Banner PLI-A10 User manual

PLI-A10 Adjustable Beam Spot Plastic Fiber Optic Assembly
Integrated convergent lens, M6 threaded housing, unterminated
Printed in USA 03/02 P/N 109026
Features
•Bifurcated coaxial ø0.5 mm/9x 0.25 mm fibers
•Integrated lens converges emitted light at a variable distance from the compact
fiber head
•Beam spot diameter varies according to fiber ferrule insertion depth
•Spot diameter is adjustable from ø0.5 mm (0.04") to ø3.2 mm (0.14")
•Metal hex nuts (M6 x 0.75) and lock washer included
•Cut-to-length fiber optic cable
•Anormal plastic fiber optic has a “beam diffusion” angle of about 60°, making it
difficult (if not impossible) to sense very small targets. A convergent lens allows
focusing of the beam to a small spot, enabling detection of minute targets at
relatively long distances.
PLI-A10 Fiber Specifications
WARRANTY: Banner Engineering Corp. warrants its products to be free from defects for one year. Banner Engineering Corp. will repair or
replace, free of charge, any product of its manufacture found to be defective at the time it is returned to the factory during the warranty
period. This warranty does not cover damage or liability for the improper application of Banner products. This warranty is in lieu of any
other warranty either expressed or implied.
Construction
Anodized aluminum housing
Glass lens
PMMA (acrylic) fiber core
Fluoropolymer fiber cladding
Polyethylene jacket
Stainless steel hardware
Focal Distance 8 mm (0.31") to 32 mm (1.26")
Beam Spot Diameter ø0.5 mm (0.04") to ø3.2 mm (0.14")
Operating Temperature -40°to +70°C (-40°to +158°F)
Cable Length Standard length 2 m (79")
Custom lengths available on request
Excess Gain Dependent on amplifier used
Dimensions
32.2 mm
(1.27")
ø3.0 mm (0.12")
Smooth Ferrule
(Stainless)
Anodized Aluminum Knurled
Locking Ferrule
2x 1.25 mm (0.049")
(Polyethylene)
2x M6 x 0.75
Jam Nuts (Stainless)
Detail View
M6 Washer (Stainless)
M6 x 0.75 Thread
(Anodized Aluminum)
9x ø0.25 mm (0.010")
ø0.50 mm (0.20")
