Balboa bwa Kit User manual

Quick Install Guide For bwa™ Kit - BP500/600
– Use a phillips screwdriver to remove
the 2 top screws that hold the system
cover in place.
– Insert the Y-cable (25657) in Panel Jack C14.
TOOL YOU WILL
NEED
STEP
1
STEP
2
12
ZOOM IN
STEP
3
– Insert the Balboa Wi-Fi Cable into the first
end of the Y-Cable (25657) Panel Jack.
– Insert your Control Panel into the second
end of the Y-Cable Panel Jack.
WARNING!
Please contact an electrician or your local electrical company to
connect the Wi-Fi connector for you. DO NOT OPEN THE SPA
SYSTEM AND ATTEMP TO CONNECT THE WI-FI CONNECTOR
YOURSELF. The high electrical voltage will harm or kill you.

STEP
4
STEP
5
– Remove 1 screw to open the cable holder.
– Insert the plastic holder and screw back
in place. Make sure the 2 cable wires are
secure in place.
– Place the Wi-Fi cable and Control Panel
cable inside the wire holder.
– Close up shot of how the 2 wires
should look.
– Close the Control Panel System cover and
secure the 2 top screws. YOU’RE DONE!
This is how your system should look like when finished.
1219BP500/600
©2019 Balboa Water Group. Single Source Solution. All rights reserved.
3030 Airway Avenue | Costa Mesa, CA 92626 | p714.384.0384 | www.balboawater.com
Specifications subject to change without notice.
Note: Place the
Wi-Fi module
away from any
metal tub
supports.
