MATERIALS NEEDED
In addition to the furnished parts, an appropriate length of 16
gauge electrical wire and a 10A 12V in-line fuse assembly is
needed. (Use 10A fuse for 24V.)
55EK & 85EK RETROFIT ASSEMBLY
(DAHL diesel fuel filter/water separators with an -H sux
come already assembled.)
1. If installing the kit in an used unit, drain and remove the DAHL
body assembly.
2. Disassemble the body assembly.
a. Remove the filter element.
b. Remove the socket head bolts around the bowl ring. Lift o
the bowl ring, then the clear bowl.
3. Install the heater element into the body assembly:
For 55-EK on Models 100 &150 Series
a. Place the heater band into the body with the wire lead side
down. The heater band fits within the wall of the unit body.
b. Run the lead wires through one of the 3/8 inch flow holes at
the bottom of the body and then through the depressurizer
set.
c. Gently push the heater band into the body.
For 85-EK on Models 200 &300 Series
a. Place the heater element wafer into the body with the wire
lead side up. The center hole of the heater element fits
around the centerpipe in the unit body.
b. Bend the wire down at the heater element wafer notch,
then run it through one of the 3/8 inch flow holes at the
bottom of the body and then through the depressurizer
set.
c. Align the holes in the heater element wafer with the ejector
springs and gently push the element to the bottom of the
body.
LEAD WIRE CONNECTIONS
1. Connect the lead wire to the clear bowl.
a. Make sure the bowl ring is around the clear bowl before
installing the bolts. (It will not fit over the bolts after they
are installed.)
b. Insert the #8-32 bolts through the terminals of the heater
wire leads. Secure the terminal with one #8 nut. (Note: Be
sure the terminal’s flush side is facing the bowl.)
c. Secure the #8-32 bolts to the clear bowl. Be sure the
O-Ring is between the outside of the bowl and the flat
washer.
2. Reassemble the new clear bowl to the filter body and reinstall
the body assembly. (Note: Replace and grease the bowl
gasket.)
ELECTRICAL HOOKUP
1. Install the toggle switch. Drill a 31/64 inch hole in the desired
location.
2. Connect the wire to a 12 volt power source capable of
delivering 10A. (Use 16 gauge wire.) (Note: 24V systems use
10A fuses.)
a. Splice the 10A fuse assembly to the 16 gauge wire between
the power supply and the toggle switch. Position the fuse
assembly for accessible servicing.
b. Connect the other end of the 16 gauge wire to the power
terminal of the toggle switch with a female quick disconnect
terminal. (One for each toggle switch is included.)
3. Connect the ground wire. Use a second length of 16 gauge
wire to ground the terminal of the toggle switch. Connect the
other end to a suitable ground such as the engine block or
steel frame.
4. Connect the third length of the 16 gauge wire to the “ACC”
terminal of the toggle switch. Insert the other end into one
of the 90° insulated connectors. Plug the 90° insulated
connector into one of the heater terminal #8-32 bolts.
5. Plug the remaining 90° insulated connector to the second
heater terminal #8-32 bolt. Find suitable ground for the other
end of the wire.
The toggle switch should light up when the heater is on.
DAHL 55-EK and 85-EK In-Filter Heater Kit Installation
For Retrofitting Models 100, 150, 200 & 300 Series with Heater
Included with 100-H, 150-H & 200-H

55EK KIT CONTENTS
Item Part Number Qty. Description
1 1 55-EK Electric Heater for Kit
2 2 90° Insulated Connectors
3 1 Illuminated Toggle Switch
4 3 Female Quick Disconnect
Terminals
5 2 #8-32 Stainless Steel Bolts
6 4 #8-32 Stainless Steel Hex Nuts
7 2 #8 Stainless Steel Flat Washers
8 2 #8 Stainless Steel Lock Washers
9 2 O-Rings
10 2 Ring-Type Terminals
11 100-21H 1 55-EK Clear Bowl with Heater
Probes
12 Incl. In 100-GK 1 55-EK Bowl Gasket
13 Form 4011 1 Installation Instructions
85EK KIT CONTENTS
Item Part Number Qty. Description
1 1 85-EK Heater Element Wafer
2 2 90° Insulated Connectors
3 1 Illuminated Toggle Switch
4 3 Female Quick Disconnect
Terminals
5 2 #8-32 Stainless Steel Bolts
6 4 #8-32 Stainless Steel Hex Nuts
7 2 #8 Stainless Steel Flat Washers
8 2 #8 Stainless Steel Lock Washers
9 2 O-Rings
10 2 Ring-Type Terminals
11 200-21H 1 85-EK Clear Bowl with Heater
Probes
12 Incl. In 200-GK 1 85-EK Bowl Gasket
13 Form 4011 1 Installation Instructions
1. Drain and remove the DAHL diesel fuel/water separator body
assembly.
2. Remove the filter element.
3. Remove the clear bowl by removing the socket head bolts
around the bowl ring.
4. Lift the clear bowl far enough to hold the #8-32 bolts while
removing the #8-32 nuts.
5. Remove the #8 washer and O-Rings. Push the #8-32 bolts to the
inside of the clear bowl and remove the clear bowl and ring.
6. To remove the heater element, reach inside the body and
gently pull the heater element up, making sure the wires do
not get caught on anything.
7. Before reassembly, check the O-Rings and gaskets for any
cuts, cracks or excessive swelling. If in doubt, replace them.
8. See assembly instructions in Form 4100 (Model 100 & 150
Series) or Form 4230 (Model 200 & 300 Series) to reassemble
the diesel fuel/water separator.
HEATER ELEMENT DISASSEMBLY INSTRUCTIONS
DAHL 55-EK and 85-EK In-Filter Heater Kit Installation (Cont’d.)
For Retrofitting Models 100, 150, 200 & 300 Series with Heater
Included with 100-H, 150-H & 200-H
Baldwin Filters warrants each new Baldwin or DAHL Filter
Product to be free from defects in workmanship and material
as follows:
1. Housings one year from date of user’s purchase.
2. Electronics, Pumps and Motors 90 days from date of
user’s purchase.
3. Replaceable Elements, Spin-ons, Etc. during equipment
manufacturer’s recommended filter service interval, if properly
installed in a Baldwin recommended application.
Baldwin will replace or repair at its option, free of charge, any
part still in the Baldwin warranty period found by Baldwin’s
inspection to be defective when such product is returned to
place of purchase or to Baldwin Filters with transportation
charges prepaid.
Specifically excluded from this warranty is damage
resulting from excessive force, negligence, abuse, misuse,
misapplication, tampering, improper installation, fire or
accident. The warranty will not apply to any filter which has
been cut apart or subject to tampering. Also, damage to
plastic parts of fuel/water separators caused by the use of
fluids containing alcohol is not covered by this warranty.
Full details of this warranty are in the Policy and Procedures
Manual at the Baldwin or DAHL distributor or may be obtained
from Baldwin’s Service Engineering Department.
BALDWIN LIMITED WARRANTY
Form 4011 (R 1/11) © 2017 Baldwin Filters, a Parker Hannifin company Printed in U.S.A.
