Bai Ba-440 dualbeam Manual

INSTALLATION AND MAINTENANCE

MANUAL FOR

BA-440 DUALBEAM BARCODE READER

revised 3/29/2012

800-528-9167

407-327-2177

FAX 407-327-6172

Post Office Box 195268

Winter Springs, FL 32719-5268

email Cust-Svc@Barcode-Automation.com

web page http://www.Barcode-Automation.com

Doi g It Better - Because We Care.

Barcode Automatio i c.

FOREWORD

The purpose of this manual is to provide information on how to install,

configure, operate, and maintain the Barcode Automation BA-440

DualBeam Barcode Reading and Access Control System. Barcode

Automation Inc. has made every effort to insure that the information in

this manual is both accurate and adequate. It is recommended, in the

interest of safety and efficiency, that each section be read carefully

before installing or servicing this system.

This manual may not be copied or reproduced, in whole or in part,

without the express written consent of Barcode Automation inc.

March 2012

INTRODUCTION

This section contains information for proper installation, operation and

maintenance of the Barcode Automation BA-440 DualBeam Barcode

Reader. Each item in this section should be read completely before

proceeding to other sections of this manual. If there are any

questions contact Barcode Automation, inc at 1-800-528-9167 for

assistance.

FCC CLASS A STATEMENT

This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with this manual,

may cause interference to radio communications. A class A

computing device, as defined in Part 15, Subpart J of the Federal

Communications Commission rules is designed to provide reasonable

protection against such interference when operated in a commercial

environment. Operation of this equipment in a residence is likely to

cause interference in which case the user, at his own expense, will be

required to take whatever measures necessary to correct the

interference.

CDRH COMPLIANCE STATEMENT

This laser barcode reading system complies with Standard 21CFR,

Subchapter J, for Class II laser products as set forth by the Center for

Devices and Radiological Health. Any alteration or adjustment for

Class II laser products is not authorized, and will void certification of

the system as a Class II laser product. Figure 1 on page 6 shows the

type and location of warning labels affixed to the reader in compliance

of the CDRH standard.

SAFETY PRECAUTIONS

This Barcode Reader incorporates features that provide for maximum

safety. However, it must be recognized that any equipment employing

electrical voltage and emitting direct or scattered radiation may cause

serious damage and/or personal injury if improperly handled. The

following are recommended safeguards that should be observed at all

times.

WARNING

Use of controls, adjustments or performance of procedures other

than those specified herein may result in exposure to hazardous

radiation or electrical voltages.

OPTICAL SAFETY

Never stare directly into laser beam. The laser diode is interlocked

with the motor that turns the polygon mirror so that if the motor slows

or stops for any reason the laser will be automatically turned off.

ELECTRICAL SAFETY

Disconnect the main power line before working on any electrical

equipment. Always use insulated tools.

REQUIRED MAINTENANCE

The BA-220 DualBeam laser window should be cleaned both inside and outside as needed

with a non-abrasive glass cleaner.

The internal reader optics should be cleaned at 6 month intervals with 100% denatured

alcohol and soft material such as tissue or soft toilet paper. DO NOT USE OPTICAL

CLEANING MATERIAL SOLD FOR CAMERA LENSES.

The internal optic pieces to be cleaned are:

1. Each of the 8 sides on the gold mirror wheel in the upper right corner of the reader should

be cleaned using a wet (100% denatured alcohol) tissue followed by a dry tissue. This

wheel is a metal part that is polished to a reflective surface, so use light pressure to

prevent scratches.

2. Below the gold mirror wheel is a small silver mirror to clean.

3. Below the small silver mirror is a glass lens in a silver block to clean.

REQUIRED MAINTENANCE

The BA-440 window should be cleaned as needed with a non-

abrasive glass cleaner. Optical components inside the reader should

be inspected and cleaned at 6 month intervals. These include:

•

Window glass both inside and

outside

•

8 sided gold mirror wheel

(Polygon)

•

Small mirror below gold wheel

(Polygon)

•

“Fisheye” lens in the silver block

below the small mirror

Optics should be cleaned with 100% denatured alcohol and soft

material such as Kleenex® or cotton balls. DO NOT USE LENS

CLEANING MATERIAL or OPTICAL WIPES. These will scratch the

metal of the gold wheel and degrade reader performance. Cleaning is

best accomplished by following these steps:

1. Remove 6 flanged nuts from bottom of reader.

2. Lift hood/cover straight up off of the reader.

3. Clean inside/outside the window glass on the reader hood/cover.

4. Clean all 8 mirror sides on the gold wheel (polygon).

5. Clean the small mirror directly below the gold wheel (polygon).

6. Clean the lens in the receiver block located below the small mirror.

7. Replace Desi-Paks if necessary.

8. Replace the reader hood cover over the unit.

9. Reinstall and tighten the 6 flanged nuts on the bottom of reader.

Do not adjust or remove any hardware not specified in these

directions. Any change to the optical alignment may result in poor

reader performance. If you have questions contact 800-528-9167.

Warning Label Placement for BA-440

CAUTION

LASER LIGHT

DO NOT STARE INTO BEAM

658nm LASER DIODE

1.0 MILLIWATT MAX. OUTPUT

CLASS II LASER PRODUCT

THIS PRODUCT CONFORMS

TO DHHS REGULATION 21

CFR SUBCHAPTER J.

NOT USER SERVICEABLE

Front

AVOID EXPOSURE

LASER LIGHT IS EMITTED

FROM THIS APERTURE

Back

CAUTION

LASER LIGHT WHEN OPEN

DO NOT STARE INTO BEAM

Contents

Foreword ...................................................................................2

Introduction................................................................................3

FCC Class A Statement.............................................................3

CDRH Compliance Statement...................................................3

Safety Precautions ....................................................................3

Optical Safety ............................................................................4

Electrical Safety.........................................................................4

Required Maintenance ..............................................................5

Warning Label Placement .........................................................6

General Specifications...............................................................8

Input Power .........................................................................8

Environmental .....................................................................8

Communications..................................................................8

Optical .................................................................................9

Scan Pattern..............................................................................9

Basic Installation and Setup Steps ............................................10

Determine where the Reader will be installed.....................10

What Wiring do I need?.......................................................12

Typical Installation Illustration....................................................15

Wiring Connections ...................................................................16

Wiring Connection Definitions ...................................................17

Wiring Connection Details .........................................................18

Power Input Terminals.........................................................18

Wiegand Connection Terminals...........................................19

Optoisolated Wiegand Connection ......................................20

Direct Wiegand Connection.................................................21

Vehicle Detect Input Terminals ............................................22

Relay Output Terminals .......................................................24

Finishing the BA-440 Installation...............................................25

Mounting Angle..........................................................................25

Powering up the BA-440 for the first time .................................25

LED Indicators...........................................................................26

Barcode label placement on vehicles........................................28

General Specifications

Light Source: Visible Laser Diode

Output Wavelength (nominal): 658 nM

CDRH Safety Class II

Output Power: less than 1mW/cm

Read Zone:

Operating Distance: 24 to 72 in (61 to 182 cm) measured from window

Decals:

Various Color Decals can be used; Configurable to Read decals from

Accu-Sort, Amtel, ISI, & LazerData

Communication (RS232):

Data Rate: 2400, 4800, 9600, 19200, 38400 Baud

Parameters: 8N1, 7E1

Communication (Wiegand): 26bit format

Timing of Wiegand pulses is adjustable

Indicator:

Audible indicator for Good Read (beep)

Length of audible beep adjustable or can be disabled

Power Input:

Voltage input: 24 Vdc @ 1.5A max

Power: 36 Watts max

Environmental:

Operating Temperatures: -22 to 130°F (-30 to 55°C)

Relative Humidity: 10% to 100% (non-condensing)

Relay Contacts:

Do Not Exceed 30 Vdc @ 2A

Mechanical Specifications: NEMA 4

General Specifications

OPTICAL

Reading area begins 24” from enclosure and extends out to 72”

The laser lines are vertical with a fan shaped read area.

Read area chart is measured in inches above pavement.

This

assumes

that the

center of the

BA-440

DualBeam

window is

50” above

the

pavement.

Reading distance in inches from the body of the

BA-440 DualBeam.

Basic Installation and Setup steps

1. Determine where the Reader will be installed

2. Run wiring to the mounting point for power & communications

3. Pour concrete pad for post mount

4. Secure mounting post and BA-440 DualBeam to the pad

5. Connect power & communications to the reader

6. Place decals on vehicles (the same side the reader will be on)

7. Turn Power Switch On

8. You're up & running

If the BA-440 DualBeam was not set up for your specific installation at

the Factory you may have to configure the Reader after it is mounted

in place. To do this refer to the Operation and Configuration Manual

for details.

Determine where the BA-440 DualBeam will be installed:

Overhead view of Installation

As shown in this figure, the reader should be located 25 feet before

the gate. This allows about one car length (plus a small gap) for

vehicles to pass the reader. It does not matter which side of the road it

is mounted on, as long as the vehicle decals are on the same side.

Always locate the reader and decals on the same side of the car.

25’

BA-440 DualBeam

Determine where the BA-440 DualBeam will be

installed:

The height of the reader above the pavement is very important. The

general rule of thumb is for the bottom of the reader to be 44” above

the pavement where the vehicle tires ride. BAI offers a standard

mounting post that is 38” high. It is intended to be used on a 6” curb or

concrete mounting pad for a total height of 44”.

The reader should be mounted close to the edge of the road or drive

without being in danger of collision with a vehicle. It has a 6 foot

reading distance which will extend out across the road or drive. Traffic

should not pass by closer than 2 feet from the reader. Protective

bollards or barriers around the BA-440 DualBeam are recommended.

In some locations the vehicle drive is very wide, as shown in the

illustration below. In these cases, we recommend painting lane lines

or stripes to indicate where the vehicle must pass by in order to be

read by the BA-440 DualBeam.

6’ read distance

BA-440 DualBeam

6’ read distance

Automatic

Reader

Lane

What Wiring do I need?

For most applications, there are three basic ways to use the BA-440

DualBeam Reader.

In this situation, the BA-440 DualBeam reader acts as the Access

Control. Barcode decal numbers are programmed into the reader and

set to grant or deny access based on the individual number. The

reader can be programmed via a laptop computer. When vehicles

pass by the BA-440 DualBeam reads the barcode and checks to see if

that number has access. If access is granted the Gd Read relay

contact closes to open the gate. If access is denied the gate does not

open and the Aux Out relay contact will close that can be connected to

an indicator or alarm to indicate that access is denied.

Wiring Needed:

•

2 conductor 18 AWG from reader to gate operator

•

2 conductor 18 AWG copper for 24VDC power connection

Optional:

Shielded 3 conductor 18 AWG for connecting RS232 serial port of

reader to computer. Distance should not exceed 100 feet.

24VDC

input

2 wires for relay contacts

♦

BA-440 DualBeam reads barcode and if Valid closes relay contacts to Open Gate

♦

Up to 100,000 different label numbers can be programmed

♦

Configure the BA-440 DualBeam with a Laptop Computer

♦

Change access control database with Laptop

As a Stand Alone Access Control

Gate

What Wiring do I need?

In this situation the BA-440 DualBeam is connected to an external

Access Control panel by Wiegand communication. The barcode ID

numbers are programmed into the Access Control panel and set up to

have access granted or denied. When the vehicle pulls up to the

BA-440 DualBeam it reads the decal and transmits the number to the

Access Control panel, which checks the database for valid numbers. If

access is granted, the panel opens the gate.

Wiring Needed:

•

Shielded 3 conductor 18 AWG from reader to access control panel

for Wiegand communication

•

2 conductor 18 AWG copper for 24VDC power connection

3 wires for Wiegand Signal

♦

BA-440 DualBeam reads barcode decal and sends number to Access Panel

♦

Panel determines if the decal number is Valid and controls gate

♦

Change access control database through the Access Control Panel

♦

Compatible with any Access Control Panel using 26 bit Wiegand Interface

Reader connected to Access Control Panel

Access

Control

Panel

Gate

24VDC

input

What Wiring do I need?

In this application the BA-440 DualBeam is connected to a Computer

Security System through an RS232 serial port. Barcode decal ID

numbers are programmed into the Computer Security system. When a

vehicle pulls up to the BA-440 DualBeam reader, it reads the decal

and transmits the number to the Security system. If valid, the Security

system opens the gate.

Power Input

24VDC - Two wires (Ground and +24VDC) Recommend 18 AWG

copper wire. Refer to local building codes for special requirements.

Communications

For RS232 interface - Three wires (Transmit, Receive, Ground)

Minimum 3 conductor shielded cable 18 AWG

For Wiegand interface - Three wires (Wiegand 0, Wiegand 1, Ground)

Minimum 3 conductor shielded cable 18 AWG

For I/O

GdRead relay - Two wires 18 AWG

AuxOut relay - Two wires 18 AWG

AuxIn - Two wires 18 AWG

3 wires for RS232 Signal

♦

BA-440 DualBeam reads barcode decal and sends data to Computer System

♦

Computer System determines if the number is Valid

♦

Configure BA-440 DualBeam through the Computer System or Laptop

♦

Change access control database through the Computer System

♦

Compatible with any Computer System with RS232 or Wiegand Interface

Reader connected to Computer Security System

Computer

System

Gate

24VDC

input

Typical Installation Illustration

With a 38” mounting post, and a 6” curb, the BA-440 DualBeam (at

24” from the housing) can read barcode decals between 35” and 65”

above the pavement .

Wiring Connections

Wiring Terminal Block Main Power Switch

Beeper On/Off Switch

Wiring Connection Definitions

Input from Power Supply, 24 Vdc @ 1.5A

GND IN the negative or “-” from the 24 Vdc power supply

+24V IN the positive or “+” from the 24 Vdc power supply

OptoIsolated Wiegand Communications

Data1 Wiegand 1 data communication to access system

Data0 Wiegand 0 data communication to access system

Comm signal ground or common to access system

*All three connections required for reliable communication*

Optional Vehicle Detect input to reader (Not Required)

Aux In- dry contact input to arm reader

Aux In+ dry contact input to arm reader

Auxiliary Relay Output

AuxOut- dry contact relay output

AuxOut+ dry contact relay output

Ouput Relay for Gate Operator used in Standalone Operation

GdRead- dry contact relay output for gate operator

GdRead+ dry contact relay output for gate operator

Wiring Connection Details

Power Input Terminals

GND IN

+24V IN

The power input terminals for 24Vdc input are marked for the Ground

and +24Vdc leads. Reader is Reverse polarity protected.

NOTE: The 24Vdc input must supply 1.5 Amps to the Reader for

proper operation. Recommend 18AWG copper cable for runs up to

200’.

To +24Vdc Power

To Power Ground

Wiring Connection Details

Wiegand Communication Terminals

Data1

Data0

Comm

Wiegand communication from the BA-440 can be run two different

ways; optoisolated or direct connection. The Optoisolated connection

has several advantages, provided the Access panel or telephone entry

system supports it. To use the Optoisolated connection the access

panel or telephone entry system must provide voltage to the Data0

and Data1 connections on the reader. Be sure to connect Wiegand

communications to the access panel as shown on page 20 before

proceeding with the following test.

To check compatibility with Optoisolated communications connect the

access panel as shown on page 20. With the access panel powered

on, measure from the Data0 and Data1 terminals to Comm with a

voltmeter. There will be about +5Vdc at each Wiegand line when using

access panels that support the Optoisolated connection.

If no voltage is measured from Data0 or Data1 to Ground the

Optoisolated connection will not function. Instead, the BA-440 must be

configured for a direct Wiegand connection. See page 21 for details

on how to configure the BA-440 for direct Wiegand connection.

Wiring Connection Details

Wiegand Communication Terminals

Data1

Data0

Comm

Optoisolated Connection (Preferred)

The Wiegand output communication terminals are marked as Data1,

Data0 and Common. The normal configuration for Wiegand

communication from the BA-440 is optoisolated, where the reader

does not supply voltage on the Data0 and Data1 terminals and Comm

does not have a direct connection to the reader ground. Voltage and

ground reference is supplied by the access panel or telephone entry

system. Use 18Ga shielded copper cable for runs up to 400’ and

ground the shield at the access system end only.

Once Wiegand communication is connected to the access system,

turn the access system on and measure voltage between Common

and Data0, then Common and Data1. There should be approximately

5Vdc present on the Data0 and Data1 terminals.

To Common at Access panel

To Data 0 at Access panel

To Data 1 at Access panel

Other manuals for BA-440 DualBeam

Table of contents

Bai BA-440 DualBeam Manual

Popular Barcode Reader manuals by other brands
