How to: Circuit Board Replacement
Encore, Virtuoso, Preciso
Time: 10 min
Difculty: Easy
Tools/supplies: Flat head screwdriver. Phillips driver. Torx size 10 driver.
Parts: Conical Circuit Board (SKU: 6082 [110v] / 6083 [220v])
Additional Resources: Case Removal (PDF/video)
*** Unplug the grinder from power supply ***
www.baratza.com sup[email protected]m rev. 5/2/2019
ver. 1.1
Remove the case using our Case Removal guide.
Flat head
Phillips
Torx 10 Circuit Board
SKU: 6082 [110v] / 6083 [220v]

www.baratza.com sup[email protected]m rev. 5/2/2019
Pg. 2
Lift the safety interlock
switch off of its posts
and let it hang to the side
of the grinder.
Remove the three screws
securing the gearbox/
motor assembly to the
chassis.
Unplug the motor and
lift the gearbox/motor
assembly from the
chassis.
*If the motor wires are
soldered to the circuit
board, a new board-to-
motor connector wire
will be required.

www.baratza.com sup[email protected]m rev. 5/2/2019
Pg. 3
Unplug the power cord
connector from the
circuit board.
Remove the two screws
securing the circuit board
to the chassis.
Plug in the connector for
the power cable. Install
the new power board.
These may
be Phillips, or
T-10 screws.

www.baratza.com sup[email protected]m rev. 5/2/2019
Pg. 4
Install the gearbox/motor
assembly and plug the
motor cable to the board.
Route the safety
interlock cable between
the chassis and gearbox
as pictured.
Secure the three screws
which mount the
assembly to the chassis.

www.baratza.com sup[email protected]m rev. 5/2/2019
Pg. 5
Set the safety interlock
switch onto its posts.
Ensure that the button
portion faces in toward
the adjustment ring.
Reinstall the case and
knob to return the grinder
to operation.
For case alignment
troubleshooting, see our
Case Removal guide.
If you have questions,
or encounter issues
with this guide, please
reach out to
suppor[email protected]
