baracuda tracker User manual

Owner’s Manual
H0532000 REV A

page 2
Important Information
Notice for Vinyl Liner Pools: Before installing your pool cleaner, examine the interior of your pool carefully. If the
vinyl liner is brittle or has stones, wrinkles, roots or metal corrosion in contact with the underside of the liner, or has
damage to the base material or supporting walls, do not install the cleaner before having a qualified professional
perform the necessary repairs or liner replacement. Zodiac Group Australia Pty Ltd (Zodiac) will not be
responsible for liner damage caused by a cleaner which is in disrepair, pattern removal from a vinyl liner,
or a cleaner used in a pool having an aged or deteriorated liner. Please see Limited Warranty.
• Clean the skimmer basket, pump basket and pool filter before installing the cleaner and on a
regular basis thereafter.
• Always disconnect the cleaner from the pool wall or skimmer before cleaning or backwashing the pool filter.
After cleaning or backwashing, let the filtration system run for at least five (5) minutes before re-connecting
the cleaner.
• Remove the cleaner from the pool before chemical or shock treatments. Wait a minimum
of four (4) hours after super chlorination before re-installing the cleaner.
Read owner’s manual completely before operating the cleaner.
Remove cleaner before entering the pool.
Do not operate outside of the pool.
Do not let children play with cleaner.
Exceptional After Sales Support
We have a trained team on hand to help walk you through how to
set up your cleaner and equipment. For installation and troubleshooting
questions, please directly contact BARACUDA®After Sales.
And don’t forget to register your product online for warranty
(see Warranty Card inside the pack).
Happy Swimming!
For more information visit www.baracuda.com.au
or call 1300 784 423

page 3
Introduction
Congratulations on the purchase of your new BARACUDA®Tracker™automatic pool cleaner. Your Tracker is
designed and manufactured for easy installation, and years of carefree operation. Before installing the cleaner,
please take a few moments to become familiar with its components and to review the items listed under Important
Information.
Like most mechanical devices, the Tracker requires periodic adjustments, routine maintenance, and the
replacement of certain hardworking parts.
Always insist on genuine Baracuda replacement parts. Non-Baracuda parts are not made to our specifications.
They may have an adverse effect on the operation of your Tracker, or may even damage it.
Complete Cleaner Parts in the Pack
1. Cleaner Body
2. AD Flow Valve & Connector
3. Universal Weir Cuff
4. Flow Regulator Valve
5. Twist-Lock Hose Section (x 9)
6. Leader Hose with Float
7. 90 Degree Elbow
1
5
6
3
2
7
4
1
5
6
3
2
7
4
1
5
6
3
2
7
4

page 4
1. Before You Start
For best cleaner performance, you will need to follow the following steps of the installation.
1.1 Following manufacturer’s instructions, clean the filter and empty the skimmer and the pump strainer basket.
1.2 If your main drain is connected to the skimmer box, block off access.
1.3 Manually vacuum the pool.
1.4 Ensure circulation system is operating at maximum water flow, or you will need to re-adjust when it comes to
clean the filter baskets.
1.5 Adjust water flow, from all return inlets:
a) Downward and toward each other OR
b) Downward and toward the centre of the pool.
Installation
90 Degree Elbow
Speed Regulator
1
5
3
2
6
7
4
8
If return inlet directional fittings can’t be directed far enough
down to prevent water flow affecting the natural movement
of the hose, you will need to install return line diverters.
2. AD Flow Valve
The AD Flow valve works by regulating the flow through the pool cleaner
to the pump. As the filter collects debris, the valve will automatically
maintain the correct flow.
The installation of the AD Flow valve will depend upon the type of
skimmer box and Vac plate you have. It is either installed straight in from
the top of the Vac plate or from the bottom of the Vac plate.
See the 4 different cases below.
1st case: with Waterco®Skimmer Box/Vac Plate
Screw in the AD Flow valve connector into the top of the Vac plate
2nd case: with Poolrite Skimmer Box/Vac Plate
Screw in the AD Flow valve connector into the bottom of the Vac plate.
3rd case: with Speed Regulator/Skimtrol Vac Plate
Simply connect the 90 Degree Elbow into the top of
the Vac Plate.

page 5
Installation
4th case: with any other type of Skimmer Box and Vac plate
Simply insert the AD Flow valve directly into the universal
weir cuff which will then fit into the top of the Vac plate.
NOTE: The AD Flow valve has three settings: High (3), Medium (2) and Low (1). To deliver the maximum pool
cleaning efciency, the AD Flow valve comes preset at a factory setting of 2. You will need to adjust the AD
Flow valve when and if a problem occurs.
3. Assemble the hose sections
Start to connect one of the standard hose to the skimmer box Vac plate. Then continue adding lengths of
standard hose sections until you reach the furthest point of the pool, opposite to the skimmer box. THEN
add the leader hose section.
See below examples.
WARNING
To avoid any serious injury, turn off the pool pump before proceeding to this step.
Leader hose
section
Hose Float 23cm
from Head Cleaner
Skimmer
Lengths of standard
hose sections
Leader hose section
Hose Float 23cm from
Head Cleaner
Lengths of standard
hose sections
Skimmer
AD Flow valve
Universal Weir Cuff
1
5
3
2
6
7
4
8

page 6
4. Connecting Cleaner Head to Flow Regulator Valve
4.1 Remove orange sticker off leader hose.
4.2 Attach the flow regulator valve to the leader hose
and connect the cleaner head to the
flow regulator valve.
5. Re-Connecting to Skimmer Box
5.1 Temporarily disconnect hose from skimmer, turn on pool filter pump.
5.2 Flood the hose with water, turn off pool filter pump, reconnect hose to skimmer box, then turn pool
filter pump back on.
6. Check Cleaner Flow
6.1 Watch the orange wheel marker,
use a stopwatch to time ten (10)
wheel rotations.
7. Adjust Flow if Necessary, using the
AD Flow Valve
7.1 The AD Flow Valve has three settings:
(1) Low, (2) Medium, and (3) High.
The valve comes with a factory setting of (2).
+ Adjust the AD Flow Valve to setting (3) to increase flow.
– Adjust the AD Flow Valve to setting (1) decrease flow.
Installation
IF Time is ... Result ... Adjust Flow ...
26-50 Poor Performance Increase Flow
20-25
10-19 Possible Damage Decrease Flow
10 rotations
_ _ _ _ _ _ _ seconds

page 7
Care and Maintenance
The Tracker™pool cleaner cycles on/off with the pool filtration pump, vacuuming and cleaning all
surfaces randomly throughout the pool. The climbing ability of the cleaner is dependent on the pool’s
shape and available water flow. If your Tracker is not climbing the pool walls, ensure the flow is correct
by counting wheel speed. Also, ensure the pools surface is not covered in algae as this slippery surface
will affect the cleaner’s traction.
During each coverage pattern cycle, the Tracker cleaner moves forward and pivots to the left. The power
scrubbers underneath the cleaner create down force for climbing and stability as well as directing debris
into the cleaner mouth.
Removing the cleaner out of your pool
It is most important to disconnect the head of the cleaner from the leader
hose section when you take the cleaner out of the pool.
Backwashing the Pool Filter
Always disconnect the Tracker from the pool wall before cleaning
or backwashing the pool filter. After cleaning or backwashing, let the filtration
system run for at least three (3) minutes to flush out the suction lines
before re-connecting the cleaner.
Adding Chemicals to the Pool
Remove the cleaner from the pool for at least four (4) hours when adding chemicals.
Storage and Winterizing
Never store the Tracker in direct sunlight. When storing for the winter, drain out all the water (freeze
damage is not covered by the warranty). Remove all connectors and adapters from the dedicated suction
line or skimmer. When storing the cleaner, even for short times, do not coil the hose as the hose may
develop memory which can affect cleaner performance. Disassemble the hoses and layout flat to store.

page 8
Removing Debris from the Engine
WARNING
To avoid serious injury, make sure that the cleaner is disconnected from the hose
and the pool suction pump is turned off prior to starting this operation.
1. Push the latch release button on the top of the cleaner.
2. Rotate the top lid assembly back until it clicks into an upward position.
3. Look into engine and remove debris that is present.
4. If needed, slowly push engine paddles forward and/or backwards to move stuck debris to an accessible position
then remove it. When moving the engine paddles, make sure the cleaner tracks are allowed to move freely as
they will turn as the engine paddles rotate.
5. Close engine top and ensure the latch clicks in place.
6. Turn cleaner over and check for debris in scrubber and inlet.
Care and Maintenance

page 9
If you experience a problem with your Tracker™, please follow the troubleshooting steps below to
restore performance. If further assistance is required, contact BARACUDA®After Sales Support Department at
1300 784 423. Please have your serial number and date of purchase available when you call.
Problem Solution
Cleaner does not move
or moves slowly
(+25 seconds for
10 wheel revolutions)
• Confirm that the main drain is closed.
• Check for debris jammed in engine. Backwash filter and empty
pump basket.
• Check for air in system. If water level in pump basket drops or
you see excessive air bubbles in the pump basket or coming
from the return lines, there is air in the system. Tighten all fittings
at pump.
Cleaner patterns, does not
cover entire pool.
• Count Wheel Revolutions, flow may need to be adjusted via
AD Valve/Skimtrol plate.
• Ensure return fittings are directed down. Add a return diverter if
necessary.
• Make sure hose is not kinked or coiled. Lay in sun to straighten
if necessary.
• Verify correct hose float positioning on the leader hose.
• Observe the cleaner for more than five (5) minutes and ensure
that the drive track is going forwards smoothly. If it is not, contact
your dealer or service center for help.
• Confirm proper hose length.
Cleaner gets stuck at steps. • Observe the cleaner for more than five (5) minutes and ensure
that the drive track is going forwards smoothly. If it is not, contact
your dealer or service center for help.
• Ensure the swivel on top of the cleaner rotates freely.
• Count Wheel Revolutions, flow may need to be adjusted via
AD Valve/Skimtrol plate.
• Confirm proper hose length. Shorten if necessary.
Cleaner won’t climb walls. • Count Wheel Revolutions, flow may need to be adjusted via
AD Valve/Skimtrol plate.
• Verify correct hose float positioning on the leader hose.
Cleaner climbs too much
(-18 seconds for
10 wheel revolutions)
• Count Wheel Revolutions, flow may need to be adjusted via
AD Valve/Skimtrol plate.
• Verify correct hose float positioning on the leader hose.
Troubleshooting

H0532000 Rev A
