Baby Trend Safari 1866CT User manual

Safari BabiesTravel System
MODEL # 1866CT
Instruction Manual
08.06
Convenience through Innovation and thoughtful design
Read all instructions BEFORE assembly and USE of product.
KEEP INSTRUCTIONS FOR FUTURE USE.

WARNING: Please follow all of these instructions to ensure the
safety of your child. Keep these instructions for future reference.
WARNING: Failure to follow these instructions could result in
serious injury or death. Avoid serious injury from falling or sliding out.
Always use the seat belt and insure that the child is properly positioned
according to these instructions.
WARNING: Never leave child unattended.
* Purses, shopping bags, parcels, diaper bags or accessory items may change the balance of the stroller and
cause hazardous unstable conditions.
* The maximum weight that can be carried in the basket is 5 lbs. The maximum weight that can be carried
in the Parent Tray is 3 lbs. Excessive weight may cause a hazardous unstable condition to exist.
* Be certain the stroller is fully erect and latched in the open position before allowing the child near the
stroller.
* The maximum weight capacity of this stroller is up to 45 pounds additional weight will cause excessive wear
and stress on the stroller and may cause a hazardous unstable condition to exist.
* DO NOT use the stroller on stairways or escalators.
* Never allow your stroller to be used as a toy
* To clean use only mild household soap or detergent and warm water on a sponge or clean cloth.
* Check your stroller for loose screws, worn parts, torn material or stitching on a regular basis. Replace or
repair parts as needed
* Discontinue use of stroller should it malfunction or become damaged. Please contact our customer service
Parts Hotline to arrange for repair or obtain replacement parts.
Please: If you experience any difculty with the use of our product or have a question regarding these instruc-
tions, please contact our Customer Service Department at [phone] between the hours of 8:00 am and
4:30 pm Pacic Coast Time. Please do not return to the store as once it is returned it cannot be resold and the
materials and energy used to make it are wasted.
To Contact Us:
Baby Trend, Inc. Customer Service Hot Line
1567 S. Campus Ave. [phone]
Ontario, CA 91761 8:00 a.m. to 4:30 p.m. Pacic Standard Time
WARNINGS
2

* Remove stroller from box. The front wheels, rear wheels, and child tray,
and parent tray need to be installed prior to use.
* To attach the front wheels, slide the red unlock mechanism and squeeze
the stroller handle while pulling backward on the stroller to unfold. See
gures 1 and 2.
* Lean the stroller backwards so that it rests on the handle and rear frame
tubes and the front wheel tubes are pointing upward. Position the front
wheel assembly at the front tube such that the hole in the swivel assembly
will slide onto the front tube. Please see gure 3. Push each front wheel
assembly onto the front tube being careful that wheel assembly locks onto
the front leg. Pull on the wheel assembly to ensure that it is securely
attached to the stroller. Please see gure 3.
* Lean the stroller forward to rest on the front wheels. Assemble the rear
wheels as follows:
1. Slide the rear axle assembly onto the rear stroller legs until they lock
into place. Please see gure 4.
2. Slide each wheel onto the rear axle and secure in place with the
Locking Cap. Snap the solid cap over the Locking Cap. Snap the
Hub Cap onto the wheel. Please see gure 5. Please see gure 6 for
order assembly.
Pull on each wheel to ensure that each is rmly attached to the axle.
* Ensure that the wheels are rmly locked into place. Do Not use the stroller
if the wheels are not locked into place, but rather contact our customer
service department immediately at [phone], between the hours of
8:00am and 4:30pm PCT, for assistance.
TO ENSURE SAFE OPERATION OF YOUR STROLLER, PLEASE FOLLOW THESE
INSTRUCTIONS CAREFULLY. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Car Seat
Front Wheels
Figure 3.
PARTS
TO ASSEMBLE STROLLER
Figure 6.
Child Tray
Figure 5.
Solid Cap
Locking Cap
Rear Wheels
Stroller
Figure 1.
Base
Car Seat
Figure 2.
Rear Axle Assembly
Hub Cap
Front Wheels
3
Figure 4.
Parent Tray

* To attach the front child tray, push the angled tray onto the post at the
end of the right armrest, while pressing downward on the snap button,
until locked into place. Please see gure 7. Rotate the tray downward
until latched onto the left armrest. Please check that the snap button
comes through and securely latches the tray in place. Please see gure
8.
* To remove front child tray, press inward on the left side tray release
button and rotate upward on the tray. Please see gure 9. Please note
that you may remove the tray completely by depressing the snap button
on the right side as shown in gure 10 while pulling forward on the tray.
Please see gure 7.
* To install the canopy slide the male ends of the canopy into the female
slots on the stroller frame. Please see gure 11. To open the canopy
push forward on the front frame tube of the canopy. Please see gure
12.
* The stroller handle has multiple positions. To adjust the handle to your
desired position, press in both round buttons at each end of the handle.
Please see gure 13.
* To attach the parent tray line up the parent tray slots with the
corresponding slots on the stroller frame, slide down until it locks into
place. Check to make sure the parent tray is secure before using. Please
see gure 14
* To remove the parent tray, locate the locking tabs under the tray, pull
outward on the locking tabs and lift up to remove. Please see gure 15
4
Figure 9.
Figure 7.
Figure 8.
Figure 12.
Front frame
tube
Figure 10.
Figure 11.
Figure 13.
Figure 14. Figure 15.

5
• The shoulder straps of the 5-point harness have 3 attachment positions.
Select the position that places the shoulder strap level with, or below
the top of the child's shoulder. To access the harness pull apart seat pad.
Please see gure 16.
• Carefully place the child in the stroller seat and bring the safety harness
around the child's waist and over the shoulders. Place the crotch strap
between the child's legs. Insert the male end of each shoulder/waist belt
into the buckle on the crotch strap. Tighten the harness to be snug around
the child's waist and over the child's shoulders Please see gure 17.
TO SECURE THE CHILD
Shoulder Strap
Squeeze
Crotch Strap
Waist
Strap
Adjust for a
snug fit
• To release, apply pressure to both sides of each male clip until the clip is released. See gure
18. This process requires a moderate amount of effort so as to prevent an accidental release by
your child.
WARNING: Avoid serious injury from
falling or sliding out. Always use the safety
harness.
STRANGULATION HAZARD:
Child can strangle in loose straps. Never leave
child in seat when straps are loose or undone.
Figure 17.
Figure 18.
Figure 16.

6
ATTACHMENT OF THE BABY TREND INFANT CAR SEAT
* To attach the Baby Trend Infant Car Seat, recline the seat all the way
back. Please see gure 19
* Check that the front child tray is rmly attached to the stroller
armrests. Make sure that the car seat locks into the front child tray. Then
turn tabs on stroller frame to lock the front of the car seat into the stroller.
See gure 20.
* Position the Infant Car Seat, facing toward the rear of the stroller, so
that the seat shell goes into the front tray and latches into place. Please
see gure 21. Check that the Infant Car Seat is rmly locked onto
the front tray before using.
* To remove the Infant Car Seat, squeeze the release handle located at the
foot-end of the seat and carefully lift upward on the seat. Please see
gure 23.
Figure 20.
Figure 22.
Locks
into tray
Figure 21.
WARNING: Failure to follow these
car seat attachment instructions could re-
sult in serious injury or death.
Figure 19.

7
SEAT BACK POSITIONING
WARNING: The upright position should
be used only for a child that is at least 6 months
old.
* The seat has a multiple position recline that is controlled by a cord and
spring loaded adjuster behind the seat. To recline the seat, pull back
on the loop of the adjuster. Please see gure 23. To place the seat back
in a more upright position, grab the adjuster with one hand and pull
the cord to the desired position with the other hand. See gure 24. The
cord will lock automatically.
BRAKES
WARNING: Always set brakes when the
stroller is not being pushed so that the stroller will not
roll away. Never leave stroller unattended on a hill or
incline as the stroller may slide down the hill.
* To engage brakes, apply light downward pressure to the brake lever
located on each rear wheel. The stroller may require slight forward or
rearward movement in order to line up the teeth on the brake with each
wheel brake cluster. See gure 25. Check that the stroller will not move
and that the brakes are properly applied. To release, gently lift up on the
brake lever.
Figure 23.
Figure 24.
Figure 25.

Figure 26.
8
* To open the canopy, push forward on the front frame of the canopy. To
close canopy, pull the front edge toward the rear of the stroller until
folded. Always fold the canopy prior to folding the stroller frame. Please
see gure 26.
CANOPY
Front frame
tube
Figure 27.
TO FOLD STROLLER
* Close the canopy as described in the canopy section. NOTE: For an
easier fold place the seat in the furthest recline position. Also you
must ip the carseat support tabs to the outside of the stroller frame
before folding. To fold the stroller slide the red fold lock with your
thumb while squeezing the large red fold button in the center of the
handle and push forward on the handle. Please see gure 27. Once the
stroller begins to fold, release the red handle and push forward on the
handle until the stroller is folded. Please see gure 28. To stroller will
automatically lock when folded correctly, and will stand freely in the
folded position.
Figure 28.
CAUTION: Read the following section completely before folding your stroller!
WARNING: Failure to
follow these folding instructions
could result in serious injury or
death.

9
TO UNFOLD STROLLER
Figure 30.
* To unfold the stroller slide the red fold lock with your thumb while
squeezing the large red fold button in the center of the handle and push
down on the handle.
WARNING: Failure to
follow these folding instructions
could result in serious injury or
death.
Figure 29.
CLEANING SEAT PAD
* To clean the seat pad. use warm water, soap and a sponge, and let air
dry.
IF YOU EXPERIENCE ANY DIFFICULTY IN USING THIS PRODUCT,
PLEASE CONTACT OUR CUSTOMER SERVICE DEPARTMENT AT [phone]
BETWEEN THE HOURS OF 8:00AM AND 4:30PM PACIFIC COAST TIME FOR ASSISTANCE.
STOP
