B&R Power Panel T30 User manual

Power Panel T30
User's manual
Version: 1.42 (November 2018)
Model no.: MAPPT30-ENG
Translation of the original documentation
All values in this manual are current as of its publication. We reserve the right to change the contents of this manual
without notice. B&R Industrial Automation GmbH is not liable for technical/editorial errors or incomplete information
in this manual. In addition, B&R Industrial Automation GmbH shall not be liable for incidental or consequential
damages in connection with or arising from the furnishing, performance or use of this material. We point out that the
software and hardware names and brand names of the respective companies used in this document are subject
to general trademark, brand or patent protection.

Table of contents
2 Power Panel T30 User's manual V1.42 - Translation of the original documentation

Table of contents
Power Panel T30 User's manual V1.42 - Translation of the original documentation 3
1 General information.................................................................................................. 6
1.1 Manual history.................................................................................................................................................6
1.2 Safety guidelines.............................................................................................................................................7
1.2.1 Introduction................................................................................................................................................ 7
1.2.2 Intended use..............................................................................................................................................7
1.2.3 Protection against electrostatic discharge.................................................................................................7
1.2.4 Policies and procedures............................................................................................................................ 8
1.2.5 Transport and storage...............................................................................................................................8
1.2.6 Installation..................................................................................................................................................8
1.2.7 Operation................................................................................................................................................... 9
1.2.8 Environmentally friendly disposal.............................................................................................................. 9
1.2.9 Organization of notices............................................................................................................................10
2 System characteristics........................................................................................... 11
2.1 Compact solution.......................................................................................................................................... 11
2.2 Flexibility........................................................................................................................................................11
2.3 Simple HMI....................................................................................................................................................12
2.4 Model number key........................................................................................................................................ 13
3 Device description.................................................................................................. 14
3.1 Type overview............................................................................................................................................... 14
3.1.1 Compare Power Panel T30 variants.......................................................................................................15
3.2 General technical data..................................................................................................................................16
3.2.1 Viewing angles........................................................................................................................................ 16
3.2.2 Automation Studio and Automation Runtime dependencies...................................................................16
3.2.3 Surface resistance of the panel overlay..................................................................................................17
3.2.4 Surface resistance of the touch screen.................................................................................................. 17
3.3 Power Panel T30 - 4.3" variants.................................................................................................................. 18
3.3.1 Order data............................................................................................................................................... 18
3.3.2 Content of delivery.................................................................................................................................. 18
3.3.3 Technical data......................................................................................................................................... 18
3.3.4 Temperature/Humidity diagram............................................................................................................... 20
3.3.5 Dimensions.............................................................................................................................................. 21
3.4 Power Panel T30 - 5.7" variants.................................................................................................................. 23
3.4.1 Order data............................................................................................................................................... 23
3.4.2 Content of delivery.................................................................................................................................. 23
3.4.3 Technical data......................................................................................................................................... 23
3.4.4 Temperature/Humidity diagram............................................................................................................... 25
3.4.5 Dimensions.............................................................................................................................................. 26
3.5 Power Panel T30 - 7.0" variants.................................................................................................................. 28
3.5.1 Order data............................................................................................................................................... 28
3.5.2 Content of delivery.................................................................................................................................. 28
3.5.3 Technical data......................................................................................................................................... 28
3.5.4 Temperature/Humidity diagram............................................................................................................... 30
3.5.5 Dimensions.............................................................................................................................................. 31
3.6 Power Panel T30 - 10.1" variants................................................................................................................ 33
3.6.1 Order data............................................................................................................................................... 33
3.6.2 Content of delivery.................................................................................................................................. 33
3.6.3 Technical data......................................................................................................................................... 33
3.6.4 Temperature/Humidity diagram............................................................................................................... 35
3.6.5 Dimensions.............................................................................................................................................. 36
3.7 Connection elements.................................................................................................................................... 38
3.7.1 Ethernet interface.................................................................................................................................... 38
3.7.2 USB interfaces.........................................................................................................................................39
3.7.3 Power supply........................................................................................................................................... 39

Table of contents
4 Power Panel T30 User's manual V1.42 - Translation of the original documentation
4 Commissioning........................................................................................................41
4.1 Installation..................................................................................................................................................... 41
4.1.1 Installation cutout requirements.............................................................................................................. 42
4.1.2 Mounting with retaining clips...................................................................................................................42
4.1.3 Installation instructions............................................................................................................................ 43
4.1.4 Mounting orientations.............................................................................................................................. 46
4.1.5 Grounding (functional ground).................................................................................................................47
4.2 Instructions for use in Ex zone 2 / 22.......................................................................................................... 49
4.3 Operating the Power Panel.......................................................................................................................... 51
4.3.1 Touch screen........................................................................................................................................... 51
4.3.2 Touch screen calibration..........................................................................................................................52
4.3.3 Keyboard..................................................................................................................................................53
4.3.4 Mouse...................................................................................................................................................... 53
5 Configuration........................................................................................................... 54
5.1 Service pages............................................................................................................................................... 54
5.1.1 Overview.................................................................................................................................................. 57
5.1.2 Service page Startup...............................................................................................................................58
5.1.3 Service page Network............................................................................................................................. 59
5.1.4 Service page Time.................................................................................................................................. 62
5.1.5 Service page Screen...............................................................................................................................63
5.1.6 Service page Audio................................................................................................................................. 66
5.1.7 Service page Hand button...................................................................................................................... 67
5.1.8 Service page VNC...................................................................................................................................71
5.1.9 Service page Web................................................................................................................................... 73
5.1.10 Service page Storage............................................................................................................................75
5.1.11 Service page Update............................................................................................................................. 77
5.1.12 Service page Backup & Reset.............................................................................................................. 81
5.1.13 Service page Security........................................................................................................................... 82
5.1.14 Service page OPC UA.......................................................................................................................... 83
5.1.15 Service page Save & Exit..................................................................................................................... 85
5.1.16 Service page About & Info.................................................................................................................... 86
5.2 Update........................................................................................................................................................... 87
5.2.1 Updating with Automation Studio and a USB flash drive (AS 4.2.1 and later)........................................87
5.2.2 Updating with a file downloaded from website and a USB flash drive....................................................88
5.2.3 Duplicating an existing setup using a USB flash drive........................................................................... 88
6 Software-specific information................................................................................89
6.1 Installing certificates in the browser............................................................................................................. 89
6.2 Supported video formats...............................................................................................................................89
6.3 File formats................................................................................................................................................... 90
6.3.1 PPT image...............................................................................................................................................90
6.3.2 System settings....................................................................................................................................... 90
6.3.3 Boot logo................................................................................................................................................. 90
6.3.4 Boot animation.........................................................................................................................................90
6.4 RFB extension...............................................................................................................................................91
6.4.1 Temperature monitoring.......................................................................................................................... 91
6.4.2 Starting touch screen calibration.............................................................................................................92
6.4.3 Adjusting display brightness....................................................................................................................92
6.4.4 Audio signal output..................................................................................................................................92
6.5 Supported fonts.............................................................................................................................................93
6.6 OPC UA server............................................................................................................................................. 94
6.6.1 Information model....................................................................................................................................94
6.6.2 Description of the nodes of the information model................................................................................. 98
6.7 Touch keys as data points via OPC UA.....................................................................................................123

Table of contents
Power Panel T30 User's manual V1.42 - Translation of the original documentation 5
7 Maintenance...........................................................................................................124
7.1 Cleaning...................................................................................................................................................... 124
7.2 User tips for increasing the service life of the display or touch screen...................................................... 125
7.2.1 Service life............................................................................................................................................. 125
7.2.2 Backlight................................................................................................................................................ 125
7.2.3 Image persistence................................................................................................................................. 125
8 Accessories........................................................................................................... 127
8.1 Overview......................................................................................................................................................127
8.2 TB6102 2-pin power supply connector.......................................................................................................128
8.2.1 Order data............................................................................................................................................. 128
8.2.2 Technical data....................................................................................................................................... 128
8.3 Data storage devices.................................................................................................................................. 128
8.4 Cable accessories.......................................................................................................................................128
9 International and national certifications.............................................................129
9.1 Overview of certifications............................................................................................................................129
9.2 EU directives and standards (CE).............................................................................................................. 130
9.2.1 Overview of standards...........................................................................................................................132
9.2.2 Requirements for immunity to disturbances..........................................................................................133
9.2.3 Emission requirements.......................................................................................................................... 135
9.2.4 Mechanical conditions........................................................................................................................... 136
9.2.5 Electrical safety..................................................................................................................................... 137
9.3 Underwriters Laboratories (UL)...................................................................................................................137
9.4 Det Norske Veritas - Germanischer Lloyd..................................................................................................138

General information
6 Power Panel T30 User's manual V1.42 - Translation of the original documentation
1 General information
Information:
B&R makes every effort to keep user's manuals as current as possible. The most current versions can
be downloaded from the B&R website www.br-automation.com.
1.1 Manual history
Version Date Comment
1.42 November 2018 New content:
•Updated OPC UA interface.
•Data points for touch keys (Hand button) via OPC UA.
•Added notes regarding UL certification.
Minor corrections and editorial changes.
1.41 August 2018 New content:
•"Installing certificates in the browser" on page 89
•"Supported fonts" on page 93
•Note regarding OPC UA server and service page (see "OPC UA server" on page 94)
1.40 July 2018 New content:
•"Service page OPC UA" on page 83
•Information about "OPC UA server" on page 94
1.31 May 2018 New content:
•Added DNV GL to chapter "International and national certifications".
•Added note to Installation cutout requirements.
Changed content:
•Improved description of Hand button.
•Harmonized technical data.
•Changed tightening torque of retaining clips from 0.6 to 0.4 Nm.
Editorial changes and corrections.
1.30 December 2016 Restructured manual:
•Moved section "System characteristics" into a separate chapter.
•Merged chapter "Power Panel T-Series" and section "T30-Series"
and renamed to chapter "Device description".
•Restructured chapter "Device description" and renamed individual sections.
•Additional editorial changes.
Other changes:
•Renamed chapter "Standards and certifications" to "International and national certifications", updated.
•New section "Instructions for use in Ex zone 2 / 22" in chapter "Commissioning"
•Corrected content in "Technical data".
•Revised section "Grounding (functional ground)".
•Restructured chapter "Configuration".
1.20 November 2015 Updated "Installation" and "Standards and certifications".
1.10 September 2015 Added new chapter "Operating the Power Panel with a USB mouse".
Updated "Technical data", "Automation Studio and Automation Runtime dependencies" and "Installation".
1.00 May 2015 Added new chapter "Automation Studio and Automation Runtime dependencies".
Updated "Installation".

General information
Power Panel T30 User's manual V1.42 - Translation of the original documentation 7
1.2 Safety guidelines
Important!
If the device is not used in accordance with the manufacturer's instructions, the protection provided
by the device may be impaired.
1.2.1 Introduction
Programmable logic controllers (PLCs), operating/monitoring devices (industrial PCs, Power Panels, Mobile Pan-
els, etc.) and uninterruptible power supplies from B&R have been designed, developed and manufactured for
conventional use in industrial environments. They were not designed, developed and manufactured for any use
involving serious risks or hazards that could lead to death, injury, serious physical impairment or loss of any kind
without the implementation of exceptionally stringent safety precautions. In particular, this includes the use of these
devices to monitor nuclear reactions in nuclear power plants, in flight control or flight safety systems as well as in
the control of mass transportation systems, medical life support systems or weapons systems.
When using programmable logic controllers or operating/monitoring devices as control systems in connection with
a Soft PLC (e.g. Automation Runtime or comparable product) or Slot PLC (e.g. B&R LS251 or comparable product),
safety precautions relevant to industrial control systems (e.g. the provision of safety devices such as emergency
stop, etc.) must be observed in accordance with applicable national and international regulations. This also applies
to all other devices connected to the system, such as drives.
All tasks such as the installation, commissioning and servicing of devices are only permitted to be carried out by
qualified personnel. Qualified personnel are those familiar with the transport, mounting, installation, commissioning
and operation of devices who also have the appropriate qualifications to perform these tasks (e.g. IEC 60364).
National accident prevention regulations must be observed.
The safety notices, information about connection conditions (nameplate and documentation) and limit values spec-
ified in the technical data must be read carefully before installation and commissioning and are to be observed
in all cases.
1.2.2 Intended use
Electronic devices are never completely failsafe. If the programmable logic controller, operating/monitoring device
or uninterruptible power supply fails, the user is responsible for ensuring that other connected devices such as
motors are brought to a safe state.
1.2.3 Protection against electrostatic discharge
Electrical components that can be damaged by electrostatic discharge (ESD) must be handled accordingly.
1.2.3.1 Packaging
•Electrical components with a housing
...do not require special ESD packaging but must be handled properly (see "Electrical components with
a housing" on page 7).
•Electrical components without a housing
...are protected by ESD-suitable packaging.
1.2.3.2 Guidelines for proper ESD handling
Electrical components with a housing
•Do not touch the connector contacts on the device (bus data contacts).
•Do not touch the connector contacts on connected cables.
•Do not touch the contact tips on circuit boards.

General information
8 Power Panel T30 User's manual V1.42 - Translation of the original documentation
Electrical components without a housing
The following points apply in addition to the points listed under "Electrical components with a housing":
•Any persons handling electrical components or devices with installed electrical components must be
grounded.
•Components are only permitted to be touched on their narrow sides or front plate.
•Components must always be placed on or stored in a suitable medium (ESD packaging, conductive foam,
etc.).
Information: Metallic surfaces are not suitable storage surfaces!
•Components must not be subjected to electrostatic discharge (e.g. caused by charged plastics).
•Observe a minimum distance of 10 cm from monitors and television sets.
•Measuring instruments and equipment must be grounded.
•Probe tips of galvanically isolated measuring instruments must be temporarily discharged on suitably
grounded surfaces before taking measurements.
Individual components
•ESD protective measures for individual components are thoroughly implemented at B&R (conductive floors,
footwear, arm bands, etc.).
•Increased ESD protective measures for individual components are not required for handling B&R products
at customer locations.
1.2.4 Policies and procedures
Electronic devices are never completely failsafe. If the programmable logic controller, operating/monitoring device
or uninterruptible power supply fails, the user is responsible for ensuring that other connected devices such as
motors are brought to a safe state.
When using programmable logic controllers or operating/monitoring devices as control systems in connection with
a Soft PLC (e.g. B&R Automation Runtime or comparable product) or Slot PLC (e.g. B&R LS251 or comparable
product), safety precautions relevant to industrial control systems (e.g. the provision of safety devices such as
emergency stop, etc.) must be observed in accordance with applicable national and international regulations. This
also applies to all other devices connected to the system, such as drives.
All tasks such as the installation, commissioning and servicing of devices are only permitted to be carried out by
qualified personnel. Qualified personnel are those familiar with the transport, mounting, installation, commissioning
and operation of devices who also have the appropriate qualifications to perform these tasks (e.g. IEC 60364).
National accident prevention regulations must be observed.
The safety notices, information about connection conditions (nameplate and documentation) and limit values spec-
ified in the technical data must be read carefully before installation and commissioning and are to be observed
in all cases.
1.2.5 Transport and storage
During transport and storage, devices must be protected against undue stress (mechanical loads, temperature,
moisture, corrosive atmospheres, etc.).
Devices contain components sensitive to electrostatic charges that can be damaged by improper handling. It is
therefore necessary to provide the required protective measures against electrostatic discharge when installing or
removing these devices (see "Protection against electrostatic discharge" on page 7).
1.2.6 Installation
•Installation must be performed according to this documentation using suitable equipment and tools.
•Devices are only permitted to be installed by qualified personnel and when the power is switched off.
•General safety guidelines and national accident prevention regulations must be observed.
•Electrical installation must be carried out in accordance with applicable guidelines (e.g. wire cross sections,
fuses, protective ground connections).
•Take the necessary protective measures against electrostatic discharge (see "Protection against electro-
static discharge" on page 7).

General information
Power Panel T30 User's manual V1.42 - Translation of the original documentation 9
1.2.7 Operation
1.2.7.1 Protection against touching electrical parts
To operate programmable logic controllers, operating/monitoring devices and uninterruptible power supplies, cer-
tain components must carry dangerous voltage levels over 42 VDC. Touching one of these components can result
in a life-threatening electric shock. This could lead to death, severe injury or damage to property.
Before switching on programmable logic controllers, operating/monitoring devices or the uninterruptible power
supply, it must be ensured that the housing is properly connected to ground (PE rail). Ground connections must
also be established when the operating/monitoring device or uninterruptible power supply is connected for test
purposes or only being operated for a short period of time!
Before switching on the device, all voltage-carrying components must be securely covered. During operation, all
covers must remain closed.
1.2.7.2 Environmental conditions - Dust, moisture, corrosive gases
The use of operating/monitoring devices (e.g. industrial PCs, Power Panels, Mobile Panels) and uninterruptible
power supplies in very dusty environments must be avoided. The collection of dust on devices can affect function-
ality and may prevent sufficient cooling, especially in systems with active cooling (fans).
The presence of corrosive gases can also result in impaired functionality. When combined with high temperature
and humidity, corrosive gases – e.g. with sulfur, nitrogen and chlorine components – can induce chemical reactions
that can damage electronic components very quickly. The presence of corrosive gases is indicated by blackened
copper surfaces and cable ends on existing installations.
When operated in dusty or moist environments that could potentially impair functionality, operating/monitoring
devices such as the Automation Panel and Power Panel are protected on the front against the ingress of dust
or moisture when installed properly (e.g. cutout installation). The back of all devices must be protected from the
ingress of dust and moisture, however; any collected dust must be removed at suitable intervals.
1.2.7.3 Viruses and dangerous programs
This system is subject to potential risk each time data is exchanged or software is installed from a data storage
medium (e.g. diskette, CD-ROM, USB flash drive, etc.), network connection or the Internet. The user is responsible
for assessing these risks, implementing preventive measures such as virus protection programs, firewalls, etc. and
making sure that software is obtained only from trusted sources.
1.2.8 Environmentally friendly disposal
All programmable controllers, operating/monitoring devices and uninterruptible power supplies from B&R are de-
signed to minimize harm to the environment as far as possible.
1.2.8.1 Separation of materials
It is necessary to separate out the different materials so that devices can undergo an environmentally friendly
recycling process.
Component Disposal
Programmable logic controllers
Operating/Monitoring devices
Uninterruptible power supply
Batteries and rechargeable batteries
Cables
Electronics recycling
Cardboard/Paper packaging Paper/Cardboard recycling
Plastic packaging material Plastic recycling
Table 1: Environmentally friendly disposal
Disposal must take place in accordance with applicable legal regulations.

General information
10 Power Panel T30 User's manual V1.42 - Translation of the original documentation
1.2.9 Organization of notices
Safety notices
Contain only information that warns of dangerous functions or situations.
Signal word Description
Danger! Failure to observe these safety guidelines and notices will result in death, severe injury or substantial damage to property.
Warning! Failure to observe these safety guidelines and notices can result in death, severe injury or substantial damage to property.
Caution! Failure to observe these safety guidelines and notices can result in minor injury or damage to property.
Notice! Failure to observe these safety guidelines and notices can result in damage to property.
Table 2: Organization of safety notices
General notices
Contain useful information for users and instructions for avoiding malfunctions.
Signal word Description
Information: Useful information, application tips and instructions for avoiding malfunctions.
Table 3: Organization of general notices

System characteristics
Power Panel T30 User's manual V1.42 - Translation of the original documentation 11
2 System characteristics
The Power Panel T30 is equipped with an embedded browser and can also be used as a Visual Components
client. The terminal series has 2 Ethernet and 2 USB interfaces as well as various configuration options.
2.1 Compact solution
With an extremely compact design, minimal installation depth and intelligent cable outlet arrangement, Power
Panels are extreme space-savers that are very easy to install. They also have no hard disks, fans or batteries, which
makes them maintenance-free. The front of the panel provides IP65 protection, making these devices extremely
well-suited for harsh industrial environments.
2.2 Flexibility
Power Panel T30 devices are available in 4 different display sizes ranging from 4.3" to 10.1" (see "Type overview"
on page 14).
A touch button is integrated in the panel overlay at the lower right corner of the display. This element can be
elegantly incorporated into the HMI application and easily set up for home or help functionality.
The ability to choose between a landscape or portrait format adds even more flexibility to the machine layout. It is
easy to switch between panel models depending on the machine. In addition to the 2 different formats, users can
also select between 2 pinstripe options: anthracite gray or aluminum white.
Regardless of model, size and color, what all these devices have in common is a shallow installation depth and
minimized border width. At the same time, no compromises were made with regard to stability and seal integrity.

System characteristics
12 Power Panel T30 User's manual V1.42 - Translation of the original documentation
2.3 Simple HMI
The Power Panel T30 is a dedicated HMI device that can be operated in 2 different terminal modes:
•Terminal as VNC client for VNC-based HMI applications created in Automation Studio with Visual Com-
ponents.
•Terminal with web browser technology (full screen mode).

System characteristics
Power Panel T30 User's manual V1.42 - Translation of the original documentation 13
2.4 Model number key
Product area
6 Device with browser technology
Product family
P P Power Panel
Model
T Terminal series
Variant (processor power)
3 0 ARM processor (Cortex-A8, single core)
Diagonal
. 0 4 3 4.3"
. 0 5 7 5.7"
. 0 7 0 7.0"
. 1 0 1 10.1"
Resolution
2 WVGA (800 x 480) landscape
3 VGA (640 x 480) landscape
F WQVGA (480 x 272) landscape
G WSVGA (1024 x 600) landscape
K WQVGA (272 x 480) portrait
L VGA (480 x 640) portrait
M WVGA (480 x 800) portrait
N WSVGA (600 x 1024) portrait
Display / Touch screen technology
- 2 TFT color + analog resistive touch screen
Optional interfaces and features
0 No optional interfaces/features
Front design
Standard variants
B Anthracite gray pinstripe
W Aluminum white pinstripe
Industry-specific variant
I . . . Seq. number: I[0...Z][0...Z][0...Z]
Customized panel overlay only
F . . . Seq. number: F[0...Z][0...Z][0...Z]
Complete customized variant
C . . . Seq. number: C[0...Z][0...Z][0...Z]
Model or I/O variants
Base model
- 0 1 Derivative: Sequential number [0...Z]
Examples
6 P P T 3 0 . 0 4 3 F - 2 0 W
Power Panel T30, 4.3", landscape format. CPU and memory: 600 MHz (ARM
Cortex-A8), 512 MB onboard flash drive. Display and touch screen: 4.3", 480
x 272 (WQVGA) resolution, analog resistive touch screen, landscape format,
aluminum white pinstripe. Interfaces: 2x Ethernet 10/100 Mbit/s (integrated
switch), 2x USB 2.0. Client software: Integrated service page, VNC client,
embedded web browser.
6 P P T 3 0 . 0 5 7 L - 2 0 B
Power Panel T30, 5.7", portrait format. CPU and memory: 600 MHz (ARM
Cortex-A8), 512 MB onboard flash drive. Display and touch screen: 5.0", 480 x
640 (VGA) resolution, analog resistive touch screen, portrait format, anthracite
gray pinstripe. Interfaces: 2x Ethernet 10/100 Mbit/s (integrated switch), 2x
USB 2.0. Client software: Integrated service page, VNC client, embedded web
browser.
6 P P T 3 0 . 0 7 0 2 - 2 0 W
Power Panel T30, 7.0", landscape format. CPU and memory: 600 MHz (ARM
Cortex-A8), 512 MB onboard flash drive. Display and touch screen: 7.0", 800
x 480 (WVGA) resolution, analog resistive touch screen, landscape format,
aluminum white pinstripe. Interfaces: 2x Ethernet 10/100 Mbit/s (integrated
switch), 2x USB 2.0. Client software: Integrated service page, VNC client,
embedded web browser.
6 P P T 3 0 . 1 0 1 N - 2 0 B
Power Panel T30, 10.1", portrait format. CPU and memory: 600 MHz (ARM
Cortex-A8), 512 MB onboard flash drive. Display and touch screen: 10.1", 600
x 1024 (WSVGA) resolution, analog resistive touch screen, portrait format,
anthracite gray pinstripe. Interfaces: 2x Ethernet 10/100 Mbit/s (integrated
switch), 2x USB 2.0. Client software: Integrated service page, VNC client,
embedded web browser.

Device description • Type overview
14 Power Panel T30 User's manual V1.42 - Translation of the original documentation
3 Device description
3.1 Type overview
Panel size 4.3" 5.7" 7.0" 10.1"
Model number 6PPT30.043x-20x 6PPT30.057x-20x 6PPT30.070x-20x 6PPT30.101x-20x
Format / Resolution Landscape format Portrait format
Resolution WQVGA
480 x 272
VGA
640 x 480
WVGA
800 x 480
WSVGA
1024 x 600
WQVGA
272 x 480
VGA
480 x 640
WVGA
480 x 800
WSVGA
600 x 1024
043F 0573 0702 101G 043K 057L 070M 101N
Model number 6PPT30.xxxx-20x 6PPT30.xxxx-20x
Panel overlay Pinstripe pattern in aluminum white Pinstripe pattern in anthracite
6PPT30.xxxx-20W6PPT30.xxxx-20B

Device description • Type overview
Power Panel T30 User's manual V1.42 - Translation of the original documentation 15
3.1.1 Compare Power Panel T30 variants
Format / Panel overlay
Landscape format Portrait format
Aluminum white Anthracite Aluminum white Anthracite
4.3" / WQVGA
5.7" / VGA
7.0" / WVGA
Display size / Resolution
10.1" / WSVGA

Device description • General technical data
16 Power Panel T30 User's manual V1.42 - Translation of the original documentation
3.2 General technical data
Name Description
Processor ARM Cortex A8 600 MHz / 1 GHz
Memory 256 MB DDRAM
Interfaces 2x Ethernet interfaces 10/100BASE-T
2x USB 2.0 interfaces
Other IP65 protection (front)
Temperature range from -20 to 60°C
Fanless
8 to 32 VDC power supply
3.2.1 Viewing angles
For the viewing angles values (U, D, R, L) of the display types, see the technical data of the respective device.
D
U
R
L
Landscape
D
U
R
L
Portrait
Legend: Display viewing angle
U From top
D From bottom
L From left
R From right
The viewing angles are specified for the horizontal (L, R) and vertical (U, D) axes in reference to the vertical axis of
the display. The specified viewing angles above always refer to the standard mounting orientation of the respective
Power Panel.
Standard mounting orientation: The Hand button is at the bottom right.
3.2.2 Automation Studio and Automation Runtime dependencies
The Power Panel functions below refer to the most recent version of the PPT system. The following table shows
dependencies between these functions and the hardware revision and Automation Studio / Automation Runtime
version:
Function
Starting with
AS version
Starting with
AR version
Starting with
HW revision
Updating with Automation Studio and a USB flash drive 4.2.1 - -
Support "Load configuration from PLC" 4.2.3 A4.23 -
Using a boot logo for Power Panels in portrait format 4.2.4 - D3
Using a boot animation in GIF format 4.3.2 - -
* AS ... Automation Studio, AR ... Automation Runtime, HW ... Hardware

Device description • General technical data
Power Panel T30 User's manual V1.42 - Translation of the original documentation 17
3.2.3 Surface resistance of the panel overlay
The panel overlay conforms to DIN 42115 (Part 2). This means it is resistant to exposure to the following chemicals
for a 24-hour period with no visible signs of damage:
Ethanol
Cyclohexanol
Diacetone alcohol
Glycol
Isopropanol
Glycerine
Methanol
Triacetin
Dowandol
DRM/PM
Formaldehyde 37%-42%
Acetaldehyde
Aliphatic hydrocarbons
Toluene
Xylene
White spirits
Trichloroethane
Ethyl acetate
Diethyl ether
n-Butyl acetate
Amyl acetate
Butylcellosolve
Ether
Acetone
Methyl ethyl ketone
Dioxan
Cyclohexanone
Methylisobutylketone (MIBK)
Isophorone
Formic acid <50%
Acetic acid <50%
Phosphoric acid <30%
Hydrochloric acid <36%
Nitric acid <10%
Trichloracetic acid <50%
Sulphuric acid <10%
Ammonia <40%
Caustic soda <40%
Potassium hydroxide
Alkali carbonate
Bichromate
Potassium ferro cyanide
Acetonitrile
Sodium bisulphate
Cutting oil
Diesel oil
Linseed oil
Paraffin oil
Ricinus oil
Silicon oil
Turpentine oil substitute
Brake fluid
Aviation fuel
Gasoline
Water
Sea water
Decon
Sodium chloride <20%
Hydrogen peroxide <25%
Potassium carbonate
Washing agents
Tenside
Fabric conditioner
Iron (II) chloride
Iron (III) chloride
Dibutyl phthalate
Dioctyl phthalate
Sodium carbonate
Information:
The specified characteristics, features and limit values only apply to this individual component and
can deviate from those specified for the complete system.
The panel overlay is resistant to exposure to glacial acetic acid for less than one hour without visible damage per
DIN 42115 Part 2.
3.2.4 Surface resistance of the touch screen
The surface of the analog resistive touch screen is resistant to the following chemicals at a temperature of 25°C
for a duration of 1 hour.
•Acetone
•Methylene chloride
•Butanone
•Isopropyl alcohol
•Hexane
•Turpentine
•Mineral spirit
•Unleaded gasoline
•Diesel fuel
•Motor oil
•Transmission fluid
•Antifreeze
•Ammonia-based glass cleaner
•Washing agents
•Household cleaners
•Vinegar
•Coffee
•Tea
•Lubricating grease
•Cooking oil
•Salt

Device description • Power Panel T30 - 4.3" variants
18 Power Panel T30 User's manual V1.42 - Translation of the original documentation
3.3 Power Panel T30 - 4.3" variants
3.3.1 Order data
Model number Short description Figure
Power Panel T30
6PPT30.043F-20W Power Panel T30, 4.3", landscape format. CPU and memo-
ry: 600 MHz (ARM Cortex-A8), 512 MB onboard flash drive.
Display and touch screen: 4.3", 480 x 272 (WQVGA) resolu-
tion, analog resistive touch screen, landscape format, aluminum
white pinstripe. Interfaces: 2x Ethernet 10/100 Mbit/s (integrated
switch), 2x USB 2.0. Client software: Integrated service page,
VNC client, embedded web browser.
6PPT30.043F-20B Power Panel T30, 4.3", landscape format. CPU and memo-
ry: 600 MHz (ARM Cortex-A8), 512 MB onboard flash drive.
Display and touch screen: 4.3", 480 x 272 (WQVGA) resolu-
tion, analog resistive touch screen, landscape format, anthracite
gray pinstripe. Interfaces: 2x Ethernet 10/100 Mbit/s (integrated
switch), 2x USB 2.0. Client software: Integrated service page,
VNC client, embedded web browser.
6PPT30.043K-20W Power Panel T30, 4.3", portrait format. CPU and memory: 600
MHz (ARM Cortex-A8), 512 MB onboard flash drive. Display and
touch screen: 4.3", 272 x 480 (WQVGA) resolution, analog resis-
tive touch screen, portrait format, aluminum white pinstripe. In-
terfaces: 2x Ethernet 10/100 Mbit/s (integrated switch), 2x USB
2.0. Client software: Integrated service page, VNC client, em-
bedded web browser.
6PPT30.043K-20B Power Panel T30, 4.3", portrait format. CPU and memory: 600
MHz (ARM Cortex-A8), 512 MB onboard flash drive. Display and
touch screen: 4.3", 272 x 480 (WQVGA) resolution, analog re-
sistive touch screen, portrait format, anthracite gray pinstripe. In-
terfaces: 2x Ethernet 10/100 Mbit/s (integrated switch), 2x USB
2.0. Client software: Integrated service page, VNC client, em-
bedded web browser.
Included in delivery
Terminal blocks
0TB6102.2110-01 Accessory terminal block, 2-pin (3.81), cage clamp terminal
block 1.5 mm²
Optional accessories
Other
9A0013.01 Stylus pen for resistive touch screen
Terminal blocks
0TB6102.2010-01 Accessory terminal block, 2-pin (3.81), screw clamp terminal
block 1.5 mm²
USB accessories
5MMUSB.2048-01 USB 2.0 flash drive 2048 MB B&R
5MMUSB.4096-01 USB 2.0 flash drive 4096 MB B&R
Table: Power Panel T30 - 4.3" variants - Order data
3.3.2 Content of delivery
Name Quantity Description
0TB6102.2110-01 1 Accessory terminal block, 2-pin (3.81), cage clamp terminal block 1.5 mm²
- 1 T-Series 4.3" accessory plate: Plate for securing the connection lines and connecting the shielding
- 1 Accessory set 3x retaining clip for fastening the panel in the installation cutout
3.3.3 Technical data
Model number 6PPT30.043F-20W 6PPT30.043F-20B 6PPT30.043K-20W 6PPT30.043K-20B
General information
Cooling Passive
LED status indicators Ethernet
B&R ID code 0xE589 0xE58A 0xE58B 0xE58C
Power button No
Reset button No
Buzzer Yes
Table: Power Panel T30 - 4.3" variants - Technical data

Device description • Power Panel T30 - 4.3" variants
Power Panel T30 User's manual V1.42 - Translation of the original documentation 19
Model number 6PPT30.043F-20W 6PPT30.043F-20B 6PPT30.043K-20W 6PPT30.043K-20B
Certifications
CE Yes
UL cULus E115267
Industrial control equipment
ATEX Zone 2, II 3G Ex nA IIA T5 Gc
Zone 22, II 3D Ex tc IIIC T70°C Dc
Front IP65, back IP20
Ta (see user's manual)
TÜV 16 ATEX 7815X
DNV GL Temperature: B (0 - 55°C)
Humidity: B (up to 100%)
Vibration: A (0.7 g)
EMC: B (Bridge and open deck)
Controller
Operating system PPT30 system
Real-time clock No
Processor
Type ARM Cortex A8
Clock frequency 600 MHz
L1 cache 64 kB
L2 cache 256 kB
Flash 512 MB
Mode/Node switches No
DRAM 256 MB
Interfaces
Interface
Connection ETH1 (IF1) and ETH2 (IF2)
Type Ethernet
Variant Shielded RJ45 (integrated 2-port switch)
Line length Max. 100 m between 2 stations (segment length)
Max. transfer rate 10/100 Mbit/s
Transfer
Physical layer 10BASE-T / 100BASE-TX
Half-duplex Yes
Full-duplex Yes
Autonegotiation Yes
Auto-MDI / MDIX Yes
Interface IF3
Type USB 2.0
Variant Type A
Current-carrying capacity 0.5 A 1)
Interface IF4
Type USB 2.0
Variant Type A
Current-carrying capacity 0.2 A 2)
Display
Type Color TFT
Diagonal 4.3"
Colors 16.7 million (RGB, 8 bits per channel)
Resolution WQVGA, 480 x 272 pixels WQVGA, 272 x 480 pixels
Contrast Typ. 350:1
Viewing angles
Horizontal L direction / R direction = typ. 70° L direction = typ. 70° / R direction = typ. 50°
Vertical U direction = typ. 50° / D direction = typ. 70° U direction / D direction = typ. 70°
Backlight
Type LED
Brightness Typ. 450 cd/m²
Half-brightness time 3) 30,000 h
Touch screen
Type AMT
Technology Analog resistive
Controller B&R, 12-bit
Transmittance 80% ±3%
Screen rotation Yes
Electrical characteristics
Nominal voltage 24 VDC
Max. current at nominal voltage 230 mA
Max. power consumption 5.5 W
Fuse 4 A slow-blow, internal 4)
Voltage range 8 to 32 VDC
Reverse polarity protection Yes
Electrical isolation Ethernet (ETH1/IF1 and ETH2/IF2) to other interfaces, power supply and ground
Table: Power Panel T30 - 4.3" variants - Technical data

Device description • Power Panel T30 - 4.3" variants
20 Power Panel T30 User's manual V1.42 - Translation of the original documentation
Model number 6PPT30.043F-20W 6PPT30.043F-20B 6PPT30.043K-20W 6PPT30.043K-20B
Operating conditions
Permissible mounting orientations
Standard mounting orientation Vertical
Tilt ±25°
Rotation In 90° increments (portrait/landscape)
Installation elevation above sea level
0 to 2000 m No limitations
>2000 m Reduction of ambient temperature by 0.5°C per 100 m
Degree of protection per EN 60529 Front: IP65, Back: IP20
Environmental conditions
Temperature
Operation -20 to 60°C
Storage -20 to 70°C
Transport -20 to 70°C
Relative humidity See temperature/humidity diagram.
Mechanical properties
Front
Design Aluminum white pinstripe Anthracite gray pinstripe Aluminum white pinstripe Anthracite gray pinstripe
Dimensions
Width 140 mm 96 mm
Height 96 mm 140 mm
Depth 38.3 mm
Weight 0.3 kg
Table: Power Panel T30 - 4.3" variants - Technical data
1) The current-carrying capacity is 0.1 A for hardware revisions less than B0.
2) The current-carrying capacity is 0.1 A for hardware revisions B0 to B2.
The current-carrying capacity is 0.5 A for hardware revisions less than B0.
3) Value applies at an ambient temperature of 25°C. Reducing the brightness by 50% can increase the half-brightness time up to 50%.
4) The internal fuse cannot be replaced by the user or reset.
3.3.4 Temperature/Humidity diagram
Temperature [°C]
Relative humidity [%RH] (non-condensing)
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
-80 -70 -60 -50 -40 -30 -20 -10 0 10 20 30 40 50 60 70 80 90
Storage
Transport
Storage
Transport
OperationOperation
Figure: Power Panel T30 - 4.3" variants - Temperature/Humidity diagram
