®SETTE™ 270 QUICK START GUIDE
Rev 11/20/2016 (v7)
Time Based Grinding Operation:
Place the portalter or the grounds bin in the grinder. Press a
preset button (1,2,3). The screen will show the corresponding
programmed grind time in seconds. Press Start (>ll) button
to begin grinding. While grinding, the screen will count UP
the seconds and stop when the preset time is reached.
When the screen reaches the preset time, the motor will stop
and the display will reset again to the programmed time.
For manual quantities of ground coffee, press and hold the
START button until you obtain the desired amount of coffee,
then release the START button, the grinder will then stop with
the screen showing the total amount of seconds run. To get
out of manual mode, press STOP.
Remove the grinder, bin, power cord, and bean hopper from
the box. Install lid onto bean hopper. With the shutoff knob
facing the 11 o’clock position, line up the 3 hopper tabs
with the slots in the top of the grinder. Set the hopper in
place and rotate rmly clockwise until the hopper clicks into
place. Note: Grinder motor will not turn on with the hopper
removed. Ensure the shutoff knob is in the open position.
Macro/micro grind size adjustment:
The Macro adjustment moves from coarse (31) to ne (1).
With the grinder running, turn the knob to the right to move
from coarse to ne. Espresso: start at 9E Manual brew: start
at 20E. The micro adjust is the bottom ring, from ner (A) to
Coarser (I). Turn to the right to move from coarse to ne. The
micro adjust is stepless with guidelines for repeatability.
Convertible device holder:
The black arms that hold the grounds bin can also be used
to hold most popular brewing devices such as V60, Kalita
Wave, Clever, and Able Kone. To convert the arms to hold a
portalter, push in on the right arm and swing it down and
to the left. To convert the arms to hold the grounds bin or
other brewing devices, push in on the right arm and rotate
to the right and up. The left arm will automatically move into
position. In the center, above the arms, is a hook for holding
the lip of your portalter, providing stability. This hook can
be rotated out of the way by pressing down on the hook
and then rotating it left or right. To return to center position
simply press down and rotate it back to center.
Adjusting the portalter hook:
When grinding directly into a portalter, you must rst
convert the arms to portalter mode and swing the hook to
the front. The hook is designed to support the top lip of your
portalter. It is imperative that your hook is adjusted so that
your portalter sits level. To adjust the hook, loosen the 2mm
hex screw that sits below the hook, adjust portalter hook up
or down, and tighten screw once in the proper position.
Sette™ 270
135
FineCoarse
791113151719212325272931
CoarserFiner A B C D E F G H I
WARNING: The Sette grinds at a very high speed, be careful not to overll your portalter or
bin! If a mound of coffee backs up into the chute it will clog the grinder.

®SETTE™ 270 QUICK START GUIDE
Rev 11/20/2016 (v7)
Programming:
The Sette 270 is equipped with three programmable buttons.
The buttons are simply labeled 1,2,3. These programmable
buttons only adjust the amount of grind time, they do not
adjust the grind setting (i.e. Coarse/Fine). Each button
comes from the factory with the following presets: Time:
1=10s, 2=20s, 3=30s
You can easily program more or less grinding time
as follows:
1. Select a Preset button.
2. Press the up or down arrow buttons to adjust the
seconds
3. Once you have reached the desired time setting,
press and hold the desired preset button for 3
seconds. The screen will blink to conrm the
setting is stored.
To program the other buttons repeat steps 1-3.
Bag of Tools:
We have included a small bag with tools and shims.
5mm hex key used for removing the cone burr
from the holder.
Shims used for recalibrating the machine to a ner range.
2mm hex key used for adjusting the portalter hook.
Detailed instructions can be found in the full manual,
see link below.
Need Help?
If you have any questions or concerns, please email:
[email protected]
The full manual can be found on our website at:
www.baratza.com/documentation/
For video instructions and troubleshooting guides:
www.youtube.com/user/Baratzallc1/search?query=sette
! Use only with AC current and the correct voltage.
See the label on the base of the grinder to determine the
correct voltage.
! Only clean the grinder housing with a dry or slightly damp
cloth. Do not immerse the grinder, plug or cord in water or
any other liquid.
! Baratza will not accept any liability for damage, injury, or
warranty if the grinder is used other than for its intended
purpose (i.e. grinding roasted whole coffee beans) or is
improperly operated or repaired.
! Keep the appliance and its cord out of reach of children
aged less than 8 years
! Do not operate the grinder with a damaged cord or plug.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard
! Do not leave your grinder unattended while turned ON.
! This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.
! Cleaning and user maintenance shall not be made by
children without supervision.
! Always unplug the grinder from the electrical supply
before assembling, disassembling or cleaning.
! To unplug, grasp plug and remove from the outlet. Never
pull on the cord.
CAUTION: ALWAYS unplug the electrical supply
cord prior to cleaning the grinder.
SAFETY INFORMATION:
Please read the information below very carefully. It contains important safety information for this appliance.
Please keep these instructions for future reference.
