Backyard Creations UMB-933040 Installation guide

9’ Aluminum Crank & Tilt
Market Umbrella
Assembly & Care Instructions
IMPORTANT : RETAIN FOR FUTURE REFERENCE
READ CAREFULLY
SKU #: 272-0001
Model #: UMB-933040
ATLeisure, LLC
Toll Free: 1-855-880-7205 (English is offered)
8am - 5pm, Monday through Friday, Eastern Standard Time
Email: customerser[email protected] or visit our website at www.atleisure.com
DO NOT RETURN TO STORE
2020 Distributed by Menard, Inc., Eau Claire, WI 54703
Made in China
The schematics in this manual are for assembly and operation illustration only.
They may differ from the actual appearance.
For assistance with assembly, parts, or customer service, please contact:

2
Contents
Preparation .................................2
Package Contents ............................2
Warnings and Cautions ........................2
Canopy Care ................................2
Assembly and Operation .......................3
Warranty ...................................3
Preparation
Before beginning assembly of product, make sure all parts are present. Compare
parts with package contents list. If any part is missing or damaged, do not attempt
to assemble the product or return to the place of purchase. Contact our customer
service toll free at 1-855-880-7205 for replacement parts or further instructions.
Canopy Care
Simply clean the umbrella with a soft brush and mild detergent.
• DO NOT iron.
• DO NOT machine wash or dry.
• AIR DRY the canopy thoroughly before storing for extended period of time.
Warnings and Cautions
• Always take the umbrella down when not in use.
• Keep children away from umbrella during assembly to avoid injury.
• If the crank becomes too hard to crank, check to see if the rope has come off the
pulley. If you continue to turn the crank, the rope or crank handle could break.
• NOTE: We recommend that you insert the umbrella into an umbrella base or
table (not included) for securing the umbrella.
• WARNING: Do not use this umbrella during periods of high winds and rain.
Failure to do so may result in personal injury and/or damage.
Package Contents
Part Description Re-order Number Quantity
A Umbrella Frame with Canopy CAN-9M6RBP-T60- [BE, BL, RD] 1
B Bottom Pole BMP-38ASN-BWN-T 1
C Finial FNL-38A-BWN-T 1
For replacement parts, call our customer service department at 1-855-880-7205,
8:00am-5:00pm., EST, Monday-Friday.
ABC

3
Assembly and Operation
Step 1: Attach the finial on the um-
brella top (if unattached) by screwing
the finial onto the threaded top. Twist
until secure but, do not over tighten.
Crank
Step 3: : Turn the crank handle in
clockwise direction to open the um-
brella canopy, turn in the opposite
direction to close the canopy.
TO CLOSE THE UMBRELLA IT MUST
BE IN THE UPRIGHT POSITION.
Step 2: Insert the bottom pole into the
upper pole while pressing the snap but-
ton on the bottom pole until the snap
button locks into position.
Tilt Button
Step 4 : You can tilt the umbrella to
your desired angle while pressing the
tilt button to release the umbrella top.
Release the button to maintain the
desired angle.
OneYear Warranty
This product is covered under a manufacturer’s one year warranty from date of pur-
chase against defects in materials and workmanship. This warranty does not cover
damage due to neglect, abuse or weather related damage. This warranty gives you
specific legal rights, and you may also have other rights which vary from state to state.
If you are within your warranty, to file a claim you must have your receipt and pictures
of your damaged umbrella.
For replacement parts, call our customer service department at 1-855-880-7205,
8:00am-5:00pm., EST, Monday-Friday.
