Bajaj Platina 100 BS VI Manual

Supplementary Service Station Manual - Platina 100 BS VI
Product code
Platina 100 ES BS VI CBS : PF20
Platina 100 KS BS VI CBS : PF25

Sr No Parameter
1
Technical Specifications
2
Preventive Maintenance Chart
3
PDI check sheet
4
Torque Value & Service Limit
5
Part identification
6
Wiring Harness Routing
Index

Technical Specifications

Parameter Specification
Type 4 stroke, Natural air cooled
Bore 47 mm
Stroke 58.8 mm
Displacement 102 cc
Idling speed 1300 +/- 100 rpm
Max.Net Power 7.89 PS @ 7500 RPM
Max. Net Torque 8.34 Nm @ 5500 rpm
Ignition system DC
Spark plugs Qty 2 Nos
Spark plug gap 0.7 –0.8 mm
Engine
Parameter Specification
Lubrication Splash type
Transmission 4 Speed
Gear shifting pattern All Down
Engine oil Grade BAJAJ DTSi 10000 BS6
Compliant Engine oil
10W30API SN JASO MA2’
Engine oil Drain & Refill
quantity 1000 ml
Overhaul quantity 1100 ml

Parameter Specification
Frame Tubular Single Down Tube with
Lower Cradle frame
Suspension Front Telescopic suspension
Rear Twin suspension with nitrox
(Spring in Spring-SNS)
Brakes Front Drum, Ø 130 mm (CBS)
Rear Drum, Ø 110 mm
Tyres Front 80/100-17, 46P, Tubeless
Rear 80/100-17, 53P, Tubeless
Tyre Pressure
Front 1.75 Kgf/cm² (25 PSI)
Rear (Solo) 2 Kgf/cm² (28 PSI)
Rear (Pillion) 2.25 Kgf/cm² (32 PSI)
Fuel Tank Capacity Full 11 Litres
Fuel Tank Usable Reserve 1.5 Litres
Fuel Tank Un-Usable Reserve 0.5 Litres
Fork oil Grade Bajaj fork oil ,SAE 10W20
Fork oil Quantity / leg 150 +/- 2.5 ml
Frame
Parameter Specification
Length 2006 mm
Width 704 mm
Height 1076 mm
Wheel Base 1255 mm
Ground Clearance 200 mm
Vehicle Kerb Weight ES –117 Kg
KS –115.5 Kg
Vehicle Gross Weight ES –247 Kg
KS –245.5Kg

Electrical
Fuel Gauge Values
Fuel Level
Fuel Quantity
(Litres) Standard Value(Ω)
Empty Tank
1.5 90
Half Tank
5.5 48
Full Tank
8.5 8
Parameters Specification
System
DC
Battery
12V 3Ah VRLA
Head Lamp
12V 35W/35W
Position Lamp
Part of Daytime Running
Light (DRL)
Tail / Stop Lamp
12V 5/10W
Side Indicator
icon lamp
12V 10W
Neutral Indicator
icon lamp
12V 2W
Hi Beam Indicator
icon lamp
12V 2W
Turn Signal Indicator
icon lamp
12V 2W
Speedometer back light lamp
12V 2W
Fuel Level Indicator
1
2V 2W
Malfunction Indicator Lamp (MIL)
12V 2W
Rear Number Plate Lamp
Part of tail lamp
Horn
12V 2A

Preventive Maintenance Chart

Sr No Activities / Check points
Recommended frequency -- Service interval & Kms
Remarks
Servicing
1st
(Free)
2nd
(Free)
3rd
(Free)
4th 5th 6th 7th 8th 9th 10th 11th 12th 13th 14th 15th 16th
Kms
500
-
750
4500 -
5000
9500 -
10000
14500 -
15000
19500 -
20000
24500 -
25000
29500 -
30000
34500 -
35000
39500 -
40000
44500 -
45000
49500 -
50000
54500 -
55000
59500 -
60000
64500 -
65000
69500 -
70000
74500 -
75000
1
Servicing with water wash
√ √√√√√√√√√√√√√√√√
Ensure to prevent water entry in Petrol
tank, Silencer & electrical
parts.Use
caustic
free detergent for washing.
2
Engine oil (Bajaj DTSI 10000 oil)
Top up, R
R
Top
-
up
R
Top
-
up
R
Top
-
up
R
Top
-
up
R
Top
-
up
R
Top
-
up
R
Top
-
up
R
Top
-
up
Use BGO 10W30
Oil level window cleaning at every 10000
kms by petrol spray & nylon brush
3
Engine oil Filter
R R R R R R R R R
Replace oil filter in 1st service & at every
10000 Kms
4
Oil strainer
CL CL CL CL CL CL CL CL CL
Oil strainer cleaning at the time of oil
change.
5
Air cleaner element** & air filter cover
‘O’ ring. Drain tube cleaning.
CL,R CL CL CL RCL CL RCL CL RCL CL RCL CL R
Replace air filter at every 15,000 kms
Replace air filter cover O ring along with air
filter element
6
Fuel cock sediment bowl cleaning**
CL CL CL CL CL CL
7
Fuel pipes for cracks.
C,R C C C R C C R C C R C C R C C R
Replace at every 15000kms
8
Spark plug clean & check gap
CL,A,R CL,A CL,A R CL,A CL,A R CL,A
Replace at every 30000 kms
9
Valve tappet clearance
C,A C, A C, A C, A C, A C, A C, A C, A C, A C, A C, A C, A C, A C, A C, A C, A C, A
10
Carburettor float chamber cleaning**
CL CL CL CL CL CL
11
Carburettor
rubber duct (Sleeve) for
hard resulting in loose fitment.
C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R
Replace if required
12
Engine breather tube for cracks.
C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R
Replace if required
13
EVAP system Hoses
- check for cracks C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R
Drain EVAP "Y" connection drain
tube.Replace
if found cut / damaged
14
Engine foundation silent bushes for
cracks
C,R C,R C,R C,R C,R C,R C,R C,R
Replace if required
15
Silencer drain hole cleaning
CL CL CL CL CL CL CL CL CL CL CL CL CL CL CL
16
Wiring harness connections, routine &
Conduit / PVC sleeve inspection.
C,A,T
C,A,T
C,A,T
C,A,T
C,A,T
C,A,T
C,A,T
C,A,T
C,A,T
C,A,T
C,A,T
C,A,T
C,A,T
C,A,T
C,A,T
C,A,T
C,A,T
Damaged conduit / PVC sleeves protection
by applying electrical tape film.
17
Battery connections & health by load
tester. +ve terminal cap fitment.
C,A,L,T
C,A,L,
T
C,A,L,
T
C,A,L,
T
C,A,L,
T
C,A,L,
T
C,A,L,
T
C,A,L,
T
C,A,L,
T
C,A,L,
T
C,A,L,
T
C,A,L,
T
C,A,L,
T
C,A,L,
T
C,A,L,
T
C,A,L,
T
C,A,L,
T
Apply petroleum jelly on battery terminals.
Use Midtronics battery tester.
18
Ignition switch contacts cleaning
CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L
Use recommended WD40 spray
19
HT coil connections (Primary and
Secondary)
C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T
20
Starter motor & starter relay
connections
C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T

Sr No Activities / Check points
Recommended frequency -- Service interval & Kms
Remarks
Servicing
1st
(Free)
2nd
(Free)
3rd
(Free)
4th 5th 6th 7th 8th 9th 10th 11th 12th 13th 14th 15th 16th
Kms
500 -750
4500
-5000
9500
-
10000
14500
-
15000
19500
-
20000
24500
-
25000
29500
-
30000
34500
-
35000
39500
-
40000
44500
-
45000
49500
-
50000
54500
-
55000
59500
-
60000
64500
-
65000
69500
-
70000
74500
-
75000
21
Check fault code, Clear fault history,
Update latest hex file if applicable
C CCCCCCCCCCCCCCCC
22
Non
- sealed Drive chain wear**-
Clean,
Lubricate & adjust. Replace if required
CL,L,A
CL,L,A
CL,L,A
CL,L,A
CL,L,A
CL,L,A
CL,L,A
CL,L,A
CL,L,A
CL,L,A
CL,L,A
CL,L,A
CL,L,A
CL,L,A
CL,L,A
CL,L,A
CL,L,A
During 1st Free Service :Use lint free cloth
for cleaning & SAE 90 oil for lubrication
without removing from vehicle .
During all other services: Remove, Clean by
Diesel & Lubricate using molten chain
grease.
23
Drive chain link lock
R R R R
Replace at every 20000kms
24
Main stand & side stand both pivot pin
C,L C,L C,L C,L
Use recommended AP grease.
25
Steering play
C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A
26
Steering stem bearing & Cap steering
bearing (Plastic)**
C,CL,L
C,CL,L
C,CL,L
C,CL,L
C,CL,L
C,CL,L
C,CL,L
C,CL,L
Replace if required. Use Limaplex grease
for lubrication
27
Front fork oil & seal
C,R C,R C,R C,R C,R C,R C,R R C,R C,R C,R C,R C,R R C,R C,R C,R
Replace oil and oil seal +dust seal in pair at
every 30000 kms
28
Brake shoes Front & rear for wear limit.
C,R C,R C,R C,R R C,R C,R R C,R C,R R C,R C,R R C,R C,R R
Replace at every 15000 Kms
29
Brake cam Front & Rear.
CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L CL,L
Use AP grease
30
Rear sprocket fasteners for looseness.
C,T C,T C,T C,T C,T C,T C,T C,T C,T
3.2
- 3.8 Kfg-m
31
Rear wheel rubber shock dampers for
excess play.
C,R C,R C,R C,R C,R C,R C,R C,R
Replace rear wheel rubber shock damper if
required
32
Fairing & windshield well nuts for
rubber cracks.
C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R C,R
Replace if rubber found cracked.
33
All cables free play adjustment
C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A
Replace cables if operation found hard.
34
Head light focus adjustment
C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A
35
Check & confirm all bulbs / switches
working.
C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A
Contact type switches if found sticky then
use recommended WD40 spray

Sr No
Activities / Check points
Recommended frequency -- Service interval & Kms
Remarks
Servici
ng 1st
(Free)
2nd
(Free)
3rd
(Free)
4th 5th 6th 7th 8th 9th 10th 11th 12th 13th 14th 15th 16th
Kms
500 -750
4500
-
5000
9500
-
10000
14500 -
15000
19500 -
20000
24500 -
25000
29500 -
30000
34500 -
35000
39500 -
40000
44500 -
45000
49500 -
50000
54500 -
55000
59500 -
60000
64500 -
65000
69500 -
70000
74500 -
75000
36
General lubrication
–Clutch lever / front brake
lever & kick lever.
L L L L L L L L L L L L L L L L L
Use recommended AP grease.
37
Tyre air pressure.
C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A
Front : 1.75 Kgf/cm² (25 PSI)
Rear (Solo) : 2 Kgf/cm² (28 PSI)
Rear (Pillion) :2.25 Kgf/cm² (32 PSI)
38
Mirror position & joint firmness.
C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A C,A
39
All fasteners tightness, few are
C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T C,T
Use model wise torque values.
Front Axle
4.5
- 5.5 Kgf-m
Rear Axle
5.5
- 6.5 Kgf-m
Swing arm Shaft
5.2
–5.8 Kgf-m
Rider foot rest.
1.8
–2.2 Kgf-m
Engine foundation front.
1.8
–2.2 Kgf-m
Engine foundation Rear.
2.8
- 3.2 Kgf-m
*** More frequent cleaning may be required while driving in dusty environment.
C : Check, A : Adjust, CL : Clean, R : Replace, T : Tighten, L : Lubricate
Note : Periodic parts, Oil, Filters, All types of greases, Cleaning agents, Cables, Wear & tear parts, Rubber ‘O’ rings / oil
seals / pipes, Gaskets to be replaced as per Periodic
Maintenance and Lubrication Chart are mandatory and the same are chargeable to customer.

PDI Check sheet

PDI Check sheet
Dealer's Name
Dealer's code:
Model
City
Frame No.
Date of PDI
Engine No.
PDI done by
1. Check Points before starting the vehicle
Check Point What to check How to check Recommendation /
Reference Workshop Observation
Tools , equipment &
consumables required
Engine Oil
1. Engine oil level.
2. Oil leakages, if any.
Vehicle to be parked on
center stand.
1. Engine cold condition
--
Oil level should be in
betn
lower & upper mark of oil
level window.
2. Check this point after test
ride on road.
1. Engine oil filling
funnel.
2.
BGO 10W30
BS VI Compliant
Fuel Pipe
1.Pipe & Circlip fitting
2.Fuel leakage
Visual
_
Mirror
1.Fitment.
2.Adjustment.
Mirror adjustment as per
user's requirement.
Clear
rear view setting on
vehicle.
Leg & Saree
guard
Ease of fitment
_
Hardware fully tightened.
Lock Operation
Smooth operation of
Steering cum Ignition
lock,Seat lock, LHS cover
lock, Petrol Tank cap lock
By using vehicle key.
Insert vehicle key in lock &
check operation of
respective lock.

Check Point What to check How to check Recommendation /
Reference Workshop
Observation
Tools , equipment &
consumables
required
Battery
Battery charge condition
As per SOP
Green LED
-Battery fully
charged.
Yellow LED
-Battery
partially discharged.
Red LED
-Battery deep
discharged.
1.
Midtronics
battery
tester,
2. Battery charger
3. Petroleum jelly
Battery terminals tightness
& Petroleum jelly
application.
Carry out cable
connections.
Ensure firm connection of
+ve &
-ve terminals,
apply petroleum jelly &
ensure protection cap
fitment on +ve terminal
Tyre Pressure
Air pressure in Front &
Rear tyre
Check air pressure in both
tyres
using tyre pressure
gauge.
Front
- 1.75 Kgf/cm² (25
PSI)
Rear Solo
-
2 Kgf/cm² (28
PSI)
Rear Pillion
-
2.25 Kgf/cm²
(32
PSI)
Tyre
pressure
gauge.
Brakes
Front brake free play
Use free play checking
gauge.
2
–3 mm
Free play checking
gauge.
Free play of rear brake
pedal
Use free play checking
gauge.
Brake pedal free play 20
–
30 mm
Brake pedal play
/chain slackness
checking gauge
Clutch Lever / Throttle
Free play of Clutch lever &
Throttle.
Use free play gauge.
Free play 2 ~ 3 mm
Free play gauge
Drive Chain
Slackness
Use chain slackness
checking gauge
Slackness 20
- 30 mm
Brake pedal play
/chain slackness
checking gauge

Check Point What to check How to check
Recommendation / Reference
Worksho
p
Observati
on
Tools , equipment &
consumables
required
Fasteners Torque values
Front Axle
Using dial torque
wrench
4.5
- 5.5 Kgf-m
Dial torque wrench
20 Kgf
-m
Rear Axle
5.5
- 6.5 Kgf-m
Swing arm Shaft
5.2
–5.8 Kgf-m
Rider foot rest.
1.8
–2.2 Kgf-m
Engine foundation front.
1.8
–2.2 Kgf-m
Engine foundation Rear.
2.8
- 3.2 Kgf-m
2. Check Points during / after starting the vehicle
Switch Operation
RH & LH control switch,
ignition switch, clutch
switch & brake switches
Check for smooth
operation & functioning
_
Horn
Coupler connection,Horn
sound.
By hearing
_
All Bulbs Working
Head lamp Tail / stop
lamp, Side indicators,
Speedo bulb, No. plate
lamp, DRL
Check functioning.
_

Check Point What to check How to check Recommendation /
Reference
Workshop
Observation
Tools , equipment &
consumables
required
Speedometer
Working of speedometer,
, Fuel gauge
Fuel gauge
-
By filling fuel.
Speedometer working to
be checked during /
after test ride
Funnel for filling
petrol & measuring
jar
Working of all signal
indicators icons
(Neutral,Turn signal, High
beam,MIL
& B Logo)
By observing speedo
Indications after switching
ON ignition switch.
Headlamp
Head light Low & Hi
beam focus checking
As per head light focus
checking SOP.
Refer head light focus
values chart.
Focus to be checked
with rider & from a
distance of 5 meters.
Head light Focus
display chart with
5m mark.
3. Check Points during Test Ride
Gear shifting
Smooth operation
In case of any issue
during test ride, vehicle
to be attended in
workshop.
A.P.Grease,Feeler
gauge,Multimeter.
Driveability
Throttle response, Brakes
effectiveness
- Front &
Rear
Engine noise
No abnormal noise
4. Visual inspection for dent, scratches, rust
etc
5. Clean the vehicle thoroughly before delivery to customer.
Note
-
Vehicle FIFO system required with monitoring system.
Vehicles to be dispatched to network only after carrying out PDI activity at Dealership.
Do not drive vehicle in speed sensor dis connected condition & same to be instructed to customer.

Torque Values & Service Limits

Torque Value - Engine
Sr. No.
Parameter Torque value
(Kgf-m)
1
Cover cylinder head bolts
1 - 1.1
2
Cylinder head bolts
2.2 - 2.5
3
Intake Manifold fitted on head bolts
1 - 1.1
4
Camshaft sprocket bolt
1.6 - 1.8
5
Chain tensioner bolt
1 - 1.1
6
Chain guide bolt
1 - 1.1
7
Primary gear nut
6 - 6.5
8
Clutch nut
5 - 5.5
9
Rotor bolt
6 - 6.5
10
Output sprocket bolt fitted on O/P
shaft
0.6 - 0.8
11
Guide gear bolt fitted on gear
change drum
1 - 1.1
12
Cap oil filter bolt
1 - 1.1
13
Inhibitor bolt
1 - 1.1
Sr. No.
Parameter Torque value
(Kgf-m)
14
Oil strainer cap
1 - 1.1
15
Oil pump mounting screw
0.5 - 0.7
16
Clutch cover bolts
1 - 1.1
17
Magneto cover bolts
1 - 1.1
18
Cover LH RR Bolts
1 - 1.1
19
Air filter assembly bolts
0.5 - 0.8
20
Cover air filter bolts
0.25 - 0.3
21
Silencer mounting bolt at cylinder
head
2 - 2.2
22
Silencer mounting bolt on RH Stay
2.8 - 3.2
23
One way clutch bolts on rotor (For
100ES)
1.4 - 1.6
24
Starter Motor bolts (For 100ES)
1 - 1.1
25
Kick lever bolt
2.3 - 2.5

Torque Value - Frame
Sr.No. Parameter
Torque Value (Kgf-
m)
1
ECU Mtg bracket nuts
0.8 - 1.2
2
RR Unit bolts
0.8 - 1.2
3
HT Coil bolts
0.8 - 1.2
4
Engine mounting bolt top
1.8 - 2.2
5
Engine mounting bolt front
1.8 - 2.2
6
Engine mounting bolt rear
2.8 - 3.2
7
Steering slotted nut
0.3 - 0.7
8
RSATop nut
2.5 - 3.5
9
RSA Bottom nut
2.5 - 3.5
10
Swing arm shaft nut
5.2 - 5.8
11
Rider footrest bolt
1.8 - 2.2
12
Pillion Rider footrest bolt
1.8 - 2.2
13
Front fender bolt
0.8 - 1.2
14
Side stand bolt
2.5 - 3.5
15
Front axle nut
4.5 - 5.5
16
Rear axle nut
5.5 - 6.5
17
Rear sprocket nut on coupling
3.2 - 3.8
Sr.No. Parameter
Torque Value (Kgf-
m)
18
Rear coupling sleeve nut
6.2 - 6.8
19
Torque rod nut
2.8 - 3.2
20
Rear brake pedal bolt
0.8 - 1.2
21
Handle bar upper holder bolts
1 - 1.4
22
Handle bar lower holder bolts
2.5 - 3
23
Fork top mtg bolt
2.5 - 3.5
24
Fork underbracket bolt
2 - 3
25
Tank mtg bolt
0.6 - 1
26
Fuel gauge bolt
0.3 - 0.5
27
Fuel cock bolt
0.6 - 0.8
28
Speedometer mtg nuts
0.6 - 0.8
29
Headlight mtg nuts/bolts
0.15 - 0.19
30
Chain cover bolt
0.8 - 1.2
31
Leg guard bolt
1.8 - 2.2
32
Saree guard bolt Upper
0.8 - 1.2
33
Saree guard bolt Lower
1.8 - 2.2
34
Grab handle bolt
1.8 - 2.2

Service Limit - Engine
Sr. No
Parameter Standard (mm) Service Limit (mm)
1
Engine compression
pressure
12 - 13 Kgf/cm² Min 9.5 Kgf/cm²
2
Valve tappet clearance
IN / EX
In
- 0.05 Ex -
0.1
Not Applicable
3
Rocker arm shaft
diameter
7.99 -8 7.98
4
Cam sprocket root
diameter
59.91 - 60.11 Not Applicable
5
Cam lobe height
(Exhaust)
29.1 29.05
6
Cam lobe height (intake)
29.06 29.01
7
Valve spring free length
41.52 40.5
8
Valve stem diameter
intake
4.96 -4.98 4.95
9
Valve stem diameter
exhaust
4.94 -4.96 4.93
10
Valve stem bent
0.01 >0.01 replace
11
Cylinder head warp
0.03 0.05
12
Cam chain 20 links
length
127 -127.28 127.82
13
Cylinder
- piston
clearance
0.035 -0.057 0.11
14
Piston Ring end gap
(Top ring)
0.10 -0.25 0.5
Sr. No
Parameter Standard (mm) Service Limit (mm)
15
Piston Ring end
gap (second ring)
0.20 -0.40 0.65
16
Piston Ring end
gap (oil ring)
0.20 -0.70 1
17
Clutch assembly
part number
PF551430
PF551413
PF551430 PF551413
18
Clutch spring free
length
26.7 39.3 25.7 38.3
19
Friction plate
thickness
2.95 -
3.05
2.92
-
3.08
2.75 2.72
20
Steel plate
thickness
1.6 -1.7 1.9 - 2 1.55 1.85
21
Friction plate warp
0.1 Not Applicable
22
Steel plate warp
0.1 0.2
23
Gear shift fork
guide pin diameter
4.45 -4.49 4.4
24
Gear shift drum
groove width
4.55 -4.7 4.75
25
Crankshaft runout
0.02 0.05
26
Connecting rod
side (axial)
clearance
0.1 - 0.35 0.6
27
Cam lobe width
8.9 -9.1 Not Applicable
28
Shaft fork shift
outer diameter
9.97 - 9.98 9.96
29
Fork shift inner
diameter
10 -10.02 10.03

Service Limit - Frame
Sr.No Parameter Standard Specification (mm) Service Limit (mm)
1
Brake Panel cam hole diameter
Front 12 - 12.03 12.15
Rear 12 - 12.03 12.15
2
Brake cam diameter
Front 11.95 - 11.98 11.83
Rear 11.95 - 11.98 11.88
3
Brake Shoe lining thickness
Front 3.9 - 4.5 2
Rear 3.9 - 4.5 2
4
Brake drum inside diameter
Front 130 - 130.16 130.75
Rear 110 - 110.14 110.75
5
Axle run out
0.1 0.2
6
Axial wheel run out
0.8 or Less 2 or Less
7
Radial wheel run out
0.8 or Less 2 or Less
8
Drive chain slackness
20 -30 Upto 40
9
Drive chain length
254 - 254.6 260
10
Rear sprocket warp
0.15 or Less 0.5 or Less
11
Front Fork spring free length
394 398
12
Tyre tread depth
Front 5 Upto TWI
Rear 5 Upto TWI
