal frame and PE board from the back of the seat before washing.
• Do not use solvents, caustic or abrasive cleaning materials.
• To minimize shrinkage, simply reattach the seat to the frame to dry.
• Do not press, iron, dry clean, tumble dry or wring the fabric.
• If the seat covers need to be replaced only use parts from a Baby Jogger Authorized Dealer.
They are the only ones that are guaranteed to have been safety tested and designed to fit this seat.
Plastic/Metal Parts
• Wipe clean using a mild soap and warm water.
• You must not remove, dismantle or alter any part of the seat folding mechanism or brakes.
Wheel Care
• The wheels can be cleaned using a damp cloth. They will need to be dried completely
with a soft towel or cloth.
Storage
• Sunshine can fade seat fabric and dry out tires, so storing your stroller indoors will
prolong its good looks.
• DO NOT store outside.
• Ensure that the stroller is dry before storing for prolonged periods.
• Always store the stroller in a dry environment.
• Store the stroller in a safe place when not in use (i.e. where children cannot play with it).
• DO NOT place heavy objects on top of the stroller.
• DO NOT store the stroller near a direct heat source such as a radiator or fire.
CARE & MAINTENANCE
PR_102511d_MA_City Mini_4Whl_Instruct_UK.indd 12-13 11/18/11 12:14 PM

14
Imported by Kooltrade Ltd. M34 3QA
[email protected] • 0161 335 2508
The Baby Jogger Company: 8575 Magellan Parkway,
Suite 1000 • Richmond, VA 23227 USA • www.babyjogger.com
PR_102511d_MA_City Mini_4Whl_Instruct_UK.indd 14 11/18/11 12:14 PM
