Bajaj pulsar ns160 2023 User manual

Owner’s Manual

Doc. No. 71120194 REV. 00, FEB. 2023

Welcome to the Pulsar family!
You are now the proud owner of India’s No.1 sports bike. By No.1 we are talking about unparalleled performance, superior
technology and incredible market leadership that Pulsar today enjoys. This makes the Pulsar you ride, unbeatable and
unchallenged both on and off the road.
Before you ride out, please read this Owner's Manual carefully and familiarize yourself with the operating mechanism, controls
and maintenance requirements of your Pulsar. This will ensure you a safe and trouble free ownership experience.
To keep your bike in perfect running condition and deliver consistent performance, we have specially programmed the periodic
maintenance services which includes 3 Free and subsequent Paid services, as per the schedule contained in this booklet. We
earnestly advise you to avail all these services at any of our Bajaj Dealers or Authorised Service Dealers (ASD), who are well
equipped with all necessary facilities / genuine parts / oil and trained manpower to ensure the best care for your Pulsar. Your
Pulsar Ns160 BSVI comes with a warranty of 5 Years or 75,000 Kms whichever occurs earlier from the date of sale. For details
please refer to “Warranty : Scope & Limits” given in this manual.
Should you require any additional information feel free to contact us on helpline numbers or e-mail us at:
[email protected] or visit the Bajaj Auto website www.bajajauto.com
To be a part of the Pulsarmania, visit www.mypulsar.com and join the Pulsar fanpage on facebook:
www.facebook.com/mypulsar
Rev up, shift gears and enjoy the Pulsar experience…
SERVICE DEPARTMENT
BAJAJ AUTO LIMITED

1
3
4
5
6
7
13
15
17
18
19
20
21
25
26
27
28
29
31
32
33
41
42
45
46
“Cranking ON and OFF duration” control

Engine 4 Stroke, Single Cylinder
Bore x Stroke 58 mm x 60.7 mm
Engine Displacement 160.37 cc
Compression Ratio 9.8+/- 0.5 : 1
Idling Speed 1500 +/- 100 RPM
Max. Net Power 17 PS at 9000 RPM
Max. Net Torque 14.6 Nm at 7250 RPM
Ignition System DC
Fuel System Fuel Injection System
Spark Plug 2 Nos.
Spark Plug Gap 0.7 ~ 0.8 mm
Lubrication Wet sump forced Lubrication
Transmission 5 speed constant mesh
Gear shifting Pattern 1 Down 4 Up
Engine Cooling Oil cooled
Starting Aid Self / Kick
Front & Rear Brake Disc
Parameter
Fuel Tank Capacity
Full 12 Liters (No Reserve)
Dimensions
Length 2017 mm
Width 804 mm
Height 1060 mm
Wheel base 1372 mm
Ground Clearance 170 mm
Tyre Size Front 100/80-17,52P Tubeless
Tyre Size Rear 130/70-17,62P Tubeless
Tyre Pressure
Front 1.75 Kgf/cm (25 PSI)
2
Rear (Solo) 2 Kgf/ (28 PSI)
2
cm
Rear (with pillion) 2.25 Kgf/cm (32 PSI)
2
Electrical System 12 Volts DC
Battery 12V 4Ah VRLA
Head Lamp 35/35 W
Pulsar NS 160 BS VI Parameter Pulsar NS 160 BS VI
1

Parameter
Position Lamp Bulb-12V,3W-2 Nos.
Tail / Stop Lamp LED
Side Indicator Bulb 10W-4 Nos.
Rear No. Plate Lamp Bulb 12V,3W
Neutral Indicator LED-Green
Hi-Beam Indicator LED-Blue.
Speedometer Illumination LCD-Orange
Fuel Level Indicator LCD Bar
Malfunction Indicator LED-Yellow
Low oil pr.Indicator LED-Red
Low Battery Indicator LED-Red
Bajaj Logo LED-Blue
REV Indicator LED-Yellow
Service Reminder LCD
Side Stand Indicator LCD
ABS Indicator LED-Yellow
Horn 12V DC
Vehicle Kerb Weight 152 kg.
Vehicle Gross Weight 302 kg.
Pulsar NS 160 BS VI
2
Note : • All dimensions are under UNLADEN condition. • Above
information is subject to change without any notice. • This vehicle
complies to BS VI standards. • AHO / DRL is government regulation.
• Dual Channel ABS System is fitted in these vehicles
• Dual channel ABS means ABS is fitted on front & rear wheels
• Always maintain a safe distance between you and objects
ahead. Vehicle speeds should always be reduced during
extreme road conditions. The braking distance for motorcycle
equipped with an anti-lock braking system may be longer than
for those without it on rough road conditions. During these
conditions the vehicle should be driven at reduced speeds
• When you apply Front brake / Rear brake by pressing Front
brake lever/Rear brake pedal under conditions which may lock
the wheels, you feel a corresponding sensation (pulsation) in
Front brake lever/ Rear brake pedal. (as applicable to model)
This is normal and it means ABS is active.
• ABS technology requires the rider to brake appropriately to
ensure safer braking specially under acute conditions.
• Also it is recommended to use both front and rear brakes
simultaneously.
• Always slow down when cornering. The anti-lock brake system
cannot prevent accidents resulting from excessive speeds.
• Never drive by disconnecting wheel speedometer cable.
Speedometer

3

Reflex Reflector
Speedometer
Front Break lever
Headlamp
Front fork
Front Disc
Belly Pan
Rear Break
Pedel
Rear
Break
Disc
Engine Oil
Level Window
Pillion Foot Rest
Tail Lamp
Grab Handle
Kick Lever
Fuel Tank Cap
Front Speed Sensor Disc
4

5
“Cranking ON and OFF duration” control –
• During Engine crank cycle cranking is allowed only for
fixed duration and in between successive cranks (in ase
engine does not start) here is a cooling off period.
• Cranking on-off duration control feature to avoid battery
discharge-
- 1st Crank ON (5 sec) & Disable for 2 sec.
- 2nd Crank ON (5 sec) & Disable for 2 sec.
- 3rd Crank ON (5 sec) & Disable for 10 sec.
After a gap of 10 sec cranking cycle continues.
• Starter disabled if side stand down – With side stand
down condition and vehicle in gear, Engine cranking is
disabled through ECU.
• Headlight control on rpm – Headlamp will be turned ON
only at Engine running condition.

• There is no fuel cock.
• Always maintain minimum 3 Liter Petrol in fuel tank.
• Do not use adulterated fuel or fuel additives as it
will result in rusting & clogging of Injector, Fuel
pump module & catalytic Convertor.
• Do not rev engine in standstill condition.
• If vehicle is tiled beyond 60 Deg, then Roll
over sensor cuts off Ignition system as a
safety feature.
• Never drive by disconnecting wheel speed
sensor as ABS unit will not function.
6
Caution : Incase petrol is spilled out on petrol tank, it
is to be immediately cleaned with clean soft cotton cloth
to prevent permanent stain marks on petrol tank.

1
2
3
4
5
6
7
8
910
1A
7
1. Fuel Level Indicator: It shows available fuel in fuel tank.
1A. Low Fuel Level Indicator: ( ) It blinks if fuel bar is < 1 bar.
2. Tachometer Dial: It shows engine speed in RPM.
3. Turn Signal Indicator LH/RH : When Turn signal switch is
pushed to Left or Right, Turn Signal Indicator - LH or RH will
flash.
4. Neutral Indicator: When the transmission is in Neutral,
Neutral indicator will glow.
5. High Beam Indicator ( ): It glows when Headlight is ON & High
beam is selected with engine running.
6. Low Battery Indicator:( ) It indicates battery needs charging.
7. Low Oil Pressure Indicator ( ): It glows when engine oil
pressure is low.
8. Malfunction Indicator ( ): It glows whenever any abnormality
is noticed in functioning of Fl system related components.
9. Bajaj Logo: Bajaj logo flying “B” continuously glow.
10.Mode Button: Mode button used for toggling between different
modes e.g. ODO, Trip1, Trip2, DTE, service reminder and clock
setting.
11. ABS Indicator ( ): With Ignition switch ON the ABS indicator
glows. When vehicle speed is more than 5 Km/h the ABS
indicator goes off, if this indicator glows while vehicle is running,
it means there is problem in ABS.
11

12
13
14
15
16
17
18
19
20
8
12. Engine REV Indicator: ( ) It glows when engine RPM is between
10,000 ~ 10,500 RPM. continuously ON at RPM more than
10,500.
13. Gear Indication: It will display gear position from 1 to 5. It will
display “N” when vehicle is in neutral position.
14. Side Stand Indicator: It glows when side stand is down. starter
will be disabled if side stand down - with side stand down condition
& vehicle in gear, engine cranking is disabled through ECU
15. Digital Clock: It indicates time in HR: MM (AM/PM)
16.Speedometer: Vehicle speed will be displayed in digital form in Km/h
17. Odometer: The Odometer shows the total distance that the
vehicle has covered. Odometer can not be reset to 'Zero'.
RPM
LIMIT 18. Service Reminder: 'Wrench' symbol glows when ODO meter
reading reaches to set Kms. It indicates vehicle is due for
periodic service. This Icon will flash at -
1st: 450 km 2nd: 4450 km, 3rd: 9450 km
and subsequently at each 5000 kms. Icon will continue to glow
till it is reset. This icon is to be reset after service is carried out.
19. Trip Meter: Trip 1 & Trip 2 shows the distance traveled since it
was last reset to zero.
20. Set Button: Set button used for toggling between ODO to IFE,
Trip1 to AFE1,Trip2 to AFE2,DTE to distance to next service and
clock setting.

9
Condition
Ignition switch is ON & Set push button not pressed, ODO will be displayed. In ODO mode, press Set push button, IFE
will be displayed.
1. ODO: The Odometer shows the total distance that the
vehicle has travelled.
2. IFE (Instantaneous Fuel economy): This will indicate fuel
economy in km/L. at any given time. Value will be
displayed only when vehicle speed & Engine RPM is more
than zero.
If vehicle speed is zero then IFE will be displayed “--km/L”
Note:
IFE (Instantaneous fuel economy) / AFE (Average fuel
economy) / DTE (Distance to empty) readings are
indicative & may vary due to driving and road conditions.
Details - ODO & IFE

10
Procedure to set AFE1 & TRIP1:
Ignition switch is ON & mode push button pressed for
less than 1sec.- TRIP1 mode get selected.
Set push button pressed for less than 1 sec. in TRIP1
mode - AFE1 gets displayed.
Procedure to set AFE2 & TRIP2:
Ignition switch is ON & mode push button pressed for
less than 1sec.- TRIP2 mode get selected.
Set push button pressed for less than 1 sec. in TRIP2
mode - AFE2 gets displayed.
1. TRIP1: The Trip meter shows the total distance that
the vehicle has travelled in TRIP1 mode. If TRIP1 is
reset, average fuel economy (AFE1) will reset.
2. AFE1 (Average Fuel economy1): This will indicate
the average fuel economy in km/L in TRIP1 mode.
3. TRIP2: The Trip meter shows the total distance that
the vehicle has travelled in TRIP2 mode. If TRIP2 is
reset, average fuel economy (AFE2) will reset.
4. AFE2 (Average Fuel economy2): This will indicate
the average fuel economy in km/L. in TRIP2 mode.
Note: AFE will be updated every 60 sec. AFE will be reset if corresponding TRIP1 or TRIP 2 is reset or battery disconnected.
Details - AFE1,TRIP1 & AFE2, TRIP2

11
Note:
If vehicle is driven by ignoring fuel level display & Tank symbol ( ) blinking after reaching fuel unutilized level DTE
will be shown as ‘--’ Km.
During Petrol Refilling:
If petrol filled is more than 1 Liter then DTE will be calculated based on the revised fuel volume.
If petrol filled less than 1 Liter then there will be no change in DTE value.
DTE (Distance to empty):
It indicates the estimated distance that the vehicle can travel under current fuel
economy & fuel level condition.
DTE calculation is independent of TRIP and based on AFE for distance covered for
last 25 Kms.
Max count of DTE is 990 Km. speedometer will display values in multiple of 10.
TRIP Setting:
If Set button is pressed more than 5 sec.in TRIP1 or TRIP 2 mode, then respective AFE & trip distance will reset
to Zero while DTE will continue to show earlier value.
Note:
After completion of max value of 999.9 Km, selected trip display will get freezed and will not get set automatically
to zero.
However speedometer will continue to calculate and display AFE value.
Details - DTE & TRIP

12
Note :
After switching 'ON' the ignition switch, the following indications
will remain 'ON' till engine is started.
• Low Battery Indicator
• Low Oil Pressure
• Malfunction Indicator

13
Set

Set
14
,
,

15
be

16
