Backyard Pro Butcher Series User manual

1
STAINLESS STEEL
MEAT MIXERS
INSTRUCTION MANUAL
WARNING
06/2019#554BSMM20, #554BSMM44
Read carefully and understand all INSTRUCTIONS before operang. Failure to follow the safety
rules and other basic safety precauons may result in serious personal injury.
Save these instrucons in a safe place and on hand so that they can be read when required.
Keep these instrucons to assist in future servicing.
554BSMM20
20 LB. (4.2 GAL.) MEAT MIXER
554BSMM44
44 LB. (7 GAL.) MEAT MIXER

2
INTRODUCTION
Thank you, and congratulaons on purchasing a Backyard Pro Butcher Series meat mixer. Your mixer
comes complete with everything you need to safely and easily mix meat. Please take a few minutes
to read through this booklet to learn more about your Backyard Pro Butcher Series meat mixer. Your
mixer is made of the nest materials to ensure extended use for all of your meat processing needs.
TECHNICAL DETAILS
Item No. Tank Capacity Working Capability
554BSMM20 4.2 gallons Up to 20 lbs.
554BSMM44 7 gallons Up to 44 lbs.
ASSEMBLY AND OPERATION INSTRUCTIONS
The stainless steel meat mixer provides a quite easy way to mix meat and your favorable xing together
with clean steel structure and comfortable wood crank. It is convenient for install and transport, and
could be used at restaurant, refectory, and private dining room, etc. Before using the stainless steel
meat mixer, please read the following instrucons carefully.
554BSMM20 ASSEMBLY
Step 1: Take all parts out of #1 the meat tank, only leaving #5 the axle with paddles inside, with the
axle uted end towards the hole of shorter axle support outside.
Step 2: Put the #4 copper bolt together with #3 spring through the hole of the longer axle support
outside, with the thread end outwards, and ghten #2 the grip with female thread and the #4
copper bolt together. Then t the axle and the copper bolt inside the tank by the elasc force
of the spring.
Step 3: To make #7 the crank and the #5 axle gripped together by the step on crank’s copper ange
and axle’s uted end. Then insert #8 the grip with bolt through the hole of crank and axle to
screw them ghtly. To turn #7 the crank clockwise or counter-clockwise, the paddle will be
rotated smoothly.
554BSMM44 ASSEMBLY
Step 1: Take all parts out of #1 the meat tank, only leaving #6 the axle with paddles inside, with the
axle uted end towards the hole of shorter axle support outside.
Step 2: Fix crank #15 onto the machine body through bolt #2
General Informaon and Instrucons

3
OPERATION
Step 1: Put ground meat into the tank of the mixer, and then put your favorable xing into it.
Step 2: Turn the crank clockwise or counterclockwise, and the paddle will mix the meat and xing
together.
Step 3: When the meat and xing have been mixed well proporoned, take out them from the tank
with tools.
MAINTENANCE
The funcon of the meat mixer is to mix up the meat and xing, or other your favorable food.
Please clean the mixer with water aer using and wipe up.
WARNING: Always be as thorough as possible when cleaning and sanizing components.
Any parts exposed to raw meat may harbor or develop bacteria causes illness or death.
WARNING: When cleaning with sanizers, always follow the manufacturer’s recommendaons.
Never use products that cause exposed surfaces to render meat unsafe for consumpon.
Failure to follow this warning may lead to sickness or death!
TROUBLE-SHOOTING
Problem(s) Soluons
The mixer is hard to crank. Meat mixture has become too s. Add water to mix.
The paddle is loose and shakes a lile. Bolts to fasten the paddle are not well assembled.
General Informaon and Instrucons

4
554BSMM20 Exploded View and Parts List
Part No. Descripon Qty.
1Meat Tank 1
2Grip with Female Thread 1
3Spring 1
4Copper Bolt 1
5Axle with Paddles 1
Part No. Descripon Qty.
6Tank Cover 1
7Crank 1
8 Grip with Bolt 1
9Rubber Foot 4

5
554BSMM44 Exploded View and Parts List
Part No. Descripon Qty.
1Meat Tank 1
2Screw 2
3 Paddle Lock Knob 1
4Short Sha 1
5Nylon Bushing 1
6Tank Cover 1
7Axle with Paddles 1
8 Gear Sha 1
9Key 1
10 Gear 1
Part No. Descripon Qty.
11 C-Clip 1
12 Driving Gear Sha 1
13 Gear Box 1
14 Bolt 4
15 Crank 1
16 Rubber Foot 4
17 Large Nylon Bushing 2
18 Small Nylon Bushing 2
19 Handle Screw 1
20 Oil Seal 1

6
