Instruction 0019-9337 1
Oxor® III
1.0 INTRODUCTION
The Oxor®III is a portable analyzer designed to detect and display concen-
trations of Oxygen (O2) gas between 0 and 20.9%. The analyzer is capable
of testing for O2in both ambient room air, and in the flue-gas stream of
fossil-fuel fired furnaces and boilers (with optional probe assembly).
Ordering Information:
Part No. Description
0019-8112 Oxor III includes 4 ‘AA’ batteries, probe & hose assembly with
integral filter, and a hard carrying case.
0019-8113 Oxor III includes 4 ‘AA’ batteries, probe & hose assembly with
integral filter, hard carrying case, plus an IrDA printer.
The analyzer detects and displays the presence of O2by first drawing in a
gas sample from the area being tested by the analyzer’s built-in motorized
pump. The gas sample is next directed into a sensor chamber where the
sample is analyzed for the presence of O2.
A permanent record of the detected O2level, along with the current time
and date, can be made by using the optional wireless IrDA printer.
A backlight enables the operator to read the display in dimly-lit areas. A
power-saver feature causes the backlight to automatically turn OFF after
10 minutes, and causes the analyzer to shut OFF after 20 minutes of inac-
tivity.

Instruction 0019-9337
2
Oxor® III
2.0 TECHNICAL CHARACTERISTICS
O2Display Range ....................... 0–20.9%
O2Accuracy ................................ +0.4 / -0.8% O2
O2Resolution .............................. 0.1%
O2Response Time ...................... 90% of final value within 30 sec.
Ambient Temperature Display Range.. 0 to 100° C (32 to 212° F)
Ambient Temperature Accuracy... ±3 ° C between 0 and 40° C (32 to 104° F)
Ambient Temperature Resolution... 0.1° C (0.1° F)
Battery Requirement ................. Four disposable ‘AA’ Alkaline batteries
Operating Time .......................... Up to 18 hours continuous (pump running
and backlight off)
Warm Up Time........................... 60 seconds
Display ........................................ 4 digit by 2 line, 7-segment Liquid Crystal
Display
Front Panel Controls.................. Six push button switches
(refer to Section 3.3)
Operating Temperature Range.. 0 to 40° C (32 to 104° F)
Humidity..................................... 15 to 90% RH (non-condensing)
Printer Port ................................ IrDA or HP protocol
Weight ......................................... 16 oz with batteries
Size.............................................. 7.5"H x 3.1"W x 2.1"D (190x79x53 mm)

Instruction 0019-9337 3
Oxor® III
3.0 PREPARING THE ANALYZER
FOR OPERATION
To prepare a new analyzer for operation, you must install four ‘AA’
Alkaline batteries, install the probe (if needed), and set the correct time
and date as described in the following paragraphs.
For your convenience, and to ensure that the analyzer will provide reliable
O2readings, the O2sensor was installed and the analyzer calibrated on a
known concentration of O2at the factory.
3.1 Battery Installation
Install fresh batteries as described below. Check the analyzer for sufficient
charge prior to each use. Replace the batteries if the low-battery symbol
appears in the lower right corner of the LCD. To install batteries:
1. Remove battery cover from back of unit (see Figure 3-1).
2. If old batteries are installed, remove and properly dispose of the
batteries.
3. Observing the polarity markings inside the battery compartment,
install four ‘AA’ Alkaline batteries.
4. Replace battery cover.
Removebatterycover
by pressing hereand
sliding cover outward
Figure 3-1. Battery Installation

Instruction 0019-9337
4
Oxor® III
3.2 Probe Installation
To install the probe, simply slide its hose over the GAS inlet of the ana-
lyzer (see Figure 3-2).
Filter
Hose
Figure 3-2. Probe Connection

Instruction 0019-9337 5
Oxor® III
3.3 Front Panel Pushbuttons
Note that a push button may perform several functions, depending on what
screen is being displayed at the time.
I/O • Turns analyzer ON/OFF. There is a 60 second warm-up and
a 5 second turn-off-delay period.
•Places the analyzer into either its Setup or Calibration Mode
when used in conjunction with the ENTER or HOLD button.
•Causes the displayed value to increase or change while in
the Calibration or Setup Mode.
•Causes the displayed value to decrease or change while in
the Calibration or Setup Mode.
ENTER •Starts a test – pump ON.
•Sets up the analyzer to be placed into its Calibration Mode
when held down with the analyzer OFF. (Used in conjunc-
tion with the I/O button.)
•Stores the displayed value and automatically steps to the
next screen when pressed during calibration or setup.
•Displays the O2screen when held down for 2 seconds while
in the Calibration Mode.
•Aborts turn-off and keeps the analyzer turned ON when
pressed during either the 5 second turn-off-delay period.
HOLD •Freezes the display and stops the pump during a test.
•Starts a printout when pressed twice with the pump run-
ning, or when pressed once with the pump OFF.
• Sets up the analyzer to be placed into its Setup Mode when
held down with the analyzer OFF. (Used in conjunction with
the I/O button.)
LIGHT Toggles the backlight ON and OFF.

Instruction 0019-9337
6
Oxor® III
3.4 Setup Mode
The analyzer is preset at the factory for the parameters shown below, but
can be changed as described in their associated sections.
Function Parameter To Change
Temperature Unit °F Section 3.4.2
Time Not Set Section 3.4.3
Date Not Set Section 3.4.4
Year Not Set Section 3.4.5
Printer IrDA Section 3.4.6
3.4.1 Entering Setup
1. With the analyzer turned OFF, press and hold down the HOLD
button.
2. Press and release the I/O button.
3. Release the HOLD button.
4. The analyzer is now in its Setup Mode. Refer to Sections 3.4.2 thru
3.4.6 for information on how to set the analyzer’s various parameters.
3.4.2 Temperature Units Setup
The Temperature Units Setup Screen is labeled “Unit”.
1. Enter the Setup Mode per Section 3.4.1. If necessary, repeatedly
press ENTER until the Temperature Units Setup Screen is displayed.

Instruction 0019-9337 7
Oxor® III
2. Press the or button until the desired temperature unit
(°F or °C) is displayed.
3. Press ENTER to move to the next Setup Screen, or I/O to exit setup.
3.4.3 Time Setup
There are two Time Setup Screens, one for hours and the other for min-
utes. Two bars appear above the segments being changed. The clock is in
a 24 hour format, but will appear as AM/PM on the printout.
.
1. Enter the Setup Mode per Section 3.4.1. If necessary, repeatedly
press ENTER until the first Time Setup Screen is displayed—the
one with two bars over the hour digits.
2. Press the or button until the correct hour value is displayed.
3. Press ENTER to move the selection bars over the minute digits.
4. Press the or button until the correct minute value is displayed.
5. Press ENTER to move to the next Setup Screen, or I/O to exit setup.
3.4.4 Date Setup
There are two Date Setup Screens, each labeled “DAtE”. The first screen
sets the month while the second screen sets the day.

Instruction 0019-9337
8
Oxor® III
1. Enter the Setup Mode per Section 3.4.1. If necessary, repeatedly
press ENTER until the first Date Setup Screen is displayed.
2. Press the or button until the correct month is displayed.
3. Press ENTER to switch to the second Date Setup Screen.
4. Press the or key until the correct day is displayed.
5. Press ENTER to move to the next Setup Screen, or I/O to exit setup.
3.4.5 Year Setup
The Year Setup Screen is labeled “yEAr”.
1. Enter the Setup Mode per Section 3.4.1. If necessary, repeatedly
press ENTER until the Year Setup Screen is displayed.
2. Press the or button until the correct year is displayed.
3. Press ENTER to move to the next Setup Screen, or I/O to exit setup.
3.4.6 Selecting Printer Protocol
The Printer Setup Screen is labeled “Prnt”. The analyzer can be set up to
send data to a wireless printer using either HP or IrDA protocol.
1. Enter the Setup Mode per Section 3.4.1. If necessary, repeatedly
press ENTER until the Printer Setup Screen is displayed.
2. Press the or button to select the desired protocol.
3. Press ENTER to move to the next Setup Screen, or I/O to exit setup.

Instruction 0019-9337 9
Oxor® III
3.4.7 Exiting the Setup Screen
Press the I/O button at any time to exit the Setup Mode and turn the ana-
lyzer OFF. Note that the last displayed parameter is automatically saved
in memory.
4.0 OPERATION
• Power the analyzer ON
• Wait for the unit to warm up
• Take a gas sample
4.1 Taking a Gas Sample
Turn ON the analyzer by pressing the I/O button. Observe that when
power is first applied, the software revision level is first displayed followed
by a screen that counts down the warm-up period. The warm-up period is
60 seconds.
.
Following warm-up, the O2screen appears. This screen directly shows O2
levels in the range of 0-20.9% and ambient temperatures in the range of
0-100° C (32 to 212° F). If the probe is being used, insert the probe tip into
the area to be sampled.
AMBIENT
Note: If a sensor error was detected during warm-up, the O2Sensor Error
Screen will be displayed. Refer to Section 4.4.
Tip: An O2error will occur when the oxygen sensor's output drops to be-
tween 80 and 90. Consider replacing the oxygen sensor when its ouput level
drops below 100.

Instruction 0019-9337
10
Oxor® III
Front Panel Button Functions:
 – No effect
– No effect
HOLD – Freezes display and stops pump; pressing a second time
activates printing
ENTER – Restarts testing after the HOLD button was pressed
LIGHT – Toggles backlight ON/OFF
I/O – Turns analyzer OFF (with a 5 second delay)
4.2 Ending a Test
After taking a gas sample, remove the probe and take the analyzer to an
area containing fresh air. Allow the pump to run until the O2reading is
20.9% O2.
4.3 Turning OFF the Analyzer
Turn OFF the analyzer by pressing the I/O button. The analyzer will count
down from 5 before turning OFF. Pressing ENTER, however, will abort the
count down and keep the analyzer ON.
4.4 O2Sensor Error Screen
An O2sensor error is displayed if the analyzer determines during the
warm-up cycle that the oxygen sensor's output is too low for it to be usable.
However, in the extreme condition when the O2sensor has no output, a sen-
sor error will not occur. Instead, the O2reading will be 0.0, as displayed in
the O2Screen.

Instruction 0019-9337 11
Oxor® III
4.5 Using the Backlight
The LCD can be read in dimly-lit areas by pressing the LIGHT button.
The backlight automatically turns OFF after 10 minutes of keyboard
inactivity, but can be turned OFF at any time by again pressing the
LIGHT button.
4.6 Saving Test Data in Memory
Up to 10 individual sets of test data can be saved in memory as follows:
Note: When memory is full, the next reading saved will over-
write the oldest reading.
1. If the analyzer is in its Run Mode, press the HOLD button twice to
enter the Print/Memory Menu Screens. If the analyzer is already
in its Hold Mode, press the HOLD button only once. The first menu
item displayed is the Print Screen.
2. Press the button once to display the Save Screen. The number
shown in this screen represents the memory location (1 thru 10) to
which the current test data will be saved.
3. Press ENTER to save the test data and return to the Hold Mode, or
press HOLD to return to the Hold Mode without saving.

Instruction 0019-9337
12
Oxor® III
4.7 Opening and Viewing Saved Test Data
Perform the following to open and view saved test data:
Note: If no test data has been saved, the option to open the
memory for viewing will not be available.
1. If the analyzer is in its Run Mode, press the HOLD button twice to
enter the Print/Memory Menu Screens. If the analyzer is already
in its Hold Mode, press the HOLD button only once. The first menu
item displayed is the Print Screen.
2. Press the or button until the Open Screen is displayed, and
then press ENTER to open the memory locations for viewing. The
number shown in the second screen represents the most recent
memory location where data was stored.
3. Press the or button to scroll to the desired memory location,
and then press ENTER to recall the stored data and return to the
Hold Mode. While in the Hold Mode, the recalled data can be viewed
or printed per Section 4.8.
4.8 Printing Test Data
Tip: To avoid printing errors, it is important to select the
correct protocol per Section 3.4.6 before saving data.
Turn ON the printer. Refer to the printer’s instruction manual for detailed
operation and maintenance information.
If not already done, set the printer parameters as follows:
• Data: 8 bits • Parity: None
• Baud: 9600 • Handshaking: X-on/X-off

Instruction 0019-9337 13
Oxor® III
Align the printer with the top of the analyzer as shown in Figure 4-1.
Figure 4-1. Printer Alignment & Sample Printout
®
in
in.
Print Current Test Data
1. With the analyzer in its Run Mode, press the HOLD button twice to
display the Print Screen.
2. Press ENTER to start printing.

Instruction 0019-9337
14
Oxor® III
Print All Test Data
1. With the analyzer in its Run Mode, press the HOLD button twice
to display the Print Screen. Then press the button to display the
Print All Screen.
2. Press ENTER to start printing.
4.9 Clearing Saved Test Data
Clear all saved test data as follows:
Note: If no test data has been saved, the option to clear
memory will not be available.
1. With the analyzer in its Run Mode, press the HOLD button twice to
display the Print Screen.
2. Press the or button to scroll to the Clear Screen, and then press
ENTER to display the Clear All Screen.
3. Press ENTER again to clear memory and return to the Hold Mode,
or press HOLD to return to the Hold Mode without clearing memory.
4.10 Resetting the Microprocessor
If the analyzer ‘locks up’ and cannot be turned OFF, reset the microproces-
sor by removing one of the batteries for 5 seconds.

Instruction 0019-9337 15
Oxor® III
5.0 CALIBRATION & MAINTENANCE
Important: Fresh batteries should be installed, and the unit
allowed to stabilize at room temperature for at least two
hours before proceeding with calibration. To maintain ac-
curacy as listed in the Technical Characteristics Section of
this manual, the standards used must be at least 4 times as
accurate as the stated accuracy of the Oxor III.
5.1 Entering the Calibration Mode and
Testing the Display Segments
1. With the analyzer turned OFF, place the unit in fresh, ambient air;
then press and hold down the ENTER button.
2. Press the I/O button and release it. Observe that all LCD segments
are turned ON.
3. Release the ENTER button. Observe the unit’s model number and
software version are displayed. The word “CAL” is then displayed
while the unit counts down from 60 seconds.
.
At the end of the count-down period, the first calibration screen is
automatically displayed.
Note: During calibration, the  buttons are used to in-
crease or decrease a displayed calibration value. ENTER is
used to store the new value and move to the next screen. Exit
the Calibration Mode by holding down the ENTER button
for 2 seconds.

Instruction 0019-9337
16
Oxor® III
5.2 Ambient Temperature Calibration
Material Required: Calibrated Thermometer
Procedure:
1. Enter the Calibrate Mode as described in Section 5.1. Observe that
“AMBIENT” is displayed at the top of the display; if not, repeatedly
press ENTER until it appears.
2. Use the  buttons to adjust the displayed value to match the
reading of a calibrated thermometer.
3. Press ENTER to store the displayed value and move to the next
calibration screen, or hold down ENTER for 2 seconds to store the
displayed value and display the O2screen, or press the I/O button to
exit the Calibration Mode and turn OFF the analyzer without sav-
ing the changes.
5.3 O2Sensor Zero
Material Required: • Cylinder of 100% Nitrogen (P/N 9550-0049)
• Calibration Kit, (P/N 0024-7059)
Procedure:
1. With the analyzer sampling fresh air, enter the Calibration Mode as
described in Section 5.1. Then repeatedly press the ENTER button
until “O2” appears in the lower left side of the display.
2. Allow the pump to run and sample fresh air for at least 1 minute.
3. Use the  buttons to set the displayed value to 20.9%.
