STANDARD FEATURES
OPTIONS & ACCESSORIES
CERTIFICATIONS
SPECIFICATIONS
Extra heavy duty radiant char broilers are designed for high volume
broiling without charcoal or ceramic stones.
The CH Series features unitized construction. The entire chassis
frame including the base is hand-crafted of 1/2" (13mm) to 1/4"
(6mm) thick HRS and welded to form a single unit without
fasteners. The sides and rear of the outer shell is made of heavy
gauge CRS and is welded to the chassis frame to complete the
unitized construction and finished with durable Baker Tone paint.
CH Series features 24" long (610mm) aluminized steel burners
rated at 18,000 BTUH each (5.27kw) located every 5 1/4"
(133mm). Each burner features a separate, independent operator-
controlled valve. 14-gauge stainless steel heat deflector radiants
are located directly above each burner for an even transfer of
radiant heat to the broiling surface. Cast iron burners and cast iron
radiants are optional.
Standard top grates are heavy-duty cast iron. A variety of different
style grates are available and may be mixed and matched. Each
grate may be adjusted independently in any of three tilting
positions. Broiler grates are 23 3/4" deep (603mm) for maximum
production.
Exterior measures 28 1/4" deep (718mm) plus 8" lintel plate/shelf
(203mm) or 9 1/8" (232mm) work deck with plate shelf. Working
height measures 33 1/2" (851mm) with legs, or 20" (508mm)
without legs, plus 6 1/2" (165mm) back splash. Standard widths
range from 33 1/2" (851mm) up to 75 3/4" (1924mm).
Standard features include 2" deep stainless steel slide-out water
pans and grease drawer, rear gas connections and pressure
regulator. CH Series may be built in for display cooking and
exhibition kitchens. Legs sold separately.
One year limited parts and labor warranty.
q
q
q
q
q
q
q
q
q
q
Heavy plate steel, welded unitized construction
High performance 18,000 BTUH per burner every 5 1/4"
Individual, operator-controlled, adjustable burner valves
14-gauge stainless steel radiant heat deflectors above each
burner
8" deep lintel plate/shelf (203mm)
2" deep (51mm) stainless steel water pans
Stainless steel grease drawer
Back splash
Pressure regulator
One year limited parts & labor warranty
qNatural or LP gas
q
q
q
q
q
q
q
q
q
q
q
q
q
q
q
Cast iron burners
Cast iron radiant heat deflectors
Stainless steel exterior side panels
Leg set
Leg & caster set
Stainless steel or Richlite work deck with plate shelf
Custom cut-outs in work deck for sauce pans
4" deep water pans (102mm)
Stainless steel splash guard
Variety of top grates including meat grates, fish grates,
floating rod grates and more
Stainless steel heat shields
Side gas connections
Removable griddle plates
Log holders for smoke assisted char broiling
Gas connector hoses
BAKERS
PRIDE qModel CH-6
qModel CH-10
qModel CH-8
qModel CH-12
qModel CH-14
HIGH PERFORMANCE
HEAVY DUTY
FLOOR MODEL
RADIANT
CHAR BROILERS
BAKERS
PRIDE
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
914/576-0200 • 1-800-431-2745 • fax 914/576-0605
www.bakerspride.com
GAS CHAR BROILERS G
Model CH-6
with optional legs & casters,
splash guard, plate shelf & work deck
