Masport PG121-NG Quick start guide

STYLE MODEL
See Thru PG121-NG PG121-LPG
Left Corner PG121LC-NG PG121LC-LPG
Right Corner PG121RC-NG PG121RC-LPG
Pier PG131-NG PG131-LPG
01/06/05
Zero Clearance Room
Owners &
Installation
Manual
LISTINGSANDCODEAPPROVALS
These gas appliances have been
tested in accordance with AG 103,
NZS5262andhavebeencertifiedby
the Australian Gas Association for
installation and operation as
described in these Installation and
Operating Instructions.
Your unit should be serviced
annually by an authorised service
person.
918-367
Sealed Gas Fireplace
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
Head Office - New Zealand
1-37 Mt Wellington Hwy.Panmure,
P.O. Box 14349
Auckland 6.
Australia
P.O. Box 533
Braeside, Victoria, 3195
WARNING:
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Refer to this manual. For
assistance or additional information consult an
authorised installer, service agency or the gas
supplier.
FORYOURSAFETY
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any
otherappliance.
Installation and service must be performed by an
authorised installer, service agency or the gas
supplier.
FORYOURSAFETY
What to do if you smell gas:
Donottrytolightanyappliance
Do not touch any electrical
switch:donotuseanyphonein
yourbuilding.
Immediatelycallyourgas sup-
plierfromaneighbour'sphone.
Follow the gas supplier's in-
structions.
If you cannot reach your gas
supplier, call the fire depart-
ment.

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
2
To the New Owner:
Congratulations!
Youaretheownerofastate-of-the-artGasFireplacebyMASPORT.ThePG121/PG121LC/PG121RC/
PG131hasbeendesignedtoprovideyouwithall thewarmthandcharmofawoodfireplaceattheflick
ofaswitch. ThemodelPG121/PG121LC/PG121RC/PG131hasbeenapprovedbytheAustralianGas
Associationforbothsafetyandefficiency. Asitalsobearsourownmark,itpromisestoprovideyou
witheconomy,comfortandsecurityformanytroublefreeyearstofollow. Pleasetakeamomentnow
toacquaintyourselfwiththeseinstructionsandthemanyfeaturesofyourMasportFireplace.
IMPORTANT:
Iftheunitistobeinstalledintoabathroom,optionalNeoceramicglassPart#360-946FrontorPart#
360-948Sidemustbepurchasedandinstalledinplace ofthetemperedglasssupplied withtheunit.

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 3
TABLE OF CONTENTS
Operating Instructions
OperatingInstructions ...............................................29
LightingProcedure ....................................................29
ShutdownProcedure .................................................29
First Fire ...................................................................29
NormalOperatingSoundsof
GasAppliances ..................................................29
AerationAdjustment..................................................29
LightingPlateInstructions .........................................30
Maintenance
MaintenanceInstructions ..........................................30
GeneralFlueMaintenance ........................................30
LogReplacement ......................................................31
Thermopile/Thermocouple .........................................31
Glass Gasket............................................................31
DoorGlass................................................................31
Gold-PlatedAccessories...........................................31
RemovingValve.........................................................31
InstallingValve ..........................................................32
PartsList
Replacement/SparePartsList...................................33
Warranty
Warranty ...................................................................39
Safety Label
SafetyLabel............................................................... 4
Installation
ImportantMessage .................................................... 5
BeforeYouStart ........................................................ 5
GeneralSafetyInformation ......................................... 5
InstallationChecklist .................................................. 5
Specifications ............................................................ 6
LocatingYourFireplace ............................................. 8
Clearances................................................................. 9
CombustibleMantelClearances................................. 9
FramingandFinishing...............................................10
FacingandFinishingRequirements ..........................11
Unit Assembly Prior to Installation
TopStandoffAssembly.......................................11
FlueingIntroduction ...................................................11
ExteriorFlueTerminationLocations ..........................12
Flueing: Direct Vent System (Flex) ...........................13
Flueing:Simpson Dura-VentDirect Vent GS.............14
Flueing:SimpsonDura-VentComponentsList ..........14
FlueingArrangements
HorizontalTerminations ......................................15
VerticalTerminations ..........................................17
Flueing-Dura-VentHorizontalInstallations ...............19
Flueing-Dura-VentVerticalTermination ...................20
Flueing-InstallationProceduresforDirectVent
System (Flex).....................................................21
ConveriontoLPG ......................................................22
System Data.............................................................23
GasLineInstallation..................................................23
Pilot Adjustment .......................................................23
Gas Pipe Pressure Test ............................................23
S.I.T.ValveDescription .............................................23
LogSetInstallation ...................................................24
GlassDoorRemoval..................................................26
FinishingTrim ...........................................................26
LouversandGrills......................................................26
RemoteControl(optional)..........................................27
RemoteWallSwitch(optional) ..................................27
WallThermostat(optional) ........................................27
WiringDiagram .........................................................28

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
4
SAFETY LABEL
This is a copy of the label that accompanies
eachMASPORTPG121/PG121LC/PG121RC/
PG131ZeroClearanceRoomSealedGasFire-
place. We have printed a copy of the contents
here for your review. The safety label is
located on the front inside base of the unit,
visible when the bottom louver is open.
NOTE: Masport units are constantly being im-
proved. Check the label on the unit and if there
is a difference, the label on the unit is the
correct one.
Gas Type NG LPG NG LPG
Model
Gas Consumption
Manifold Pressure
Injector Size
PG121-NG PG121-LPG PG131-NG PG131-LPG
41mj. 38mj. 41mj. 38mj.
1.00kPa 2.65kPa 1.00kPa 2.65kPa
1x#31 1x#50 1x#31 1x#50
Electrical: 240VAC 50Hz 1.0 amp max.
Serial
Number
918-368
Model
N2134
3.05mm 1.78mm 3.05mm 1.78mm
AGA Approval number
to Code AG103 6379 6379 6379 6379
Masport Gas Fireplace
283
Distributed by:
To be installed by an
authorised person in
accordance with
installation instructions
provided with the appliance
Masport Ltd.
1-37 Mt. Wellington H/Way
Auckland 6
New Zealand
Masport Pty. Ltd.
PO Box 533
Braeside, Victoria. 3195

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 5
INSTALLATION
INSTALLATION
CHECKLIST
1) Locate appliance
a) Room location, page 8.
b) Clearances to Combustibles,
page 9.
c) Mantle Clearances, page 9.
d) Framing & FinishingRequirements,
page 10.
e) Flueing Requirements, pages 11-19.
2) Assemble Top Standoffs, page (NOTE:
page11mustbedonebeforeinstallingunit
into fireplace.)
3) Install flue, pages 19-21.
4) Makegasconnections.Testthepilot.Must
be as per diagram. Page 22.
5) Install log set where indicated on
page 24-25.
6) Glass Door Removal (page 26), Louvers
or Grills (page 26), and Finishing Trim
(page 26).
7) Final check.
Before leaving this unit with the customer, the
installermustensurethattheapplianceisfiring
correctly and operation fully explained to cus-
tomer.
This includes:
1) Clocking the appliance to ensure the cor-
rect firing rate (rate noted on label 40,000
Btu/h NG, and 39,000 Btu/h LPG) after
burning appliance for 15 minutes.
2) If required, adjusting the primary air to
ensure that the flame does not carbon.
First allow the unit to burn for 15-20 min.
to stabilize.
CAUTION: Any alteration to the product
that causes sooting or carboning that
results in damage is not the responsi-
bility of the manufacturer.
IMPORTANT:
SAVE THESE
INSTRUCTIONS
The Masport PG121/PG121LC/PG121RC/
PG131-NG or PG121/PG121LC/PG121RC/
PG131-LPG RoomSealedGasFireplacemust
be installed in accordance AG601 and NZS
5261 and with these instructions. Carefully
read all the instructions in this manual first.
Consult the "authority having jurisdiction" to
determine the need for a permit prior to starting
the installation. It is the responsibility of the
installer to ensure this fireplace is installed in
compliance with manufacturer's instructions
and all applicable codes.
BEFORE YOU START
Safeinstallationandoperationofthisappliance
requires common sense, however, we are
required to make you aware of the following:
GENERAL SAFETY
INFORMATION
1) The appliance shall be installed in accord-
ance with the manufacturer's installation
instructions, local gas fitting regulations,
municipalbuildingcodes,water supplyreg-
ulations, electrical wiring regulations, with
AG 601 (AGA gas installation code) NZS
5261 (New Zealand)
2) See general construction and assembly
instructions. The appliance and flue should
be enclosed.
3) This appliance must be connected to the
specified flue and termination cap to the
outsideofthebuildingenvelope.Neverflue
to another room or inside a building. Make
sure that the flue is fitted as per Flueing
instructions.
4) Inspect the flueing system annually for
blockage and any signs of deterioration.
5) Flueingterminalsshallnotberecessedinto
a wall or siding.
6) Any safety glass removed for servicing
must be replaced prior to operating the
appliance.
7) To prevent injury, do not allow anyone who
is unfamiliar with the operation to use the
fireplace.
8) Wear gloves and safety glasses for pro-
tection while doing required maintenance.
9) Be aware of electrical wiring locations in
walls and ceilings when cutting holes for
termination.
10)Under no circumstances should this appli-
ance be modified. Parts that have to be
removed for servicing should be replaced
prior to operating this appliance.
11)Installationandanyrepairstothisappliance
should be done by a authorized service
person.Aauthorizedservicepersonshould
becalledtoinspectthisapplianceannually.
Make it a practice to have all of your gas
appliances checked annually.
12)Do not slam shut or strike the glass door.
13)Under no circumstances should any solid
fuels (wood, paper, cardboard, coal, etc.)
be used in this appliance.
INSTALLATIONANDREPAIRSHOULD
BEDONEBYAAUTHORIZEDSERVICE
PERSON.THEAPPLIANCESHOULDBE
INSPECTED BEFORE USE AND AT
LEASTANNUALLYBYAAUTHORIZED
SERVICEPERSON.MOREFREQUENT
CLEANINGMAYBEREQUIREDDUETO
EXCESSIVELINTFROMCARPETING,
BEDDINGMATERIAL,ETC.ITISIMPER-
ATIVE THAT CONTROL COMPART-
MENTS,BURNERSANDCIRCULATING
AIR PASSAGEWAYS OF THE APPLI-
ANCEBEKEPTCLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCESHOULDBELOCATEDOUT
OFTRAFFICANDAWAYFROMFURNI-
TUREANDDRAPERIES.
WARNING:FAILURETOINSTALLTHIS
APPLIANCECORRECTLYWILLVOID
YOURWARRANTYANDMAYCAUSEA
SERIOUSHOUSEFIRE.
CLOTHINGOROTHERFLAMMABLEMA-
TERIALSHOULDNOTBEPLACEDON
ORNEARTHEAPPLIANCE.
CHILDRENANDADULTSSHOULDBE
ALERTEDTOTHEHAZARDSOFHIGH
SURFACETEMPERATURES,ESPECIAL-
LY THE FIREPLACE GLASS, AND
SHOULDSTAYAWAYTOAVOIDBURNS
ORCLOTHINGIGNITION.
YOUNG CHILDREN SHOULD BE
CAREFULLYSUPERVISEDWHENTHEY
AREINTHESAMEROOMASTHEAP-
PLIANCE. Emissions from burning wood or gas could
contain chemicals known to the State of
California to cause cancer, birth defects or
other reproductive harm.
Note: These units are
non-load bearing.
14)The appliance area must be kept clear and
free of combustible materials, (gases and
other flammable vapours and liquids).

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
6
INSTALLATION
SPECIFICATIONS
PG121 - See Thru
PG131 - Pier
Note: These units are
non-load bearing.

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 7
PG121LC - Left Corner Unit
PG121RC-RightCorner Unit
INSTALLATION
Note: These units are
non-load bearing.

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
8
LOCATING YOUR
GAS FIREPLACE
1) When selecting a location for your stove,
ensure that the clearances are met as
outlined on page 9.
2) Provide adequate clearances for servic-
ing.
3) The appliance must be installed on a flat,
solid, continuous surface (e.g. wood, met-
al, concrete). This may be the floor, or
raised up on a platform to enhance its
visualimpact.Iftheapplianceisgoingtobe
installed on carpeting, combustible linole-
um tile or other combustible material other
than wood flooring, the appliance must be
installed on a metal or wood panel extend-
ing the full width and depth of the appli-
ance.
4) The Room Sealed Gas Fireplace can be
installed as follows:
Model# Position
A) PG121: See Thru
B) PG131:Pier
C) PG121LC: Left Corner
D) PG121RC:RightCorner
5) ThisapplianceisListedforbedroom instal-
lations when used with a Listed Millivolt
Thermostat.Some areas mayhave further
requirements, check local codes before
installation.
6) The PG121/PG121LC/PG121RC/PG131
Room Sealed Gas Fireplace is approved
for alcove installations, which meet the
clearances listed on this page.
7) We recommend that you plan your instal-
lationonpaper using exact measurements
for clearances and floor protection before
actually installing this appliance. Have a
authorized inspector, dealer, or installer
review your plans before installation.
Note: For Exterior Flue Termination
Locations see page 12.
.
INSTALLATION
A) PG121 - See Thru
B) PG131 - Pier
C) PG121LC - Left Corner
D) PG121RC - Right Corner

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 9
INSTALLATION
COMBUSTIBLE MANTELS
CLEARANCES
The clearances listed below are Minimum distances unless otherwise stated (refer to diagrams on page 8):
WARNING:
Fire hazard is an extreme risk
if these clearances (air space)
to combustible materials are
not adhered to. It is of greatest
importance that this fireplace
and flue system be installed
only in accordance with these
instructions.
Clearance to Combustibles from:
Back 0" (0mm)
Side 0" (0mm)
Floor 0" (0mm)
CAUTION REQUIREMENTS: The top, back and sides of the fireplace are defined by
standoffs. The metal ends of the standoffs may NOT be recessed into combus-
tible construction.
Determine the total thickness of the finished floor (eg. tile, carpet, slate) to allow
the finished surface to be flush with the base of the unit.
Ceiling Height from Floor 72" (1828mm)
Mantel Height from Base of Unit:
39" min. (991mm)
Horizontal Flue Clearances:
Top 2-1/2"(64mm)
Side 1-1/2"(38mm)
Bottom 1-1/2"(38mm)
Vertical Flue Clearances 1-1/4" (32mm)
Because of the extreme heat this fireplace emits, the mantel clearanc-
es are critical. Combustible mantel clearances from top of unit are shown in
Diagram to the right.
Note: A non-combustible mantel may be installed at a lower height if
the framing is made of metal studs covered with a non-
combustible board.
This drawing is to scale at 1:6 (one inch = 6 inches)
Mantel can be installed anywhere in shaded area or higher using this scale.
Caution: Ensure the paint that is used on the mantel and the facing is
"heat resistant" or the paint may discolour.
* If the 3" (76mm) metal extension trim is removed it must be replaced with a 8"
(203mm) non-combustible material.
Mantel Clearances

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
10
B
C
A
FRAMING AND FINISHING
CAUTION: The unit does not have to be completely enclosed in
a chase. The clearance on top of the unit is 0" to the standoffs
so combustible building materials can be laid directly on top of
the standoffs. You must maintain clearance from the flue to
combustible materials for both rigid and flex, see Flue Clear-
ances, page 9. PG121 - See Thru
PG131 - Pier
FramingDimensions
PG121 (See Thru) PG131 (Pier) PG121LC / PG121RC
(Corner Unit)
A25"(635mm) 25"(635mm) 26-13/13"(660mm)
minus two times minus two times minus two times
the finishing the finishing the finishing
material thickness* material thickness* material thickness*
B42-1/2"(1080mm) 42-1/2"(1080mm) 42-1/2"(1080mm)
C46-3/4"(1187mm) 45" (1143mm) 45"(1143mm)
minus one time minus one time
the finishing the finishing
material thickness* material thickness*
Note: These units are
non-load bearing.
PG121LC-Corner Unit
* Finish material thickness includes: drywall, ceramic tile, slate, etc.
1) For ease of installation, frame yourfireplaceafter it is positioned and
the flue system is installed. Remember to install the top standoffs.
See page 11 for assembly. Use 2x4's and frame to local building
codes.
2) When locating your appliance on an exterior wall or in a chase, apply
a vapour barrier and drywall, as per local building codes. DO NOT
INSULATETHEFIREPLACEITSELF.
CAUTION: Verify your fireplace dimensions, framing methods
and finished wall facing details before framing. Determine the
total thickness of facing material - drywall plus ceramic tiles,
slate, etc. Allow the finish surface to be flush with the front or
side of the unit. Total facing thickness can vary from 1/2"
(13mm) to 1-1/4" (32mm) thick.
PG121RC- CornerUnit
INSTALLATION

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 11
FLUEING
INTRODUCTION
The PG121/PG121LC/PG121RC/PG131 uses
the "balanced flue" technology Co Axial
system. The inner liner flue products of com-
bustion to the outside while the outer liner
draws outside combustion air into the combus-
tionchambertherebyeliminatingtheneedtouse
heated room air for combustion and losing
warm room air up the chimney.
Note: These flue pipes must not be con-
nected to any other appliance.
The gas appliance and flue system must be
flueeddirectly totheoutsideof thebuilding,and
never be attached to a chimney serving a
separate solid fuel or gas burning appliance.
Eachdirectfluegasappliancemustuseit'sown
separate flue system. Common flue systems
are prohibited.
INSTALLATION
UNIT ASSEMBLY
PRIOR TO
INSTALLATION
The 4 Top Standoffs must be correctly positioned and attached to the top before unit is slipped
into position.
TopStandoffAssembly
The top standoffs are shipped in a flat position and must be folded into shape and attached.
1) Remove the standoffs from the fireplace
top.
2) Take each standoff and bend into the
correct shape. Bend up at the bend lines
untilthescrewholesinthestandoffand the
pre-punched screw holes on the fireplace
top line up.
3) Attach the standoff securely to the top with
4 screws per standoff (on opposite cor-
ners).
FACING & FINISHING REQUIREMENTS
This fireplace is supplied with a 3" metal extension trim above the fireplace. The extension trim may be replaced if the framing is faced with a non-
combustible material placed flush with the front and side face of the unit and extending from the top of the unit. (ie. tile, slate, etc.)

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
12
INSTALLATION
EXTERIOR FLUE TERMINATION LOCATIONS
Minimum clearances required for balanced flue terminals or
the flue terminals of outdoor appliances
according to AG 601 (AGA gas installation code) or NZS 5261 (New Zealand)
Minimum
Clearance (mm)
a Below eaves, balconies or other projections:
- Appliances up to 50 MJ/h input 300
- Appliances over 50 MJ/h input 500
b From the ground or above a balcony 300
c From a return wall or external corner 500
d From a gas meter (M) 1000
e From an electricity meter or fuse box (P) 500
f From a drain or soil pipe 150
g Horizontal from any building structure (unless appliance is approved
for closer installation) or obstruction facing a terminal 500
h From any other flue terminal, cowl or combustion air intake 500
j Horizontally from an openable window, door, or non-mechanical air inlet, or
any other opening into a building, with the exception of sub-floor ventilation
(see also Note (I)):
- Appliances up to 150 MJ/h input 500
- Appliances over 150 MJ/h input 1500
k Vertically below an openable window, door, or non-mechanical air inlet,
or any other opening into a building, with the exception of sub-floor ventilation
(see also Note (I)): see table below
Clearance 'k' in mm
Space Heaters All Other Appliances
Up to 50 MJ/h Up to 50 MJ/h input Over 50 MJ/h input Over 150 MJ/h input
input to 150 MJ/h input
150 500 1000 1500
NOTES:
(I) For mechanical air inlets, including spa blowers, the clearance 'j' and 'k' shall be 1500 mm in all cases.
(II) All distances shall be measured vertically or horizontally along the wall to a point in line with the nearest
par to of the terminal.
(III) Prohibited area below electricity meter or fuse box extends to ground level.
(IV)A flue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on
at least two sides and a free flow of air at the appliance is achieved.

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 13
FLUEING ARRANGEMENT - HORIZONTAL TERMINATIONS
Masport Direct Vent System (Flex) Horizontal Terminations Only
Theseflueingsystems,incombinationwiththePG121/PG121LC/PG121RC/PG131DirectVentGasFireplace,havebeentestedandlistedasadirect
flueheater system by Warnock Hersey.Thelocationofthe termination cap must conformtotherequirementsinthe Vent TerminalLocationsdiagram
on page 12.
Masport Direct Vent (Flex) System Termination Kit (Part# 946-513) includes all the parts needed to install the PG121/PG121LC/
PG121RC/PG131 with a maximum run of 2 feet.
1) 6-7/8" dia. flexible liner (2 ft. length)
2) 4" dia. flexible liner (2 ft. length)
3) spring spacers (3)
4) thimble (2)
5) AstroCap termination cap (1)
6) screws (12)
7) tube of Mill Pac (1)
8) plated screws (8)
9) screws #8 x 1-1/2" drill point, stainless steel (4)
Notes:
1) Liner sections should be continuous without any joints or seams.
2) Only Flex pipe purchased from Masport may be used for Flex installations.
3) Masport Direct Vent System (Flex) is only approved for horizontal terminations.
INSTALLATION

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
14
Simpson
Dura-Vent
Direct Vent GS
SIMPSON DURA-VENT FLUEING COMPONENTS LIST
All Simpson Dura-Vent components are available directly from Masport.
SIMPSON DURA-VENT FLUEING
HorizontalorVerticalTerminations
The Simpson Dura-Vent Direct Vent System offers a complete line of component parts for installation of both horizontal and vertical installations.
Many items are offered in decorative black, as well as galvanized finish. We recommend using the galvanized finish for installation with the PG121/
PG121LC/PG121RC/PG131.
The minimum components required for a
basic horizontal termination are:
1 Simpson Duravent Adaptor
1 HorizontalTermination Cap
145
oElbow
1 Flue Adaptor
1 WallThimble
1 Length of pipe to suit wall thickness
(see chart)
Wall thickness is measured from the back
standoffs to the inside mounting surface of
terminationcap. For sidingother than vinyl
furring strips may be used, instead of the
971 Horiz.TerminationKit includes:
90oblack elbow, wall thimble cover, horiz.
squaretermination cap,24"blackpipe,and 11"
-14" 5/8" adjustable black pipe
970 Basic Horiz. Termination. Kit includes:
90oblack elbow, wall thimble cover,
horiz. square termination cap
978 Vert. Termination Kit includes 0/12 -
6/12 pitch adjustable flashing, storm
collar, low profile term. cap
908B 6" Pipe Length - Black
907B 9" Pipe Length - Black
906 12" Pipe Length - Galv.
906B 12" Pipe Length - Black
904 24" Pipe Length - Galv.
904B 24" Pipe Length - Black
903 36" Pipe Length - Galv.
903B 36" Pipe Length - Black
902 48" Pipe Length - Galv.
902B 48" Pipe Length - Black
911B 11"-14 5/8" Adjustable Pipe Length -
Black
917B 17"- 24" Adjustable Length - Black
945 45O Elbow - Galv.
945B 45OElbow - Black
945G 45O Elbow - Swivel - Galv.
945BG 45OElbow - Swivel - Black
990 90O Elbow - Galv.
990B 90OElbow - Black
990G 90O Elbow - Swivel - Galv.
990BG 90OElbow - Swivel - Black
991 High Wind Termination Cap (Vertical)
980 Vertical Termination Cap
984 Horizontal Square Termination Cap
985 Horiz. Square High Wind Termination
Cap
982 Snorkel - 14" Rise Termination Cap
981 Snorkel - 36" Rise Termination Cap
940 Wall Thimble - Support/Box
941 Cathedral/Ceiling - Support/Box
3951 BrassTrimforWallThimble/CeilingSup.
963 Firestop Spacer
943 Flashing 0/12-6/12
943S Flashing 7/12-12/12
953 StormCollar
950 Vinyl Siding Standoff
988 Wall Strap
942 WallThimble
Parts not supplied by Dura-Vent
946-506/P Vent Guard (Optional)
510-994 Dura-Vent Flue Adaptor
640-530/P Riser Vent Terminal
946-205 Vinyl Siding Shield for Riser
Vent Terminal
946-206 AstroCap Standoff
vinyl siding standoff, to
create a level surface to
mount the vent terminal.
The Terminal must not be
recessedintosiding.Meas-
ure the wall thickness in-
cluding furring strips.
Ifa VinylSidingStandoffis
required (it must be used
withvinyl siding), measure
to outside surface of wall
without siding and add 2
inches.
Part # Description Part # Description Part # Description
INSTALLATION
Flat Wall Installation
Wall Thickness Vent Length
(inches) Required (inches)
4" - 5-1/2" 6"
7" - 8-1/2" 9"
10" - 11-1/2" 12"
9" - 14-1/2" 11" - 14-5/8" Adj. Pipe
15" - 23-1/2" 17" - 24" Adj. Pipe
The Masport AstroCapTM is certified for installations using FPI
venting systems as well as Simpson Dura-Vent® and Direct
Vent GS.
MasportTM, and Masport AstroCapTM are the proprietary trade-
marks of FPI Fireplace Products International Ltd.
Dura-Vent® and Direct Vent GS are registered and/or propri-
etary trademarks of Simpson Dura-Vent Co. Inc.

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 15
INSTALLATION
FLUEING ARRANGEMENTS - HORIZONTAL TERMINATIONS
SIMPSON DURA-VENT DIRECT VENT GS SYSTEM (LPG & NG)
The diagram below shows examples of horizontal termination arrangements using one, two, or three 90oelbows (two 45o elbows equal one 90o
elbow).
Note:
1) A maximum of three 90oelbows are permitted.
2) Minimum distance between elbows is 1 ft. (305mm).
• Maintain clearances to combustibles as listed on page 9.
• Horizontal flue must be supported every 3 feet.
• Firestops are required at each floor level and whenever passing through a wall.
• Must use optional flue adapter (Part# 510-994) when using Simpson Dura-Vent pipe.
• A vent guard should be used whenever the termination is lower than the specified minimum or as per local codes.
Simpson Dura-Vent
4" inner diameter
6-5/8" outer diameter
Straight Out Horizontal Flueing Horizontal Flueing with One (1) 90oElbow
Option V H
A) 1' (305mm) Minimum 3' (914mm) Maximum
B) 2' (610mm) Minimum 6' (1.86m) Maximum
C) 3' (914mm) Minimum 9' (2.7m) Maximum
D) 4' (1.22m) Minimum 12' (3.6m) Maximum
E) 5' (1.5m) Minimum 15' (4.5m) Maximum
F) 6' (1.86m) Minimum 17' (5.1m) Maximum
Diagram 1
Diagram 2
With the above options, maximum total pipe length if 37 feet with
minimumof6feettotalverticalandmaximum17feettotalhorizontal.
Please note minimum 1 foot between 90oelbows is required.
Please note the minimum centerline
for basic install shown above.

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
16
INSTALLATION
Diagram 3
Horizontal Flueing with Two (2) 90oElbows
Option V H + H1
A) 1' (305mm) Minimum 2' (610mm) Maximum
B) 2' (610mm) Minimum 5' (1.5m) Maximum
C) 3' (914mm) Minimum 8' (2.4m) Maximum
D) 4' (1.22m) Minimum 11' (3.35m) Maximum
E) 5' (1.5m) Minimum 14' (4.27m) Maximum
F) 6' (1.86m) Minimum 15' (4.5m) Maximum
Horizontal Flueing with Two (2) 90oElbows
Option V H H + H1
A) 1' (305mm) Min. 1' (305mm) Max. 3'(914mm)Max.
B) 2' (610mm) Min. 3' (0.91m) Max. 6' (1.86m) Max.
C) 3' (914mm) Min. 5' (1.5m) Max. 9' (2.7m) Max.
D) 5' (1.5m) Min. 8' (2.4m) Max. 12' (3.6m) Max.
Horizontal Flueing with Three (3) 90oElbows
Horizontal Flueing with Three (3) 90oElbows
Diagram 5
Diagram 4 Diagram 6
With the above options, maximum total pipe length if 37 feet with
minimumof6feettotalverticalandmaximum15feettotalhorizontal.
Please note minimum 1 foot between 90oelbows is required.
Option V H H + H1 + H2
A) 2' (610mm) Min. 1' (305mm) Max. 3'(914mm)Max.
B) 3' (914mm) Min. 3' (914mm) Max. 6' (1.86m) Max.
C) 4' (1.22mm) Min. 5' (1.5m) Max. 9' (2.7m) Max.
D) 5' (1.5m) Min. 7' (2.13m) Max. 12' (3.6m) Max.
With the above options, maximum total pipe length if 37 feet with
minimumof5feettotalverticalandmaximum12feettotalhorizontal.
Please note minimum 1 foot between 90oelbows is required.
With the above options, maximum total pipe length if 37 feet with
minimumof 5 feet total vertical and maximum12feettotalhorizontal.
Please note minimum 1 foot between 90oelbows is required.
Option V + V1 H + H1
A) 2' (610mm) Minimum 3' (914mm) Maximum
B) 3' (914mm) Minimum 6' (1.86m) Maximum
C) 4' (1.22m) Minimum 9' (2.7m) Maximum
D) 5' (1.5m) Minimum 12' (3.6m) Maximum
With the above options, maximum total pipe length if 37 feet with
minimumof5 feet total vertical and maximum 12 feet total horizontal.
Please note minimum 1 foot between 90oelbows is required.

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 17
INSTALLATION
FLUEING ARRANGEMENTS - VERTICAL TERMINATIONS
SIMPSON DURA-VENT DIRECT VENT GS SYSTEM (LPG & NG)
•Flue must be supported at offsets
•Maintain clearances to combustibles as listed on page 9.
•Firestops are required at each floor level and whenever passing through a wall.
•Must use optional flue adapter when using Simpson Dura-Vent pipe (Part# 510-994).
The PG121/PG121LC/PG121RC/PG131 is approved for a maximum 35 ft. (10.7m) straight vertical, with Simpson Dura-Vent Direct Vent GS flue
systems for LPG and NG, as per diagram 7 below.
Diagram 7
Diagram 8
Straight Up Vertical Flueing Vertical Flueing with One (1) 90oElbow
Option V H
A) 1' (305mm) Minimum 2' (610mm) Maximum
B) 2' (610mm) Minimum 4' (1.22m) Maximum
C) 3' (914mm) Minimum 6' (1.86m) Maximum
D) 4' (1.22m) Minimum 8' (2.4m) Maximum
With the above options, maximum total pipe length if 37 feet with
minimum of 4 feet total vertical and maximum 8 feet total horizontal.
Please note minimum 1 foot between 90oelbows is required.

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
18
INSTALLATION
Vertical Flueing with Two (2) 90oElbows
Option V H
A) 1' (305mm) Minimum 4' (1.22m) Maximum
B) 2' (610mm) Minimum 6' (1.86m) Maximum
C) 3' (914mm) Minimum 9' (2.7m) Maximum
D) 4' (1.22m) Minimum 12' (3.6m) Maximum
E) 5' (1.5m) Minimum 15' (4.5m) Maximum
F) 6' (1.86m) Minimum 17' (5.1m) Maximum
Vertical Flueing with Two (2) 90oElbows
Vertical Flueing with Three (3) 90oElbows
Diagram 9 Diagram 10
Diagram 11
Option V + V1 H H + H1
A) 2' (610mm) Min. 1' (305mm) Max. 2' (610mm) Max.
B) 3' (914mm) Min. 4' (1.22m) Max. 5' (1.5m) Max.
C) 4' (1.22mm) Min. 6' (1.86m) Max. 8' (2.4m) Max.
D) 5' (1.5m) Min. 8' (2.4m) Max. 12' (3.6m) Max.
With the above options, maximum total pipe length if 37 feet with
minimumof6 feet total vertical and maximum 17 feet total horizontal.
Please note minimum 1 foot between 90oelbows is required.
Option V H + H1
A) 1' (305mm) Minimum 2' (610mm) Maximum
B) 2' (610mm) Minimum 4' (1.22m) Maximum
C) 3' (914mm) Minimum 6' (1.86m) Maximum
D) 4' (1.22m) Minimum 8' (2.4m) Maximum
With the above options, maximum total pipe length if 37 feet with
minimumof 4 feet total vertical and maximum 8feet total horizontal.
Please note minimum 1 foot between 90oelbows is required.
With the above options, maximum total pipe length if 37 feet with
minimum of 5 feet total vertical and maximum 12 feet total horizontal.
Please note minimum 1 foot between 90oelbows is required.

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 19
INSTALLATION
HORIZONTAL
INSTALLATIONS
Install the flue system according to the
manufacturer's instructions included
with the components.
1) Set the unit in its desired location. Check to
determine if wall studs or roof rafters are in
the way when the flueing system is at-
tached. If this is the case, you may want to
adjust the location of the unit. Rough in the
gas.
2) Direct Flue pipe and fittings are designed
with special twist-lock connections to con-
nectthe flueing system to theappliance flue
outlet. A twist-lock appliance adaptor is an
available option that must be used in con-
junction with the Simpson Dura-Vent Direct
Vent GS system.
3) Putabeadofsiliconeinsidetheoutersection
of the adapter and a bead of Mill Pac on the
inner collar. Slip the adapter over the exist-
ing inner and outer flue collar and fasten to
the outer collar only with the 3 supplied
screws (drilling pilot holes will make this
easier). Level the fireplace and fasten it to
the framing using nails or screws through
the nailing strips.
4) Assemble the desired combination of pipe
and elbows to the appliance adaptor and
twist-lock for a solid connection.
Note:
a) Twist-lockprocedure:Fourindentations,
locatedon thefemaleends ofpipesand
fittings, are designed to slide straight
ontothemaleendsofadjacentpipesand
fittings, by orienting the four pipe inden-
tations so they match and slide in to the
four entry slots on the male ends, Dia-
Diagram 1
b) Horizontal runs of flue must be sup-
portedevery three feet. Wall strapsare
available for this purpose.
5) Mark the wall for a 10" x 10" square hole.
Thecenterofthesquareholeshouldlineup
with the centerline of the horizontal pipe.
Cutandframethe10inchsquareholeinthe
exterior wall where the flue will be termi-
nated. If the wall being penetrated is con-
structed of non-combustible material, i.e.
masonry block or concrete, a 7"(178mm)
dia. (7-1/2"(191mm) dia. for flex) hole is
acceptable.
Note: With Dura-Vent, the minimum height
is achieved by installing a 45oelbow di-
rectly to the flue adaptor.
Diagram 2
Note:
a) Thehorizontal runofflue mustbelevel,
or have a 1/4 inch rise for every 1 foot
of run towards the termination. Never
allow the flue to run downward. This
could cause high temperatures and
may present the possibility of a fire.
b) Thelocationofthehorizontalfluetermi-
nation on an exterior wall must meet all
local and national building codes, and
mustnot be blocked orobstructed. For
External Flue Terminal Locations, see
diagram on page 12.
6) The arrow on the flue cap should be
pointing up. Insure that the 1-1/2" clear-
ances to combustible materials are main-
tained (Diagram 3 on page 16). Install the
termination cap.
The four wood screws provided should be
replaced with appropriate fasteners for
stucco, brick, concrete, or other types of
sidings.
Note: If installing termination on a siding
covered wall, a vinyl siding stand-
off or furring strips must be used
Note: Apply sealant "Mill-Pac" to inner
pipe and high temperature sili-
cone sealant to outer pipe on eve-
ry twist-lock joint.
Diagram 12
Vertical Flueing with Three (3) 90oElbows
Option V + V1 H + H1
A) 2' (610mm) Minimum 3' (914mm) Maximum
B) 3' (914mm) Minimum 6' (1.86m) Maximum
C) 4' (1.22m) Minimum 9' (2.7m) Maximum
D) 5' (1.5m) Minimum 12' (3.6m) Maximum
gram 1. Push the pipe sections com-
pletely together, then twist-lock one
section clockwise approximately one-
quarter turn, until the two sections are
fullylocked.Thefemalelockinglugswill
not be visible from the outside, on the
Black Pipe or fittings. They may be
located by examining the inside of the
female ends.
With the above options, maximum total pipe length if 37 feet with
minimum of 5 feet total vertical and maximum 12 feet total horizontal.
Please note minimum 1 foot between 90oelbows is required.

Masport PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
20
Diagram 3
Diagram 5
Diagram 1
Diagram 2
Note: Apply sealant "Mill-Pac" to inner
pipe and high temperature sili-
cone sealant to outer pipe on eve-
ry twist-lock joint.
VERTICAL
TERMINATION
1) Maintain the 1-1/4" clearances (air
spaces) to combustibles when
passing through ceilings, walls,
roofs, enclosures, attic rafter, or
other nearby combustible surfac-
es. Do not pack air spaces with
insulation. Check pages 17-19 for
the maximum vertical rise of the
flueing system and the maximum
horizontal offset limitations.
ceiling. Drill a small hole at his point. Next,
drop a plumb bob from the roof to the hole
previouslydrilledintheceiling,andmarkthe
spot where the flue will penetrate the roof.
Determine if ceiling joists, roof rafters or
other framing will obstruct
the flueing system. You may
wishtorelocate
theapplianceor
to offset, as
shown in Dia-
gram 2 to avoid
cutting load
bearing mem-
bers.
3) A Firestop spacer must be installed in the
floor or ceiling of every level. To install the
Firestop spacer in a flat ceiling or wall, cut
a 10 inch square hole. Frame the hole as
shown in Diagram 3 and install the firestop.
4) Assemble the desired lengths of pipe and
elbows. Ensure that all pipes and elbow
connections are in the fully twist-locked
position and sealed.
5) Cut a hole in the roof centered on the small
drilled hole placed in the roof in Step 2. The
hole should be of sufficient size to meet the
minimumrequirementsforclearancetocom-
bustibles of 1-1/4". Slip the flashing under
the shingles (shingles should overlap half
the flashing) as per Diagram 4.
Roof Pitch Minimum Vent Height
Feet Meters
flat to 7/12 2 0.61
over 7/12 to 8/12 2 0.61
over 8/12 to 9/12 2 0.61
over 9/12 to 10/12 2.5 0.76
over 10/12 to 11/12 3.25 0.99
over 11/12 to 12/12 4 1.22
over 12/12 to 14/12 5 1.52
over 14/12 to 16/12 6 1.83
over 16/12 to 18/12 7 2.13
over 18/12 to 20/12 7.5 2.29
over 20/12 to 21/12 8 2.44
Diagram 4: The upper half of the flashing is
installed under the roofing material and not
nailed down until the chimney is installed.
This allows for small adjustments.
6) Continue to assemble pipe lengths.
Note: If an offset is necessary in the attic
to avoid obstructions, it is impor-
tant to support the flue pipe every
3 feet, to avoid excessive stress
on the elbows, and possible sep-
aration. Wall straps are available
for this purpose (Diagram 2).
Galvanized pipe is desirable above the roof-
line due to its higher corrosion resistance.
Continue to add pipe sections through the
flashinguntil the height of the flue capmeets
theminimumheightrequirementsspecifiedin
Diagram5orlocalcodes. Notethatforsteep
2) Setthegasapplianceinits
desired location. Drop a
plumb bob down from the
ceiling to the position of
theapplianceflueexit,and
mark the location where
the flue will penetrate the
Diagram 3
Diagram 4
Diagram 5
to ensure that the termination is
not recessed into the siding.
7) Before connecting the horizontal run of flue
pipe to the flue termination, slide the Wall
Thimble (Part # 942) over the flue pipe.
8) Slide the appliance and flue assembly to-
wards the wall carefully inserting the flue
pipe into the flue cap assembly. It is impor-
tant that the flue pipe extends into the flue
cap sufficient distance so as to result in a
minimum pipe overlap of 1-1/4 inches. Se-
cure the connection between the flue pipe
and the flue cap by attaching the two sheet
metal strips extending from the flue cap
assemblyintotheouter wallofthefluepipe.
Use the two sheet metal screws provided
toconnectthestripstothepipesection.See
Diagram4.
9) Install wall thimble in the center of the 10"
square and attach with wood screws (Di-
agram 5).
INSTALLATION
