Barco MDRC-1219 HB User manual

MDRC-1219
User Guide
19” 1MP (Multi-Touch) Color LCD Display
MDRC-1219 - MDRC-1219 TS
MDRC-1219 HB - MDRC-1219 HB TS
K5902137 (451920612603)/02
23/02/2018

Barco NV
Beneluxpark 21, 8500 Kortrijk, Belgium
Phone: [phone]
Fax: [phone]
Support: www.barco.com/en/support
Visit us at the web: www.barco.com
Registered address: Barco NV
President Kennedypark 35, 8500 Kortrijk, Belgium
Phone: [phone]
Fax: [phone]
Support: www.barco.com/en/support
Visit us at the web: www.barco.com
PrintedinBelgium

Table of contents
TABLE OF CONTENTS
1. Welcome! .......................................................................................... 3
1.1 What’s in the box.............................................................................................. 3
1.2 Product overview.............................................................................................. 4
2. Installation ......................................................................................... 7
2.1 Cable connections ............................................................................................ 7
2.2 Display position adjustment.................................................................................. 9
2.3 VESA-mount installation .....................................................................................10
3. Operation .......................................................................................... 13
3.1 Recommendations for daily operation ......................................................................13
3.2 Standby switching.............................................................................................14
3.3 OSD menu use................................................................................................14
3.4 Power status LED.............................................................................................14
3.5 Control wheel locking/unlocking.............................................................................14
3.6 Input source selection ........................................................................................15
3.7 Luminance adjustment .......................................................................................15
3.8 sRGB color space.............................................................................................15
3.9 QAWeb presets ...............................................................................................16
3.10 Display functions..............................................................................................16
3.11 White point selection..........................................................................................17
3.12 Analog video settings.........................................................................................17
3.13 Power save mode.............................................................................................18
3.14 OSD menu language .........................................................................................18
3.15 OSD menu orientation........................................................................................18
3.16 Factory reset...................................................................................................19
3.17 Touchscreen...................................................................................................19
4. Maintenance ....................................................................................... 21
4.1 Scheduled maintenance......................................................................................21
4.2 Cleaning........................................................................................................21
5. Important information ........................................................................... 23
5.1 Safety information.............................................................................................23
5.2 Environmental information ...................................................................................25
5.3 Biological hazard and returns................................................................................27
5.4 Regulatory information .......................................................................................28
5.5 EMC notice ....................................................................................................28
5.6 Explanation of symbols.......................................................................................32
5.7 Legal disclaimer...............................................................................................35
5.8 Technical specifications ......................................................................................35
K5902137 (451920612603) MDRC-1219 23/02/2018 1

Table of contents
2K5902137 (451920612603) MDRC-1219 23/02/2018

1. Welcome!
1. WELCOME!
Introduction
The MDRC-1219 is a 19” one megapixel color LCD display intended for review of medical images with a
resolution of SXGA (1280*1024) and an aspect ratio of 5:4. The display is not intended for diagnosis.
Thereare4versions:
• MDRC-1219: standard version
• MDRC-1219 TS: version equipped with projective capacitive touchscreen
• MDRC-1219 HB: high bright version
• MDRC-1219 HB TS: high bright version equipped with projective capacitive touchscreen
Warnings, cautions, notes and tips
There are four levels of precautionary or advisory statements that may be used in this user guide. In
descending order of importance, they are:
WARNING:Describes hazards or dangers that might result in personal injury or death.
CAUTION:Describes hazards that could damage the product.
Gives additional information about the described subject.
Gives extra advice about the described subject.
1.1 What’s in the box
Overview
• MDRC-1219 display
• 1xUSBcable(2m)
• 1x DisplayPort video cable (2 m)
• a set of AC power cords (depending on the region of operation)
•1xuserguide
• 1x CD containing MediCal QAWeb Agent and translated user guides
The user guide is available in other languages on www.barco.com/support
K5902137 (451920612603) MDRC-1219 23/02/2018 3

1. Welcome!
Keep your original packaging. It is designed for this display and is the ideal protection
during transport and storage.
1.2 Product overview
Front
1
3
4
2
Image 1-1
MDRC-1219 and MDRC-1219 TS
1
4
2
Image 1-2
MDRC-1219 HB and MDRC-1219 HB TS
4K5902137 (451920612603) MDRC-1219 23/02/2018

1. Welcome!
1. Display stand
2. Control wheel
- Pushlong(5sec)
oto put display in standby mode
- Push short
oto exit standby mode
oto activate the OSD menu
oto confirm selections in the OSD menu
- Turn clockwise
oto scroll down in the OSD menu
oto increase values in the OSD menu
- Turn counter clockwise
otoscrollupintheOSDmenu
oto decrease values in the OSD menu
3. Front sensor (only for MDRC-1219 and MDRC-1219 TS)
4. Power status LED
- Off: Display not powered, or display is on but power LED function is disabled in OSD (see "Power
status LED", page 14)
- Steady green: Display operational
- Blinking green: Display is entering standby mode
- Steady orange: Display in standby mode
Back
8
9
1 2 3 4 6 75
Image 1-3
MDRC-1219 and MDRC-1219 TS
K5902137 (451920612603) MDRC-1219 23/02/2018 5

1. Welcome!
8
9
1 2 4 6 3 75
Image 1-4
MDRC-1219 HB and MDRC-1219 HB TS
1. Kensington security slot
2. USB-B 2.0 upstream connector
3. USB-A 2.0 downstream connectors (2x for MDRC-1219 and MDRC-1219 TS)
4. DisplayPort video input
5. Earth pin
6. DVI-I video input
7. 100 - 240 VAC mains power input (IEC C14)
8. Height-adjustable cable routing clip
9. VESA 100 mm mounting screw holes (4x)
6K5902137 (451920612603) MDRC-1219 23/02/2018

2. Installation
2. INSTALLATION
WARNING:Read all the important safety information before installing and operating
your monitor. Please refer to the dedicated chapter in this user guide.
WARNING:Sufficient expertise is required to install this equipment. All devices and
complete setup must be tested before taking into operation.
CAUTION:When the display is assembled in the medical system, take care of the fixa-
tion of all cables, to avoid unwanted detachment.
CAUTION:The monitor is not intended to be sterilized.
2.1 Cable connections
To connect the cables
1. Connect one or more video source(s) to the corresponding video inputs. Use the appropriate video
cable(s) to do this.
The input source to be displayed can be selected in the OSD menus (see "Input source selection", page
15).
Image 2-1
MDRC-1219 and MDRC-1219 TS
K5902137 (451920612603) MDRC-1219 23/02/2018 7

2. Installation
Image 2-2
MDRC-1219 HB and MDRC-1219 HB TS
2. Connect the USB upstream connector to a PC USB host to make use of QAWeb or any of the display
USB downstream connectors (e.g. to connect a keyboard, mouse or other peripheral).
Image 2-3
MDRC-1219 and MDRC-1219 TS
Image 2-4
MDRC-1219 HB and MDRC-1219 HB TS
3. Connect the mains power input to a grounded power outlet.
8K5902137 (451920612603) MDRC-1219 23/02/2018

2. Installation
Image 2-5
MDRC-1219 and MDRC-1219 TS
Image 2-6
MDRC-1219 HB and MDRC-1219 HB TS
4. If necessary for your application, earth the MDRC-1219 by connecting the earth pin to a grounded
outlet by means of a yellow/green AWG18 wire (maximum admitted cable length according to national
regulation requirements).
Image 2-7
MDRC-1219 and MDRC-1219 TS
Image 2-8
MDRC-1219 HB and MDRC-1219 HB TS
5. Route all cables through the provided cable routing clip at the back of the display stand.
2.2 Display position adjustment
To adjust the display position
You can safely tilt, pivot, raise and lower the display as desired.
K5902137 (451920612603) MDRC-1219 23/02/2018 9

2. Installation
Image 2-9
WARNING:The display must be in its highest position before it can be properly pivoted.
The standard orientation of the video input is landscape. If you use the display in portrait
mode, make sure you change the orientation of the video input via the screen settings
of the computer.
2.3 VESA-mount installation
To mount the display on a VESA arm
The display panel, standard attached to the stand, is compatible with the VESA 100 mm standard.
10 K5902137 (451920612603) MDRC-1219 23/02/2018

2. Installation
1. Unscrew the four fixation screws to detach the panel from the stand.
Image 2-10
2. Use 4 M4 screws to attach the panel to a VESA approved arm. Please respect the following rule to
select an appropriate screw length:
-L
min =T+W+8mm
-L
max =T+W+14mm
T
W
Lmin
Lmax
Image 2-11
K5902137 (451920612603) MDRC-1219 23/02/2018 11

2. Installation
12 K5902137 (451920612603) MDRC-1219 23/02/2018

3. Operation
3. OPERATION
3.1 Recommendations for daily operation
Optimize the lifetime of your display
Enabling the Display Power Management System (DPMS) of your display will optimize its lifetime by auto-
matically switching off the backlight when the display is not used for a specified period of time. By default,
DPMS is enabled on your display, but it also needs to be activated on your workstation. To do this, go to
“Power Options Properties” in the “Control Panel”.
Barco recommends setting DPMS activation after 20 minutes of non-usage.
Use a screen saver to avoid image retention
Prolonged operation of an LCD with the same content on the same screen area may result in a form of
image retention.
You can avoid or significantly reduce the occurrence of this phenomenon by using a screen saver. You
can activate a screen saver in the “Display properties” window of your workstation.
Barco recommends setting screen saver activation after 5 minutes of non-usage. A
good screen saver displays moving content.
In case you are working with the same image or an application with static image elements for several hours
continuously (so that the screen saver is not activated), change the image content regularly to avoid image
retention of the static elements.
Understand pixel technology
LCD displays use technology based on pixels. As a normal tolerance in the manufacturing of the LCD, a
limited number of these pixels may remain either dark or permanently lit, without affecting the performance
of the product. To ensure optimal product quality, Barco applies strict selection criteria for its LCD panels.
To learn more about LCD technology and missing pixels, consult the dedicated white
papers available at www.barco.com/healthcare.
Maximize quality assurance
QAWeb guarantees optimum and stabilized image quality in every private practice.
The front sensor on the MDRC-1219 works seamlessly with QAWeb to ensure a consistent image over
time. It automatically stabilizes the image from the moment you switch on the display. What’s more,
QAWeb provides you with instant feedback on the status of the display.
K5902137 (451920612603) MDRC-1219 23/02/2018 13

3. Operation
3.2 Standby switching
About
• Push the control wheel long (5 sec) to put your display in standby mode
• Push the control wheel short (1 sec) to exit standby mode and activate your display
3.3 OSD menu use
To open the OSD menu
Shortly push the control wheel during normal operation to open the OSD menu. If the control wheel is
locked, first unlock it as described in "Control wheel locking/unlocking", page 14.
The OSD main menu comes up in the left top of the screen. If no further actions are taken within the
following 20 seconds, the OSD menu will disappear again (and the keyboard will lock if enabled).
To navigate the OSD menu
• Turn the control wheel (counter) clockwise to scroll through the different menu pages, to change values
or to make selections.
• Push the control wheel to go into a submenu or confirm adjustments and selections.
3.4 Power status LED
Overview
The power status of the display is indicated by a LED at the front of the display. Below is an overview of
the different LED color modes:
•Off:Notpowered
• Steady green*: Operational
• Blinking green*: Entering standby mode
• Steady orange: In standby mode
* This default behavior can be changed so that the power status LED is also off when the display is oper-
ational or when entering standby mode.
To change the behavior of the power status LED
1. Bring up the OSD main menu.
2. Navigate to the Adjustments >Settings menu.
3. Enter the Power Status LED submenu.
4. Change the behavior of the power status LED as desired and confirm.
3.5 Control wheel locking/unlocking
About
To avoid unwanted or accidental activation of the control wheel, a lock mechanism can be enabled. This
mechanism will lock the keyboard automatically, except while using the OSD menus.
14 K5902137 (451920612603) MDRC-1219 23/02/2018

3. Operation
To lock the control wheel
1. Bring up the OSD main menu.
2. Navigate to the Adjustments >Settings >Keyboard lock menu.
3. Switch the keyboard lock on or off.
4. Exit the OSD menu to activate the selected option.
To unlock the control wheel
During normal operation, turn and hold the control wheel counter clockwise for 5 seconds, until the
OSD unlocked message appears.
3.6 Input source selection
About input source selection
The MDRC-1219 can have multiple video inputs connected. Switching between the different inputs can
be done easily in the OSD menu.
To select the input source
1. Bring up the OSD main menu.
2. Navigate to the Input selection menu.
3. Select one of the available input sources and confirm.
3.7 Luminance adjustment
To adjust the luminance
1. Bring up the OSD main menu.
2. Navigate to the Adjustments >Luminance menu.
3. Set a luminance value as desired and confirm.
3.8 sRGB color space
About sRGB color space
The sRGB color space combines a display function and white point selection and is designed to match
typical home and office viewing conditions. It is widely used in most computer applications.
When selecting sRGB,theDisplay function and White point selection options in the Ad-
justments menu will be disabled.
To select sRGB color space
1. Bring up the OSD main menu.
2. Navigate to the Adjustments menu.
3. Select sRGB and confirm.
K5902137 (451920612603) MDRC-1219 23/02/2018 15

3. Operation
3.9 QAWeb presets
About QAWeb presets
Display function, white point selection and ambient light conditions for your display can be applied from
within the MediCal QAWeb application.
When selecting QAWeb,theDisplay function and White point selection options in the
Adjustments menu will be disabled.
To select QAWeb presets
1. Bring up the OSD main menu.
2. Navigate to the Adjustments menu.
3. Select QAWeb and confirm.
The display USB upstream port must be connected to a PC with QAWeb installed on it
before the QAWeb presets can be applied.
3.10 Display functions
Display function selection is disabled when sRGB or QAWeb are selected in the Adjust-
ments menu.
About display functions
Native, uncorrected panels will display all grayscale/color levels with luminance increments that are not
optimal for crucial diagnostic information. Studies have shown however, that in medical images certain
grayscale/color parts contain more diagnostic information than others. To respond to these conclusions,
display functions have been defined. These functions emphasize on these parts containing crucial diag-
nostic information by correcting the native panel behavior.
The available display functions for your MDRC-1219 are:
•Native: If you select Native, the native panel behavior will not be corrected.
•Gamma 1.8 or 2.2: Select one of these display functions in case the display is to replace a CRT display
with a gamma of 1.8 or 2.2 respectively.
•DICOM: DICOM (Digital Imaging and Communications in Medicine) is an international standard that
was developed to improve the quality and communication of digital images in radiology. In short, the
DICOM display function results in more visible grayscales in the images. Barco recommends selecting
the DICOM display function for most medical viewing applications.
The DICOM display function applies ambient light compensation (ALC) taking the ambient light con-
ditions of your reading room into account. The available reading room options are:
-Darkroom: Selects DICOM calibrated function, optimized for darkroom conditions (0-50 Lux)
-Office: Selects DICOM function optimized for office conditions (51-250 Lux)
-Operation Room: Selects DICOM function optimized for operating room conditions (251-500 Lux)
16 K5902137 (451920612603) MDRC-1219 23/02/2018

3. Operation
The settings of the display must be adapted to suit the requirements of the visualization
software. In case of doubt, please contact the vendor of the visualization software.
To select a display function
1. Bring up the OSD main menu.
2. Navigate to the Adjustments >Display function menu.
3. Select one of the available display functions and confirm.
3.11 White point selection
White point selection is disabled when sRGB or QAWeb are selected in the Adjustments
menu.
About white point selection
This setting allows you to modify the display white point, used as reference for all other colors to be dis-
played.
The available white point settings for your display are:
•Native: The native, unmodified color temperature of the LCD panel.
•Bluebase: Simulation of the bluebase film color temperature.
•Clearbase: Simulation of the clearbase film color temperature.
•Programmable: When selecting this setting, you will be able to manually adjust the video gain for the
red, green and blue channel in separate submenus.
To select the white point
1. Bring up the OSD main menu.
2. Navigate to the Adjustments >White point menu.
3. Select one of the available white point presets.
3.12 Analog video settings
The following settings are only available when an analog video input source (DVI-A) is
selected.
About analog video settings
When the analog video input source is active, a number of analog video settings becomes available:
•Auto Adjust: The analog video setting will automatically be adjusted
•Geometry: Allows to manually adjust the geometry settings of the analog video (clock frequency, clock
phase, horizontal position, vertical position)
•Level: Allows to manually adjust the contrast and brightness levels of the analog video
K5902137 (451920612603) MDRC-1219 23/02/2018 17

3. Operation
To adjust the analog video settings
1. Bring up the OSD main menu.
2. Navigate to the Adjustments >Analog menu.
3. Adjust one of the available analog video settings as desired.
3.13 Power save mode
About power save mode
Enabling power save mode on your MDRC-1219 will optimize the display lifetime by automatically switch-
ing off the backlight when no video signal is detected after approximately 10 seconds.
To enable/disable power save mode
1. Bring up the OSD main menu.
2. Navigate to the Adjustments >Settings menu.
3. Enter the Power save submenu.
4. Select On or Off as desired and confirm.
3.14 OSD menu language
About the OSD menu language
By default, the OSD menu comes up in English. However, there’s a wide range of other languages avail-
able for the OSD menu of your MDRC-1219.
To select the language of the OSD menu
1. Bring up the OSD main menu.
2. Navigate to the Adjustments >Settings menu.
3. Enter the OSD Language submenu.
4. Select one of the available languages.
3.15 OSD menu orientation
About the OSD menu orientation
The orientation of the OSD menu can be changed depending on the orientation of your display (landscape
or portrait).
To change the orientation of the OSD menu
1. Bring up the OSD main menu.
2. Navigate to the Adjustments >Settings menu.
3. Enter the OSD orientation submenu.
4. Select Landscape or Portrait as desired and confirm.
18 K5902137 (451920612603) MDRC-1219 23/02/2018
