barbas ATLANTA Technical manual

INSTRUCTIONS FOR USE INSTALLATION INSTRUCTIONS
ATLANTA
SAVANNAH
ECO 550
ECO 650
ECO 750
COUNTRY NATURAL GAS PROPANE
Great-Britain/ ATLANTA/ SAVANNAH NG ATLANTA/ SAVANNAH PG
Ireland ECO 550 / ECO 650 / ECO 750 NG ECO 550 / ECO 650 / ECO 750 PG
Italia ATLANTA/ SAVANNAH NI ATLANTA/ SAVANNAH PI
ECO 550 / ECO 650 / ECO 750 NI ECO 550 / ECO 650 / ECO 750 PI
España ATLANTA/ SAVANNAH NE ATLANTA/ SAVANNAH PE
ECO 550 / ECO 650 / ECO 750 NE ECO 550 / ECO 650 / ECO 750 PE
Portugal ATLANTA/ SAVANNAH NP ATLANTA/ SAVANNAH PP
ECO 550 / ECO 650 / ECO 750 NP ECO 550 / ECO 650 / ECO 750 PP

3
ENGLISH
ATLANTASAVANNAH
ECO 550
ECO 650
ECO 750
CONTENTS
1. INSTRUCTIONS FOR USE......................................................
2. INSTALLATION INSTRUCTIONS...............................................
3. MAINTENANCE......................................................................
4. FAULTS.................................................................................
5. DISASSEMBLY/ ASSEMBLY
OF THE REGULATOR AND BURNER.......................................
6. DIMENSIONS.........................................................................
7. TECHNICAL DETAILS/REGULATIONS......................................
8. REPLACEMENT PARTS LIST..................................................
Page
5
9
17
17
18
21
25
26

4
ECO 550
ECO 650
ECO 750 SAVANNAH ATLANTA

5
ENGLISH
ATLANTASAVANNAH
ECO 550
ECO 650
ECO 750
1INSTRUCTIONS FOR USE
1.1 INTRODUCTION
Congratulations on your purchase of this modern BARBAS gas fire. This quality
product will provide you with many years of enjoyment due to the flame effect and
warmth that it provides. Please read the instructions for use carefully before using
the appliance for the first time. Keep this booklet in a safe place.
1.2 BUILT-IN PROTECTION OF THE APPLIANCE
The appliance is fully protected by means of a thermo-electric pilot light shut off in
the event of a gas escape from the main burner. Additionally, the gas fire is fitted
with a thermal one-way protection safety system. This system shuts off the
appliance if the flue gas is not exhausted.
1.2.1 Safety
The gas fire must never be used with the door open or the
door glass removed.
Never place flammable material on the ceramic log set.
Do not place easily-flammable materials, such as nylon
clothing or flammable liquids, in the vicinity of the gas fire.
Children and others unfamiliar with the operation of a gas fire
should be allowed in the vicinity of the gas fire only under
supervision.
Use a fire guard to protect children and other persons
mentioned above against possible burns.

6
ECO 550
ECO 650
ECO 750 SAVANNAH ATLANTA
1.3 OPERATION GENERAL
The gas regulating block, with which the fire is operated, is located behind the flap.
Opening the operating knob:
ATLANTA, SAVANNAH, ECO 650 : Panel can be opened by pulling forwards.
ECO 550, ECO 750 : Lift the right-hand side of the panel
slightly and pull it forwards
The fire has one main burner which can be operated by the thermostatic knob and/
or the sliding knob.
The thermostatic knob is used to choose the correct setting and the modulating
thermostat ensures that the set temperature (13 - 38°C) is maintained.
The slider, is used to select the desired position, the burner will now continueously
burn as an atmospheric burner until the setting is changed.
Both operating knobs can be used in combination.
Figure 1: Operation
“OFF” POSITION
SLIDER SLIDER “OFF” POSITION
THERMOSTATKNOB “IGNITION” “IGNITION” KNOB
POSITION

7
ENGLISH
ATLANTASAVANNAH
ECO 550
ECO 650
ECO 750
1.4 IGNITING THE FIRE
lOpen the gas supply valve in the gas pipe to the fire.
lLock the slider into “ll
ll
l” position.
lTurn the thermostat knob to the ignition position “««
««
«” and then push the knob in.
lWhile keeping the thermostat knob pushed in, press the ingition button a few
times to ignite the pilot light. Check through the glass that the pilot light has
been lit.
lWhen the pilot light is lit, keep the thermostat knob pushed in for a further 10
seconds, after which it can be released.
IMPORTANT:If the pilot flame goes out, then wait for at
least 5 minutes before repeating the above
procedure.
lBy turning the thermostat knob to the required setting and/or pushing the slider
into an downward position: the burner will now ignite.
1.5 TURNING OFF THE FIRE
lTurn the thermostat knob to the ignition position “««
««
«”.
lLock the slider to the “ll
ll
l” position.
The burner will now be fully extinguished.
If the thermostat knob is turned back to the “1” position, then the burner will
continue to operate for as long as the room temperature remains below 13°C.
1.6 EXTINGUISHING THE PILOT LIGHT
lExtinguish the pilot by setting the thermostat knob to the “ll
ll
l” position.
lIf the gas fire is not going to be used for a long period of time, it is
recommended to close the gas supply valve to the fire.
IMPORTANT:If the pilot flame goes out for any reason,
wait for 5 minutes before attempting to
re-light it.
lIf the pilot light frequently goes out, then please contact your installer.

8
ECO 550
ECO 650
ECO 750 SAVANNAH ATLANTA
1.7 USING THE APPLIANCE FOR THE FIRST TIME
The gas fire is coated with a lacquer layer resistant to high temperature. During
the first hours of operation, the burning in of the lacquer may result in an
unpleasant smell. This is harmless, however. Operating the gas fire at full capacity
for a few hours, while ventilating the room, will eliminate the smell. Moreover,
deposits may form on the inside off the glass; these can be removed with a dry
cloth when the gas fire has cooled down.
1.8 DAILYMAINTENANCE
lRegulary check that the air supply is still open.
lEnsure that as little dust, and as few particles of cigarette smoke, candles
and oil lamps as possible pollute the air in the room in which the appliance is
used. Heating of these particles by the convection system of the appliance
could lead to discoloration of the walls and ceiling. It is therefore very
important to ensure that the room in which the appliance is located is
sufficiently ventilated. Regularly remove any dust deposits from behind the
control flap by means of a vacuum cleaner.
If the glass is broken or cracked, it must be
immediately replaced before operating the
gas fire again.
lIf anything is spilt on the fire, switch it off immediately and wait for it to cool
down sufficiently before cleaning. Never use scouring powder, aggressive
cleaners or fire polish on the gas fire. Use only a dry lint free cloth.
lBarbas heat resistant lacquer in aerosols can be obtained from your
distributor. During the yearly maintenance, the lacquer can be used to repair
small areas of damage.
•Stains on soap stone can be removed by rubbing gently with a washing-up
sponge and drying with a tea towel.
IMPORTANT
The installation must only be carried out by a
CORGI registered installation engineer.

9
ENGLISH
ATLANTASAVANNAH
ECO 550
ECO 650
ECO 750
2INSTALLATION INSTRUCTIONS
2.1 GENERAL
The appliance has a decorative fire.
The gas fire must be positioned and connected as a “open” appliance by a CORGI
registered gas installation engineer in accordance with the following installation
instructions, nationally and locally applicable regulations (see “Technical Details/
Regulations” at the rear of this manual).
If you have any queries regarding the installation, please consult your local gas
company.
If an existing chimney is to be used, please consult your installer first. If the
chimney was previously used for a wood or coal fire, then it should be cleaned by
an expert. Achimney draw of approximately 5 Pa (= 0,05 mbar) is sufficient for full
load of the appliance. If the chimney draw is more than 20 Pa (= 0,2 mbar), then it
is recommended to reduce it.
IMPORTANT:Before beginning the installation, check that the details
on the rating plate correspond to the gas type and
pressure to which the appliance will be connected.
2.2 FLUE PROTECTION
This appliance is supplied with a security system T.T.B. It is a thermostat which
shuts off the pilot light and main burner under any of the following circumstances:
linsufficient chimney draw.
lunder-pressure in the house due to a mechanical exhaust system.
lbad connection between the appliance and the flue.
lpartial or total blockage of the flue, for instance, due to falling debris.
linsufficient external air supply in an entirely closed house.
lflue down draught due to wind.
After the problem has been rectified, the appliance can be put back into operation.
It is not permitted to bypass the security system. Always call your installer in
case of any problem.
Replace the security system only with parts identical to those originally supplied!
NEDERLANDS

10
ECO 550
ECO 650
ECO 750 SAVANNAH ATLANTA
2.3 PREPARATIONS BEFORE INSTALLATION
The following preparation must be carried out before the gas fire can be installed.
2.3.1 The most important considerations according to the regulations:
1. NATURALLYVENTILATED HOUSE (see Figure 2).
•The room in which the appliance is to be fitted must have a non-
closable combustion air supply opening. The minimum dimensions
are detailed in “Technical Details/Regulations” at the rear of this
manual (see also Paragraph 2.4, point 2).
•The flue gas exhaust must exit at “outlet area I”.
Figure 2: Naturally ventilated house
GAS
OUTLET AREA I
AIR SUPPLY
OPENING

11
ENGLISH
ATLANTASAVANNAH
ECO 550
ECO 650
ECO 750
2MECHANICALLYVENTILATED HOUSE (see Figure 3)
•The room in which the appliance is to be fitted must have a non-
closable combustion air supply opening. The minimum dimensions
are detailed in “Technical Details/Regulations” at the rear of this
manual (see also Paragraph 2.4, point 2).
•The flue gases must be extracted by means of a flue extraction fan.
Figure 3: Mechanically ventilated house
GAS
AIR SUPPLY
OPENING
FLUE EXTRACTION
FAN

12
ECO 550
ECO 650
ECO 750 SAVANNAH ATLANTA
2.4 GENERAL SERVICES
1. FLUE
Before installation, it must be verified that the flue has sufficient draw.
Remove all flue gas dampers (if present) in the flue or fix them in the open
position. The flue must be at least 2 metres long. In order to prevent
condensation in a masonry flue and, if necessary, to improve correct
operation of the appliance, it is recommended that the flue be fitted with an,
(insulated) aluminium or (flexible) stainless steel pipe of Ø100 mm
(minimum).
An protective cap must be placed on top of the chimney to prevent rain
entering.
2. COMBUSTION AIR SUPPLY
The combustion air supply has to comply with national and local
regulations. The minimum dimensions are detailed in “Technical Details/
Regulations” at the rear of this manual. The air supply opening must be
non-closable !!!
3. THERMOSTAT SENSOR
The appliance is equipped with a thermostat sensor which is normally fitted
to the bottom plate. The thermostat function can be improved by positioning
the sensor on the plinth behind the appliance.
Ensure that the sensor remains easily accessible at all times for service
maintenance.
4. GAS CONNECTION
The Ø12 mm or Ø15 mm gas connection, is located at the rear of the
appliance. Connect the gas supply to the appliance using the push
coupling. Use only gas piping with a minimum diameter of 1/2” G with a
shut-off valve.

13
ENGLISH
ATLANTASAVANNAH
ECO 550
ECO 650
ECO 750
2.5 POSITIONING THE APPLIANCE
IMPORTANT :Leave a minimum of 10 cm space between the
rear of the appliance and the wall, and at least
20 cm clear from the sides.
Because of its weight, the appliance ECO 550 /
ECO 650 / ECO 750, needs to be installed on a
sufficiently strong floor.
Put a protective plate on the floor if the ATLANTA/
SAVANNAH, appliance installation is on wood or
carpet.
Flammable materials, such as curtains, should not
be placed in the vicinity of the gas fire.
Minimum safe distance: 100 cm
2.5.1 Chimney connection opening
The appliance has a combined chimney (top/rear) connection opening, which is
factory-fitted as a top connection.
If you wish to use the rear connection option, the connection opening must be
detached from the top and exchanged with the cover plate at the rear.
In the case of the ATLANTA/SAVANNAH, the top connection opening can be
dismantled after removal of the top plate of the appliance, which is fastened with 4
bolts. In the case of the ECO 550, ECO 650 and ECO 750, it is only necessary to
lift off the soapstone top panel.

14
ECO 550
ECO 650
ECO 750 SAVANNAH ATLANTA
2.5.2 Placing soapstone panels ECO 550 / ECO 650 / ECO 750
Position the bottom stone, with the widest part underneath, on the floor.
Position the appliance on top. Secure the side stones by gently sliding them
downwards over the rail. If necessary the rail can be adjusted. Position the top
stone (with the round hole) with the widest part facing upwards.
If you are using the rear chimney connection, the opening in the top panel needs
to be covered with a special matt-effect stainless steel grill, which is available free
of charge from the dealer
Figure 4: Placing soapstone panels

15
ENGLISH
ATLANTASAVANNAH
ECO 550
ECO 650
ECO 750
2.5.3 Chimney connection
The flue pipe/liner (Ø100 mm: ATLANTA/ SAVANNAH or Ø150 mm: ECO 550 /
ECO 650 / ECO 750) can now be connected to the appliance. Make sure that the
connection is completely gas tight.
2.5.4 Gas connection
When connecting the gaspipe, ensure it is not kinked or deformed, and that the
gastap remains unobstructed.
Also during connection of the gas, take care not to twist the gas regulating block.
Make sure that the gas regulating block and supply pipes are not sujected to
stresses.
2.5.5 Checking the Gas Connection
After connection of the gas supply, check that all connections are completely gas
tight using soapy water or a leak tester.
2.5.6 Positioning the Ceramic Log Set
IMPORTANT : •Do not place any vermiculite or logs against the pilot
flame burner. Make sure that the pilot flame can burn
freely over the main burner. Only in this way is proper
ignition of the main burner ensured.
•The burner bed (with vermiculite granules) and the
positioning of the logs must not be changed.
Remove the front and glass plate (ECO 650 / ECO 750) or, open the glass plate
(ATLANTA/ SAVANNAH / ECO 550). Distribute the vermiculite granules over
the burner and position the ceramic log set as shown in figure 5 (Natural gas
appliance) or figure 6 (Propane appliance)
(see also Chapter 5: Disassembly/assembly of the regulator and burner)
1. Distribute the vermiculite granules evenly over the burner.
2. Place the rear log (in the holder) behind the burner.
3. Position the remaining logs.

16
ECO 550
ECO 650
ECO 750 SAVANNAH ATLANTA
2.5.7 Checking the Appliance Following Installation
After installation, the installer needs to visually check the gas flames. When the
fire is ignited, the flames should be short and blue/yellow in colour. These flames
should gradually increase in height and become more yellow. When all flames are
yellow, the gas fire has reached the correct temperature.
The installer should also verify, by using the appliance for the first time, after 10
minutes of operation, that there is no flue leakage.
THE GAS FIRE IS NOW READY FOR USE
Figure 5: Log set natural gas ATLANTA/ SAVANNAH / ECO 550 / ECO 650 /
ECO 750
Figure 6: Log set propane ATLANTA/ SAVANNAH / ECO 550 / ECO 650 /
ECO 750
6
54 3 2 1
5 4 2 1 3
6

17
ENGLISH
ATLANTASAVANNAH
ECO 550
ECO 650
ECO 750
3MAINTENANCE
3.1 ANNUAL MAINTENANCE
The appliance must be checked and cleaned annually by an authorised engineer.
This also applies to the chimney.
The annual maintenance consists of the following points:
lCleaning the main burner, pilot light and chimney liner(s)l/combustion air
supply.
lRemoving dust deposits using a vacuum cleaner.
lChecking the gas, flue and combustion air supply route for leaks.
lChecking the correct operation of the gas regulating block, thermocouple
circuit and the ignition of the main burner.
lChecking the operation of the security system.
4. FAULTS
Possible reasons for the gas fire going out are:
•Operation of the security system due to flue gas escape.
•Malfunction of the security system. Check by means of testing.
lInsufficient gas pressure.
lThe pilot light is either dirty or defective.
lThermocouple voltage is too low. This is usually caused by insufficient heating
at the tip of the thermocouple by the pilot light.
lDirty electrical contacts in the thermo-electrical system; for example, the
thermocouple connection, T.T.B. wiring and/or connections of the security
system.

18
ECO 550
ECO 650
ECO 750 SAVANNAH ATLANTA
5DISASSEMBLY/ ASSEMBLYOF THE REGULATOR AND BURNER
5.1 DISASSEMBLY:
(see fig. 7 and 8.)
1. ATLANTA/ SAVANNAH / ECO 550 :
Open the glass door by unscrewing the allen socket bolt.
ECO 650 :
The front is mounted to the casing by “stud” connections in the
corners. Carefully remove the front by pulling it for-wards. Remove the
securing clips around the glassplate and carefully remove the glass plate.
Caution: The edges of the glass plate may be sharp.
WEAR GLOVES.
ECO 750 :
Remove the front by loosen the allens at the bottomside (under the
controlpanel) and the upperside (in the corners).
2. Remove the rack, the log set and the vermiculite granules.
3. Remove the support on which the rear log was positioned.
4. Remove the bottom plate (grid).
5. Loosen the tapered sealing coupling located next to the gas regulating
block.
6. Now take out the complete bottom plate with the burner and gas regulating
block.
Caution: during removal; disconnect the T.T.B. wire connections, of the
thermocouple interrupter.

19
ENGLISH
ATLANTASAVANNAH
ECO 550
ECO 650
ECO 750
Figure 7: ATLANTA/ SAVANNAH / ECO 550

20
ECO 550
ECO 650
ECO 750 SAVANNAH ATLANTA
Figure 8: ECO 650 / ECO 750
5.2 ASSEMBLY
Assemble in the reverse order.
Ensure that the bottom plate sealing cord and the glass plate mate correctly.
Re-check all re-fitted gas connections for leaks using soapy water or a leak
tester.

21
ENGLISH
ATLANTASAVANNAH
ECO 550
ECO 650
ECO 750
Gas connection
6DIMENSIONS
6.1 ATLANTA/ SAVANNAH
