Baier Elektrowerkzeuge ABDN 20 Quick start guide

Translation of the Original Instruction Manual
Cordless Diamond Wall Chaser
ABDN 20
EN

EN
| 2 | ABDN 20 | EN | ID No. 10154 | V01 | 2021-11
1User Information 6
1.1 Purpose of the instruction manual 6
1.2 Validity of the instruction manual 6
1.3 Storing the instruction manual 6
1.4 Other applicable documents 6
1.5 Presentation conventions 6
1.5.1 Warnings 6
1.5.2 Notation 7
1.5.3 Lists 7
1.5.4 Instruction 7
1.6 Target group 7
2Safety Instructions 8
2.1 Workplace safety 8
2.2 Electrical safety 8
2.3 Safety of people 9
2.4 Using and handling the power tool 10
2.5 Using and handling the battery pack 10
2.6 Service 11
2.7 Safety instructions for abrasive cutting (disc cutting) applications 11
2.8 Kickback and corresponding safety instructions 13
2.9 Further safety instructions for wall chasing 14
2.9.1 Safety instructions for all work 14
2.9.2 Workplace safety 15
2.9.3 Electrical safety 16
2.9.4 Safety of people 16
2.9.5 Further safety instructions for the power tool 17
2.9.6 Further safety instructions for the battery pack 18
2.9.7 Service / Maintenance / Repair 19
2.10 Intended use 19
2.10.1 Uses 19
2.11 Reasonably foreseeable misuse 19
3Product Description 21
3.1 Scope of supply 21

EN
A
BDN 20 | EN | ID No. 10154 | V01 | 2021-11 | 3 |
3.2 Product labelling 21
3.2.1 Pictograms on the product 21
3.3 Structure 23
3.3.1 Product structure 23
3.3.2 Safety devices 23
3.3.3 Display elements 24
3.3.4 Function 24
4Technical Characteristics 25
4.1 Technical specifications 25
4.1.1 Standards and information 26
4.2 EU Declaration of Conformity 27
5Starting Up 28
5.1 Safety 28
5.2 Uses 28
5.3 Handling diamond discs 28
5.4 Diamond discs 29
5.4.1 Mount the diamond discs 29
5.4.2 Dismantle diamond discs 31
5.5 Battery pack 32
5.5.1 Check the battery state of charge 32
5.5.2 Charge the battery pack 32
5.5.3 Insert the battery pack 33
5.5.4 Remove the battery pack 33
5.5.5 Dust extraction 34
6Operation 35
6.1 Safety 35
6.2 Requirements 36
6.3 Start the work process 36
6.4 End the work process 39
7Cleaning 41
7.1 Safety 41
7.2 Cleaning work 41

EN
| 4 | ABDN 20 | EN | ID No. 10154 | V01 | 2021-11
8Maintenance 42
8.1 Safety 42
8.2 Maintenance work 42
9Disposal 43
10 Service 44
11 Warranty 45

EN
A
BDN 20 | EN | ID No. 10154 | V01 | 2021-11 | 5 |
Maschinenfabrik OTTO BAIER GmbH
Heckenwiesen 26
71679 Asperg
Germany
Tel. [phone]
Fax [phone]
[e-mail]
www.baier-tools.com
Imprint
Translation of the Original Instruction Manual
ABDN 20 | EN | ID No. 10154 | V01 | 2021-11
Copyright © 2021
Maschinenfabrik OTTO BAIER GmbH (BAIER in the following)
All rights reserved.
It is prohibited to forward or reproduce this document or to exploit and disclose its
contents, unless expressly permitted. Any infringements will result in liability to pay
compensation for damages. All rights reserved in case of patent, utility model or design
registration.
This instruction manual has been prepared with the greatest possible care.
Nonetheless, BAIER does not accept any liability whatsoever for possible errors in this
instruction manual and their consequences. Equally, no liability whatsoever is accepted
for direct or consequential damage or losses resulting from improper use of the
machine.
The national health and safety regulations and the requirements of this instruction
manual are to be observed when using the machine.
All product names and brand names used are the property of the holder and are not
explicitly marked as such.
Subject to change without notice.

EN
| 6 | ABDN 20 | EN | ID No. 10154 | V01 | 2021-11
1 User Information
1.1 Purpose of the instruction manual
This instruction manual contains all important information necessary for safe handling
of the cordless diamond wall chaser ABDN 20.
1.2 Validity of the instruction manual
This instruction manual is valid for the cordless diamond wall chaser ABDN 20.
1.3 Storing the instruction manual
Always store this instruction manual together with the machine.
1.4 Other applicable documents
When using the machine, additionally note the following documents.
xInstructions for use for battery pack
xOperating instructions, BAIER quick charger ASC 145
xInstruction manuals for accessories and insert tools
xwww.baier-tools.com
Spare parts drawings, instruction manuals, catalogues and use videos can be
accessed here.
1.5 Presentation conventions
1.5.1 Warnings
DANGER
This notice indicates a hazard with high risk, which results in immediate
death or serious physical injury if not avoided.
¾This arrow indicates to you the appropriate precaution to avert the hazard.
WARNING
This notice indicates a hazard with moderate risk, which potentially
results in death or serious physical injury if not avoided.
¾This arrow indicates to you the appropriate precaution to avert the hazard.
CAUTION
This notice indicates a hazard with low risk, which potentially results in
minor or moderate physical injury if not avoided.
¾This arrow indicates to you the appropriate precaution to avert the hazard.

EN
A
BDN 20 | EN | ID No. 10154 | V01 | 2021-11 | 7 |
NOTE
This notice indicates potential property damage, gives use
recommendations and helpful tips.
1.5.2 Notation
xThe cordless diamond wall chaser is also referred to as the “machine” in this
instruction manual.
xMaschinenfabrik OTTO BAIER GmbH named BAIER in the following.
xThe text contains references to item numbers in the diagrams that are given in
brackets, e.g. (7).
xUnderlined text denotes a cross-reference or a hyperlink, which can be clicked in
the PDF. The place in the document named in the text is then displayed or the
hyperlink is opened in the browser.
xLists are displayed with a preceding dot.
-Lists with a preceding dash are secondary to a list with a preceding dot.
1.5.4 Instruction
1. Tasks that must be carried out in a given order are denoted by a preceding bullet
point.
¾The consequences of an action are represented by a preceding arrow and are
secondary to the respective instruction.
9The final result of an action is denoted by a preceding tick.
1.6 Target group
End users
xOnly persons over 16 years of age may use the machine.
xThe operating personnel must be familiar with the content of this instruction
manual.
1.5./LVWV

EN
| 8 | ABDN 20 | EN | ID No. 10154 | V01 | 2021-11
2 Safety Instructions
WARNING
Read all safety instructions, instructions, illustrations and technical
specifications provided for this power tool.
Failure to observe the following instructions can result in electric shock, fire
and/or serious injuries.
Keep all safety instructions and precautions for future reference.
The term “power tool” used in the safety instructions refers to mains-operated
power tools (with mains power lead) or battery-operated power tools (without
mains power lead).
2.1 Workplace safety
a) Keep your work area clean and well illuminated.
Untidiness and unlit work areas can result in accidents.
b) Never use the power tool in potentially explosive environments containing
flammable liquids, gases or dusts.
Power tools generate sparks which can ignite dust or vapours.
c) Keep children and other persons away from the power tool during use.
A moment’s distraction can cause you to lose control of the power tool.
2.2 Electrical safety
a) The connecting plug of the power tool must fit in the plug socket. The plug
must not be modified in any way. Do not use adapter plugs in conjunction
with power tools with protective earth conductor.
Unmodified plugs and properly fitting plug sockets reduce the risk of electric shock.
b) Avoid physical contact with earthed surfaces such as pipes, heaters,
cookers and refrigerators.
There is an increased risk of an electric shock if your body is earthed.
c) Keep power tools away from rain and moisture.
The ingress of water into a power tool increases the risk of an electric shock.
d) Do not misuse the connection cable in any way by using it to carry or hang
up the power tool or to pull the plug out of the socket. Keep the connection
cable away from heat, oil, sharp edges and moving machine parts.
Damaged or kinked connection cables increase the risk of an electric shock.

EN
A
BDN 20 | EN | ID No. 10154 | V01 | 2021-11 | 9 |
e) When working with a power tool outdoors, use only extension leads that are
suitable for outdoor use.
Use of an extension lead suitable for outdoor use reduces the risk of electric
shock.
f) If the use of the power tool in a damp environment is unavoidable, use a
residual-current circuit breaker.
Use of a residual-current circuit breaker (RCCB with 10 mA maximum tripping
current) reduces the risk of an electric shock.
2.3 Safety of people
a) Always work carefully, attentively and sensibly when using a power tool. Do
not use the power tools if you are tired or are under the influence of drugs,
alcohol or medication.
A moment of inattention while using the power tool can result in serious injuries.
b) Wear personal protective equipment and always wear goggles.
The wearing of personal protective equipment, such as dust mask, non-slip safety
shoes, helmet or ear protectors, depending on the type and application of the
power tools, reduces the risk of injuries.
c) Avoid accidental switching on of the power tool. Ensure that the power tool
is switched off before connecting it to the mains power supply and/or
connecting the battery and before picking up or carrying the tool.
If you have your finger on the switch when carrying the power tool or you connect
the tool to the power supply when it is switched on, this can lead to accidents.
d) Remove the adjusting tools or wrenches before switching on the power tool.
A tool or wrench in a rotating part of the power tool can result in injuries.
e) Avoid abnormal postures when working. Ensure you are standing firmly and
maintain your balance at all times.
This will enable you to control the power tool better in unexpected situations.
f) Wear suitable clothing. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts.
Loose clothing, jewellery and long hair can get caught in moving parts.
g) If dust extractor and collection equipment can be mounted, they must be
connected and used correctly.
Use of a dust extraction system can reduce the hazards caused by dust.
h) Don’t be lulled into a false sense of safety and do not break the safety rules
for power tools even if, after much use, you are familiar with the power tool.
Careless action can cause severe injuries within fractions of a second.

EN
| 10 | ABDN 20 | EN | ID No. 10154 | V01 | 2021-11
2.4 Using and handling the power tool
a) Do not overload the power tool. Use the intended power tool for your work.
You work better and safer within the given power range if you use the suitable
power tool.
b) Do not use a power tool whose switch is defective.
A power tool which can no longer be switched on or off is dangerous and must be
repaired.
c) Remove the plug from the plug socket and/or remove a removable
rechargeable battery before carrying out tool adjustments, changing insert
tools or placing the power tool aside.
This precautionary measure prevents unintentional starting of the power tool.
d) Store power tools out of the reach of children when not in use. Do not allow
people to use the power tool if they are not familiar with it or if they have not
read this instruction manual.
Power tools are dangerous if they are used by inexperienced people.
e) Maintain power tools and insert tools with care. Check whether moving parts
are in proper working order and do not jam, whether parts are broken or
damaged in such a way that they impair the function of the power tool. Have
damaged parts repaired before using the power tool.
Many accidents are caused by poorly serviced and maintained power tools.
f) Keep cutting tools sharp and clean at all times.
Carefully maintained cutting tools with sharp cutting edges jam less easily and are
easier to control.
g) Use the power tool, insert tools, etc. in accordance with this instruction
manual. Take into consideration the working conditions and the work to be
carried out.
Use of power tools other than the intended applications can lead to dangerous
situations.
h) Keep the handles and gripping surfaces dry, clean and free from oil and
grease.
Slippery handles and gripping surfaces prevent safe operation and control of the
power tool in unforeseen situations.
2.5 Using and handling the battery pack
a) Only use chargers recommended by the manufacturer to charge the
rechargeable batteries.
There is a risk of fire if a charger that is suitable for a certain type of rechargeable
batteries is used to charge other rechargeable batteries.
b) Use the intended rechargeable batteries only in the power tools.
Use of other rechargeable batteries can cause injuries and a risk of fire.

EN
A
BDN 20 | EN | ID No. 10154 | V01 | 2021-11 | 11 |
c) While it is not in use, keep the rechargeable battery away from paper clips,
coins, keys, nails, screws or other small metal objects that could cause
bridging of the contacts.
Leaking battery fluid can cause skin irritation or burns.
d) Incorrect use can cause fluid to leak from the rechargeable battery. Avoid
contact with the fluid. In case of accidental contact, rinse off with water. If
the fluid gets in the eyes, seek medical help.
Leaking battery fluid can cause skin irritation or burns.
e) Do not use damaged or modified rechargeable batteries.
Damaged or modified rechargeable batteries can behave in an unforeseeable way
and lead to fire, explosion or a risk of injury.
f) Do not expose a rechargeable battery to fire or high temperatures.
Fire and temperatures above 130 °C can cause an explosion.
g) Follow all charging instructions and never charge the rechargeable battery
or the cordless tool outside the temperature range given in the instruction
manual.
Incorrect charging or charging outside the approved temperature range can cause
irreparable damage to the rechargeable battery and increase the risk of fire.
2.6 Service
a) Have your power tool repaired by qualified personnel only and use original
spare parts only.
This will ensure that the safety of the power tool is maintained.
b) Never service damaged rechargeable batteries.
All servicing of rechargeable batteries should only be carried out by the
manufacturer or authorised customer service agents.
2.7 Safety instructions for abrasive cutting (disc cutting)
applications
a) The protective hood belonging to the power tool must be attached securely
and set to achieve maximum safety, i.e. smaller part of the grinding body is
open in the direction of the operator. Keep yourself and people nearby
outside the level of the rotating grinding disc.
The protective hood is intended to protect the operator from fragments and
accidental contact with the abrasive product.
b) Only use bonded, reinforced or diamond coated cutting discs with your
power tool.
Just because you can attach the accessories to your power tool is not a guarantee
of safe use.
c) The approved speed of the insert tool must be at least as high as the
maximum speed given on the power tool.
Accessories which rotate faster than approved can break and fly off the tool.

EN
| 12 | ABDN 20 | EN | ID No. 10154 | V01 | 2021-11
d) Abrasive products may only be used for their recommended use options.
E.g.: never grind with the side (circular face) of a cutting disc.
Cutting discs are intended for removing material with the edge of the disc. Lateral
forces applied to these abrasive products can cause them to break.
e) Always use undamaged mounting flanges of the correct size and form for the
grinding disc chosen by you.
Suitable flanges support the grinding disc and thus reduce the risk of grinding disc
fracture.
f) Do not use worn grinding discs of large power tools.
Grinding discs for larger power tools are not designed for the higher speeds of
smaller power tools and can break.
g) The outer diameter and thickness of the insert tool must correspond to the
dimensions of your power tool.
Incorrectly dimensioned insert tools cannot be adequately shielded or controlled.
h) Grinding discs and flanges must precisely match the grinding spindle of
your power tool.
Insert tools which do not precisely fit on the rotating spindle of the power tool rotate
irregularly, vibrate severely and can result in loss of control.
i) Never use damaged grinding discs. Before each use, check the grinding
discs for splinters and cracks. If the power tool or grinding disc is dropped
or falls, check whether it is damaged, or use an undamaged grinding disc. If
you have checked and inserted the grinding disc, keep yourself and other
people nearby outside the level of the rotating grinding disc and let the tool
run at maximum speed for one minute.
Most damaged grinding discs break during this test period.
j) Wear personal protective equipment. Depending on the task for which the
tool is used, wear full face protection, eye protection or goggles. If
appropriate, wear a dust mask, ear protectors, safety gloves or a special
apron, which keeps cutting debris, abrasive and material particles away from
you.
Your eyes should be protected against flying foreign bodies which result during
various applications. A dust or breathing mask must filter any dust produced during
the application. If you are exposed to loud noise for a long time, you can suffer
from loss of hearing.
k) Ensure other people keep a safe distance from your work area. Any person
entering the work area must be wearing personal protective equipment.
Broken pieces of the workpiece or broken insert tools can fly off and cause injuries,
even outside the immediate work area.
l) Hold the tool by the handle gripping surfaces only when carrying out work
during which the insert tool can hit concealed electrical cables.
Contact with a live conductor can also energise metal parts of the tool and cause
an electric shock.

EN
A
BDN 20 | EN | ID No. 10154 | V01 | 2021-11 | 13 |
m) Never put down the power tool until the insert tool has come to a complete
standstill.
The rotating insert tool can come into contact with the surface on which the power
tool is placed, which could cause you to lose control of the power tool.
n) Do not leave the power tool running while you are carrying it.
Your clothing can get caught by inadvertent contact with the rotating insert tool and
the insert tool can drill into your body.
o) Regularly clean the ventilation slots of your power tool.
The motor fan draws dust into the housing and a large accumulation of metal dust
can cause electrical hazards.
p) Do not use the power tool near flammable materials.
Sparks could ignite these materials.
q) Do not use any insert tools which require liquid coolant.
The use of water or other liquid coolants could result in an electric shock.
2.8 Kickback and corresponding safety instructions
Kickback is the sudden reaction caused by a rotating grinding disc that gets caught or
is blocked. Entanglement or blocking results in the abrupt stopping of the rotating insert
tool. This causes an uncontrolled power tool to be accelerated against the direction of
rotation of the insert tool at the blocking point.
For example, if a grinding disc gets stuck in the workpiece or becomes blocked, the
edge of the grinding disc that is immersed in the workpiece can get caught and
therefore break out the grinding disc or cause kickback. The grinding disc then moves
towards or away from the person using the tool, depending on the direction of rotation
of the disc at the blocking point. Grinding discs can also break here.
Kickback is the consequence of incorrect or faulty use of the power tool. It can be
prevented by taking suitable precautions, as described in the following.
a) Hold the power tool firmly and position your body and arms so that you can
absorb the kickback forces. Always use the additional handle, if available, to
ensure you have the greatest possible control over kickback forces or
reaction torque while the tool is starting up.
The person using the tool can control the kickback and reaction forces by taking
suitable precautions.
b) Never place your hand near rotating insert tools.
The insert tool can move across your hand during kickback.
c) Keep away from the area in front of and behind the rotating cutting disc.
The kickback drives the power tool in the opposite direction to the movement of the
grinding disc at the blocking point.
d) Take particular care when working in the area of corners, sharp edges, etc.
Prevent insert tools from rebounding from the workpiece and jamming.
The rotating insert tool tends to get stuck in corners, sharp edges or if it rebounds.
This causes loss of control or kickback.

EN
| 14 | ABDN 20 | EN | ID No. 10154 | V01 | 2021-11
e) Never use a chain or toothed saw-blade or segmented diamond disc with
more than 10 mm wide slots.
Such insert tools frequently cause kickback or loss of control of the power tool.
f) Avoid blocking of the cutting disc or excessive contact pressure. Do not
make any excessively deep cuts.
Overloading the cutting disc increases the stresses on it and its susceptibility to
cant or blocking and therefore possibility of kickback, or causes the abrasive
product to break.
g) If the cutting disc sticks or you interrupt the work, switch off the tool and
keep it still until the disc has stopped moving. Never attempt to pull the still
running cutting disc out of the cut, otherwise kickback can occur.
Determine and remove the cause of the jamming.
h) Do not switch the power tool back on while it is still in the workpiece. Allow
the cutting disc to reach its full speed first before carefully continuing with
the cut.
Otherwise the disc can pinch, jump out of the workpiece or cause kickback.
i) Support slabs, boards or large workpieces to reduce the risk of kickback due
to a jammed cutting disc.
Large workpieces can sag under their own weight. The workpiece must be
supported on both sides of the disc, not only near the cut but also at the edge.
j) Be especially cautious in case of "pocket cuts" in existing walls or other
concealed areas.
The plunging cutting disc can cause kickback when cutting gas or water pipes,
electric cables or other objects.
2.9 Further safety instructions for wall chasing
2.9.1 Safety instructions for all work
xWear hearing protection when abrasive cutting (disc cutting).
Exposure to noise can cause loss of hearing.
xSupport the power tool properly before using.
This power tool produces a large torque. If the power tool is not properly supported
during use, the user can loose control of it and injuries can occur.

EN
A
BDN 20 | EN | ID No. 10154 | V01 | 2021-11 | 15 |
2.9.2 Workplace safety
xWatch out for exposed and concealed electricity cables, and water and gas
pipes. Use suitable detectors to find concealed utility pipes and cables, or
contact the local utility company for advice.
Contact with electricity cables can cause fires and an electric shock. Damage to a
gas pipe can cause an explosion. Penetrating a water pipe causes damage to
property or could cause an electric shock.
xAvoid damage to load-bearing walls (structural calculations).
Before chasing in load-bearing walls, consult the responsible structural engineer,
architects or the site supervisors.
xAvoid causing situations where other people can stumble or trip over leads.
Tripping over leads can cause serious injuries.
xNever hold the workpiece to be machined in your hand or across your leg.
Secure the workpiece in a stable holder.
It is important to fix the workpiece properly to minimise the risk of body contact,
jamming of the insert tool or loss of control. A workpiece securely held in clamping
devices or a vice is more safely held than in the hand.
xAvoid dust accumulation in the workplace.
Dusts can easily ignite.
xEnsure adequate ventilation in closed rooms.
Risk due to dust and impaired vision.
xReduce dust load.
WARNING
Health hazards due to dust product during cutting, grinding, milling,
sawing, drilling and other work. This dust contain harmful substances
that are known to cause allergies, cancer, congenital defects or other
reproduction damage and other diseases.
¾Where possible, use dust extraction suitable for the material.
¾Asbestos-containing material may only be machined by specialists.
¾Pay attention to good ventilation of the workplace.
¾We recommend wearing a face mask respirator with filter class P2 or P3
(to EN 149:2001).
¾Vacuum or wash the protective clothing. Do not blow out, knock or
brush.
¾Vacuum the workplace to keep it clean. Sweeping or blowing swirls up
dust.
NOTE
Observe the relevant regulations in your country for the materials to be
machined.

EN
| 16 | ABDN 20 | EN | ID No. 10154 | V01 | 2021-11
2.9.3 Electrical safety
xDo not touch or short-circuit the contacts of the battery pack!
xBefore each use, check the power tool for damage.
Damaged equipment is dangerous, and no longer safe to use.
xNote the rechargeable battery voltage! The rechargeable battery voltage
must match the details given on the rating plate of the power tool.
xRegularly clean the ventilation slits of your power tool by blowing them out.
Never use liquids. Never insert screwdrivers or any other objects into the
ventilation slits. Do not cover the ventilation slits.
The motor fan draws dust into the housing and a large accumulation of metal dust
can cause electrical hazards.
2.9.4 Safety of people
xWear personal protective equipment and, depending on the work situation,
use:
Full-face protection, eye protection or safety glasses/goggles, hard hat
and special apron
Protect yourself against debris thrown up by wearing a hard hat, safety
goggles or face protection and wear an apron if necessary.
Hearing protection
The typical A-weighted sound pressure level of this power tool is over 85 dB
(A) while working with the tool.
If you are exposed to loud noise for lengthy periods, there is a risk of hearing
damage or even hearing loss.
Anti-vibration safety glove
A
t an action value A (8) for arm-hand vibrations of over 2.5 m/s², the wearing
of anti-vibration safety gloves is recommended.
Non-slip safety footwear
Dust mask, half-face filter mask or face mask respirator
Inhaling fine mineral and/or toxic dust can cause health hazards. We
recommend wearing a face mask respirator with filter class P2 or P3 (to
EN 149:2001).

EN
A
BDN 20 | EN | ID No. 10154 | V01 | 2021-11 | 17 |
xEnsure other people keep a safe distance from your work area. Any person
entering the work area must be wearing personal protective equipment.
Broken pieces of the workpiece or broken insert tools can fly off and cause injuries,
even outside the immediate work area.
xNever put down the power tool until the insert tool has come to a complete
standstill.
The rotating insert tool can come into contact with the surface on which the power
tool is placed, which could cause you to lose control of the power tool.
xDo not leave the power tool running while you are carrying it.
Your clothing can get caught by inadvertent contact with the rotating insert tool and
the insert tool can drill into your body.
xIf the machine is switched on, do not direct insert tools towards your own or
other people's bodies. Do not touch or take hold of the tools.
xThe protective hood or the disc guard clip may not be damaged or cracked,
otherwise they must be replaced immediately.
2.9.5 Further safety instructions for the power tool
Further safety instructions
xRemove the battery pack from the machine before making any adjustment,
retooling, servicing or cleaning.
xCheck that the machine is switched off when inserting the battery pack.
xWhen removing and inserting the battery pack, hold the machine so that the
On / Off switch cannot be operated accidentally.
xOnly use abrasive products approved for your power tool and the protective
hood intended for these abrasive products.
Abrasive products that are not intended for the power tool cannot be shielded
sufficiently and are unsafe.
xDo not use any accessories which have not been especially provided and
recommended for this power tool by the manufacturer.
Just because you can attach the accessories to your power tool is not a guarantee
of safe use.
xChange insert tools carefully and only use the mounting tools provided if
they are in perfect condition. Disconnect the plug before changing the insert
tool.
Use of the mounting tool provided prevents damage to the power tool and insert
tool.
xDo not expose power tools to extreme heat or cold.
Mechanical and electrical damage can occur during extreme heat and/or cold.
xAllow the insert tools, tool holders and other parts to cool in the immediate
vicinity of the work area after use.
The tools can get very hot after use. Do not touch or grip the parts, risk of injury.

EN
| 18 | ABDN 20 | EN | ID No. 10154 | V01 | 2021-11
xAdditional signs or other, non BAIER-specific parts may not be screwed or
riveted onto the motor, handle, gearbox or protective housing.
This could damage the power tool and cause malfunctions to occur.
xAvoid unnecessary noise emissions.
xNote and follow the safety and work instructions for the accessories used.
xDo not use cutting discs for rough grinding (cutting discs may not be
exposed to lateral pressure).
xAfter attaching insert tools, before switching on, check that they are
correctly fitted and can freely rotate. Ensure that insert tools do not touch
the protective hood or other parts.
2.9.6 Further safety instructions for the battery pack
xKeep battery pack dry!
xStore battery packs only within the temperature range from 10 °C to 30 °C.
Never leave battery packs in your car in the summer.
xDo not open battery packs!
xDo not expose battery packs to fire!
xDo not use defective or deformed battery packs!
xA slightly acidic, flammable liquid can leak from defective Li-ion battery
packs!
xIf battery fluid leaks and comes into contact with the skin, rinse off
immediately with plenty of water. If battery fluid gets into your eyes, rinse
them with clean water and seek medical treatment immediately!
xIf the machine is defective, remove the battery pack from the machine.
xDo not touch or short-circuit the contacts of the battery packs.
xTransporting Li-ion battery packs: The shipping of Li-ion battery packs is
subject to dangerous goods law (UN 3480 and UN 3481). When shipping
Li-ion battery packs, clarify the current relevant regulations. If necessary,
contact your transport company to find out further information.
Certified packaging is available from Maschinenfabrik OTTO BAIER GmbH. Ship
battery packs only if the housing is undamaged and there is no leaking fluid.
Remove the battery pack from the machine for shipping. Secure the contacts
against short-circuit (e.g. insulate with adhesive tape).
xFollow the disposal instructions (ÎChapter 9, Disposal; Page 43).
xBefore disposing of the power tool, discharge the battery pack in it. Secure
the contacts against short-circuit (e.g. insulate with adhesive tape).

EN
A
BDN 20 | EN | ID No. 10154 | V01 | 2021-11 | 19 |
2.9.7 Service / Maintenance / Repair
xIf the power tool is dropped or becomes wet, have it checked.
A possibly damaged power tool is dangerous and no longer safe to operate. Have
the power tool checked by our customer service department or a workshop
authorised by BAIER before further use.
xRepair and maintenance work may only be carried out by a workshop
authorised by BAIER.
Otherwise all liability and warranty claims against BAIER expire.
xEnsure that, where necessary, only original spare parts and original
accessories are used.
Original parts are available from authorised dealers. Use of non original parts can
cause damage to the machine and an increased risk of accidents.
xRegular servicing by BAIER or a servicing and repair firm authorised by
BAIER is a specified requirement.
Many accidents are caused by poorly serviced and maintained power tools.
2.10 Intended use
2.10.1 Uses
The cordless diamond wall chaser ABDN 20, together with diamond discs, is intended
to be used for subsequent installation work or for individual cable laying. The cordless
diamond wall chaser ABDN 20 is only approved for making dry cuts in Poroton, bricks,
calcium silicate, plaster and exposed aggregate concrete in conjunction with a special
dust extractor.
NOTE
Observe the relevant regulations in your country for the materials to be
machined.
NOTE
The user is solely liable for damage caused by non-intended use.
2.11 Reasonably foreseeable misuse
Never use the cordless diamond wall chaser ABDN 20
xwithout a correctly mounted protective hood
xwithout a special dust extractor suitable for stone dusts.
xfor rough grinding. (Diamond discs may not be exposed to lateral pressure.)

EN
| 20 | ABDN 20 | EN | ID No. 10154 | V01 | 2021-11
xwith liquid coolants.
xfor milling curves. (Diamond cutting discs are designed for straight cuts. If used to
cut curves the diamond cutting disc becomes deformed, which causes internal
cracks and segments to break off.)
Do not machine the following materials:
xmetal, wood, glass, etc.
