Bajaj Auto Avenger 150 Street User manual

Foreword
Dear Customer,
Congratulations on becoming the proud owner of a “Avenger 150 DTS-i” motorcycle, one of the
finest motorcycles in the country.
Your safety and the safety of others is extremely important. Hence, before you ride the bike,
please read this Owner's Manual carefully and familiarize yourself with the operating mechanism,
controls and maintenance requirements. This will ensure you a long and trouble free ownership
experience.
To keep your bike in perfect running condition and ensure consistent performance, we have
specially programmed the periodic maintenance services which includes 3 Free and subsequent
Paid services.
We earnestly advise you to avail all these services at any of our Vehicle Dealers or Authorised
Service Centers as per the schedule contained in this booklet. They are well equipped with all
necessary facilities / genuine parts / oil and trained manpower. All this would ensure better care of
your bike.
Your “Avenger 150 DTS-i” has been provided with a warranty of 2 Years or 30,000 Kms.
whichever occurs earlier from the date of sale. For details please refer to “Warranty : Scope &
Limits” given in this manual.
Should you require any additional information feel free to contact us on our toll free no.:
1800 233 2453 or e-mail us at: [email protected] or visit the Bajaj Auto website
www.bajajauto.com
Thank you for choosing a Avenger and wish you unlimited miles of happy riding !!
SERVICE DEPARTMENT
BAJAJ AUTO LIMITED

Description
1. Technical Specifications 1
2. Identification Data 3
3. Location of Parts 4
4. Steering cum Ignition lock 5
5. Fuel Tank Cap / Fuel Tap 6
6. Speedometer Details 7
7. Control Switches 8
8. Removal & Fitment of Side Covers 10
9. Battery / Tool kit 11
10. Daily Safety Checks 12
11. How to ride your Bike 13
12. Safe Riding Tips 17
13. Engine Oil 18
14. Wheels - Tyre 19
15. Periodic Maintenance Information 20
16. Free Service Guidelines 23
16. Periodic Maintenance & Lubrication Chart 24
17. Non Use Maintenance 29
18. Delivery Certificate 30
19. Warranty Scope & Limit 31
20. Battery Warranty Card
Notice:
The description and illustration in this booklet
are not to be taken as binding on the
manufacturers. The essential features of the
type described and illustrated herein remaining
unaltered. Bajaj Auto Limited reserves the
right to carry out at any moment without
being obliged to bring this booklet upto-date
& to do modifications on the vehicle, parts or
accessories as may be convenient and
necessary.
Safety and Warning information :
Table of Contents
Caution : This indicates that a potential
hazard that could result in vehicle
damage. Follow the Advice provided with
the caution.
Warning : This indicates that a potential
hazard or injury to you or other persons &
to the vehicle can happen if advice
provided is not followed.

Brakes
Front Brake : Hydraulic disc brake.
Rear Brake : Mechanical expanding
shoe.
Fuel Tank Capacity
Full : 13 liters
Reserve : 3.8 liters
Dimensions
Length : 2077 mm
Width : 801 mm
Height : 1070 mm
Wheel base : 1480 mm
Ground Clearance : 169 mm
Tyre Size
Front Tubeless : 90/90 - 17, 49P
Rear Tubeless : 130/90 -15, 66P
Technical Specifications
1
Engine : 4 stroke
Bore X Stroke : 58.00 mm x 56.4 mm
Eng. Displacement : 149 cc
Compression Ratio : 9.8 : 1
Idling Speed : 1400 +/- 150
Max. Net Power : 14.54 PS at 9000 rpm
Max. Net Torque : 12.5 Nm at 6500 rpm
Ignition System : DC CDI
Spark Plug : CHAMPION RG4HC,
BOSCH - UR6CE
Spark Plug Gap : 0.7 to 0.8 mm.
Transmission : 5 speed constant mesh
Gear Shifting
Pattern : 1 Down 4 Up
Engine Lubrication : Wet sump, forced
Cooling System : Air cooled
Starting Aid : Electric Starter

2
Technical Specifications
Tyre Pressure
2
Front : 1.5Kg/cm (21PSI)
2
Rear (Solo) : 1.5Kg/cm (21PSI)
2
Rear (with Pillion ) : 1.75Kg/cm (25PSI)
Vehicle Kerb Weight : 149 kg.
Gross Vehicle Weight : 299 Kg.
Electrical System : 12 Volts DC
Battery : 12V, 4Ah VRLA
Head Lamp : 55/60W Blue Tinge
Pilot Lamp : 4W
Tail /Stop Lamp : 5/21W
Turn Signal Lamp : 10W
Speedometer Lamp : LED
Bajaj Logo : LED
Fuel Gauge Lamp : LED
Neutral Indicator Lamp : LED
High Beam Indicator Lamp : LED
Turn Pilot Indicator Lamp : 1.7W
Low Battery Indicator : LED
Horn : 12V DC
Note :
• All dimensions are under UNLADEN condition.
• Above information is subject to change without
any notice.
• This vehicle complies to BS IV standards.
• AHO is government regulation.

Identification Data
The Frame and Engine serial numbers are used to register the motorcycle. They are the unique
alpha-numeric codes to identify your particular vehicle from others of the same model and type.
Frame Number Location
On Side of Steering Tube
(Alpha-Numeric - 17 Digits)
Engine Number Location
On LH Side Crankcase Near Gear
Change Lever (Alpha-Numeric - 11 Digits)
3
