Badger Meter CB-30 User manual

CTL-UM-01028-EN-03 (April 2017)
Batch Controller
Model CB-30
User Manual

Batch Controller Model CB-30
Page 2 April 2017CTL-UM-01028-EN-03

User Manual
Page 3April 2017 CTL-UM-01028-EN-03
CONTENTS
Scope of This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety Terminology and Symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CB-30 Batch Controller Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unpacking, Assembling and Installing the CB-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unpacking the CB-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Assembling the CB-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Wiring the CB-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Flow Valve Solenoid Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Pulse Transmitter Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Remote Control Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
AC Power Supply Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Operating the CB-30 Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setup Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Function Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Understanding the Batch Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Presetting Batch Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
The Initial Batch Cycle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
The Wash Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Stopping the Batch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Manual Batching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setting a Batch Limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Determining the Compensation Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Determining the Scale Factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Troubleshooting the CB-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Batch Controller Model CB-30
Page 4 April 2017CTL-UM-01028-EN-03

Scope of this manual
Page 5April 2017 CTL-UM-01028-EN-03
SCOPE OF THIS MANUAL
The sections in this manual have been arranged in such a way that you can, step by step, install, program, operate and when
required, troubleshoot the instrument.
MPORTANTI
Read this manual carefully before attempting any installation or operation.
Keep the manual in an accessible location for future reference.
Safety Terminology and Symbols
Indicates a hazardous situation, which, if not avoided, is estimated to be capable of causing death or serious personal injury.
Indicates a hazardous situation, which, if not avoided, could result in severe personal injury or death.
Indicates a hazardous situation, which, if not avoided, is estimated to be capable of causing minor or moderate personal
injury or damage to property.
CB30 BATCH CONTROLLER DESCRIPTION
The CB-30 is a batch controller that accepts a signal input from the meter transmitter, scales it to the desired unit of measure
and—at a preset point(s)—sends a signal to operate the flow valve.
Other features include: automatic compensation for valve overrun, batch size limit, fail-safe shutdown, and manual batching.
UNPACKING, ASSEMBLING AND INSTALLING THE CB30
Unpacking the CB-30
OTE:N If damage to the shipping container is obvious, request that the carrier be present when the product is unpacked. All
claims for equipment damage during transit are the sole responsibility of the recipient.
After carefully unpacking the unit, check for any visible sign of damage. If found, notify the carrier for insurance purposes and
call the factory for possible replacement. Keep all packing material in the event that the unit must be returned to the factory.
OTE:N Operating temperature is 32…130° F (0…55° C) with a maximum humidity of 85% non condensing. Always select a
mounting location with proper ventilation and environmental protection.
5.63 in.
(138 mm)
2.64 in.
(67 mm)
Panel Cutout
2.83” (72 mm)
5.67” (144 mm)
Figure 1: Panel Cutout and Mounting Dimensions

Batch Controller Model CB-30
Page 6 April 2017CTL-UM-01028-EN-03
Assembling the CB-30
The CB-30 can be mounted on the flow meter, on a wall or shelf, or in an instrumentation panel. Figure 2 shows the exploded
view of a meter or wall mounted unit. In this configuration the CB-30 is shipped separately and must be installed as shown
(see wiring diagrams for proper transmitter signal connections).
The basic unit is equipped for panel mount. To install:
1. Measure and cut mounting hole to the dimensions shown in Figure 1 on page 5.
2. Install gasket around the mounting bezel.
3. Insert the unit through the front panel cutout.
4. Secure the unit to the panel with the mounting clips.
Figure 2: CB-30 Assembly
PARTS LIST
Description Part Number
Mounting harware kit 259170-005
Connector kit 259170-004
Replacement triac 259170-003
Replacement face plate 259170-002
Table 1: Parts list

Wiring the cb-30
Page 7April 2017 CTL-UM-01028-EN-03
WIRING THE CB30
The rear panel of the CB-30 controller contains connectors with screw terminals for connecting #28 to #14 gauge insulated
stranded wire (#18 gauge stranded wire is recommended).
A wire stripper and a small screwdriver are the only tools required. Figure 3 on page 8 through Figure 6 on page 11
illustrate step-by-step the proper wiring procedures for all standard and optional functions.
At installation, be sure to comply with the following requirements:
• Disconnect power to the unit before attempting any connection or service to the unit.
• Avoid using machine power service for AC power. When possible, a dedicated or lighting circuit is recommended.
• Do not bundle or route signal lines with power lines.
• Keep all lines as short as possible.
• Use shielded wire for all input wiring.
• Observe all local electrical codes.
TO PREVENT ACCIDENTS, POWER SHOULD BE CONNECTED ONLY AFTER ALL OTHER CONNECTIONS HAVE
BEEN COMPLETED.
Terminal Function
1 Common (GND)
2 Lockout
3 Common (GND)
4 24V DC in
5 Sends out 12V (50 mA)
6 Fast in
7 Slow in
8 Common (GND)
9 RESET
10 START
11 HOLD
12 MANUAL
13 Common (GND)
14 Output
15 —
16 —
25 TRIAC
26 TRIAC
21 L1 85…265V AC
22 L2 85…265V AC
23 System Ground
Table 2: Wiring Terminal Identification
BECAUSE THE CB-30 IS MICROPROCESSOR CONTROLLED, IT IS VERY IMPORTANT THAT THE POWER SUPPLY BE FREE OF
ELECTRICAL NOISE. AVOID USING POWER LINES THAT FEED HEAVY LOAD ELECTRICAL DEVICES SUCH AS PUMPS
AND MOTORS.
THE CB-30 POWER INPUT IS INTERNALLY FUSED AND PROTECTED FROM COMMON LINE NOISE BY A FILTERING NETWORK.

Batch Controller Model CB-30
Page 8 April 2017CTL-UM-01028-EN-03
Flow Valve Solenoid Connections
The CB-30 uses an electronic optically isolated TRIAC to control the valve solenoid during the Batch process.
ALWAYS MAKE SURE TO CONNECT THE HOT AC LINE TO TERMINAL #21 AND THE NEUTRAL TO THE SOLENOID.
At the beginning of the Batch the normally open contacts will close, allowing the AC supply to energize the solenoid and open
the valve. At the end of the Batch the contact will open and interrupt the AC supply to the solenoid, therefore closing the
valve. The TRIAC is field replaceable.
TRIAC Rating SHARP S202T02F
Load Voltage 80…240V AC
Load Current 2 A
Transistor Output Terminal # 14 is activated at the same time as the TRIAC, for use with
external relays or transistor compatible input devices.
One open collector NPN. 12V DC max.
50 mA sink max. (1V DC type V CE at 50 mA)
Table 3: Flow Valve Solenoid Specifications
85 . . . 265V AC
POWER SUPPLY
SOLENOID
VALVE
HOT
COMMON
OPEN COLLECTOR
TRANSISTOR OUTPUT
BADGER METER
MODEL CB-30
1
2345678910 11 12 13 14 15 16 25 26 21 22 23
BADGER METER
MODEL CB-30
Figure 3: Flow Valve Solenoid Connections

Wiring the cb-30
Page 9April 2017 CTL-UM-01028-EN-03
Pulse Transmitter Connections
The CB-30 is designed to accept pulses from open collector transistors or dry contact closure transmitters.
Before making any connections please make sure to comply with the following:
1. Always use shielded wire to protect the signal line from external noise (round shield to terminal #3).
2. Make sure the signal lines are not bundled with or touching power lines.
Figure 4 shows the connection to Model PFT-3E transmitter, usually supplied with a Badger Meter Industrial Turbo meter. The
Model PFT-3E provides an open collector transistor output for the CB-30.
Frequency DC to 5 kHz (high speed)
DC to 150 Hz (low speed)
Low Level 0…2V DC max.
High Level 8…20V DC max.
Impedance 4.7 KWpullup to +12V DC
VDC Current 2.5 mA steady state
Response 100 ms min pulse (high speed) 3.5 ms min pulse (low speed)
Table 4: Transmitter Count Input
MODEL PFT-3E
TRANSMITTER
RED
GREEN
BLACK
USE SHIELDED CABLE
NOTE: DO NOT GROUND
SHIELD AT METER
1
2345678910 11 12 13 14 15 16 25 26 21 22 23
BADGER METER
MODEL CB-30
Figure 4: Pulse Transmitter Connections

Batch Controller Model CB-30
Page 10 April 2017CTL-UM-01028-EN-03
Remote Control Connections
For operator convenience and process automation the functions START, HOLD, RESET and MANUAL can be wired to be used
with remote mounted switches or with electronic control processors. Always use shielded wire to protect the signal from
external noise interference.
Control Inputs Remote start, reset, hold, manual, keyboard lockout
Frequency DC to 20 Hz typical
Type Current sinking
Logic Level sensitive
Low Level 0…2V DC max.
High Level 8…20V DC max.
Impedance 4.7 KWpullup to +12V DC
Current 2.5 mA steady state
Response 32 ms make and break time
Table 5: Remote Control Specifications
USE SHIELDED CABLE
SHEILD TO TERM 8
MANUAL
HOLD
START
RESET
1
2345678910 11 12 13 14 15 16 25 26 21 22 23
BADGER METER
MODEL CB-30
Figure 5: Remote Control Connections
