BaByliss PRO LO-PRO BAB726U User manual

BAB726U
LO-PRO TRIMMER

LO-PRO TRIMMER
Ergonomically designed, ultra low prole, high torque metal trimmer for
smooth powerful cutting and comfortable handling.
FEATURES
• High torque 6800 rpm brushless motor
• Metal housing with ultra low prole design
• Ergonomic design for comfortable handling
• Advanced high capacity lithium battery for up to 4 hours cordless use
• Ultra durable low friction, lower temperature PVD graphite coated
zero-gap adjustable T-Blade
• 360° exposed T-Blade for total visibility
• Cord/cordless
• LED low battery indicator
• Cord/cordless

SAFETY CAUTIONS
• Original instructions. Read these safety precautions
carefully before using the unit! This appliance should
only be used as described within this instruction
booklet. Please retain for future reference.
IMPORTANT CHILD SAFETY
• ALWAYS keep out of the reach of very young children
(during and after use).
• This appliance should not be used, cleaned or
maintained by children.
• Always take extra care if used on children or near
children.
• Do not use on very young children.
IMPORTANT SAFETY
• WARNING! Do not use this appliance near bathtubs,
showers, basins or other vessels containing water.
• Do not immerse the appliance in water or other liquids.
• Keep the appliance dry.
• UK Only: Do not use this appliance in the
bathroom.
• Outside the UK: If using the appliance in a
bathroom, unplug after use as the proximity of water
can be dangerous even if the appliance is switched
off. For additional protection the installation of a
residual current device (RCD) with a rated residual
operating current not exceeding 30mA is advisable in

the electrical circuit supplying the bathroom. Ask your
installer for advice.
• The appliance’s charging stand and/or adaptor must
be kept away from sources of water so that they do not
fall into the water.
• CAUTION! Keep the power cord and the appliance
dry. For appliances with a removable power supply
unit, remove the power cord before cleaning.
• Always inspect the appliance before use for noticeable
signs of damage. Do not use if damaged or if the
appliance has been dropped. In the event of damage
contact the Conair Customer Care Line (refer to ‘UK
After Sales Service’ section for further information).
• Do not use the appliance if the charging adaptor or lead
is damaged. In the event of damage, discontinue use
immediately. If the charging adaptor or lead is damaged,
it must be replaced by the manufacturer. Return the
appliance to the Customer Care Centre (refer to ‘UK
After Sales Service’ section for further information). No
repair must be attempted by the consumer.
• Only use the attachments supplied with this appliance.
• WARNING! For the purposes of recharging the battery,
only use the detachable charging supply unit provided
with this appliance - (CA78M). This symbol
indicates there is a detachable power supply for means
of charging.
• Do not leave the appliance unattended when switched
on.

• Do not leave the appliance plugged in for more than
24 hours.
• Unplug immediately if any problems occur during use.
• Do not place the appliance on any surface whilst in
operation.
• Special care is required when using the appliance close
to the ears, eyes and face.
• This appliance may be used by children aged from 8
and older and people with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction on the
safe use of the appliance and understand the hazards
involved. Children must not play with the appliance.
• This product contains a lithium ion rechargeable
battery that is not to be removed from the appliance
for charging. The batteries in this appliance are non-
replaceable. Batteries must be disposed of safely at
the end of life. Please take to a recycling centre for
safe disposal. If the battery leaks, avoid touching it and
dispose of it at a recycling centre.
• The supply terminals are not to be short circuited.
• This product complies fully with all appropriate EU
and UK Legislation and the standards relevant to this
type and class of appliance. We are an ISO9001:2015
certied company that continually evaluates our
Quality Management System performance. If you have
any queries regarding product safety and compliance,
please contact the Conair Customer Care Line (refer to
‘UK After Sales Service’ section).

WEEE - END-OF-LIFE ELECTRICAL AND
ELECTRONIC EQUIPMENT
In everybody’s interest and to actively participate in
protecting the environment and human health:
• Do not discard your products with your unsorted
household wastes.
• The WEEE (Waste electrical and electronic equipment)
must be collected separately.
• Use the return and collection systems dedicated to
the WEEE available in your area. In this way, some
materials can be recycled, re-used or recovered.
• By ensuring this product is disposed of properly, you
will help prevent potential negative consequences for
the environment and human health due to possible
content of hazardous substances.
For more detailed information about the disposal of this
product, please contact your local household waste
disposal service.
TECHNICAL DATA
Vibration and noise levels
Adaptor CA78M
Vibrations <2.5m/s²
LpA (dB(A)) <70

PREPARATION FOR USE
General
• Always inspect the appliance before use to ensure the trimmer blades
are free from hair, debris etc.
• Use on clean, dry hair that has been combed until tangle-free.
Oiling Instructions
• For optimum cutting performance, it is highly recommended to oil the
blades after every use.
• When using the oil for the rst time, unscrew the cap and cut off the
very end of the plastic tube with a pair of scissors.
• Remove the blade guard and switch the appliance on.
• Holding the trimmer at a 45 degree angle, gently squeeze the oil tube
and apply 2 drops directly onto the blades.
• Leave the unit on for a further few seconds to allow the oil to
thoroughly spread along the length of the blades.
• Switch off the unit and remove any excess oil by gently dabbing with
a cloth before using on hair.
INSTRUCTIONS FOR USE
Charging the Appliance
• Before using the appliance for the rst time, charge the battery
continuously for 3 hours. Maximum battery capacity will only be
reached after 3 completed charging and discharging cycles.
• Plug the charging adapter into a suitable mains power socket and
connect to the unit and switch on. The LED indicator light will ash
when correctly connected to the mains power and will continuously
ash until the battery has fully charged. When the battery is fully
charged the LED indicator light will stop ashing but remain on.
NOTE: Always place the trimmer in the base with the ‘I/0’ switch in the
OFF position.
• When the trimmer is running low on charge, the LED indicator light
will ash, warning there is approximately 3 minutes of battery use
remaining. A 3 hour charge will provide approximately 4 hours use.
• If the charging light starts to ash rapidly (more than 4 ashes per
second) then the appliance is faulty. If this happens then please stop
charging and remove the adapter from the mains and contact the

Conair Customer Care Line. (See ‘UK After Sales Service’ section for
further information).
Preserving the Batteries
• In order to maintain the optimum capacity of the rechargeable
batteries, the appliance should be recharged for 3 hours approximately
every 6 months.
• Using the trimmer on the mains - ensure that the trimmer is switched
off. Plug into a suitable mains socket. Wait for approximately a
minute, and then switch on.
IMPORTANT: Do not use the trimmer in this mode for more than 20
minutes.
REMOVING AND REPLACING THE BLADE
Ensure the trimmer isn’t connected to the mains and is switched off.
Turn the trimmer upside down so that the teeth of the trimmer are facing
down. Place the trimmer on a at surface and using the screwdriver,
loosen the fastening screws from the blade. Remove the blade from
the trimmer (Fig. 1).
Blade
Blade screws
Fig. 1
To install or replace your trimmer blade, reverse the procedure, aligning
the blade cushion shaft into the moving blade cushion (Fig. 2). With
the blade held in place, replace blade screws and tighten loosely. Turn
the trimmer over and align the blade set parallel to the trimmer’s upper
housing.
Fig. 2 Blade cushion Screws
Moving blade
Fixed blade
Screws
Screw holes

ZERO GAP ADJUSTMENT TOOL
IMPORTANT! Only attempt to zero gap the blades by using the
adjustment tool and following the instructions very precisely.
The adjustment tool is required to adjust the blades to zero gap, which
will achieve a closer, more precise cut.
• Step 1 – Using the screwdriver included,
gently loosen the two small screws on each
side of the blade.
• Step 2 – Slide the zero gap tool over the gold
xed blade until it is tight against the back
portion of the moving cutting blade.
• Step 3 – Using your ngers on each side of
the zero gap tool, push up until the cutting
blade is even with or slightly below the xed
blade.
Be sure that the blades are aligned properly. The teeth of the smaller
blade (cutter) should rest slightly below the upper edge of the larger
blade (comb) — approximately 0,5 mm to 1 mm apart (Fig. 3). If the
blades are not correctly aligned, they may cut or scratch your skin
when trimming. Once the blades have been aligned, tighten the screws
rmly.
Fig. 3 Comb (large blade)
Cutter (small blade)
0.5 mm - 1 mm
• Step 4 – WARNING! Make sure the moving
cutting blade doesn’t extend past the xed
blade. If the cutting blade extends past the
xed blade it can potentially cut the skin.

• Step 5 – Once the blade is adjusted to zero gap
or your liking, gently tighten the two screws on
each side of the blade while holding the zero
gap tool in place. If the blade is not adjusted to
satisfaction after testing, repeat the adjusting
process.
Cleaning & Maintenance
• To maintain optimum performance, the appliance should be cleaned
after each use.
• Blow away any remaining hair on the blades or use the cleaning
brush provided.
• Oil the blades after every use to ensure optimum cutting performance.
IMPORTANT: Blades must be cleaned and oiled on a regular basis for
proper functioning. Failure to regularly clean and oil the blades will void
the guarantee.
DO NOT RINSE BLADE, TRIMMER HANDLE OR ADAPTER

UK GUARANTEE
This BaByliss PRO appliance is guaranteed for professional use for 2
years and is only valid within the United Kingdom.
Exclusions
This guarantee will no longer be valid meaning that The Conair Group
Ltd will not be liable to repair or replace your product where:
1.) The appliance has been used on a voltage supply other than that
which is marked on the product, or advised within this instruction
booklet.
2.) The appliance has been purchased from an unauthorised stockist*.
3.) Repairs or alterations have been attempted by unauthorised
persons.
4.) The failure of the appliance is a direct result of misuse.
5.) The failure is a result of not following the instructions for use.
This guarantee does not cover any cosmetic damage due to misuse
of the product nor any damage to persons or property that occurs
because of product misuse.
*unauthorised stockists include, but are not limited to online auction
sites, private sellers and those selling second hand goods, refurbished
products etc.
Please contact the Conair Customer Care Line on 03705 133 191
(09:00 to 17:00 Monday to Friday) or e-mail [e-mail] for
further information on authorised stockists.
It is important to retain your proof of purchase. We recommend
attaching your receipt to this page.
Even where a refund may be applicable, no refund will be provided
without a valid receipt or proof of purchase, we will only be able
to offer a repair or replacement service. Please note this does
not apply if the product was purchased directly from The Conair
Group Ltd.

Guarantees on replacement products run from the original purchase
date or date of delivery, whichever is later, and not from the date of
replacement.
This guarantee is an additional benefit and does not affect your
statutory rights as a consumer.
If you have any queries regarding this guarantee please contact the
Conair Customer Care Line on 03705 133 191 (09:00 to 17:00 Monday
to Friday) or e-mail [e-mail].
UK AFTER SALES SERVICE
For further advice on using the appliance or should you need to return
your product, please contact the Conair Customer Care Line on
03705 133 191 (09:00 to 17:00 Monday to Friday) or e-mail your enquiry to
[e-mail].
Return address:
Customer Care Centre
Conair Logistics
Unit 4, Revolution Park
Buckshaw Avenue
Buckshaw Village
Chorley
PR7 7DW
Please enclose your returns number, name and address details, together
with a copy of proof of purchase and details of the fault.
Please note this Instruction Booklet is not the guarantee.

SAFE DISPOSAL
The symbol on the product or on its packaging indicates that this
product may not be treated as household waste. Instead it should be
handed to an appropriate collection point for the recycling of Electrical
and Electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for
the environment and human health, which could otherwise be caused
by inappropriate waste handling of this product. For more detailed
information about the recycling of this product, please contact your
local council ofce or your household waste disposal service.

IB-
