Baldor TS25 User manual

REVISED/EFFECTIVE MAY 1, 2003 C:\ISO9001\FORMS\SPSG–002–48msw
FORM#: S–PSG–002–48
PRESENTS YOUR
BALDOR GENERATORS
3815 OREGON STREET OSHKOSH WI 54902
PHONE: [phone] FAX: [phone]

TOWABLES
OPERATOR’S MANUAL
Table of Contents
ACCESSORIES AND EQUIPMENT WITH THIS GENERATOR SET INCLUDES:
ITEM PAGE
SAFETY RECOMMENDATIONS: These recommendations must be read and followed 1
to safely operate your generator set.
VOLTAGE RATINGS: This informational page describes features and specifications for 7
all Towable Units.
ELECTRICAL CONNECTION INFORMATION: This information explains how to interface 9
your generator with the AC loads and other standard and optional accessories.
CONTROL PANEL: This includes a drawing of the control panel and a description of 11
the components associated with it.
PRE–START PROCEDURE: This described a pre–start check that should be performed 14
prior to initial start–up.
OPERATION GUIDE: Information on how to start, stop, and operate the generator set 15
is included here. Included also is information in regards to the operation of the
genset/ engine control device and the different fault shutdown circuits designed to
protect the generator set from potential engine operational problems.
TROUBLESHOOTING GUIDE: Included in this guide are basic instructions to help 18
troubleshoot most problems with your generator set. For more troubleshooting
help please contact the service department at Baldor Generators
HIGHWAY TRAILER: This includes information in regards to safe operation, proper 23
utilization, and recommended guidelines for using and operating the trailer.
BALDOR GENERATORS WARRANTIES: this details the warranty provided by Baldor 27
Generators for coverage for electrical generator end of the generator set.
OTHER MANUALS AND ACCESSORIES THAT SHOULD ACCOMPANY YOUR TOWABLE
GENERATOR:
ENGINE OPERATOR’S MANUAL: This operator’s manual includes information in regards to
the operation and maintenance of the engine utilized in this generator set.
AC GENERATOR, ACCESSORIES, AND LOAD CONNECTION DIAGRAMS / ENGINE
CONTROLS, ACCESSORIES, AND REMOTE CONNECTION DIAGRAMS: These diagrams contain in-
formation in regards to the internal wiring of the generator set, specifically the AC and
Engine Control circuits. These diagrams will also include information for any optional AC
or DC powered accessories that are included.
PARTS LIST: This is a listing of all parts used by Baldor Generators to build this specific generator set.

SAFETY WARNINGS
Revised: 8/13/02 Page 1 of 4 FORM#: S–PSG–001–3
Effective: 2/27/98 C:\ISO9001\FORMS\SPSG0013.msw.bbk
1
zPlace protective covers and guards over the rotating parts, if rotating parts such as the drive shaft, pulley,
belt, etc. are left exposed, they are potentially hazardous.
zWhen cleaning, repairing or inspecting, make sure all moving parts have stopped.
zPrior to working on the generator set, disconnect the spark plug and battery to prevent accidental starting.
zUse only original equipment or authorized replacement parts. Use of correct parts will assure the operator
of the safety integrity that was designed into the unit.
zUnauthorized modifications to the generator set may impair the function and/or safety of the unit.
zDo not operate the generator set without a muffler. Inspect periodically and replace if necessary.
zDo not touch the hot exhaust components or the high voltage spark plug and coil terminals. While Spark
Plug Voltages are not normally lethal, an involuntary jerk of the hand caused by a hot surface or by
an electrical shock can result in injury.
zRepair of electrical generating equipment requires specialized skills. Repair personnel must have a
thorough understanding of generator and small engine repair procedures.
zNever inhale exhaust gases. They contain carbon monoxide; a colorless, odorless and extremely
dangerous gas that can cause unconsciousness or death. Symptoms of carbon monoxide poisoning
can include: dizziness, nausea, headaches, sleepiness, vomiting or incoherency. If you or anyone else
experiences any of these symptoms, get out into the fresh air immediately. Shut the unit down and
do not operate it until it has been inspected and, if necessary, repaired.
zNever Operate the generator set indoors or in a poorly ventilated area such as a tunnel or cave.
zCALIFORNIA PROPOSITION 65 WARNING: engine exhaust from this product contains chemicals known
to the state of California to cause cancer, birth defects or other reproductive harm.
zKnow how to stop the engine quickly and understand the operation of all controls.

SAFETY WARNINGS
Revised: 8/13/02 Page 2 of 4 FORM#: S–PSG–001–3
Effective: 2/27/98 C:\ISO9001\FORMS\SPSG0013.msw.bbk
2
zNever permit anyone to operate the generator set without proper instructions.
zNever allow children to operate the generator set.
zChildren and pets must be kept away from the area of operation due to the possibility of burns from hot
engine components or injury from any equipment the generator set is powering.
zAlways wear eye protection and Hearing protection when working near the generator set.
zOperate the generator set only with the guards, shields and other safety items in place and working
properly.
zDo not put hands, feet, tools or other objects near rotating parts.
zUse reasonable care when moving or lifting the unit. The generator set may move around inside the wrap
frame creating ”Pinch Points”.
zDo not run the generator set while it is being moved.
zDo not support the generator set from the top of the wrap frame.
zDo not operate the generator set while under the influence of alcohol, drugs or medication.
zWhen transporting or using a generator set with the wheel option, secure the unit to prevent it from moving
around.
zDo not tamper with or change the engine speed as it has been preset at the factory for proper operation.
zKeep hands and face away from the carburetor when the air cleaner is being moved. A sudden backfire
can cause serious burns.
zBe careful of hot parts. The muffler and other generator parts become very hot while the engine is running.
zDo not ”jump start”the generator set.
zSulfuric acid can cause severe injury and can give off gases, which are corrosive and potentially explosive.
Avoid contact with skin, eyes, and clothing. In case of contact, flush area immediately with water.
zWhen transporting a generator set, secure it to prevent it from moving or shifting.
zKnow how to stop the engine quickly and understand the operation of all controls.
zDo not operate electrical equipment while standing in water, on wet ground or with wet hands or shoes.
zUse extreme caution when working on electrical components. Potentially dangerous voltage is present
when the engine is running.

SAFETY WARNINGS
Revised: 8/13/02 Page 3 of 4 FORM#: S–PSG–001–3
Effective: 2/27/98 C:\ISO9001\FORMS\SPSG0013.msw.bbk
3
zAlways treat the electrical circuits as if they were energized.
zDisconnect all leads plugged into the unit Prior to working on it.
zHave the electrical circuits serviced only by qualified technicians.
zInspect wiring frequently and replace frayed, broken or poor leads.
zDo not connect this unit to any building’s electrical system unless you utilize an approved transfer switch or
the main service entrance switch has been disconnected and locked open.
zCircuit overload protection must be provided in accordance with national electrical codes and local
regulations.
zCheck GFCI Receptacles monthly by using the ”Test”and ”Reset”buttons designed into them.
zDepending on your application it may be mandatory to ground or not ground this unit to earth ground.
Comply with local electrical codes.
```` FOR GASOLINE OR DIESEL POWERED GENERATOR SETS ````
zOperate the generator set on a level surface. If the generator set is tilted, fuel spillage may result.
zHandle fuel with care. It is highly flammable. Use only clean, properly marked and approved safety
containers for refueling and storing fuel.
zStop the engine and allow it to cool before refueling.
zDo not overfill the fuel tank. Only fill the tank to within 1/2”of the top of the tank to allow space for fuel
expansion.
zIf fuel is spilled, wipe it up carefully and wait until the fuel has dried before starting the engine.
zMake sure the fuel cap is properly closed after refueling.
zNever operate the generator set while smoking.
zNever operate the generator set near an open flame.
zNever store the generator set with fuel in the tank indoors or in an enclosed, poorly ventilated enclosure
where fuel fumes may reach an open flame, electrical spark or pilot light as on a furnace, water heater,
clothes dryer, etc.
zWhen transporting over long distances or rough roads, drain the fuel tank to prevent leakage and spillage.

SAFETY WARNINGS
Revised: 8/13/02 Page 4 of 4 FORM#: S–PSG–001–3
Effective: 2/27/98 C:\ISO9001\FORMS\SPSG0013.msw.bbk
4
```` FOR GASOLINE OR DIESEL POWERED GENERATOR SETS ````
zCheck all fuel supply piping and their connections on a monthly basis for fuel leaks.
zUse only approved piping and componentry in your fuel supply system.
zA professional, experienced technician should only install the fuel supply system.
zDo not run the fuel line up against any sharp objects.
zComply with NFPA regulations and your local codes in regard to shut–off valves, regulators, etc. and any
other recommendations or requirements they may have.
zKeep the generator set at least three feet away from buildings or other structures.
zKeep the generator set away from flammable and other hazardous materials (trash, rags, lubricants,
explosives, paints, etc.)
zKeep the generator set free of grass, leaves and excessive grease and oils.
zAllow the generator set to cool before transporting it or storing it indoors.
zHave fire extinguisher accessible and nearby while operating the generator set.
zThis generator set must not be used on or near any forest covered brush covered or grass covered land
unless the engine’s exhaust system is equipped with a spark arrester and it must be maintained
in effective working order by the operator.
zOperation inside an enclosed compartment or building is a potential fire hazard and should not be done
unless approval is obtained from Baldor Generators. Engine/Generator overheating can cause severe
damage due to restricted, obstructed or improper air–flow that is necessary for the proper cooling of the
unit.
zHot exhaust gases being discharged by the engine must never be directed toward anything that could
catch fire or explode.

Effective: February 26, 1998
Revised 2/01/02
Form#: S–CSD–003–7 C:\ISO9001\FORMS\SCSD0037.MSW
5
FORWARD
This manual contains the information you need to safely and efficiently operate your generator
set. During the preparation of this manual every effort was made to ensure the accuracy of its
contents.
Never operate this generator set without first carefully reading this manual and observing all the
safety warnings it presents. While safety is built into every Baldor Pow’R Gard generator set,
careless or improper operation could possibly result in mechanical failure, property damage, se-
vere injury or death.
Note that this manual covers only very basic information in regards to the engine. A separate
owner’s manual for the engine is supplied with this unit for your use. Please refer to this manual
for information relative to engine operation, maintenance, recommendations and additional
safety warnings.
As soon as you receive your generator set, inspect it closely for shipping damage. If you find
some damage, notify the transportation company immediately and file a freight damage claim.
Think of this manual as a tool to help you get the most out of your generator set. We strongly
suggest that you keep this manual with your generator set and refer to it when questions arise
in regards to its operation.
Baldor Generators, formerly Pow’R Gard Generator Corporation has been in business since
1965. The generator sets we manufacture have earned the reputation of being of high quality
and a dependable product. We take pride in this fact and continue to keep our quality standards
high on our list of priorities. We are also constantly researching new technological ideas to de-
termine if they could be used to make our generator sets even better.
Thank you for purchasing your Baldor Pow’R Gard Generator Set.

Effective: February 26, 1998
Revised 2/01/02
Form#: S–CSD–003–7 C:\ISO9001\FORMS\SCSD0037.MSW
6

7
Features & Specifications
Model TS25 TS45 TS80 TS130 TS175
Standby output–1500C Rise
(KVA/KW):
3 PH @ 480 Volt 25/20 48/38 81/65 134/107 175/140
3 PH @ 208/240 Volt 25/20 46/37 72/58 131/105 169/135
1 PH @ 240 Volt 18/18 27/27 45/45 70/70 80/80
Continuous Output–
1250C Rise (KVA/KW):
3 PH @ 480 Volt 23/18 44/35 75/60 121/97 169/135
3 PH @ 208/240 Volt 23/18 44/35 69/55 119/95 156/125
G1 PH @ 240 Volt 18/18 25/25 43/43 66/66 75/75 G
E
NVoltage –3 PH Adjustable 208/220/240/
416/440/460/480 208/220/240/ 416/440/460/480 208/220/240/ 416/440/460/480 208/220/240/ 416/440/460/480 208/220/240/ 416/440/460/480
E
RVoltage –1 PH Adjustable 120/127/139/
240/254/277 120/127/139/ 240/254/277 120/127/139/ 240/254/277 120/127/139/ 240/254/277 120/127/139/ 240/254/277
AAmperage (Continuous):
T3 PH 480 Volt 27.1 52.6 90.2 145.8 203.0
O3 PH 208 Volt 62.5 121.4 190.8 329.6 433.7
R3 PH 240 Volt 54.1 105.3 165.4 285.7 375.9
1 PH 240 Volt/120 Volt 75.0/150.0 104.2/208.3 179.2/358.3 275/550 312.5/625.0
Receptacles:
120 Volt, 15 Amp GFCI 4 6 6 6 6
120/240 Volt, 50 Amp,
CS6369 Twistlock 2 3 3 3 3
Voltage Regulation 1/2% 1/2% 1/2% 1/2% 1/2% 1/2%
Power Factor –3 Phase 0.8 0.8 0.8 .08 .08
Frequency 50 or 60 Hertz 50 or 60 Hertz 50 or 60 Hertz 50 or 60 Hertz 50 or 60 Hertz
Total Harmonic Distortion <5% <5% <5% <5% <5%
Insulation Class F Class F Class F Class F Class F
Engine Make/Model Isuzu
4LE Isuzu 4BG1 John Deere TO4045T John Deere TO6068 John Deere RG6081T
Design Water Cooled
4 Cycle Diesel Water Cooled 4 Cycle Diesel Water Cooled 4 Cycle Diesel Water Cooled 4 Cycle Diesel Water Cooled 4 Cycle Diesel
Starting System 12 VDC 12 VDC 12 VDC 12 VDC 12 VDC
Displacement (cid) 133.0 264.2 276.0 414.0 498.0
Cylinders 4 4 4 6 6
HP @ Rated Speed 34.5 64.0 100.0 166.0 211.0
RPM 1800 1800 1800 1800 1800
ESafety Shutdowns:
NHigh Temperature Std. Std. Std. Std. Std.
GLow Oil Std. Std. Std. Std. Std.
IOverspeed Std. Std. Std. Std. Std.
NOvercrank Std. Std. Std. Std. Std.
EFuel Capacity 50 80 80 160 160
Fuel Consumption (GPH):
1/2 Load 1.3 2.0 2.7 4.2 5.6
Full Load 2.0 3.4 4.9 8.1 10.5
Approx. Run Time (Hrs.):
1/2 Load 38 40 30 38 29
Full Load 25 24 16 20 15
Battery Recommendation Min. Cold
Cranking Amps
(Battery not included)
750 900 900 (2) 750 (2) 750
Dimensions (L x W x H):
With Trailer 123”x 62”x 70”139”x 60”x 81”139”x 60”x 81”163” x 66” x 94” 163” x 66” x 94”
Without Trailer 74”x 38”x 52”84”x 38”x 61”84”x 38”x 61”108” x 42” x 74” 108” x 42” x 74”
Weight (Lbs.):
Without Fuel 2265 3540 3848 5600 6200
Without Fuel & Trailer 1790 2829 3053 4610 5205

8

AVAILABLE VOLTAGE:
SWITCH POSITION STUD
277/480 1–2–3 = 480 VAC, 3 Phase
1–N, 2–N, 3–N = 277 VAC, 1 Phase
120/240 1–2–3 = 240 VAC, 3 Phase
2–3 = 240 VAC, 1 Phase
2–N, 3–N = 120 VAC, 1 Phase
1–N = 180 –200 VAC, Wild Leg
120/208 1–2–3 = 208 VAC, 3 Phase
2–3 = 208 VAC, 1 Phase
1–N, 2–N, 3–N = 120 VAC, 1 Phase
9
SWITCHABLE
ELECTRICAL CONNECTION INFORMATION
WARNING: High voltage may be present at receptacles and load studs while engine is
operating – DANGER of electrical shock is present. Use extreme care.
LOAD RECEPTACLES
1. Voltage is present in 120/240 volt switch position only.
2. Load wires may be brought into receptacle compartment through access door at control station.
HARD WIRE LOAD TERMINAL BLOCK
1. Voltage available at load block is outlined in chart below.
2. Cables must be brought into load block compartment through access hole in base of trailer.
3. Opening load block door will cause load disconnect to trip.
4. Do not start engine with load turned “on”. Allow engine to come up to speed and warm up (1).
5. If left unattended, lock all doors to prevent tampering or injury.
NOTE: To prevent damage to loads and generator, select voltage switch position prior to starting
engine.
NOTE: Upon switching voltage selector switch, adjust voltage and adjust rheostat (located on engine
control panel) for proper voltage.
Revised: October 3, 2002 D:\ISO9001\FORMS\MSW’98bbk
Effective: April 23, 1999
Form#: S–PSG–001–15

10
CONNECTION INFORMATION
Your new Baldor Generator has all interconnecting wiring terminated at a junction box. All wiring will be
clearly labeled as being load; remote start contacts and AC input terminals and are to be connected as
described below.
Load –These connections are rated and sized according to the KW of the generator. Proper lead
wire from these points to the automatic transfer switch (or load switching device) is mandatory.
See enclosed transfer switch information for corresponding generator input terminals.
Remote Start Contacts –This two–wire connection, once connected to an appropriate switch,
will start the generator and perform as described in the remote start/stop literature. These
contacts are connected to the “Engine Start Contacts”of the automatic transfer switch.
A Two Pole normally open, closed to operate switch may also be used to start the generator.
AC Input –These connections are for units with float type battery chargers or engine block
heater combinations. A Constant supply of 120 volts AC (or as specified) is needed at these
terminals to power these devices.
NOTE: Power is not required when the unit is in operation. Internal battery charging and radiant heat
during operation eliminate the need for these devices.
NOTE: It is recommended that units utilizing an automatic transfer switch with adjustable time delays
have the initial adjustments made prior to start–up.
Factory recommendations are; allow a 2 second delay on start–up, 15–second delay on emergency to
normal.
Revised: March 20,2001 D:\ISO9001\FORMS\MSW’98bbk
Effective: April 23, 1999
Form#: S–PSG–001–19

11
CONTROL PANEL OPERATION
AND FUNCTION
A. MASTER CONTROL SWITCH –This switch controls the starting and stopping of the engine via
the engine control logic circuitry.
With this switch in the “Manual”mode, the engine will start and run immediately after a
10 –20 second time delay.
CAUTION: Please note that once the engine has been told to start, the gen set
should be treated as though it is operational, even though the start
delay has not yet allowed the engine to crank.
With this switch in the “Automatic”mode, the engine can be started and stopped from a remote
contact. (Standard switch, transfer switch, etc.) There is a time delay, to cool down, of 60–90
seconds when the unit is shut down from the remote contacts while the Master Control Switch is in
the “Automatic Mode.
With this switch in the “Off”position, the engine will immediately stop. The position must also be
utilized to clear fault shut–down conditions.
B. PANEL LIGHTS –By turning on the panel light switch, the panel lights will be energized and will
illuminate the control panel. The fuse next to the switch is to protect this circuit from damage due to
excessive current.
C. FIELD AND CONTROLLER FUSES –These fuses protect the internal workings of the generator
set.
D. GAUGES –These gauges monitor some of the more critical operating parameters of the engine as
well as the run time of the generator set.
The Voltmeter displays the charging rate that is currently being produced by the engine’s alternator to
facilitate the charging of the battery. This gauge should normally be above 12.5V whenever the unit is
running. If you ever notice the gauge is reading below 12V while the engine is running please contact
the service department at Baldor Generators.
The Temperature Gauge monitors and displays the operating temperature of the engines coolant. The
point at which a fault shut–down will occur is approximately 230°F.
The Oil Pressure Gauge displays and monitors the current operating pressure of the engine’s oil
system. The trip point at which a fault shutdown will occur is approximately 15 PSI or below.
Fuel level is checked by the owner or is usually a separately supplied fuel tank.
The Hour Meter accumulates and displays the total running time of the generator set.

12
E. VOLTAGE ADJUST –The rheostat allows the user to “fine tune”the generator set’s voltage
output. It is normally used to adjust output voltage after switching the output of the generator set to a
different voltage.
F. METERS –These meters monitor and display the current operating parameters of the generator set.
The Voltmeter monitors and displays the current operating AC output of the generator set.
The Hertz Meter monitors and displays the current operating frequency of the generator set.
The ammeter monitors and displays the amount of current that is being delivered by the generator set.
This meter works in conjunction with the Voltmeter Switch (Item G) in determining which output leg
to monitor.
G. AMMETER SWITCH –The switch allows the user to switch between L1, L2 and L3 to monitor the
current in each output leg of the generator.
H. PANEL LIGHT –By turning on the panel light switch, the panel lights (Not pictured on diagram)
will be energized and will illuminate the control panel.
I –SYSTEM FAULT INDICATORS –These lights will come on when a fault condition or a warning
condition develops.
The “Low Oil Pressure”light will come on when the engine’s oil pressure drops below 15 PSI. This
condition will trigger a fault shut–down and the unit will stop.
The “Over–crank”light will come on when the engine has failed to start after four attempted crank
cycles. Each crank cycle consists of a 12 second time period followed by a 12 second rest time
period.
The “Over–speed”light will come on when the engine’s operating speed rises above it’s normal
operating parameters. This condition will trigger a fault shut–down and the engine will stop.
High Temperature light will come on when the engine’s operating temperature exceeds the safety
set–point.

13

14
OPERATION –PRE–START PROCEDURE
1. Fill system fuel tank with clean, fresh diesel fuel.
CAUTION: Wipe up any and all fuel spillage.
2. Fill engine crankcase to full mark with clean, fresh lubricating oil per attached engine operating guide.
3. Radiator coolant should be checked at the beginning of each day and filled in compliance with the engine
manufacturer’s guidelines.
4. Secure the generator for operation.
Skid mounted –the power generating system should be mounted to a smooth,
hard surface suitable for supporting the system under all stress conditions.
Trailer mounted –block wheels to prevent accidental movement.
Adequate clearance must be provided for access doors to fully open.
NOTE: The generating system exhaust also exits radiator end. When
positioning a generator system ensure position does not cause a
concentration of toxic emissions.

15
OPERATION –STARTING
1. Conduct ‘Pre–start Procedures.
2. Switch the generator set to the applicable voltage setting.
3. Connect the load(s) to the circuit breaker.
WARNING: High voltage is present when the generator set is running.
4. Move the ‘Master Control Switch”to the appropriate position.
5. Adjust the voltage if necessary by turning the voltage adjustment knob located on the control panel.

16
OPERATION
The prime mover utilized in this power generating system is controlled via an engine control module.
Starting is accomplished by commanding the control to ”start”the engine. This command can be
given by a number of controls.
? The operator control mounted on the front panel.
? The remote controls via the transfer switch or remote start terminal closure.
Initially, the system may be started and operated by placing the operator control in the ”manual/run”
position. To cease operation, return the switch to the ”off”position.
NOTE: Clear unit of all loose objects and perform all ”pre–start”procedures before operating
generator system.
ENGINE CONTROL MODULE:
The engine control module (ECM) is a microprocessor–based module that monitors the control and
safety inputs and provides all the required START and STOP functions automatically.
The following front panel controls and instruments are wired into the microprocessor through the
ECM terminal blocks:
1. Run–Off–Auto Switch
a. * ”Run”–run position causes the generator set to start and run immediately.
b. * ”Auto”–auto position allows unit to be controlled via any remote single–pole ”dry”contact
(transfer switch, etc.). Contact closure causes the unit to start and run, while contact opening causes
unit to shut down after a preset cool down period.
c. ”Off”–unit operation is terminated.
* –units equipped with Isuzu engines may have a time delay glow plug cycle before starting.
2. Lamp Test
Push button energizes all alarm lights simultaneously. This feature is disabled with the
run–stop–auto switch in the ”stop”position, and has no other effect on unit operation.
SAFETY INPUTS
1. Low Oil Pressure Shutdown –(LOP)
Monitoring of oil pressure begins for a preset time after unit starts and remains in effect until
unit is shut down (except as noted in ”loss of frequency input”below). The LOP signal is derived
from an oil pressure switch gauge mounted on the control panel
2. High Temperature Shutdown –(HT)
The engine temperature monitoring begins immediately with the start signal. However, if engine
temperature is excessive prior to start (i.e., heat soak after shutdown), the unit is permitted to
start.
The high temperature condition is permitted to exist for up to 60 seconds after the unit is running
before shutdown when alarm occurs. If the excessive temperature condition is corrected within
that time period, the HT circuit reverts to normal monitoring. The HT signal is derived from a
monitoring device located on the prime mover.

17
3. Over–speed Adjustment –(OS) –Over Frequency
Over–speed protection is provided by a frequency sensing network within the controller. The trip
point of the frequency network is adjustable via a rheostat located on the top of the controller at
the right hand side. Clockwise (CW) rotation increases the trip frequency and, thereby, raises the
shutdown speed.
CRANKING CONTROL
1. Over–crank Protection
This feature provides a preset second crank cycle. Failure of the engine to start by the end of the
crank period results in an ”Over–crank”shutdown and alarm indication.
2. Cranking Disconnect Adjustment (CDS Adjustment)
The cranking disconnect signal is obtained by a frequency network within the controller. The trip
point of the frequency network is not adjustable.
LOSS OF FREQUENCY
Internal protection against loss of frequency input to the cranking disconnect circuit is programmed in
after the unit has started normally. In the event the frequency goes to zero (engine runs out of fuel,
frequency signal source fails, etc.) the LOP shutdown circuit is bypassed and a 12–second wait
period is initiated. If frequency returns within this time period, LOP monitoring resumes and operation
continues normally. If frequency has not returned at the end of this time period, the engine oil
pressure status is observed to determine whether the engine is actually running or stopped. If the
engine has stopped (i.e., air in fuel, etc.), the cranking cycle will begin in an effort to restart the
engine. If the engine has not stopped (loss of input signal, etc.), the unit is shutdown with an
”Over–crank”indication and alarm.
WARNING: Over–crank indication can mean a loss of crank–disconnect signal during the
previous run period. Attempting to restart the engine with no crank–disconnect signal can
destroy the starter motor, which can cause serious personal injury.
This is of particular note since the tendency is to pursue only cranking and start related faults. The
cranking disconnect signal source is a key component in this system and must be checked out
thoroughly whenever an ”Over–crank”shutdown occurs.
NOTE: The controller does not provide protection against loss of signal during start–up. A
shutdown with alarm, due to any of the above conditions, will prevent any subsequent
operation of the generator set. The run–stop–auto selector switch on the control panel
must be momentarily placed in the stop position to reset these functions.
CAUTION: If a dead battery is suspected, remove controller fuse, charge battery (or replace), and
then attempting starting. Damage to engine control may result from jump starting.
