Barco DB-220 User manual

DB-220
Installation manual
R59770240/04
11/06/2009

Barco nv Media & Entertainment Division
Noordlaan 5, B-8520 Kuurne
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Visit us at the web: www.barco.com
Printed in China

Changes
Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied war-
ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the
program(s) described in this publication at any time without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the information in this
publication; these changes are incorporated in new editions of this publication.
Copyright ©
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be recorded, transmitted or
stored in a retrieval system without the prior written consent of Barco.
Federal Communications Commission (FCC Statement)
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area may
cause harmful interference, in which case the user will be responsible for correcting any interference at his own expense
EN55022/CISPR22 Class A ITE (Information Technology Equipment)
Class A ITE is a category of all other ITE which satisfies the class A ITE limits but not the class B ITE limits. Such equipment should not
be restricted in its sale but the following warning shall be included in the instructions for use:
Warning : This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures.
Guarantee and Compensation
Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guarantee. On receipt, the purchaser
must immediately inspect all delivered goods for damage incurred during transport, as well as for material and manufacturing faults Barco
must be informed immediately in writing of any complaints.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning,
at latest 30 days after the transfer of risks. In the event of justified notice of complaint, Barco can repair the fault or provide a replacement
at its own discretion within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a
reduction in the purchase price or cancellation of the contract. All other claims, in particular those relating to compensation for direct or
indirect damage, and also damage attributed to the operation of software as well as to other services provided by Barco, being a component
of the system or independent service, will be deemed invalid provided the damage is not proven to be attributed to the absence of properties
guaranteed in writing or due to the intent or gross negligence or part of Barco.
If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly,
in particular if the systems are commissioned operated incorrectly or if, after the transfer of risks, the goods are subject to influences not
agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid. Not included in the guarantee coverage are
system failures which are attributed to programs or special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear as
well as normal maintenance are not subject to the guarantee provided by Barco either.
The environmental conditions as well as the servicing and maintenance regulations specified in the this manual must be complied with by
the customer.
Trademarks
Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders.
All brand and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for
the products or their manufacturers.

Table of contents
TABLE OF CONTENTS
1. Safety................................................................................................................. 3
1.1 Safety guidelines ..................................................................................................................... 4
1.2 Important safety instructions ......................................................................................................... 5
1.3 Important warnings . .................................................................................................................. 6
2. Installation requirements ......................................................................................... 7
2.1 Mechanical requirements. . . .......................................................................................................... 8
2.2 Electrical requirements ..............................................................................................................12
3. Components of the DB-220 Display............................................................................15
3.1 DB-220 display segments...........................................................................................................16
3.2 Clamps............................................................................................................................... 17
3.3 Remote enclosure ................................................................................................................... 19
3.4 RMS-1 control Software.............................................................................................................21
3.5 Ambient Environment Controller (AEC-4000) . . . ...................................................................................22
3.6 Camera .............................................................................................................................. 23
4. Physical installation of the DB-220 Display ..................................................................25
4.1 Opening the container and the cage ................................................................................................26
4.2 Lifting out and preparing the top segment .. ........................................................................................29
4.3 Mounting the AEC-4000.............................................................................................................34
4.4 Mounting the top segment upon the bottom segment. . . ...........................................................................36
4.5 Lifting out and preparing the DB-220 display .......................................................................................39
4.6 Mounting the DB-220 display upon the support structure..........................................................................44
4.7 Hiding the gap between the display segments . ....................................................................................48
4.8 Mounting the telescopic camera arm ...............................................................................................49
4.9 Mounting the video camera .........................................................................................................54
4.10 Connecting the AEC cable of the DB-220 display..................................................................................55
4.11 Connecting the power cables of the DB-220 display...............................................................................56
4.12 Installing the remote enclosure of the DB-220 display .............................................................................60
4.13 Power cabling of the remote enclosure . . . . . ........................................................................................66
4.14 Data cabling of the DB-220 display.................................................................................................67
4.15 Securing the cables of the DB-220 display.........................................................................................70
A. Specifications .......................................................................................................73
A.1 Dimensions of the DB-220 display..................................................................................................74
A.2 Dimensions of the installation brackets for the remote enclosure .................................................................75
A.3 Specifications of the DB-220 display................................................................................................76
B. Cabling diagrams...................................................................................................77
B.1 Cabling diagrams of the DB-220 display............................................................................................78
Index......................................................................................................................81
R59770240 DB-220 11/06/2009 1

Table of contents
2R59770240 DB-220 11/06/2009

1. Safety
1. SAFETY
About this chapter
Read this chapter attentively. It contains important information to prevent personal injury while installing the DB-220 display. Fur-
thermore, it includes several cautions to prevent damage to the DB-220 display. Ensure that you understand and follow all safety
guidelines, safety instructions and warnings mentioned in this chapter before installing the DB-220 display. After this chapter, addi-
tional “warnings” and “cautions” are given depending on the installation procedure. Read and follow these “warnings” and “cautions”
as well.
Overview
• Safety guidelines
• Important safety instructions
• Important warnings
R59770240 DB-220 11/06/2009 3

1. Safety
1.1 Safety guidelines
Personal protection
WARNING:Ensure you understand and follow all the safety guidelines, safety instructions, warnings and
cautions mentioned in this manual.
WARNING:Be aware of suspended loads.
WARNING:Wear a hard hat to reduce the risk of personal injury.
WARNING:Be careful while working with heavy loads.
WARNING:Mind your fingers while working with heavy loads.
Installation personnel
This installation must be performed by authorized and qualified technical personnel only.
Accredited safety officers must ensure the safety of the site, construction, assembly, connection, use, dismantling, transport etc. of
such safety critical systems.
Caution
Installation should be performed only after you are thoroughly familiar with all of the proper safety checks and installation instructions.
To do otherwise increases the risk of hazards and injury to the user.
Assembly parts are designed for intended use only in conjunction with DB-220 LED displays.
Do not modify and/or replicate any component. Barco uses specific materials and manufacturing processes in order to achieve part
strength. Consult Barco for assistance with custom applications.
Always follow Barco installation instructions. Contact Barco if you should have any question regarding the safety of an application.
The manufacturer assumes no liability for incorrect, inadequate, irresponsible or unsafe assembly of systems.
Product care
Structural & mounting components should be kept dry, clean, lubricated (only if recommended), coated properly, and otherwise
maintained in a manner consistent with part design. Barco products must be used in a manner consistent with their design and
inspected on a routine basis for security, wear, deformation, corrosion and any other circumstances that may affect the load handling
capability of the part.
Barco recommends inspections at regular intervals for all installations and increasing in frequency for more critical installations. If
a part is found to have damage, which may cause a decrease in load capability, the part must be removed for service or replaced
immediately.
Under no circumstances are Barco parts repairable by anyone other than Barco.
4R59770240 DB-220 11/06/2009

1. Safety
1.2 Important safety instructions
Instructions:
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Clean only with materials or chemicals that are inert, nonabrasive, noncorrosive and non-marking. Consult the manufacturer
for further advice should any doubts exist regarding any cleaning procedure.
• Do not block ventilation openings. Install in accordance with the manufacturers instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
• Do not defeat the safety purpose of the polarized or grounding type plugs/sockets. If the provided sockets/plugs are damaged
then replacement of the defective parts must be undertaken immediately.
• Protect the power/data cords from being walked on or pinched particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus. Replace damaged power/data cords immediately.
• Only use attachments/accessories specified by the manufacturer.
• Disconnect the power to this apparatus during lightning storms or provide suitable additional lightning protection. Unplug this
apparatus when unused for long period of time.
• Refer all servicing to qualified service technicians/personnel. Servicing is required when the apparatus has been damaged in
any way, such as power-supply cord or plug is damaged, the apparatus does not operate normally, or has been dropped.
• Use only with systems or peripherals specified by the manufacturer, or sold with the apparatus. Use caution during lifting/moving
or transporting to avoid damage by possible tipping.
R59770240 DB-220 11/06/2009 5

1. Safety
1.3 Important warnings
Important warnings:
Risk of electric shock:
Do not open. To reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. Refer servicing
to qualified service personnel.
Maximum and minimum ambient temperature:
The maximum ambient temperature for the LED wall is 40 °C, the minimum temperature is -20 °C.
High leakage current:
The combination of multiple tiles in an installation results in increased levels of leakage current. In order to avoid risk of electric
shock due to high leakage current, proper grounding of the installation is required.
Flammable materials:
Keep flammable materials away from the installation (such as curtains). A lot of energy is transferred into heat. The installation
should be such that the amount of air flow required for safe operation of the equipment is not compromised. Proper ventilation must
be provided.
Disconnect device:
The disconnect device shall simultaneously interrupt all poles of the AC mains supply except for the earthing conductor. It shall be
installed near the equipment and be easily accessible.
Disconnect device:
When the appliance inlets of the individual tiles are not accessible, the socket outlets supplying the rack shall be installed near the
equipment and be easily accessible, or a readily accessible general disconnect device shall be incorporated in the fixed wiring.
This equipment MUST be earthed:
In order to protect against risk of electric shock, the installation should be properly grounded. Defeating the purpose of the grounding
type plug will expose you to the risk of electric shock.
Power system:
It is recommended to use a TN-S power distribution system (a power distribution system with a separate neutral and grounding
conductor) in order to avoid large ground current loops due to voltage differences in the neutral conductor. The total electrical
installation should be protected by an appropriately rated disconnect switch, circuit breakers, over voltage protector and Ground Fault
Current Interrupters. The installation shall be done according to the local electrical installation codes. In Europe special attention
should be given to EN 60364, the standard for electrical installation of buildings. In Germany VDE 0100 should be adhered to. In
America, special attention should be given to the National Electrical Code, ANSI/NFPA 70.
6R59770240 DB-220 11/06/2009

2. Installation requirements
2. INSTALLATION REQUIREMENTS
About this chapter
This chapter enumerates the mechanical and electrical requirements for the DB-220 display
Required installation tools
• Crane.
• Straps and shackles.
• Six-foot bubble level.
• Wire stripper.
• Adhesive tape.
• Adjustable wrench.
• 15/16” open-end wrench.
• 15/16” box-end wrench.
• 9/16” open-end wrench.
• 9/16” box-end wrench.
• 5/16” open-end wrench.
• 5/16” box-end wrench.
• 1/2” open-end wrench.
• 1/2” box-end wrench.
• 5/8” open-end wrench.
• 5/8” box-end wrench.
• 1/8” open-end wrench.
• 1/8” box-end wrench.
• 3/8” Allen wrench.
Overview
• Mechanical requirements
• Electrical requirements
R59770240 DB-220 11/06/2009 7

2. Installation requirements
2.1 Mechanical requirements
Installs in coastal city care
It is NOT recommended to operate DB series products in an atmosphere worse than Class C3 according to ISO 9223.
What distance is suitable for DB-220 when it installs in coastal cities.
•Display shall be installed 250 meters away from the shoreline horizontally in dry and cold climates.
•Display shall be installed 500 meters away from the shoreline in case of high humidity and hot climates.
Definition of C3 is based on ISO 9223 Corrosion of metals and alloys – Corrosivity of atmospheres- Classifi-
cation, where C3 is regarded as medium corrosivity
The high humidity and hot climate mean the climate that the humidity is higher than 80% RH and temperature
is higher than 0°C for one third of time every year.
Support structure
The support structure has to be provided and installed by the customer because it varies from system to system. Although, the
following must be taken into account and must be precisely calculated on individual basis:
1. Weight tolerance: Ensure that the support structure and the floor or the wall on which the support structure has to be installed,
is able to handle the complete weight of the fixed DB-220 display.
2. Environmental conditions: Humidity, wind, temperature, rain, etc.
3. Location: Outdoor, altitude, etc.
4. Ground stability
5. Front clearance: For optimal impact ensure that there is sufficient free area in front of the DB-220 display and respect the
minimum viewing distance.
6. Local regulations regarding such installations
WARNING:Never construct the DB-220 display if there is uncertainty regarding the stability of an installation
or the load holding capacities. If there are doubts on a system viability, consult Barco for advice on profes-
sional rigging organizations.
When installing the DB-220 display on a support structure against a wall, it is recommended to integrate a
service platform in the support structure. Such platform allows a fast and easy access if required.
WARNING:When installing the DB-220 display on a support structure against a wall, it is required to keep a
distance of at least 0.75m / 29.5” between the wall and the DB-220 display.
Support structure
Structural requirements of the support structure:
Vertical direction 3.000 kg Maximum deformation of 3mm/m
Horizontal direction 60000 N Maximum deformation of 3mm/m
The support structure consists of at least 3 vertical I-beams(each one I-beam bottom should have one small support for standing
the display)which are equally spread over the length of the DB-220 display. The supply of the I-beams and how the I-beams have
to be mounted in the ground, on a wall or on a pole is the responsibility of the customer.
8R59770240 DB-220 11/06/2009

2. Installation requirements
Image 2-1
It’s recommended to mount the support structure into a concrete foundation. Use caution, the vertical beams
do not block access to power or data cable connection points.
It is obliged to provide a small support on the bottom of each I-beam to stand the whole DB-220 display.
2 mm
Image 2-2
R59770240 DB-220 11/06/2009 9

2. Installation requirements
Horizontal alignment of the supports 2mm
Depth of the supports 220 mm — 245 mm
Width of the supports Same as the I-beam
Clamps
The DB-220 display is equipped with clamps. These clamps are the interface between the support structure and the DB-220 display.
Each I-beam requires 6 clamps which can be horizontally and vertically aligned according to the customers wishes. Barco offers
horizontal and vertical clamps.
Image 2-3
Clamps to be used on vertical I-beams (R837438)
Image 2-4
Clamps to be used on horizontal I-beams (R837947)
There are two different types of clamps.
Specified torque values for the clamps:
5/8” nuts in the cage 144 Nm
3/8” bolts in the cage 30 Nm
5/8” nuts when used in the mounting procedure on the support
structure
144 Nm
3/8” bolts when used in the mounting procedure on the support
structure
30 Nm
Lifting the display
To lift the DB-220 display, the top segment is provided with two eyebolts. The customer is responsible for providing the straps and
shackles needed to lift the display.
10 R59770240 DB-220 11/06/2009

2. Installation requirements
A
Image 2-5
WARNING:The angle (A) between the top of the DB-220 display and the straps needs to be bigger than 45
degrees.
WARNING:Before lifting, consult the specifications regarding the weight of the DB-220 display and the de-
tailed information regarding the lifting points of the DB-220 display. see "Specifications of the DB-220 display",
page 76
WARNING:The two lifting points are only for hoisting the panels itselves. When installing the screen and the
metal structure, these two points can not be used hoisting anymore.
R59770240 DB-220 11/06/2009 11

2. Installation requirements
2.2 Electrical requirements
General
It is the responsibility of the customer to realize the electrical connection between the LED-wall and the main power net. This con-
nection must be equipped with appropriate circuit breakers. The DB-220 display requires an input voltage between 200 VAC and
240 VAC. The table below shows the power requirements of the DB-220 display. Note that these values do not include the power for
the remote enclosure, which contains control equipment (e.g. digitizer). Take into account that the maximum power consumption of
the whole remote enclosure is 920W.
Power requirements DB-220 Remote enclosure Minimum wire size
Max Watts 8600 W 780 W not applicable
2 Wires (excluding grounding wire) single
phase (240V/US; 220V/CN/EU) (US
/CN/EU)
36 A / 40 A (Phase
current)
3.25 A 3.55 A 6AWG
3 Wires (excluding grounding wire) three
phase (208V) (US)
24 A (Phase current) 2.17 A 8AWG
4 Wires (excluding grounding wire) three
phase (220V) 14(EU/China)
14 A (Phase current) 1.18 A 10AWG
The single conductor shielded power cables between the disconnection device and the integrated power distribution box of the
DB-220 display must have a specific diameter (mentioned above) and must comply with the local regulations (should comply with
UL1015 for the US). The DB-220 display must be properly connected to the ground (protected earth) using a single conductor cable
with the same specified diameter.
Power input diagram for a three wire single phase distribution network (US/CHINA/EU)
Image 2-6
Power input diagram for a three wire three phase distribution network (US)
Image 2-7
12 R59770240 DB-220 11/06/2009

2. Installation requirements
Power input diagram for a three wire three phase distribution network (EU and China)
Image 2-8
R59770240 DB-220 11/06/2009 13

2. Installation requirements
14 R59770240 DB-220 11/06/2009

3. Components of the DB-220 Display
3. COMPONENTS OF THE DB-220 DISPLAY
General introduction
The fundamental elements of the DB-220 system are:
•A: Support structure. Provided by the customer.
•B: Display segments. The DB-220 display consists of two display segments.
•C: Remote enclosure. The remote enclosure can consist in a digitizer, compact link, rugged PC, embedded PC, modem,...
and other peripherals. All these peripherals are mounted inside a 19” rack covered in an IP55 rated cabinet.
•D: Ambient Environment Controller (AEC).
•E: Camera and camera arm. For visual display monitoring.
Image 3-1
Overview
• DB-220 display segments
• Clamps
• Remote enclosure
• RMS-1 control Software
• Ambient Environment Controller (AEC-4000)
• Camera
R59770240 DB-220 11/06/2009 15

3. Components of the DB-220 Display
3.1 DB-220 display segments
Introduction
The DB-220 display consists of two segments which are the basic building blocks of the display. The two segments of the DB-220
display are different from each other. So, each segment has its own place in the display. The two display segments must be assem-
bled together to form one big display. Afterwards the whole assembly is mounted on the support structure using the clamps.
Image 3-2
Left side: the top and bottom segments. Right side: the two segments secured in a cage for transportation
For transportation reasons, the two display segments are secured in a frame work which can be placed inside a container. Three
units of a DB-220 fit inside one container.
40’ Open Top Container
3 units
Image 3-3
16 R59770240 DB-220 11/06/2009
