BaByliss 7861U User manual

JAPANESE STEEL
12 IN 1 MULTI TRIMMER
7861U
SAFETY CAUTIONS
• Original instructions. Read these safety precautions
carefully before using the unit! This appliance should
only be used as described within this instruction booklet.
Please retain for future reference.
IMPORTANT CHILD SAFETY
• ALWAYS keep out of the reach of very young children
(during and after use).
• This appliance should not be used, cleaned or maintained
by children.
• Always take extra care if used on children or near children.
• Do not use on very young children.
IMPORTANT SAFETY
• This appliance can be used in the bath or shower.
CAUTION! for appliances with a removable
power supply unit, remove the power cord before
cleaning or using the appliance under running water.
• UK Only: Do not charge this appliance in the bathroom.
• Outside the UK: If using the appliance in a bathroom,
unplug after use as the proximity of water can be

dangerous even if the appliance is switched off. For
additional protection the installation of a residual current
device (RCD) with a rated residual operating current not
exceeding 30mA is advisable in the electrical circuit
supplying the bathroom. Ask your installer for advice.
• The appliance’s charging stand and/or adaptor must be
kept away from sources of water so that they do not fall
into the water.
• Always inspect the appliance before use for noticeable
signs of damage. Do not use if damaged or if the
appliance has been dropped. In the event of damage
contact the Conair Customer Care Line (refer to ‘UK After
Sales Service’ section for further information).
• Do not use the appliance if the charging adaptor or lead
is damaged. In the event of damage, discontinue use
immediately. If the charging adaptor or lead is damaged,
it must be replaced by the manufacturer. Return the
appliance to the Customer Care Centre (refer to ‘UK After
Sales Service’ section for further information). No repair
must be attempted by the consumer.
• Only use the attachments supplied with this appliance.
• WARNING! For the purposes of recharging the battery,
only use the detachable charging supply unit provided
with this appliance (CA76). This symbol indicates
there is a detachable power supply for means of charging.
• Do not leave the appliance unattended when switched
on.
• Do not leave the appliance plugged in for more than 24
hours.

• Unplug immediately if any problems occur during use.
• Do not place the appliance on any surface whilst in
operation.
• Special care is required when using the appliance close
to the ears, eyes and face.
• This appliance may be used by children aged from 8
and older and people with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction on the
safe use of the appliance and understand the hazards
involved. Children must not play with the appliance.
• This product contains a Lithium ion rechargeable battery
that is not to be removed from the appliance for charging.
The batteries in this appliance are non-replaceable.
Batteries must be disposed of safely at the end of life.
Please take to a recycling centre for safe disposal. If the
battery leaks, avoid touching it and dispose of it at a
recycling centre.
• The supply terminals are not to be short circuited.
• For domestic use only.
• This product complies fully with all appropriate EU
and UK Legislation and the standards relevant to this
type and class of appliance. We are an ISO9001:2015
certied company that continually evaluates our Quality
Management System performance. If you have any
queries regarding product safety and compliance, please
contact the Conair Customer Care Line (refer to ‘UK After
Sales Service’ section).

WEEE - END-OF-LIFE ELECTRICAL AND ELECTRONIC
EQUIPMENTS
In everybody’s interest and to actively participate in
protecting the environment and human health:
• Do not discard your products with your unsorted
household wastes.
• The WEEE (Waste electrical and electronic equipment)
must be collected separately.
• Use the return and collection systems dedicated to the
WEEE available in your area. In this way, some materials
can be recycled, re-used or recovered.
• By ensuring this product is disposed of properly, you will
help prevent potential negative consequences for the
environment and human health due to possible content
of hazardous substances.
For more detailed information about the disposal of this
product, please contact your local household waste
disposal service.
INSTRUCTIONS FOR USE
IMPORTANT! Only use the adaptor and attachments supplied with
this appliance.
General
• Always inspect the appliance before use to ensure the trimmer blades
are free from hair, debris etc.
• Use on clean, dry hair that has been combed until tangle-free.

Oiling Instructions
• For optimum cutting performance, it is highly recommended to oil the
blades after every use.
• When using the oil for the rst time, unscrew the cap and cut off the
very end of the plastic tube with a pair of scissors.
• Remove the blade guard and switch the appliance on.
• Holding the trimmer at a 45 degree angle, gently squeeze the oil tube
and apply 2 drops directly onto the blades.
• Leave the unit on for a further few seconds to allow the oil to
thoroughly spread along the length of the blades.
• Switch off the unit and remove any excess oil by gently dabbing with
a cloth before using on hair.
Charging the appliance
• This trimmer is equipped with lithium ion batteries.
• Before using for the rst time, the appliance should be fully charged
continuously for 3 hours. This initial super-charge ensures optimum
power performance to ensure smooth fast trimming every time.
Maximum battery capacity will only be reached after 3 charging and
discharging cycles.
• Plug the charging adapter into a suitable mains power socket and
switch on at the wall. A blue LED light will continuously ash whilst
the product is charging. When the battery is fully charged the blue
LED light will stop ashing and remain alight.
Note: Always ensure the trimmer in the I/0 ‘OFF’ position when
charging.
• A 2 hour charge will provide 120 minutes of cordless use. A 20 minute
quick charge will provide approximately 20 minutes use.
IMPORTANT! Only use the adaptor and attachments supplied with
this appliance. Please note, if the wrong adaptor is used, the blue LED
will blink continuously. Once the wrong adaptor is removed the blue
LED will continue to blink for some time after removal. This is normal.

Cordless Operation
• Ensure appliance is charged for a minimum of 20 minutes. The blue
LED charging light will ash when the adaptor is correctly inserted
into the appliance and connected to the mains.
• Once the appliance is fully charged the blue LED charging light
will stop ashing but remain on. Remove the mains cord from the
appliance, turn on and use as required.
Preserving the batteries
• In order to maintain the optimum capacity of the Lithium-ion
rechargeable batteries, the trimmer should be fully discharged and
then recharged for 3 hours every 6 months.
• For optimum performance, we recommend you charge the unit for at
least 30 minutes before using the appliance each time. This applies
to whether you are using it with cordless power.
Changing the Heads
• Before changing the heads, ensure the trimmer is switched off.
• To remove the head, twist the pull off (Fig. 1).
• To attach the head, by aligning the markers up, sliding the head on and
twisting the head to lock (Fig. 2).
1. 2.
1. 2.
1. 2.
1. 2.
1. 2.
Remove head
Place head
Place Comb Shaver
Place Comb trimmer
release Comb trimmer
1. 2.
1. 2.
1. 2.
1. 2.
1. 2.
Remove head
Place head
Place Comb Shaver
Place Comb trimmer
release Comb trimmer
(Fig. 1) (Fig. 2)

Comb Guides
7-Position comb guide for Precision Trimmer
• Ensure the appliance is switched off.
• Attach the Precision Trimmer head.
• Align the trimmer with the tracks at the back
of the handle. Slide the trimmer head onto the
tracks. Push down the release mechanism to
push it right on to the handle.
• The comb guide will be set to the shortest length
when the comb guide is fully pressed down.
• With your thumb, push the guide up to the required length (2-14mm).
The comb guide has 7 positions; 2mm, 4mm, 6mm, 8mm, 10mm,
12mm and 14mm.
• To remove the comb, place your thumb on the back of the attachment
and pull out the comb base lock from the bottom, before pushing up.
1. 2.
1. 2.
1. 2.
1. 2.
1. 2.
Remove head
Place head
Place Comb Shaver
Place Comb trimmer
release Comb trimmer
1. 2.
1. 2.
1. 2.
1. 2.
1. 2.
Remove head
Place head
Place Comb Shaver
Place Comb trimmer
release Comb trimmer

6-position stubble comb guide for Precision Trimmer
The stubble comb with 6-position switch enables
super ne cut adjustment for precision trimming.
• Attach stubble comb by sliding the head onto
the tracks at the rear of the handle.
• Choose a length between 1-3.5mm in 0.5mm
increments. Slide the switch across, so the line
is lined up with the desired length.
Body Groomer comb guides for the Body Groomer
• Ensure the appliance is switched off
• Attach the body groomer head by taking off the current head and
snapping the body groomer head into the base of the appliance.
• Attach a comb guide (3, 5, 7mm) by placing on top of the body
groomer head and pressing down.
• To remove the body groomer comb guide push the comb guide up
TRIMMING
Precision Trimmer
Using the Precision Trimmer with 7-position stubble and
6-position beard comb guides
• Attach the 7-position beard comb guide (2-14mm) or the 6-position
stubble comb guide (1-3.5mm) and select the required length.
• If you require more than one cutting length, start with the longest
length rst.
• Switch the trimmer on.
• Hold the trimmer with the teeth of the trimmer pointing upwards, yet
at against the skin.
• Move the trimmer upwards and outward through the hair, against the
direction of hair growth.
• The trimmer will work most efciently when cutting through hair at its
own speed.
• Never switch the appliance off whilst in the hair.
• Note: The Precision Trimmer can be used without any comb guides
and will cut roughly to a length of 0.5mm.

To outline using the Precision Trimmer
• Do not attach a comb guide.
• Hold the trimmer upside down with the blade
facing downwards, yet at against the skin.
• Move the trimmer gently downwards in small
strokes around the edge of the area you wish to
outline.
• Having dened the outline, hold the trimmer with
the blades pointing upwards, yet at against
the skin and move the trimmer upwards against the direction of hair
growth. This will trim the unwanted hair adjacent to the outline.
Using the Body Groomer with comb guide
• Attach the body grooming attachment.
• Add on the comb guide if a longer length is
required
• Switch the trimmer on.
• Hold the trimmer at against the skin.
• Move the trimmer upwards and outward through
the hair, against the direction of hair growth.
• Make sure to be particularly careful when
trimming sensitive areas.
• The trimmer will work most efciently when cutting through hair at its
own speed.
• Never switch the appliance off whilst in the hair.
• Note: The Body Groomer can be used without any comb guides and
will cut roughly to a length of 0.1mm.
Foil Shaver
Using the Foil Shaver
• For an ultra-smooth nish, use the foil shaver
attachment.
• Always ensure the foil is not damaged before
each use.
• Switch the trimmer on.

• Move the shaver gently over the skin, applying minimal pressure and
shaving in the direction of hair growth.
• Make sure to be particularly careful when trimming sensitive areas.
• Never switch the appliance off whilst in the hair.
Nose & Ear Trimmer
Using the Nose & Ear Trimmer
• For the safe and easy removal of unwanted nose
and ear hair use the rotary trimmer head.
• Switch the trimmer on.
• Insert the trimmer into the nose or ear and gently
move the trimmer in a circular motion.
• Onlyusethetrimmerattheentrancetotheearornose.
Do not use any deeper, as this could cause injury.
• Never turn the trimmer off whilst in the nose and ear hair.
Detail Trimmer
Using the Detail Trimmer
• For accurate tramlines and detailed effects,
attach the Detail Trimmer head.
• Switch the trimmer on.
• Gently move the blade through the area of hair
you wish to trim.
• The trimmer will work most efciently when
cutting through hair at its own speed.
• Never turn the trimmer off whilst in the hair.
CLEANING & MAINTENANCE
To maintain optimum performance, the appliance should be cleaned
after each use:
• Remove the comb guide after use. Rinse under running water and dry
thoroughly before storage or use.
• Remove the trimmer head after use. The heads are washable for
easy cleaning. Rinse under running water and dry thoroughly before
storage or use.

• Do not disassemble the blades.
• For instructions on how to re-attach the head, please refer to
‘Changing the heads’ section.
BATTERY DISPOSAL
This appliance contains Li-ion batteries. To protect the environment this
appliance and its batteries must be disposed of safely. At the end of its
life, please take this appliance to a recycling centre, where the internal
rechargeable battery should be removed by a professional and recycled
separately.
For more information about the recycling of electrical and battery operated
appliances please contact your local council ofce or your household
waste disposal service.
For specic enquiries regarding the replacement of batteries in this
product please contact our Conair Customer Care Line – see ‘UK After
Sales Service’ section.
UK GUARANTEE
This BaBylissMEN appliance is guaranteed for consumer use for 3
years and is only valid within the United Kingdom.
This guarantee covers consumer use only i.e. defects occurring under
normal use within the home from date of purchase or date of delivery,
whichever is later.
If the product develops a fault due to defects in materials or manufacture
within 12 months from the date of purchase, to avoid delays and
unnecessary inconvenience, where possible please return the product
to the point of purchase for an exchange.
If the product develops a fault due to defects in materials or manufacture
after 12 months from the date of purchase, and within the guarantee
period, Conair UK After Sales Service will repair or replace the product.

Exclusions
This guarantee will no longer be valid meaning that The Conair Group
Ltd will not be liable to repair or replace your product where:
1.) The appliance has been used on a voltage supply other than that
which is marked on the product, or advised within this instruction
booklet
2.) The appliance has been purchased from an unauthorised stockist*
3.) The appliance is used for professional / non domestic usage
4.) Repairs or alterations have been attempted by unauthorised persons
5.) The failure of the appliance is a direct result of misuse
6.) The failure is a result of not following the instructions for use
This guarantee does not cover any cosmetic damage due to misuse
of the product nor any damage to persons or property that occurs
because of product misuse.
*unauthorised stockists include, but are not limited to online auction
sites, private sellers and those selling second hand goods, refurbished
products etc.
Please contact the Conair Customer Care Line on 03705 133 191
(09:00 to 17:00 Monday to Friday) or e-mail [e-mail] for
further information on authorised stockists.
It is important to retain your proof of purchase. We recommend
attaching your receipt to this page.
Even where a refund may be applicable, no refund will be provided
without a valid receipt or proof of purchase, we will only be able
to offer a repair or replacement service. Please note this does
not apply if the product was purchased directly from The Conair
Group Ltd.

Guarantees on replacement products run from the original purchase
date or date of delivery, whichever is later, and not from the date of
replacement.
This guarantee is an additional benefit and does not affect your
statutory rights as a consumer.
If you have any queries regarding this guarantee please contact the
Conair Customer Care Line on 03705 133 191 (09:00 to 17:00 Monday
to Friday) or e-mail [e-mail]
UK AFTER SALES SERVICE
For further advice on using the appliance or should you need to return
your product, please contact the Conair Customer Care Line on 03705
133191 (09:00 to 17:00 Monday to Friday) or email your enquiry to
[e-mail].
The return address is:
Customer Care Centre,
Conair Logistics
Unit 4
Revolution Park
Buckshaw Avenue
Buckshaw Village
Chorley
PR7 7DW
Please enclose your returns number, name and address details,
together with a copy of proof of purchase and details of the fault.

IB-19/147B
