Balboa Water Group EL Series User manual

EL/GL Series - Mach 3
MLM990S Quick Reference Guide
Initial Start-up
When your spa is first actuated, it will go into Priming
mode. Please see the M-7 Installation Instruction Manual
for complete instructions on Power-up and Pump Priming.
The Priming mode will last for up to 4 minutes and
then the spa will begin to heat and maintain the water
temperature in Standard mode. Follow the on screen
instructions. Make your choice, then press Select ( ). If
left alone, the system will resume after 4 minutes. The
Home display screen will then appear after completion.
To Navigate : Use the buttons on the front panel to move
within the menu: Up , Left , Right , or Down .
chooses your menu selection.
J1
J2
BL
LT
HT
FC
OZ
Select
Jets 2Jets 1
LightBlower
102ºF
9Mode
s
0
Music
AM
Setting the Time
From the Display Screen, select “Set”, then .
Arrow or to select “Time of Day”, then .
Arrow or to change hour.
Arrow to select minutes. Press or to change.
Repeat to change AM/PM. To Save and Exit: .
For quick spa temperature set-up. From Home screen,
Arrow Up ; or to set temperature. to Exit.
Front Panel Buttons and Lights
For instant activation, press Jets 1, Jets 2, Blower, or Light.
The LEDs will light when activated.
Fast Keys Give Quick Access to System Set-up
Fast Keys quickly shows status and allows control of a
device. (See User’s Manual: “Fast Keys--Programming”.)
From the Home display screen, select
“Fast Keys”, then . The circle
represents the four directional keys.
Pressing the designated arrow key
will turn the function to Hi/Med/Low
or On/Off. Press to exit.
Jets 1 L
Home
98°F

pn 40711-80_B October 5, 2007
900854
Set Menu Presets Your Equipment
Within the “Set” menu (located on the “Home” screen),
you can program your system, view diagnostic and software
information. Move within each menu with the arrow keys.
Follow the on screen instructions. to activate any menu
or device. to Exit. Options depend on devices installed.
To Program
Filter Cycles: “Home” > Set > > Filter Cycle > .
Fast Keys: “Home” > Set > > Fast Keys > .
Mode, Change Heat: “Home” > Set > > Mode > .
User Settings: “Home” > Set > > User Settings > .
Panel Settings: “Home” > Set > > Panel Settings > .
Diagnostics: “Home” > Set > > Diagnostics > .
To View
Invert Display: “Home” > Set > > Invert > .
Version Information:
“Home” > Set > > Diagnostics > > Versions > .
Spa Button Menus Turn Accessories On or Off
“Home” > Spa > > Spa Functions menu.
The “Spa Functions” menu allows you to access: Jet Control,
Lighting, Blower, Mister, Options, Chemistry, Standby Mode,
and Stir.
Select and highlight a device, press , then move within
the Spa Functions/device menu with the arrow keys.
Press to turn the accessory On/Off, or High/Med/Low.
Left Arrow ( ) to exit. (Note: Devices must be set up for the
Spa buttons to function. See User Guide for set up.)
About Heat Mode
“Home” > Set > > Mode > .
You can choose from Standard, Economy, or Sleep modes
when using the heater. Select the mode, then .
Standard mode maintains the desired temperature.
Economy mode heats the spa to set temperature only
during filter cycles.
Sleep mode heats the spa to within 20°F (11°C) of the set
temperature only during filter cycles.
Arrow Left to return to “Spa Settings”.
nnn%YXcYfXnXk\i^iflg%Zfd
Refer to User Guide for additional
information
